Product Manual
Trimbox Mixed Flow Fans
ventilation systems
TP220T TP221T TP222T TP223T
EN
Safety Information
Important Information
Important: read these instructions fully before the installation
of this appliance
1. Installation of the appliance and accessories must be carried out
by a qualied and suitable competent person and be carried out
in clean, dry conditions where dust and humidity are at minimal
levels.
2. This manual covers the installation of the Titon In-Line Fans
3. All wiring must conform to current I.E.E. Wiring Regulations and
all applicable standards and Building Regulations.
4. The units must be connected to a local three pole isolation
switch with a contact separation of at least 3mm.
5. The units are suitable for 230V ~ 50/60Hz single phase suppy.
6. The units are DOUBLE INSULATED and marked with
symbol.
There are no Earth terminals and these
units MUST NOT BE EARTHED.
7. Ensure cable clamp is used and fully tightened.
8. Cable entry must be made using the grommet supplied.
9. The unit must be stored in a clean and dry environment.
10. Do not install the appliance in areas where the following may be
present or occur;
• Excessive oil or a grease laden atmosphere,
• Corrosive or ammable gases, liquids or vapours,
• Ambient temperatures above 50°C or below 0°C,
• Obstructions which would hinder access to the fan unit.
• Ducting bends or duct transformations close to the fan unit.
• Humidity levels above 90% or is a wet environment.
2
11. The appliance is not suitable for installation to the exterior of the
dwelling.
12. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children
should be supervised to ensure that they do not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
13. The unit must not be connected to a tumble dryer or a cooker
hood.
14. Precautions must be taken to avoid the back-ow of gases into
the room from an open ue appliance.
15. Ensure impellor rotates and is free from obsructions and debris
before conneting ducting.
16. Ensure all ducting associated pipe work is free from debris and
blockages before switching on the unit.
Important environment information about this product.
This symbol on this unit or package, indicates that disposal of this unit
after its life cycle could harm the environment. Do not dispose the unit
as municipal waste; it should be disposed by a specialized company for
recycling. This unit should be returned to your distributor or to a local
recycling service. Respect the local environmental rules.
If in doubt contact your local authorities about waste disposal rules.
3
Read instruction Manual.
Risk of Electric Shock.
Isolate from the mains power supply before removing
the cover.
Contains rotating mechanical parts. Following
isolation from the mains power supply allow sucient
time for all moving parts to stop before removing any
ducting.
Airow Direction
Explanation of symbols on the appliance.
4
Contents
When this document is viewed
as a PDF the headings & sub
headings on this page are
hyper links to the content.
Safety Information
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Explanation of symbols on the appliance. . . . . . . . . . . .4
Product Information
Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Packaging Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Component Identication . . . . . . . . . . . . . . . . . . . . . . . .8
Fixing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Ducting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Overrun Timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Speed Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Product Fiche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Maintenance
Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Faults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
5
Product Information
Titon In-Line Fans are designed to extract humid & stale air and expel it to the exterior.
They are also suitable for extracting air from one room and expelling it to another room.
The fan unit is usually tted in the ceiling void, well away from the inlet. This In-Line
feature allows the inlet grille to be mounted in wet areas (eg near the splash zones of
bathrooms) or even above a shower. As the unit is in the ceiling cavity (away from the
inlet grille), noise from the fan is minimized
Product Features
Three speed Low, Medium & High.
Overun timer, 3-30 minutes.
Part Number TP220T TP221T TP222T TP223T
Duct Diameter ID Ø100mm Ø125mm Ø150mm Ø160mm
Supply Voltage 220-240V~ 50Hz
Power Rating 30W 60W
Supply Voltage 220-240V~ 60Hz
Power Rating 38W 84W
Fuse Rating 3A
Protection Class Class II
IP Rating IP55
Weight 1.9Kg 2.0Kg 3.0Kg 3.1Kg
Packaging Contents
Inspect the unit when taking delivery. Check the unit for damage and that all
accessories have been supplied. Package supplied with;
In-Line Fan Unit x 1.
Product Manual x 1.
Any shortages or damage must be immediately reported to the supplier.
6
Dimensions
The diagram details the overall size of the unit. Installer must allow additional space
around the unit to allow for future servicing and maintenance.
Part Number TP220T TP221T TP222T TP223T
Duct Diameter ID Ø100mm Ø125mm Ø150mm Ø160mm
Dimensions mm
ØA 98 123 148 158
ØB 173 200
C 111 131
D 295 269 289 271
E 100 110
F 195 231
G Fixing Centres 135 136
H Fixing Centres 176 214
7
Component Identication
Fixing
The units are designed as in-line duct fans to be tted between two duct runs.
1. Choose a suitable mounting location for the inlet grille. Ensure there is adequate
clearance for the ducting.
2. Choose a suitable location for the extract grille ensuring there is adequate clearance
for the ducting.
3. Choose a suitable mounting location for the fan unit. Ensure that a power outlet is
installed near the intended location of the unit.
4. The fan unit must be positioned at the highest point on the system so the ducting
will slope downwards to both grilles.
5. The airlfow direction is marked on the rating label.
6. Do not cover the fan unit with thermal insulation. Keep at least 100mm clearance
between the unit and any thermal insulation.
7. Mount the unit to a support using suitable xings through the four xing holes.
Impellor
Fixing Holes
Gromet
INLET
Terminal Box
8
8. The unit should be positioned so that the power cord is pointing downwards.
9. Orientation of the junction box can be adjusted to suit the fan units location
10. Unscrew and open the clamps.
11. Rotate the motor unit to the desired position.
12. Replace the clamps and tighten the screws.
13. The duct must not be installed vertically into a roof terminal - the product is not
designed or intended for this type of installation.
Ducting
1. Titon recommend using rigid ducting, any exible ducting used should be fully
extended.
2. All ducting joints must be xed using a method that ensures a long term seal is
achieved.
9
Wiring
1. Access to the wiring terminals is via
the terminal box on top of the unit.
N
Ls NL
TP 2xxT
L
220-240V~
50/60Hz
10
Commissioning
Overrun Timer
The Overrun Timer is factory set to approximately 3 minutes. The Overrun Timer can be
set between 3 and 30 minutes.
Access to Overtime Timer Control is via the terminal box on top of the unit.
WARNING: Unit uses a 220-240V~
supply and contains rotating
mechanical parts. ISOLATE the unit
from mains power supply and allow
sucient time for all moving parts to
stop before Commissioning.
Adjust the Overrun Timer Control on the PCB with using a small at bladed screwdriver.
Clockwise Increase.
Counter clockwise Decrease..
11
Speed Setup
Access to Speed Selection is via the terminal box on top of the unit.
WARNING: Unit uses a 220-240V~
supply and contains rotating
mechanical parts. ISOLATE the unit
from mains power supply and allow
sucient time for all moving parts to
stop before Commissioning.
The Titon Mixed Flow Fans runs at one of 3 speeds;
1. Low [L];
2. Medium [M];
3. High [H].
The factory default is Medium.
To change the speed of the fan;
disconnect the wire and reconnect
to the terminal corresponding to
the desired speed.
12
Documentation
Product Fiche
Supplier Name Titon
Supplier Address 894 The Crescent
Colchester Business Park
Colchester
Essex
CO4 9YQ
Model Ø100mm Trimbox Ø125mm Trimbox
Mixed Flow In-line fan Mixed Flow In-line fan
Model Identier TP220T TP221T
Declared Typology NRVU - UVU NRVU - UVU
Type of Drive installed Multi-speed drive Multi-speed drive
Type of heat recovery system none none
Thermal eciency of heat recovery not applicable not applicable
Nominal NRVU Flow Rate (m3/s) 0.083 0.083
Eective power input (kW) 0.03 0.03
SFPint W/(m3/s) n/a n/a
Face velocity in m/s n/a n/a
Nominal external pressure in Pa 85 85
Internal pressure drop in Pa n/a n/a
Static eciency of fan in accordance
with (EU) No 327/2011 22% - < 125W motor 22% - < 125W motor
Declared maximum
internal leakage rate (%) n/a n/a
Energy performance of the lters n/a n/a
Filter Warning (RVU) n/a n/a
13
Model Ø150mm Trimbox Ø160mm Trimbox
Mixed Flow In-line fan Mixed Flow In-line fan
Model Identier TP222T TP223T
Declared Typology NRVU - UVU NRVU - UVU
Type of Drive installed Multi-speed drive Multi-speed drive
Type of heat recovery system none none
Thermal eciency of heat recovery not applicable not applicable
Nominal NRVU Flow Rate (m3/s) 0.138 0.138
Eective power input (kW) 0.06 0.06
SFPint W/(m3/s) n/a n/a
Face velocity in m/s n/a n/a
Nominal external pressure in Pa 150 150
Internal pressure drop in Pa n/a n/a
Static eciency of fan in accordance
with (EU) No 327/2011 33% - < 125W motor 33% - < 125W motor
Declared maximum
internal leakage rate (%) n/a n/a
Energy performance of the lters n/a n/a
Filter Warning (RVU) n/a n/a
Internet address (for dissassembly instructions) www.titon.co.uk
14
Maintenance
Routine Maintenance
WARNING: The unit uses a 220-240V~ supply and contains rotating mechanical
parts. ISOLATE the unit from mains power supply and allow sucient time for all
moving parts to stop before undergoing any Servicing or Maintenance.
All ventilation units require periodic maintenance, units should be inspected and
cleaned. Routine maintenance must only be carried out by a suitably qualied and
competent person.
Cleaning
This product should only be cleaned with a damp cloth. Cleaning agents and solvents
should not be used.
In the event of any queries please contact the system installer.
Faults
This product contains no serviceable parts and no attempt should be made to repair it.
If the product is faulty it should be discarded.
15
Installed by:
MARKETING DIVIS ION
894 The Crescent, Colchester Business Park, Colchester, CO4 9YQ
Tel : +44 (0) 1206 713 800 Fa x: +4 4 (0) 1206 5 43126
Email : ventsales@titon.co.uk Web: www.titon.com
©2018 TITON DO 5581 Iss 02
In the event of any queries please contact the system installer.
Ensure this booklet is passed to the householder once installation & commissioning of the
ventilation system is complete. This Product Manual must be kept in the Home Information
Pack and used as a service record.
Loading...
