PIV L3 Unit
3 STOREY INSTALLATION AND USER GUIDE
1
PIV L (3 STOREY)
Description Item
8 X FOAM PADS
4 X WASHERS
4 X PLASTER BOARD
PLUGS
4 X WOOD SCREWS
(10 X 1.5)
4 X WOOD SCREWS
(10 X 3)
4 X WOOD SCREWS
(8 X 1)
4 X WOOD SCREWS
(8 X 1.5)
ROLL OF
INSULATION TAPE
Description Quantity
VENTILATION UNIT 1 X
DIFFUSER 1 X
FIXING KIT 1 X
UNSWITCHED
FUSE SPUR
1 X
200mm FLEXI DUCT 1m
PRE-INSTALLATION CHECKLIST
Check that the loft has adequate
cross flow ventilation.
Check that all party walls are intact,
seek advice if the wall is missing or
broken.
Check that any flue which passes
through the loft is not damaged, seek
advice if the flue is in a poor state of
repair.
Check for any flued appliance which
may draw air from the loft, report to
the client.
Check for any holes in the ceilings
which may allow leakage of air to the
loft and repair as appropriate.
Check that the water storage tank is
covered.
FIXING KIT
CONTENTS FOR UNIT
2
INSTALLATION INSTRUCTIONS
IMPORTANT
Be sure to have read and understood
these instructions before beginning the
installation process.
Smoke Detectors
The ventilation unit must be wired through a
suitable smoke alarm so that it shuts down
when the alarm is activated (see page 7).
Diffuser
The metal supply diffuser must be located
a minimum of one metre from a smoke
alarm.
SAFETY AND RECOMMENDATIONS
• All wiring must comply with Building
Regulations and the current I.E.E. Wiring
Regulations (BS7671) or the equivalent
standards for your country. The nal
installation should be examined and
tested by a qualied electrician.
• Precautions must be taken to avoid the
back-flow of gases into the dwelling from
the open flue of gas or other fuel-burning
appliances.
• Make sure the mains supply complies
with the rating label for voltage, frequency
and phase.
• This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way
and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by children without supervision.
• Do not remove or tamper with electronic
circuit board. This is not a user function.
3
PIV L (3 STOREY)
INSTALLATION DIAGRAMS
3 STOREY INSTALLATION
Installation diagram for the PIV L3
UNIT DIMENSIONS
Dimensions of the PIV L3 - 470 x 405 x 372mm
Unswitched fuse spur
tted with 3 Amp fuse
230V A.C.
3 core mains lead
For xing instructions,
please refer to the xing
instructions.
See Fig. 1 on page 4
650mm x 50mm x 25mm batten
Ceiling joists
405mm
372mm
470mm
4
Ventilation Unit
Steel re diffuser rmly
attached to ceiling
Ø200 Diffuser
Ceiling
Duct
INSTALLATION INSTRUCTIONS
SECOND STAGE
Position the unit on 50mm x 25mm wooden
battens (not supplied) laid across the joists
or raised platform if the insulation is thicker
than the joists so that the ducting between
the unit and the diffuser is not impeded.
Lightly screw the drilled battens to the
joist through the foam mounts and metal
washer provided. Fit the ducting to the unit
spigot using half of the tape provided.
Fig.1 Fixing Instructions
FIRST STAGE
Determine the position of the re diffuser. It must be located a minimum of one metre from
a smoke alarm but may be tted closer than one metre from a wall or other obstructions if
required. Position a dustsheet beneath the site you have chosen for cutting the hole for the
diffuser. Protect your lungs with a mask. Enter the loft space with the unit and check there are
no obstructions to your chosen position for the diffuser.
Cut an appropriately sized hole using the diffuser spigot as a template.
10 x 3 screw
Washer
Foam pad
Foam pad
50mm x 25mm
batten with 20mm
clearance hole
Existing joist
FOURTH STAGE
The unit must only be installed by a
competent person and should be connected
to an electrical supply in accordance
with the current electrical regulations. A
disconnection device should be used in the
xed wiring.
FIFTH STAGE
Check the unit is working correctly. Set the
unit’s controls according to the house size
and check that the lters are securely in
place. For maximum airflow set the diffuser
fully open.
THIRD STAGE
Push ducting through the hole in the ceiling. Return to the hallway and connect the ducting onto
the neck of the diffuser. Secure the duct to the spigot of the diffuser using the other half the tape
supplied. Fix the diffuser in position using plasterboard plugs and the screws provided.
5
PIV L (3 STOREY)
INSTALLATION INSTRUCTIONS
SMALL /
TRICKLE
MEDIUM
PRESS
BUTTON
PRESS
BUTTON
PRESS
BUTTON
PRESS BUTTON
LARGE BOOST
SIXTH STAGE - Method of Operation
On Unit Control: Adjust the settings on the top of the unit by pressing the house setting button.
By pressing the button, the correct ventilation rate for the size of the house can be selected
i.e. if the unit is on SMALL / TRICKLE and the button is pressed, the unit will then switch to
MEDIUM. Similarly, if the unit is on BOOST and the button is pressed, the unit will then switch
to SMALL / TRICKLE.
To pair additional remote control switches:
1. Turn the unit OFF at the isolation point.
2. Restore power; for 20 seconds from restart the unit will be in pairing mode.
3. Press the remote button once within the 20 seconds and the control will pair to the unit.
4. Successful pairing is indicated by a green light on the control.
Note: When the battery needs replacing, unscrew the front cover.
The battery is located on the back of the cover. Battery type - 3V Lithium, CR2032.
Comfort Heater enable ON
Auto LED stays ON
constant for
a few seconds.
Comfort Heater enable OFF
Auto LED flashes
for a few seconds.
Boost
(Green)
Remote Control
in range (Green)
Remote
button
Remote Control
out of range (Red)
Comfort Heater enable
(Red)
Remote Control Operation:
6
SEVENTH STAGE - Installation Checks
The smoke alarm should be checked at
installation to ensure proper function. In
the case of a re, the system should be
thoroughly inspected.
On commissioning
the unit will default
to the trickle flow
rate with comfort
heater enable ON
Press button for
ve seconds turns
comfort heater
enable off. LED will
flash red for a few
seconds
Press button for
ve seconds turns
comfort heater
enable ON. LED will
show constant red
for a few seconds
Press button once,
to indicate current
fan speed and
comfort heater
status. LEDs stay
on constant for a
few seconds
Note: If the two LEDs situated just above the
remote button flash alternately red and green
(when it is pressed) the control may be out of
range.
Boost
Trickle Medium High
AutoBoost
Trickle Medium High
Auto
Next press moves
the unit to the next
speed and so on.
When the speed
is chosen the LED
remains on for a
few seconds
Boost
Trickle Medium High
Auto
Boost
Trickle Medium High
Auto
To change speed setting
Boost
Trickle Medium High
Auto
LED Colours
Constant Red
Flashing Red
Constant Green
For comfort heater enable/disable
7
PIV L (3 STOREY)
INSTALLATION INSTRUCTIONS
Wiring into Smoke Alarm
The 3 storey PIV unit MUST be wired into a smoke alarm to switch off on detection of smoke.
The unit can be wired into an existing smoke alarm. Check compatibility with smoke alarm
manufacturer. Alternatively a 1AC SMOKEALARM can be installed into the unit itself.
*
*Must be wired in by a qualied electrician.
Fused spur
6AMP
- Earth
- Neutral
- Live
- Interconnect
(depending on type of smoke alarm used)
N/C (live)
N
N
I/C
L
L
Ventilation
Unit
Smoke Alarm
N
I/C
L
1m min
Ø200mm steel re diffuser
8
USER GUIDE
FOR RESIDENT
9
PIV L (3 STOREY)
USER GUIDE
About your PIV L3
DO YOU KNOW WHAT’S GOING ON IN YOUR OWN HOME?
In a dwelling of 4 people, each will contribute
approximately 4 pints of moisture per day
– through showers, boiling kettles, cooking
etc totalling over 100 pints of liquid per
week.
Other airborne contaminants which exist
in a typical dwelling like dust, tobacco
products, exhaust gases – even chemical
emissions from furnishing and building
products further deteriorate air quality.
In older, less energy efcient dwellings,
there is a natural escape for this hot, damp
problem air – through ill-tting windows
and doors, uncarpeted floorboards, lofts
without insulation and so forth.
Improved building features such as cavity
wall insulation, double-glazing and draft
proong prohibit ‘natural ventilation’. Stale,
humid air is trapped – increasing the
condensation problem in the dwelling.
THE CAUSE OF CONDENSATION, DAMP AND MOULD
The Benets
Say goodbye to condensation & mould
Whole house ventilation
Improved air quality
Musty odours removed
Streaming windows stopped
Condensation control
Enhanced heat distribution
Benets allergy and asthma sufferers
MOISTURE
The typical household creates
around 100 pints per week - from
showers, baths, cooking etc.
CHEMICAL EMISSIONS
From everyday household
furnishings, building products etc.
FUMES
From tobacco products, exhaust
gases etc.
DUST
From furniture, carpets, bedding etc.
= Poor Air Quality = Condensation, Damp & Mould
10
How does my PIV L3 work?
The unit works by supplying fresh, ltered air throughout the home to transform a stagnant
and stale atmosphere into a fresh, healthy and condensation-free environment.
The unit delivers air into a home via a single input, usually located in a central landing.
How does my PIV L3 help?
It prevents the build-up of moisture in the house, controlling steam/condensation from
bathing and cooking to prevent the formation of black mould on walls, behind cupboards etc.
It will also help to stop dampness and musty smells caused by poor ventilation.
11
PIV L (3 STOREY)
Energy Saving Benets
The unit will help you to save energy in the following ways:
Minimal Energy Consumption
Using the latest technology, the unit is powered by ultra-low watt motors to achieve low
running costs.
Solar Gain
The unit takes maximum advantage of the benets from solar gain within the loft space.
This is the natural accumulation of heat from the sun on bright days. Temperatures in the
loft are on average 3°C higher than outside, which results in a relative saving of around
150 Watts per day in an average modern family home. This equates to approximately
10% of annual heating costs.
Heat Distribution
Warm air accumulates at ceiling level. This air can be up to 7°C higher than the internal
air at ground level. By introducing an air supply from the loft space, the unit helps to
redistribute heat around the home to further reduce heating costs.
No need to open windows
To reduce humidity and condensation, people often have to open windows. This can
lead to a signicant energy loss, particularly in the winter period. The unit provides fresh,
ltered air to the home and reduces humidity without the need to open windows, saving
energy and heat loss.
Health Benets:
Reduces mould spores, a trigger for respiratory problems and allergies.
Reduces house dust mite populations by lowering humidity levels - a main trigger for
asthma and allergies.
How do I control my PIV L3?
The unit will operate continuously, 24 hours a day. It is important that the unit is not turned off.
The flow rate of the unit will be set at the appropriate level for your home during installation.
With the remote control switch you can change the unit flow rate/speed at any time at the
push of a button. You can also use it to enable or disable the comfort heater (see pages 5-6
for operation instructions).
USER GUIDE
About your PIV L3
12
What features does my PIV L3 have?
The intelligent comfort heater is designed to temper the air during periods of low external
temperature. It is capable of holding incoming air temperature accurately at 10°C. With the
function enabled, the comfort heater may be on 10% of the time, depending on the fan speed
setting and only activates at loft temperature of 10°C or below.
The unit has an automatic increased airflow setting. This function increases airflow rates
per setting by 10% to deliver additional air into the property at temperature above 19°C. At
temperatures above 25°C the unit will go into standby mode to prevent hot air being delivered
into the dwelling.
Maintenance
The unit has been subjected to rigorous testing and are constructed from durable materials.
There should be no requirement for any maintenance within the ve year period.
At the ve year service, the lter located on the unit must be replaced to ensure maximum
efciency of the unit. The lter is mounted around the unit with velcro, simply pull off and
replace.
How much does my PIV L3 cost to run?
The unit is very energy efcient. On a constant medium setting with the comfort heater
enabled, the heater will be ON around 10% of the time. With the comfort heater disabled the
unit will cost less than £6* a year.
*Based on an average electricity unit price of 15p.
Costs will vary depending on atmospheric conditions and unit settings.
Helpful hints and tips
Keeping your home condensation free:
• Try to keep the house as warm as possible for as long as possible
• Do not dry clothes over radiators
• Vent your tumble dryer outside
• Do not use parafn / Calor gas type heating
Energy bills:
• To minimise energy bills you may need to adjust the central heating down if the diffuser is
in the same room as your thermostat.
13
PIV L (3 STOREY)
WARRANTY CONDITIONS AND EXCLUSIONS
The PIV L3 is covered by a 5 year warranty.
Do not turn your unit off. It is important that the unit runs continuously. Your warranty covers
any defect or break down that arises due to faulty materials or construction.
Terms of Warranty
• The system must be correctly installed and operated according to the instructions
contained in this guide.
• Periodic cleaning and maintenance must be carried out by a technically competent person.
• The warranty will be rendered invalid if the unit is turned off. Turning the unit off can damage
it.
• The warranty does not cover accidental damage, misuse or abuse.
• The warranty is in addition to your statutory or legal rights.
• The warranty will only be honoured from approved suppliers.
894 The Crescent
Colchester Business Park
Colchester
CO4 9YQ
T / (0)1206 713800
F / (0)1206 543126
E / enquiries@titon.co.uk
W / www.titon.co.uk/
V1-22.02.18
Due to our policy of continuous
innovation and improvement, the
manufacturer reserves the right to alter
products specication and appearance
without notice.
AFTER INSTALLING THIS FAN PLEASE PASS ONTO END USER
DO NOT THROW AWAY
Please read carefully to ensure simple
installation and a long trouble free life for
the user.
DO 5619 Iss 01
Loading...
