BAND SAW TTB364BDS
SAFETY AND OPERATING MANUAL
Original instructions
GUARANTEE
This product carries a guarantee of 24 months. If your product develops a fault
within this period, you should,in the first instance contact the retailer where the item
was purchased.
This guarantee specifically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (such as batteries)
- Accidental damage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
This guarantee does not affect your statutory rights. This guarantee is only valid in the
UK.
For further technical advice, spare parts or repair service (outside of guarantee) please
contact the customer helpline number on 0845 607 6380
Congratulations on your purchase of a
power tool from Titan Power
Tools (UK) Ltd. We want you to continue getting the best performance from
it so this handbook includes information on safety, handling and care. Please
retain this handbook in case you need to refer to any of the information in
the future.
Your
power tool comes with a 24-month guarantee,so should it develop
a fault within this period contact your retailer.
BAND SAW TTB364BDS
SAFETY INSTRUCTIONS
WARNING! When using electric tools basic safety precautions should always
be followed to reduce the risk of fire, electric shock and personal injury including
the following.
Read all these instructions before attempting to operate this product and save these
instructions.
Safe operation
1. Keep work area clear.
- Cluttered areas and benches invite injuries.
2. Consider work area environment.
- Do not expose tools to rain.
- Do not use tools in damp or wet locations.
- Keep work area well lit.
- Do not use tools in the presence of flammable liquids or gases.
3. Guard against electric shock.
- Avoid body contact with earthed or grounded surfaces (e.g. Pipes, radiators,
ranges, refrigerators, other metal surfaces).
4. Keep other persons away.
- Do not let persons, especially children, not involved in the work touch the tool
or the extension cord and keep them away from the work area
5. Store idle tools.
-When not in use, tools should be stored in a dry locked-up place, out of reach of
children.
6. Do not force the tool.
- It will do the job better and safer at the rate for which it was intended.
7. Use the right tool.
- Do not force small tools to do the job of a heavy duty tool.
- Do not use tools for purposes not intended; for example do not use circular
saws to cut tree limbs or logs.
8. Dress properly.
- Do not wear loose clothing or jewellery, they can be caught in moving parts.
- Non-skid footwear is recommended when working outdoors.
- Wear protective hair covering to contain long hair.
9. Use protective equipment.
- Use safety glasses.
- Use face or dust mask if working operations create dust.
10. Connect dust extraction equipment.
- If the tool is provided for the connection of dust extraction and collecting
equipment, ensure these are connected and properly used.
11. Do not abuse the cord.
- Never yank the cord to disconnect it from the socket Keep the cord away from
heat, oil and sharp edges.
12. Secure work.
- Where possible use damps or a vice to hold the work. It is safer than using your
hand.
13. Do not overreach.
- Keep proper footing and balance at all times.
14. Maintain tools with care.
- Keep cutting tools sharp and clean for better and safer performance.
- Follow instruction for lubricating and changing accessories.
- Inspect tool cords periodically and if damaged have them repaired by an
authorized service facility.
- Inspect extension cords periodically and replace if damaged.
- Keep handles dry, clean and free from oil and grease.
15. Disconnect tools.
- When not in use, before servicing and when changing accessories such as
blades, bits and cutters, disconnect tools from the power supply.
16. Remove adjusting keys and wrenches.
- Form the habit of checking to see that keys and adjusting wrenches are removed
from the tool before turning it on.
17. Avoid unintentional starting.
- Ensure switch is in “off” position when plugging in.
18. Use outdoor extension leads.
- When the tool is used outdoors, use only extension cords intended for outdoor
use and so marked.
19. Stay alert.
- Watch what you are doing, use common sense and do not operate the tool
when you are tired.
20. Check damaged parts.
- Before further use of tool, it should be carefully checked to determine that it will
operate properly and perform its intended function.
- Check for alignment of moving parts, binding of moving parts, breakage of
parts, mounting and any other conditions that may affect its operation.
- A guard or other part that is damaged should be properly repaired or replaced
by an authorized service centre unless otherwise indicated in this instruction
manual.
- Have defective switches replaced by an authorized service centre.
- Do not use the tool if the switch does not turn it on and off.
21. Warning.
- The use of any accessory or attachment other than one recommended in this
instruction manual may present a risk of personal injury.
22. Have your tools repaired by qualified person.
- This electric tool complies with the relevant safety rules. Repairs should only be
carried out by qualified persons using original spare parts, otherwise this may
result in considerable danger to the user.
23. If the replacement of the supply cord is necessary, this has to be done by
the manufacturer or his agent in order to avoid a safety hazard.
24. For tools intended to be connected to a water supply.
– for tools provided with a PRCD: Never use the tool without the PRCD delivered
with the tool.
BAND SAW TTB364BDS
– for tools provided with an isolating transformer: Never use the tool without
the transformer delivered with the tool or of the type as specified in these
instructions.
– Replacement of the plug or the supply cord shall always be carried out by the
manufacturer of the tool or his service organisation.
– Keep water clear off the electrical parts of the tool and away from persons in the
working area.
ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR BAND
SAW
1. Safety precautions
1) Do not use saw blade which are damaged or deformed;
2) Replace the table insert when worn;
3) Lock the work table firmly before operation;
4) Tension the saw blade properly;
5) Do not clean the saw band whilst it is in motion;
6) Wear suitable personal protective equipment, when necessary, this could include:
a) Hearing protection to reduce the risk of induced hearing loss,
b) Respiratory protection to reduce the risk of inhalation of harmful dust,
c) Gloves for handling the saw band and rough material.
2. Safe operation
1) When straight cutting against the fence use a push;
2) This saw must be attached to a solid secure work surface by means of the fixing holes
in the base.
3) Never adjust or assemble the rip fence or mitre gauge when the machine is
working;
4) When the workpiece is near to the saw blade, never use your hand to push it. Always
use the push stick provided (See 25 on main diagram)
5) Never tension the saw blade when working;
6) If need to adjust the blade guide, stop the machine first.
VIBRATION
The European Physical Agents (Vibration) Directive has been brought in to help
reduce hand arm vibration syndrome injuries to power tool users. The directive
requires power tool manufacturers and suppliers to provide indicative vibration test
results to enable users to make informed decisions as to the period of time a power
tool can be used safely on a daily basis and the choice of tool.
Further Advice can be found at www.hse.gov.uk
Vibration total values (triax vector sum) determined according to EN61029:
Work mode description 1
(if required by the relevant Part 2)
Vibration emission value a
h
= 3.0m/s²
Uncertainty K = 1.5m/s²
The declared vibration emission value should be used as a minimum level and
should be used with the current guidance on vibration.
Calculating the actual period of the actual period off use can be difficult and the HSE
website has further information.
The declared vibration emission been measured in accordance with a standardised
test stated above and may be used to compare one tool with another
The declared vibration emission value may also be used in a preliminary
assessment of exposure.
Warning: The vibration emission value during actual use of the power tool
can differ from the declared value depending on the ways in which the tool is
used dependant on the following examples and other variations on how the tool is
used:How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring it is sharp and in good
condition.
The tightness of the grip on the handles.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not adequately managed
Warning: identify safety measures to protect the operator that are based on
an estimation of exposure in the actual conditions of use (taking account of
all parts of the operating cycle such as the times when the tool is switched off and
when it is running idle in addition to the trigger time).Note The use of other tools will
reduce the users’ total working period on this tool.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades
BAND SAW TTB364BDS
Maintain this tool in accordance with these instructions and keep well lubricated
(where appropriate)
Avoid using tools in temperatures of 10°C or less
Plan your work schedule to spread any high vibration tool use across a number of
days.
Health Surveillance
All employees should be part of an employer’s health surveillance scheme to help
identity any vibration related diseases at an early stage, prevent disease progression
and help employees stay in work.
SYMBOLS
Read the manual
Warning
Wear gloves
Wear ear protection
Wear eye protection
Wear dust mask
Conforms to relevant safety standards
RyyWxx Manufacturing date code; Year of manufacturing (20yy) and week of
manufacturing (Wxx); “R”: Complies with Directive 2002/95/EC on the restriction of
the use of certain hazardous substances in electrical and electronic equipment.
1. ON/OFF SWITCH
2. FIXING KNOB
3. SIDE COVER
4. BLADE TENSION KNOB
5. UPPER BAND PULLEY
6. SAW BLADE GUARD
7. UPPER BLADE GUIDE
8. LOWER BLADE PULLEY
9. BASE
10. DUST EXTRACTION PORT
11. SETTING SCREW FOR UPPER BAND PULLEY
12. SETTING KNOB FOR BLADE GUIDE
13. MACHINE FRAME
3
7
6
5
4
8
9
10
2
1
