FOR AUTOMATIC TRANSMISSION ONLYFOR AUTOMATIC TRANSMISSION ONLY
www.titan-innovations.cawww.titan-innovations.ca
Revision 1.01
ADVANCED REMOTE STARTERADVANCED REMOTE STARTER
OWNER'S GUIDEOWNER'S GUIDE
The owner/user MUST INSTALL a CARBON MONOXIDE
DETECTOR in the living area near to where the vehicle is being
stored or parked. It is the sole responsibility of the owner/user
to keep the remote transmitters away from the reach of
children and handle with care so that the system does not
unintentionally start. When the vehicle is parked in an enclosed
/partially enclosed area (ex: garage, car port...), being serviced
(ex: oil change) or if the vehicle is loaned to an operator not
familiar with a remote starter, the system MUST BE placed in
Service (Valet) Mode.
NEVER OPERATE THE SYSTEM IN AN ENCLOSED/ PARTIALLY
ENCLOSED AREA!
MANUAL TRANSMISSION STARTERS the installation of a
remote starter MUST only be done with a specified manual
transmission starter. It is the sole responsibility of the vehicles
owner to insure that the vehicle is left with the transmission in
neutral position when the remote starter is in use. The manual
transmission starter is designed to be an added measure of
safety ONLY! The manufacturer does not guarantee or insure
against any damages or loss of life that could result in the
event of a remote starter starting while the vehicle is in gear.
Manual transmission models are designed only to act as a
deterrent against the vehicle starting in gear, this is the
vehicle’s owner’s and operator’s responsibility.
Lock
Unlock
Start
Car Finder
Button Operations
* This feature is not available for all vehicles.
** Optional feature, requires additional parts & installation.
*** Vehicle must be equipped with factory window roll-up feature.
ACTION FUNCTION
Press LOCK button once
Locks doors* and activates Starter Disable**
Press LOCK once then press and hold
Window Roll-up***
Press UNLOCK button once
Unlocks doors* and deactivates Starter Disable**
Press and hold LOCK for 3 sec
Remote panic*
Press and hold UNLOCK for 3 sec
Trunk release*
Press LOCK & UNLOCK buttons simultaneously
Silent Lock or Unlock
Press START button once
Remote engine starter on
Press and hold START button for 3 seconds
Remote engine starter off
Press and hold the button for 3 sec
Car finder*
Press button once then button for 3 sec
Timer Start mode on/off
LOCK
A. Press LOCK button momentarily.
B. Parking lights will flash 1 time, horn will honk 1 time*, doors will lock.
C. The LED on the antenna will begin to flash slowly.
D. If the optional starter-disable circuit has been installed, it will activate as well.
UNLOCK
A. Press UNLOCK button momentarily.
B. Parking lights will flash 2 times, horn will honk 2 times*, doors will unlock.
C. The LED on the antenna will stop flashing. (If passive starter-disable is
programmed, the LED will flash quickly for 60 seconds then rearm automatically.)
D. If the optional starter-disable is installed, it will be deactivated to allow the
vehicle to be started by key.
SILENT LOCK/UNLOCK
A. Press both LOCK and UNLOCK buttons simultaneously.
B. Parking lights will flash once or twice to indicate doors locking or unlocking.
C. Any programmed horn confirmations are temporarily bypassed.
REMOTE START
A. With the engine off, press the START button.
B. The parking lights will flash and the horn will chirp once*.
C. The vehicle’s ignition system will come on and within 3 seconds, the vehicle will
start. (If vehicle does not start, see the diagnostics section for possible solutions.)
D. The parking lights will flash 5 times to confirm a successful start.
E. The vehicle will run for the programmed runtime (15 minute default). To change
your remote starter runtime, contact your dealer.
F. The vehicle can be remotely shutdown by pressing and holding the START button
for 3 seconds.
