110_F/06.03 1/15 www.tissot.ch
T-Touch, multifunctions
User’s manual
Page
15
9
14
4
5
6
7
8
10-11
12
13
Minutes hand
Hour hand
Rotating bezel
Digital display
Scratch-resistant sapphire tactile glass
- correction / chrono
Activation-validation
+ correction / chrono
Tactile area
Synchronisation
Display mode
Setting the time
Setting the date
Selecting the units
www.tissot.ch 2/15 110_F/06.03
110_F/06.03 3/15 www.tissot.ch
Congratulations
Congratulations on choosing to buy a Tissot watch, a Swiss brand with one of the greatest reputations in the world.
Your T-Touch watch incorporates state-of-the-art technology. It offers permanent analogue display of the time as well
as varied digital displays. In addition, the following functions are available by simply touching the crystal: meteo, altimeter, chronograph, compass, alarm and thermometer.
Important notes
For the best reading of the temperature, remove the watch from your wrist and wait for approximately
15 to 30 minutes.
For correct use of the altimeter, adjust it as often as possible.
The METEO function indicates a trend. Hands superposed to the left of midday = bad weather, at midday =
stable weather, to the right of midday = good weather.
Your T-Touch is waterresistant to 30 m. However, no function can be operated if the crystal is in contact
with a liquid.
General information on use
• Activate the crystal by pressing
• When the crystal is activated, a flashing
bar will appear on the digital display
• Select a function by touching the corresponding area on the crystal
• Brief pressures on the pushers = step by step movement of the hands or incrementation (decrementation) on
the digital display
• Long pressures on the pushers = continuous movement or incrementation (decrementation)
• Incorrect operation of the pushers = different alarm from the normal beep
• No operation for 30 seconds = automatic deactivation of the crystal
• No operation for 3 seconds in setting mode = exit setting mode
Use :
Adjustment :
Touching action (without pressing)
Listening / Vision
Additional information
Replacing the battery
Type: Renata CR 1632
Hand position display
Beep
Time for pressing on
the pushers(e. g. 2 seconds)
Repetitive actions
2"
Synchronisation
www.tissot.ch 4/15 110_F/06.03
Activation of the glass
Selecting the "Units" mode
Using pushers and ,
bring the 2 hands precisely to
12 o'clock
Incrementation of the minute
hand (3 steps = 1 minute)
Incrementation of the hour
hand (3 steps = 1 minute)
Validation of the setting
(1) Procedure allowing the digital display to be synchronised
with the hands.
Note: it is not necessary to perform this synchronisation
operation when the digital display and the hands show
the same time.
110_F/06.03 5/15 www.tissot.ch
Display mode
h-m-s / date / units
1"
Activation of the crystal
Activation of the glass
h-m-s
Selecting the display mode
Selecting the "Units" mode
(1)
date
Using pushers and ,
(2)
units
bring the 2 hands precisely to
12 o'clock
Incrementation of the minute
hand (3 steps = 1 minute)
Return to h-m-s mode
Incrementation of the hour
hand (3 steps = 1 minute)
(1) The "h-m-s" and "date" modes remain active.
Validation of the setting
(2) The "units" mode is a temporary setting mode.
(1) Procedure allowing the digital display to be synchronised
(3) This procedure is valid when the crystal
is activated for the ALTIMETER, CHRONO,
COMPASS, ALARM, THERMO and METEO functions.
with the hands.
Note: it is not necessary to perform this synchronisation
operation when the digital display and the hands show
the same time.
(3)
www.tissot.ch 6/15 110_F/06.03
Setting the time
1"
2"
or
Activation of the crystal
Selecting the "h-m-s" mode
(eg. 8 h 34' 20'')
Activation of the setting
(1)
Incrementation or decrementation
+ or - 1 minute
by one minute
(2)
Validation of the setting,
the seconds restart at zero
Validation of the setting,
the seconds continue normally
(1) Accuracy: -0.3 to +0.5 seconds / day.
(2) Pressing continuously on or allows
continuous advance of the setting.
After one complete revolution, the minute hand stops
and the hour hand advances in one hour steps.
110_F/06.03 7/15 www.tissot.ch
Setting the date
(1)
1"
Activation of the crystal
Selecting the "date" mode
(eg. 5 July)
2"
Activation of the setting
Incrementation or decrementation
+ or - 1 day
by one day
Validation of the setting
(1) The calendar is semi-perpetual, that is the number
of days per month is predefined.
For February it is necessary to reset the date when
it is only 28 days.
Selecting the units
www.tissot.ch 8/15 110_F/06.03
1"
2"
Activation of the crystal
Selecting the "Units" mode
Activation of the setting
Selecting "Celsius degree / metre"
or "Fahrenheit degree / foot"
Selecting "12" or "24" hours
Validation of selections
110_F/06.03 9/15 www.tissot.ch
METEO
(1)
(1)
1"
Activation of the crystal
Activation of the meteo function
(1) For more information, see the explanation of the meteo
function on page 18.
(2) The two hands indicate a tendency while the digital display
gives a calculated pressure in hectoPascal.
After 30 seconds, the digital display returns to "h-m-s" mode.
(2)
www.tissot.ch 10/15 110_F/06.03
CHRONO
Precise measurement of a specific duration
1"
Activation of the crystal
Activation of the chronograph
Starting the chronograph
Stopping the chronograph
(eg. 10'' and 34/100)
Resetting the chronograph
(1) Resolution: 1/100 of a second
Measuring range: 9 h 59' 59'' and 99/100.
(1)
(2)
(2) After 30 seconds, the hands display the time again but
the digital display remains in CHRONO mode.
After 10 h, the digital display returns to "h-m-s" mode".
110_F/06.03 11/15 www.tissot.ch
CHRONO (split)
Precise measurement of a specific
duration with intermediate time
1"
Activation of the crystal
Activation of the chronograph
Starting the chronograph
Displaying the intermediate time
(eg. 48'' and 15/100)
Restarting the chronograph,
taking into account the running time
Stopping the chronograph
(eg. 2' 54'' and 88/100)
Resetting the chronograph
COMPASS
www.tissot.ch 12/15 110_F/06.03
Compass
Indication of the geographical North
1"
2"
Activation of the crystal
N
Activation of the compass
function
S
(1)
Activation of the adjustment
of the magnetic declination
(2)
Setting the magnetic declination
+ or - 1 degree
to the east (+) or west (-)
Validation of the setting (eg. 2° East)
(1) The minute hand points to the North. A more accurate
reading is obtained by holding the T-Touch horizontally.
The digital display gives the set magnetic deviation.
After 30 seconds, the digital display returns to "h-m-s"
mode.
(2) For more information, see the explanation of the
magnetic declination on page 20.
110_F/06.03 13/15 www.tissot.ch
ALARM
1"
1"
2"
+ or - 1 minute
Activation of the crystal
Activation of the alarm function
(eg. 12h19')
Activation of the alarm
Deactivation of the alarm
Setting the time
Incrementation or decrementation
by one minute
(1)
Validation of the setting
(1) When the programmed time is reached,
the alarm can be stopped by pressing one of the pushers.
ALTIMETER
www.tissot.ch 14/15 110_F/06.03
Indication of altitude
in relation to sea level
1"
2"
Activation of the crystal
Activation of the altimeter function
Adjusting the altitude
(2)
(1)
Incrementation or
+ or - 1 step
decrementation (1 m or 3 ft)
Validation of the setting
(1) The altitude is displayed in metres or feet depending on
the units selection (see "Selecting the units" on page 8).
After 30 seconds, the hands show the time again
but the digital display remains in ALTIMETER mode.
After 10 h, the digital display returns to "h-m-s" mode
(2) The adjustment shows the altimeter setting at the value
of the actual altitude. For more information,
see the explanation of the altimeter on page 22.
110_F/06.03 15/15 www.tissot.ch
s
Indication of the temperature (1)
THERMO
1"
Activation of the crystal
Activation of the thermometer
function
(1) To obtain the best reading, it is necessary to remove the watch
from your wrist and wait for approximately 15 to 30 minutes.
For more information, see the explanation of the thermometer
on page 24.
(2) The temperature is displayed in degrees Celsius or in degrees
Fahrenheit depending on the units selected (see "selecting the
units" on page 8).
After 30 seconds, the hands display the time again but the digital
display remains in THERMO mode.
(2)
