Tinytag Transit 2 User Manual

Tinytag Transit 2

Manual

2

3

C O N T E N T S

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

LED Flash Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Calibration . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Further Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4

W A R N I N G S

• If this equipment is installed or used in a manner not specified by the manufacturer

then the protection provided by the equipment may be impaired.

• This equipment contains a lithium battery. Danger of explosion if the battery is

incorrectly fitted. Do not cut open, incinerate, recharge or expose to temperatures in
excess of 100°C (212°F).

• The battery should be replaced by a trained technician using the battery supplied in

the appropriate manufacturer’s service pack.

• This equipment should only be interfaced to a UL or CSA listed computer with RS232

levels of not more than ±12V.

• This equipment should only be interfaced to equipment which is powered by a Safety

Extra Low Voltage Supply. The maximum voltage levels are to be 30V rms, 42V peak
or 60Vdc and separated from hazardous voltages by double or reinforced insulation.
For the United States consider a Safety Extra Low Voltage Supply to be a Class 2
source as defined in the National Electrical Code. If the unit is connected to a
computer outdoors the computer must also comply.

• This equipment should be used within the temperature range and other

environmental conditions specified in this manual.

5

G E T T I N G S T A R T E D

To use the Tinytag Transit 2 data logger you will need the following items:

• A copy of the Tinytag Explorer software

• A USB Inductive Pad OR a Tinytag Transit / Talk USB Download Cable

You will first need to install the Tinytag Explorer software and the USB inductive pad or
cable as described in the Tinytag Explorer quick start guide.

To use the Tinytag Transit 2 with an inductive pad it is simply as case of positioning
the logger in the centre of the pad as shown below.

To use the Tinytag Transit 2 with the download cable, remove the unit’s lid and plug
the cable into the unit’s jack socket as shown below.

For further information on how to start the data logger recording, and to view recorded
results, please see the Tinytag Explorer quick start guide.
