TIMES MICROWAVE SYSTEMS
LMR-®400-UF
UltraFlex Communications Coax
Ideal for…
• Drop-in replacement for RG-8/9913 Air-Dielectric type Cable
• Jumper Assemblies in Wireless Communications Systems
• Short Antenna Feeder runs
LMR-400-UF
• Any application that requires periodic/repeated exing
• LMR
®
- UltraFlex has a stranded center conductor
and rubber outer jacket designed for multiple bending/
exing cycles. It is used for both indoor and outdoor
applications.
• Flexibility and bendability are hallmarks of the LMR-
400-UF cable design. The exible outer conductor
enables the tightest bend radius available for any cable of
similar size and performance.
• Low Loss is another hallmark feature of LMR-400-
UF. Size for size LMR has the lowest loss of any exible
cable and comparable loss to semirigid hard-line cables.
• RF Shielding is 50 dB greater than typical single
shielded coax (40 dB). The multi-ply bonded foil outer
conductor is rated conservatively at > 90 dB (i.e. >180
dB between two adjacent cables).
• Weatherability: LMR-400-UF cables are designed
for outdoor exposure and have a life expectancy in excess
of 10 years.
• Connectors: A wide variety of connectors are available
for LMR-400-UF cable, including all common interface
types, reverse polarity, and solder-on center pins. Most
LMR connectors employ crimp outer attachment using
standard hex crimp sizes.
• Cable Assemblies: All LMR-400-UF cable types are
available as pre-terminated cable assemblies. Refer to
the section on FlexTech for further details.
Stock
Part Number Application Jacket Color Code
LMR-400-UF Indoor/Outdoor TPE Black 54040
Construction Specications
Description Material In. (mm)
Inner Conductor Stranded BC 0.108 (2.74)
Dielectric Foam Polyethylene 0.285 (7.24)
Outer Conductor Aluminum Tape 0.291 (7.39)
Overall Braid Tinned Copper 0.320 (8.13)
Jacket Black Thermoplastic Elastomer 0.405 (10.29)
Part Description
62
(800) TMS-COAX • www.timesmicrowave.com
TIMES MICROWAVE SYSTEMS
Mechanical Specications
Performance Property Units US (metric)
Bend Radius: installation in. (mm) 1.0 (25.4)
Bend Radius: repeated in. (mm) 4.0 (101.6)
Bending Moment ft-lb (N-m) 0.375 (0.51)
Weight lb/ft (kg/m) .088 (0.131)
Tensile Strength lb (kg) 160 (72.6)
Flat Plate Crush lb/in. (kg/mm) 20 (0.36)
Environmental Specications
Performance Property
Installation Temperature Range -40/+185 -40/+85
Storage Temperature Range -94/+185 -70/+85
Operating Temperature Range -40/+185 -40/+85
0
F
o
C
Attenuation vs. Frequency (typical)
100.0
Electrical Specications
LMR-400-UF
Performance Property Units US (metric)
Velocity of Propagation % 85
Dielectric Constant NA 1.38
Time Delay nS/ft (nS/m) 1.20 (3.92)
Impedance ohms 50
Capacitance pF/ft (pF/m) 23.9 (78.40)
Inductance uH/ft (uH/m) 0.060 (0.21)
Shielding Effectiveness dB >90
DC Resistance
Inner Conductor ohms/1000ft (/km) 1.07 (3.51)
Outer Conductor ohms/1000ft (/km) 1.65 (5.4)
Voltage Withstand Volts DC 2500
Jacket Spark Volts RMS 8000
Peak Power kW 16
10.0
1.0
Attenuation
(db per 100 feet)
0.1
10 100 1,000 10,000
Frequency (MHz)
Frequency (MHz) 30 50 150 220 450 900 1500 1800 2000 2500 5800
Attenuation dB/100 ft 0.8 1.1 1.8 2.2 3.3 4.7 6.2 6.8 7.2 8.1 13.0
Attenuation dB/100 m 2.7 3.5 6.1 7.4 10.7 15.4 20.2 22.3 23.6 26.6 42.6
Avg. Power kW 2.77 2.14 1.22 1.00 0.69 0.48 0.36 0.33 0.31 0.28 0.17
Calculate Attenuation = (0.146748) • FMHz + (0.000312) • FMHz (interactive calculator available at http://www.timesmicrowave.com/cable_calculators)
Attenuation: VSWR=1.0; Ambient = +25°C (77°F) Power: VSWR=1.0; Ambient = +40°C; Inner Conductor = 100°C (212°F);
Sea Level; dry air; atmospheric pressure; no solar loading
(800) TMS-COAX • www.timesmicrowave.com
63
TIMES MICROWAVE SYSTEMS
LMR®-400-UF
UltraFlex Communications Coax
1 3
2
4
TC-400-716-FC
3190-376
5
LMR-400-UF
TC-400-NFC
3190-299
10
13 14
Connectors
Part Stock VSWR ** Coupling Contact Contact Body Length Width Weight
TC-400-NMH-RA-D
TC-400-TM-RA-D
6/7
11
3190-2293
3190-2671
Inner Outer Finish*
TC-400-716-MC
3190-279
SC-400NM
3190-1454
TC-400NM
3190-188
12
TC-400-TM
3190-260
TC-400-TM-RX
3190-2532
TC-400-BM
3190-318
TC-400-NMH-X
3190-2626
TC-400-MUHF
98
TC-400-NMC
TC-400-SM
3190-439
Interface Description Number Code Freq. (GHz) Nut Attach Attach /Pin in (mm) in (mm) lb (g)
1.
7-16 DIN Female
2. 7-16 DIN Male Straight Plug TC-400-716-MC 3190-279 <1.25:1 (2.5) Hex Solder Clamp S/S 1.4 (36) 1.40 (35.6) 0.268 (121.6)
3. BNC Male Straight Plug TC-400-BM 3190-318 <1.25:1 (2.5) Knurl Solder Crimp N/S 1.7 (43) 0.56 (14.2) 0.063 (28.6)
4. Mini-UHF Straight Plug TC-400-MUHF 3190-520 <1.25:1 (2.5) Knurl Solder Crimp N/G 1.1 (28) 0.50 (12.7) 0.020 (9.1)
5. N Female Straight Jack TC-400-NFC 3190-299 <1.25:1 (2.5) NA Solder Clamp N/S 1.6 (41) 0.75 (19.1) 0.119 (54.0)
6. N Male Straight Plug SC-400-NM 3190-1454 <1.25:1 (2.5) Knurl Solder Crimp N/G 1.5 (38) 0.75 (19.1) 0.090 (40.8)
7. N Male Straight Plug TC-400-NM 3190-188 <1.25:1 (2.5) Knurl Solder Crimp N/G 1.5 (38) 0.75 (19.1) 0.090 (40.8)
8. N Male Straight Plug TC-400-NMH-X 3190-2626 <1.25:1 (10) Hex/Knurl Solder Crimp A/G 1.5 (38) 0.89 (22.6) 0.113 (51.3)
9. N Male Straight Plug TC-400-NMC 3190-277 <1.25:1 (2.5) Knurl Solder Clamp N/G 1.5 (38) 0.75 (19.1) 0.121 (54.9)
10. N Male Right Angle TC-400-NMH-RA-D 3190-2293
11. SMA Male Straight Plug TC-400-SM 3190-439 <1.25:1 (8) Hex Solder Crimp N/G 1.2 (29) 0.50 (12.7) 0.032 (14.5)
12. TNC Male Straight Plug TC-400-TM 3190-260 <1.25:1 (2.5) Knurl Solder Crimp N/S 1.7 (43) 0.59 (15.0) 0.074 (33.6)
13. TNC Male Right Angle TC-400-TM-RA-D 3190-2671 <1.35:1 (6) Hex/Knurl Solder Crimp A/G 1.4 (35) 1.41 (35.8) 0.130 (59.0)
14. TNC Male Straight Plug TC-400-TM-X 3190-2532 <1.25:1 (6) Hex/Knurl Solder Crimp A/G 1.9 (48) 0.67 (17.5) 0.075 (34.3)
* Finish metals: N=Nickel, S=Silver, G=Gold, SS=Stainless Steel, A=Alballoy **VSWR spec based on 3 foot cable with a connector pair
Straight Jack TC-400-716-FC 3190-376 <1.25:1 (2.5) NA Solder Clamp S/S 1.6 (41) 1.13 (28.7) 0.281 (127.5)
#
<1.35:1 (6) Hex/Knurl Solder Crimp A/G 1.8 (46) 1.25 (31.8) 0.130 (59.0)
3190-520
3190-277
64
(800) TMS-COAX • www.timesmicrowave.com
TIMES MICROWAVE SYSTEMS
LMR-400-UF
GK-S400TT
HG-400T
Hardware Accessories
Part Stock
Type Number Code Description
Ground Kit GK-S400TT GK-S400TT Standard Grounding Kit (each)
Hoisting Grip HG-400T HG-400T Laced Type (each)
HX-4
3190-200
CR-400
3190-830
Y1719
3190-202
3190-1544
CT-400/300
3190-666
CCT-01
Install Tools
Part Stock
Type Number Code Description
Crimp Tool HX-4 3190-200 Crimp Handle
Crimp Dies Y1719 3190-202 .429" Hex Dies
Crimp Tool CT-400/300 3190-666 Crimp tool for LMR 400 connectors
Crimp Rings CR-400 3190-830 Crimp rings for TC/EZ-400 connectors (package of 10)
Cutting Tool CCT-01 3190-1544 Cable end ush cut tool
Replacement Blade RB-01 3190-1609 Replacement blade for cutting tool
(800) TMS-COAX • www.timesmicrowave.com
65
