Slimline LED High Power
Floodlights
Model: LEDMF70FLB, LEDMF100FLB,
LEDMF150FLB
Installation & Operating Instructions
1
1. General Information
These instructions should be read carefully before installation and retained
for further reference and maintenance.
2. Safety
• Before installation or maintenance, ensure the mains supply to the luminaire
is switched off and the circuit supply fuses are removed or the circuit breaker
turned off.
• It is recommended that a qualified electrician is consulted or used for the
installation of this luminaire and install in accordance with the current
IEE wiring and Building Regulations.
• Check that the total load on the circuit including when this luminaire is fitted
does not exceed the rating of the circuit cable, fuse or circuit breaker.
• This product is not suitable for use in food preparation areas.
3. Technical Specifications
• 230V AC, 50Hz
• These luminaires are of class I construction and must be earthed
• Colour Temperature: 4000K
• Operating Temperature: -20°C to +40°C
• Energy Efficiency: Class A
• Beam Angle: 100 Degrees
• Cable Gland Thread Size: M20
• IP65 Rated suitable for restricted external applications
• CE Certified
LEDMF70FLB
• 70W Non-replaceable LED
• Energy Usage: 70kWh/1000h
• Lumen Output: 5840lm
• Mounting Centres: 140mm
• Dimensions: H 335mm, W 285mm, D 78mm
2
LEDMF100FLB
• 100W Non-replaceable LED
• Energy Usage: 100kWh/1000h
• Lumen Output: 8130lm
• Mounting Centres: 150mm
• Dimensions: H 375mm, W 310mm, D 88mm
LEDMF150FLB
• 150W Non-replaceable LED
• Energy Usage: 150kWh/1000h
• Lumen Output: 11220lm
• Mounting Centres: 150mm
• Dimensions: H 375mm, W 310mm, D 88mm
4. Installation
4.1 Ensure the mains supply is switched off and the circuit supply fuses are
removed or the circuit breaker turned off.
4.2 An isolating switch should be installed to the switch the power ON and OFF
to the luminaire. This allows the unit to be easily switched OFF for
maintenance purposes.
4.3 Remove the mounting bracket by undoing the 2 Allen bolts and washers
located on the left and right side of the luminaire. You will need a 6mm
Allen key (not supplied). Take note of the order of the washers as you
remove the bracket.
4.4 Mark the position of the mounting holes on the wall using the mounting
bracket as a template.
4.5 Drill the holes for the rawl plugs ensuring not to infringe with any gas/water
pipes or electrical cables that may be hidden below the surface. Insert the
rawl plugs.
4.6 Fix the mounting bracket to the wall using the correct screws for the
rawl plugs installed.
4.7 Remove the panel and rubber gasket located on the back of the luminaire
by undoing the 4 fixing screws.
3
4.8 Attach the supplied cable glands to the luminaire. If an outgoing mains
supply cable is not required, use a cable blank on one of the provided holes.
4.9 Pass the 230V 50Hz mains supply cable through the cable gland making
sure to tighten it, and prepare the cable for termination.
4.10 Terminate the mains supply cable into the terminal block (please refer
to section 5. Connection Diagram) ensuring correct polarity is observed
and that all bare conductors are sleeved.
4.11 Re-fit the panel to the back of the luminaire ensuring the rubber gasket
is in place. Secure into place using the 4 fixing screws previously removed.
4.12 Re-attach the luminaire to the mounting bracket using the 2 Allen bolts
and washers previously removed, just enough to secure into place but
do not overtighten.
4.13 Adjust the angle of the luminaire so it lights the required area, and then
tighten the Allen bolts holding the luminaire to the mounting bracket.
LN
230V~50Hz
MAINS SUPPL
L
E
N
4
5. Connection Diagram
• Connect the 230V AC 50Hz mains supply cable
to the terminal block as follows;
Y
ISOLATION
SWITCH
230V 50Hz Mains Supply
Live Supply (Brown or Red) to L
Neutral Supply (Blue or Black) to N
Earth (Green/Yellow) to
6. Operation
• Turn the power ON to the isolation switch and test for correct
ON/OFF operation.
3 Year Guarantee
In the unlikely event of this product becoming faulty due to defective material or
manufacture within 3 years of the date of purchase, please return it to your supplier
in the first year with proof of purchase and it will be replaced free of charge.
For years 2 and 3 or any difficulty in the first year, telephone the helpline
on 020 8450 0515.
Note: A proof of purchase is required in all cases. For all eligible replacements
(where agreed by Timeguard) the customer is responsible for all shipping/postage
charges outside of the UK. All shipping costs are to be paid in advance before
a replacement is sent.
If you experience problems, do not immediately return the unit
to the store. Telephone the Timeguard Customer Helpline;
HELPLINE
020 8450 0515
or email helpline@timeguard.com
Qualified Customer Support Co-ordinators will be on-line
to assist in resolving your query.
For a product brochure please contact:
Timeguard Limited.
Victory Park, 400 Edgware Road,
London NW2 6ND
Sales Office: 020 8452 1112
or email csc@timeguard.com
Zerofour – December 2016
www.timeguard.com
67.058.573 (Issue 1)
