Installation & Operating Instructions

WiFi Controlled Fused

Spur Time Switch

Model: FSTWiFi –

WiFi Controlled Fused Spur

M

odel: FSTWiFiTGV –

WiFi Controlled IP66 Fused Spur

1

1. General Information

These instructions should be read carefully and retained for further
reference and maintenance.

Note: Timeguard reserve the right to alter these instructions, and the
SupplyMaster app, at any time. Up to date instructions will always be
available for download at www.timeguard.com.

2. Safety

• Before installation or maintenance, ensure the mains supply to the
time switch is switched off and the circuit supply fuses are removed
or the circuit breaker turned off.

• It is recommended that a qualified electrician is consulted or used
for the installation of this thermostat and install in accordance with
the current IEE wiring and Building Regulations.

• Check that the total load on the circuit including when this
thermostat is fitted does not exceed the rating of the circuit cable,
fuse or circuit breaker.

• To clean use a clean dry cloth only. Do not use liquid cleaners.

3. Technical Specifications

• Mains Supply: 220-240V AC 50Hz

• Fused: Supplied with BS1362 13A Fuse

• Rocker Switch: 2 Pole, providing isolation

• Switch Rating: 13A Resistive (3kW)
1000W Incandescent, Halogen lighting
500W Fluorescent, LED lighting
100W Compact Fluorescent lighting

• Contact Type: Normally Open, micro disconnection

2

• Wi-Fi Specification: 2.4 GHz b/g/n

• Frequency Range: 2.412 – 2.484 GHz

• Operating Modes: Permanent ON or OFF, Auto timed, Holiday

• Boost Times: 1 or 2 hour

• Output Light: Yes

• Operating Temperature: 0°C to +40°C

• IP Rating: FSTWiFi – Intended for indoor use only
FSTWiFiTGV – IP66 rated suitable
for restricted external applications

• Minimum Depth of Wall Box: 25mm

• Multiple Device Support: Yes

• CE Compliant

• Dimensions: H = 85mm, W = 85mm, D = 44mm

Note: Not suitable for use with Discharge Lighting.

ON/OFF
indicator

Override

button

and Wi-Fi

connect

Wi-Fi
connection
indicator

Double pole switch BS1362 (1" x 1/4") fuse

3

FSTWIFI MAC address and ID Wi-Fi number label

Important: Do not remove this label from the side of the product.

4. Contents

FSTWIFI

• 1x FSTWIFI time switch

• 2x Mounting screws

• 1x Cable clamp

• 1x Cable blank

• 1x Instruction manual

Note: all instructions are to be left with the customer after installation.

5. Installation

FSTWiFi – Wi-Fi Controlled Fused Spur

Note: The unit is designed to replace an existing single gang connection unit
or fixed appliance outlet giving timed mains output, protected by a BS1362
fuse. The unit is capable of forming part of a ring main (the terminals can
accept 2x 2.5mm sq. cables), or terminating a spur off the ring main.
The unit requires a minimum depth of 25mm within the box.

5.1 Ensure the mains supply is switched off and the circuit supply

fuses are removed or the circuit breaker is turned off.

FSTWIFITGV

• 1x FSTWIFITGV time switch

• 2x 20mm cable glands

• 1x Instruction manual

4

5.2 Connect the incoming 230V 50Hz mains supply and outgoing

load cables to the relevant terminals ensuring correct polarity
is observed and that all bare conductors are sleeved
(see section 6. Connection Diagram).

5.3 There is a removable cable blank to cover the front cable exit

if this feature is not required.

5.4 If the front cable exit is required, for instance to connect to

a washing machine, use one of the cable clamps provided
to secure the outgoing cable.

5.5 Secure the unit to the back box with the M3.5mm screws provided,

forming cables during installation to avoid entrapment, and
cable damage.

FSTWiFiTGV – Wi-Fi Controlled IP66 Fused Spur

5.6 IMPORTANT Switch off the electricity at the fuse box by removing

the relevant fuse or switching off the circuit breaker before
proceeding with the installation.

5.7 Using a Phillips screwdriver, separate the faceplate from the back

box by removing the four tapped screws located in each corner.

Tapped

screws

5

5.8 Using the back box as a template mark the position for the holes.

Note the back box must be mounted in the correct orientation,
following the ‘TOP’ marking inside the back box. If the mounting
position desired is uneven use a sheet of marine ply as a base plate
and fit the back box.

5.9 Drill the wall using a 4mm Ø drill bit making sure not to infringe

or compromise any gas, water pipes or cables. Insert the rawl
plugs into the holes.

5.10 The drain feature must be drilled out using a 5mm drill bit if the top

or side entry conduit is used. Opening this drain hole will reduce
the IP rating of the product. Only the lower drain feature on the
back box must be opened.

5.11 Select the required entry point by unscrewing the appropriate

seal located on all four sides of the back box. If conduit is not
going to be used, a waterproof cable with suitable rated 20mm
glands will be required to maintain the overall IP rating. If the
bottom entry conduit is used, there must be adequate drainage
from the lowest point of the conduit.

5.12 Secure the back box to the wall using suitable screws for the rawl

plugs installed. Ensure that the back box is correctly orientated
following the ‘TOP’ marking which is labelled inside.

5.13 Pass through the 230V AC 50Hz mains supply cable and secure

the cables tightly to their respective terminals, ensuring that all
bare conductors are sleeved and that correct polarity is observed.
Note that if metal conduit is used the earth continuity between
the conduits must be maintained.

5.14 Once the mains supply is connected to the correct terminals,

mount the face plate to the four mounting holes on the back box.
Tighten until secured.
