LED Half Carriage PIR Lantern
Model: CLLEDH44PIRB – Black
Model: CLLEDH45PIRWH – White
Installation & Operating Instructions
1
1. General Information
These instructions should be read carefully and retained for further reference
and maintenance.
2. Safety
• Before installation or maintenance, ensure the mains supply to the luminaire
is switched off and the circuit supply fuses are removed or the circuit breaker
turned off.
• It is recommended that a qualified electrician is consulted or used for
the installation of this luminaire and install in accordance with the current
IEE wiring and Building Regulations.
• Check that the total load on the circuit including when this luminaire is fitted
does not exceed the rating of the circuit cable, fuse or circuit breaker.
3. Technical Specifications
• 230V AC 50 Hz
• This Luminaire is of class II construction and must not be earthed
• Lamp Type Supplied: 4W LED
• Energy Efficiency: Class A
• Energy Usage: 4kWH/1000H (Lamp Supplied)
• Lamp Rating: 60W halogen (max.)
18W compact fluorescent (max.)
5W LED (max.)
• Lumen Output: 320-335lm
• Colour Temperature: Warm White 2900 – 3200K
• Operating Temperature: -10°C to 40°
• IP44 Rated suitable for limited external applications
• Detection Angle: 150°
• Detection range: Up To 8m
• Beam angle: 120°
• On time: 10 seconds – 8minutes
• Lux ON/OFF: 30/60
• Manual Override: No
• CE Compliant: Yes
2
4. Installation
1. IMPORTANT Switch off the electricity at the fuse box by removing
the relevant fuse or switching off the circuit breaker before proceeding
with the installation.
2. An isolating switch should be installed to switch the power to the unit
on and off. This is for maintenance purposes.
3. Remove the front housing machine threaded bolts from the wall mount
plate using the hexagonal Allen key supplied, see diagram A.
Diagram A
Machine threaded
4. Using both hands gently lift the front housing from the wall mount plate
with each hand at the top and bottom lengths of the housing. Once removed
place the front housing in a safe area to reapply later.
5. Using the back plate as a template mark the position for the holes. Note the
back plate must be mounted in the correct orientation as shown in diagram B.
6. Drill the wall using a 6mm Ø masonry drill bit making sure not to infringe
or compromise any gas, water pipes or cables. Insert the supplied rawl plugs
into the previously drilled holes.
7. Pierce the pre-installed rubber grommet and pass through the 230V AC 50Hz
mains supply cable. Ensuring the IP rating of the fitting is maintained
(Silicon sealant may be used).
8. Secure the back plate to the wall using the screws provided.
Diagram B
Rawl plugs
Mains supply cable
230V AC 50Hz
9. Use the cable clamp next to the grommet to hold the supply cable securely
in place.
3 4
Cable clamp and
screws supplied to be
fitted as shown
10. Connect the 230V AC 50Hz mains cable to the terminal block ensuring
that all bare conductors are sleeved and that correct polarity is observed.
For wiring please refer to section 5 Connection Diagram.
11. Decide if the plain or frost panel is required for the installation, there are
two screws that hold the panel to the front housing located on the top
and bottom centre of the panel. Please note the front housing will have
the clear panel attached by default.
Diagram C
