360º Night Eye PIR
Light Controller
Model: MLSA360N
Installation & Operating Instructions
![](/html/ce/ce44/ce446b650eb44fa9f1b63adb4bde26145e4b9d717ec34d42e050ea493ea2d0d6/bg2.png)
1
Motion Sensor Detection
Sensor Tilt Angle = 0º
Ceiling Mount Position Sensor Tilt Up 3º Sensor Tilt Down 30º
3º0º 30º
Perspective
View
5 metre5 metre
2.5m
1m
![](/html/ce/ce44/ce446b650eb44fa9f1b63adb4bde26145e4b9d717ec34d42e050ea493ea2d0d6/bg3.png)
2
Sensor Head Adjustment
Lens Mask
Pan Adjustment: Left 45º, Right 45º.
Tilt Adjustment: Up 3º – To extend (Max. 8m) the forward detection.
Down 30º – To shorten the forward detection to 2.5m.
![](/html/ce/ce44/ce446b650eb44fa9f1b63adb4bde26145e4b9d717ec34d42e050ea493ea2d0d6/bg4.png)
3
Mounting Insulation Steps
1 Wall Mounting
1
32
Round wall box
Ø6mm
60mm
4
65
For surface
mounting
OPTIONAL
Cable entry
from top x2
Cable entry from
bottom x2
Max. Ø11mm
Max. Ø11mm
OFF
![](/html/ce/ce44/ce446b650eb44fa9f1b63adb4bde26145e4b9d717ec34d42e050ea493ea2d0d6/bg5.png)
4
2 Ceiling/Eave Mounting
3 External Corner Mounting
1
2
OPTIONAL
OFF
Cable entry
from rear x2
Max.
Ø11m m
60mm
Ø6mm
3 4
Cable entry
from
front x2
Max. Ø11mm
5 6
For
surface
mounting
1 2
3
Ø6mm
4 5
OFF
![](/html/ce/ce44/ce446b650eb44fa9f1b63adb4bde26145e4b9d717ec34d42e050ea493ea2d0d6/bg6.png)
5
6
Wiring Connection Steps
Removing
8
9
1
3
10
2
4
21
7
(1) Power supply
(2) Wires connect to
lighting fi xture
“Click”
