Time Electronics 1068 User Manual

Time Electronics
1068 Precision Fixed
Resistance Box
Technical Manual
V1.1 18/01/11 Time Electronics Ltd
Botany Industrial Estate, Tonbridge, Kent, TN9 1RH
Tel: +44(0)1732 355993 Fax: +44(0)1732 770312
Email: mail@TimeElectronics.co.uk
Web Site: www.T imeElectronics.com
2

Contents

1. Introduction ........................................................................................................ 3
2. Opera tion ............................................................................................................ 3
3. Guarantee & S ervicing ....................................................................................... 4
All Time Electronics' instruments are subject to continuous development and improvement and in
consequence may incorporate minor detail changes from the information contained herein.
V1.1 14/09/10 Page | 2 1068 Technical Manual
3

1. Introduction

5 Fixed Resistance Ranges: 1R, 10R, 100R, 1K,10K Accuracy: 1R ± 1mR 10R ± 5mR 100R ± 10mR 1K ± 100mR 10K ± 1R Maximum Operating Voltage: 250v DC Dimensions: L115 x W65 x H86mm (Including terminals) Weight: 0.29 Kg Optional Extras: Standard Traceable or UK AS Certificates
Terminal shroud kit
If voltages above 70V DC or 30V AC (RMS) are present the optional terminal shroud kit (Part No. 9722) must be fitted.

2. Operation

The 1068 is a portable 5 fixed resistance box, housed in a robust metal case and desig ne d for industrial, laboratory and education requirements.
The high accuracy obtained in the 1068 is achieved by the use of accurate, precision resistors.
To select a value simply connect test leads to one of the fixed value resistors
i.e. 1R, 10R, 100R, 1K or 10K.
Connection to the box is via 4mm binding posts.
V1.1 14/09/10 Page | 3 1068 Technical Manual
4

3. Guarantee & Servicing

Guarantee Period. This unit is guaranteed against defects in materials and workmanship for a period of one year from its delivery to the customer.
We maintain comprehensive after sales facilities and the unit can, if necessary be returned to us for servicing. During this period, Time Electronics Ltd will, at its discretion, repair or replace the defective items. For servicing under guarantee, the instrument type and serial number must always be quoted, together with details of any fault and the service required. The purchaser of the instrument must prepay all shipping charges. Time Electronics Ltd will pay return shipping charges.
This guarantee is void if servicing has been attempted by an unauthorised person or agent. If, during the guarantee period, failure is due to misuse or abuse of the unit, the repair will be put in hand without delay and charged unless other instructions are received.
Please note that if you require a new UKAS Certificate during the warranty period, this will be charged at the current rate on our price list.
Service After Guarantee Period.
Even after the guarantee period has expired, Time Electronics Ltd., can still service your instrument. As the manufacturer, we have the specialised knowledge needed to keep your instrument in peak condition and we also maintain a comprehensive spare parts service.
Please enclose details of the service required and your full company details including a contact name when returning for servicing.
Returning Instruments.
When returning instruments, please ensure that they have been adequately packed, preferably in the original packing supplied. Time Electronics Ltd will not accept responsibility for units returned damaged. Please ensure that all units have details of the service required and all relevant paperwork.
Send the instrument, shipping charges paid to:-
Time Electronics Ltd
Botany Industrial Estat e, Tonbr i dg e, K ent, TN9 1RH
Tel: +44(0)1732 355993 Fax: +44(0)1732 770312
Email: mail@TimeElectronics.co.uk
Web Site: www.TimeElectronics.com
Disposal of your old equipment
1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact
V1.1 14/09/10 Page | 4 1068 Technical Manual
your city office, waste disposal service or return to Time Electronics.
