ACL1000/ACL2000

Refrigerant
Leak Detectors

Owner ’s Manual

BOTH MODELS ARE:

DESIGN CERTIFIED BY

MET LABORATORIES, INC.TO MEET

SAE J1627 FOR R134a, R12 AND R22.

CLASS 1 DIVISION 2 GROUPS
C & D HAZARDOUS

LOCATIONS
HAND HELD
GAS DETECTOR
CLASSIFIED BY
UNDERWRITERS

LABORATORIES,
INC.® AS TO FIRE ELECTRICAL
SHOCK AND EXPLOSION HAZ­ARDS ONLY. READ OWNERS
MANUAL BEFORE OPERATING.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,DE­ENERGIZE UNIT BEFORE RE­PLACING SENSING TIP OR
SERVICING UNIT, USE ONLY
WITH 1.5V ALKALINE BATTER­IES, SIZE C.

z

{

C US

C

L

A

S

S

I

F

I

E

D

67X1

1

General Description ............................................................2

Features ..............................................................................2

Parts & Controls ..................................................................3

Getting Started.....................................................................3

Installing Batteries .....................................................3

Operating Features..............................................................4

Constant Power Indication ........................................4

Automatic Circuit/Reset .............................................4

Sensitivity Adjustment.................................................4

Operating Instructions..........................................................5

Operating Tips .....................................................................5

Applications .........................................................................7

Maintenance ........................................................................7

Replacement Parts .............................................................8

Specifications.......................................................................9

Warranty...............................................................................9

TABLE OF CONTENTS

Thank you for purchasing the MAC TOOLS Refeigerant Leak Detector.
The advanced micro-processor is at the heart of the ACL1000 and 2000. It permits
more advanced management of the circuitry and sensing tip signal than ever before
possible. Additionally, the number of components used in the circuit is reduced 50%,
increasing reliability and efficiency. The micro-processor monitors the sensing tip and
battery voltage levels 4000 times per second, compensating for even the most minor
fluctuations in signal. This translates into a stable and dependable tool in almost any
environment.

Convenience features have been added to enhance usability. A revolutionary new
case design gives the user grip and control, and places the visual indicators
(ACL2000) in direct sight during use.

Please take a few moments to read through the following pages, in order to under­stand and benefit from all the capabilities of your new ACL2000 or ACL1000. We trust
that you will be 100% satisfied with your new purchase. If you have any questions or
comments after reviewing the manual, please feel free to contact us toll free at
[phone].

Both Models Feature:

• Microprocessor controlled circuit with Advanced Digital Signal Processing

• Detect ALL Halogenated refrigerants

• Rubber cushion grip

• Certified to SAE J1627 for R12, R22 & R134a

• Variable frequency audible alarm

• Constant Power Indication

• Cordless and portable, operate on 2 C-cell batteries

• 14" (35.5cm) flexible stainless probe

• Spare sensing tip included

• UL Classified for Intrinsic Safety

• CE Approved

• Carrying case included, optional holster and reference leak source

• Two Year Warranty

Additional Features of ACL1000

• Single switch control

Additional Features of ACL2000

• Six segment visual leak size indicator

• True mechanical pump provides positive airflow through sensing tip

• High and Low sensitivity levels

• One touch reset

• Tactile keypad controls

• Real time sensitivity adjustment

2

GENERAL INFORMATION

FEATURES
