Page 1
TOR30L
COOK
LIKE
A
GOD
30 INCH MICROWAVE OVEN
Page 2
USE AND CARE MANUAL
30 INCH
MICROWAVE OVEN
TOR30L
Page 3
TABLE OF CONTENTS
Precautions .................................................................................................................................................. 1
Important Safety Instructions .................................................................................................................. 2-3
Grounding instructions ................................................................................................................................ 4
Radio interference ....................................................................................................................................... 5
Utensils ..................................................................................................................................................... 6-7
Control Panel / Manual cooking .............................................................................................................. 8-1
One touch cook ...................................................................................................................................... 14-15
Maintenance ............................................................................................................................................... 16
Warranty ..................................................................................................................................................... 17
Read these instructions carefully before using your microwave oven,
and save this manual. If you follow the instructions, your oven will
provide you with many years of good service.
SAVE THESE INSTRUCTIONS
Page 4
PRECAUTIONS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
A. Do not attempt to operate this oven with the door open since open door operation can result in
harmful exposure to microwave energy. It is important not to defeat or tamper witht he safety interlocks.
B. Do not place any object between the oven front face and the door or allow dirt and cleaner residue to
accumulate on sealing surfaces.
C. Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly
and that there is no damage to the:
1. Door
2. Hinges and latches
3. Door seals and sealing surfaces
D. The oven should not be adjusted or repaired by anyone except properly qualified service personnel
SPECIFICATIONS
MODEL EM044K6LP-P00A
Rated
voltage:
Rated Input Power (Microwave)
Rated Output Power (Microwave)
120V-60Hz
1550W
1000W
1
Page 5
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed, including
the following:
WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or
exposure to excessive microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specific: “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” found on page 2.
3. This appliance must be grounded. Connect only to properly grounded outlet. See “GROUNDING
INSTRUCTIONS” found on page 5.
4. Install or locate this appliance only in accordance with the provided installation instructions.
5. Some products such as whole eggs and sealed containers - for example, closed glass jars - are able to
explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook or dry
food. It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when used by children.
8. Do not operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has
been damaged or dropped.
9. This appliance should be serviced only by qualified service personnel. Contact nearest authorized
service facility for examinati
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this product near water - for example, near a
kitchen sink, in a wet basement, near a swimming pool, or similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that comes together on closing the door, use only mild,
nonabrasive soaps, or detergent applied with a sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
1). Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
2). Remove wire twist-ties from paper or plastic bag before placing bag in oven.
3). If material inside of the oven ignite, keep oven door closed, turn oven off, and disconnect the power
cord, or shut off power at the fuse or circuit breaker panel.
4). Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils, or food in
the cavity when not in use.
on, repair, or adjustment.
2
Page 6
IMPORTANT SAFETY INSTRUCTIONS
17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or boiling when the container is removed from the
microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN THE CONTAINER IS
DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
(1) Do not overheat the liquid.
(2) Stir the liquid both before and halfway through heating it.
(3) Do not use straight-sided containers with narrow necks.
(4) After heating, allow the container to stand in the microwave oven for a short time before removing
the container.
5. Use extreme care when inserting a spoon or other utensil into the container.
18. Oversized food or oversized metal utensils should not be inserted in a microwave / toaster oven as
they may create a fire or risk of electric shock.
19. Do not clean with metal scouring pads. Pieces can burn off the pad and touch electrical parts
involving a risk of electric shock.
20. Do not use paper products when appliance is operated in the toaster mode.
21. Do not store any materials, other than manufacturer's recommended accessories, in this oven
when not in use.
22. Do not cover racks or any other part of the oven with metal foil. This will cause overheating of
the oven.
23. Clean Ventilation Hoods Frequently - Grease should not be allowed to accumulate on hood
or filter.
24. When flaming foods under the hood, turn the fan on.
25. Use care when cleaning the vent-hood filter. Corrosive cleaning agents, such as lyebased oven
cleaners, may damage the filter.
26. Suitable for use above both gas and electric cooking equipment.
SAVE THESE INSTRUCTIONS
3
Page 7
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord
having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded.
WARNING - Improper use of the grounding can result in a risk of electric shock. Consult a qualified
electrician or serviceman if the grounding instructions are not completely understood, or if doubt exists
as to whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a
3-wire extension cord that has a 3-blade grounded plug, and 3-slot receptacle that will accept the plug
on the appliance. The marked rating of the extension cord shall be equal to or greater than the electrical
rating of the appliance.
DANGER - Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or death. Do not
disassemble this appliance.
WARNING - Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is
properly installed and grounded.
1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or
tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised in their use.
3. If a long cord or extension cord is used:
(1) The marked electrical rating of the cord set or extension cord should be at least as great as the
electrical rating of the appliance.
(2) The extension cord must be a grounding-type 3-wire cord.
(3) The longer cord should be arranged so that it will not drape over the counter top or tabletop where it
can be pulled on by children or tripped over unintentionally.
4
Page 8
RADIO INTERFERENCE
1. Operation of the microwave oven may cause interference to your radio, TV or similar equipment.
2. When there is interference, it may be reduced or eliminated by taking the following measures:
1) Clean door and sealing surface of the oven
2) Reorient the receiving antenna of radio or television.
3) Relocate the microwave oven with respect to the receiver.
4) Move the microwave oven away from the receiver.
5) Plug the microwave oven into a different outlet so that microwave oven and receiver are on different
branch circuits.
This device complies with part 18 of the FCC Rules.
5
Page 9
UTENSILS
CAUTION - Personal Injury Hazard
Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches should
be pierced before cooking.
See the instructions on “Materials you can use in microwave oven or to be avoided in microwave oven.”
There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can
test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
MATERIALS YOU CAN USE IN MICROWAVE OVEN
Utensils Remarks
Browning dish
Dinnerware
Glass jars
Glassware
Oven cooking bags
Paper plates and cups
Paper towels
Parchment paper
Plastic
Follow manufacturer’s instructions. The bottom of browning dish must
be at least 3/16” or (5mm) above the turntable. Incorrect usage may
cause the turntable to break.
Microwave-safe only. Follow manufacturer’s instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim
Do
not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use to cover food for reheating and absorbing fat. Use with supervision
for short-term cooking
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer* instructions. Should be
labeled “Microwave Safe”. Some plastic containers soften, as the food
inside gets hot. “Boiling bags” and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Paper wrap
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
6
Page 10
UTENSILS
Thermometers
Wax paper
Microwave-safe only (meat and candy thermometers).
Use as a cover to prevent splattering and retain moisture.
MATERIALS YOU CAN USE IN MICROWAVE OVEN
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metaltrimmed
utensils
Metal twist ties
Paper bags
Plastic foam
Wood
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dis Metal shields
the food from microwave energy. Metal trim may cause arcing.
May cause arcing and could cause a fire in the oven.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and
or crack.
may split
7
Page 11
CONTROL PANEL
MANUAL COOKING
• Before operating your new oven make sure you read and understand this Use & Care guide competely.
• The clock can be disabled when the microwave is first plugged in and the stop key is selected.
SETTING THE CLOCK
• Suppose you want to enter the correct time of day 10:59
Touch: Display Shows:
1. Clock
1 0 5 9
2.
3. START
Enter / +30 Sec
Setting Kitchen Timer
Your microwave oven can be used as a kitchen timer. You can set up to 99 minutes, 99 seconds The
kitchen timer can be used while the microwave oven is running.
• Suppose you want to set for three minutes.
8
Page 12
MANUAL COOKING
Setting Kitchen Timer
Your microwave oven can be used as a kitchen timer. You can set up to 99 minutes, 99 seconds The
kitchen timer can be used while the microwave oven is running.
• Suppose you want to set for three minutes.
Touch:
Display Shows:
1. Timer
3 0 0
2.
3. Timer
NOTE
There are not any other programs during the
kitchen timer
Microwave
Your Over the Range Microwave Oven can be programmed for 99 minutes and 99 seconds (99:99). Always
enter the seconds after the minutes, even if they are both zeroes.
• Suppose you want to cook for 2 minutes at 90% power.
Touch:
Display Shows:
1. Timer
2 0 0
2.
3. Power level x1
4. Power level x2
5. START
Enter / +30Sec
9
Page 13
POWER CHART
MANUAL COOKING
PRESS
POWER LEVEL x 1 or 1
POWER LEVEL x 2 or 9
POWER LEVEL x 3 or 8
POWER LEVEL x 4 or 7
POWER LEVEL x 5 or 6
POWER LEVEL x 6 or 5
POWER LEVEL x 7 or 4
POWER LEVEL x 8 or 3
POWER LEVEL x 9 or 2
POWER LEVEL x 10 or 1
POWER LEVEL x 11 or 0
POWER LEVEL
100%
90%
80%
70%
60%
50%
40%
30%
20%
10%
0%
DISPLAY
PL-HI
PL-90
PL-80
PL-70
PL-60
PL-50
PL-40
PL-30
PL-20
PL-10
PL-0
10
Page 14
MANUAL COOKING
Popcorn
Press “Popcorn” key and LED displays 3.3 oz. and the “PRESS AGAIN FOR OPTIONS” icon. You can press
“Popcorn” key again to select 3.0 oz.
• Suppose you want to cook 3.3 oz. popcorn.
Touch:
1. Popcorn
1. Popcorn X2
1. Popcorn X2
Press popcorn pad Amount
X1
X2
Display Shows:
Time Counting Down
(3 seconds later)
3.3 oz.
3.0 oz.
Potato
Touch:
1. Potato
Display Shows:
2. START / +30 SEC.
Veggies
Touch:
1. Veggies X1
Veggies X2
2. START / +30 SEC.
Time Counting Down
(3 seconds later)
Display Shows:
Time Counting Down
(at the threshold of humidity sensor)
11
Page 15
MANUAL COOKING
Melt / Soften
The oven uses low power to melt and soften items. See the following table.
• Suppose you want to melt 2 sticks of Butter.
Touch: Display Shows:
1. Melt / Soften X1
2. STRT / +30 SEC.
3.
4. START / +30 SEC. Time counting down
Press Melt Soften pad
X1 Melt Butter 1/2 stick
X2 Melt Chocolate 2/4/8 oz.
X3 Soften Ice Cream Pint / 1.5 Quart
X4 Soften Cream Cheese 3/8 oz.
2
(2 seconds later)
Food Amount
12
Page 16
MANUAL COOKING
Touch:
1. Auto cook
2. START / +30 SEC.
3. 2
4. START / +30 SEC. Time counting down
Press auto cook
X1
X2
Food
Scrambled eggs
Hot cereal
Display Shows:
(2 seconds later)
Amount
1-6 Eggs
1-3 Servings
X3
Frozen pizza
1(4oz)-3
13
Page 17
USER PREF
ONE TOUCH COOK
Key
USER PREF X1
USER PREF X2
USER PREF X3
USER PREF X4
Volume Low / Hi
Touch:
USER PREF X1
Setting
Volume Hi / Med / Low / Off
Weight lb/kg
Clock Display Off/On
Demo Mode
Display Shows:
Weight (lbs / kg)
In waiting state
Touch:
1. USER PREF X2
2. START / +30 SEC.
Clock Display Off / On
In waiting state
Touch:
1. USER PREF X3
2. START / +30 SEC.
Display Shows:
Display Shows:
14
Page 18
ONE TOUCH COOK
Child Lock
Touch:
1. STOP / CANCEL
2. STOP / CANCEL
Demo Setting
Touch:
1. STOP / CANCEL
2. STOP / CANCEL
Display Shows:
L O C K E D
(3 seconds later)
L O C K E D
(3 seconds later)
U N L O C K E D
(2 seconds later)
Display Shows:
D E M O
O F F
D E M O
O N
O F F
or
O N
15
Page 19
MAINTENANCE
Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the microwave
oven still does not work properly, contact the nearest authorized service center.
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Oven will not start.
Arcing or sparking
Unevenly cooked
foods
Overcooked foods
Undercooked
foods
A. Electric cord for oven is not
plugged in.
B. Door is open.
C. Wrong operation is set.
A. materials to be avoided in
microwave oven were used.
B. The oven is operated when empty.
C. Spilled food remains in the cavity.
A. Materials to be avoided in
microwave oven were used.
B. food is not defrosted completely.
C. Cooking time, power level is not
suitable.
D. Food is not turned or stirred.
Cooking time, Power level is not
suitable.
A. Materials to be avoided in
microwave oven were used.
B. Food is not defrosted completely
C. Oven ventilation ports are
restricted.
D. Cooking time, power level is not
suitable.
A. Plug into the outlet.
B. Close the door and try again.
C. Check instructions.
A. Use microwave-safe cookware only.
B. Do not operate with oven empty.
C. Clean cavity with wet towel.
A. Use microwave-safe cookware only.
B. Completely defrost food.
C. Use correct cooking time, power
level.
D. turn or stir food.
Use correct cooking time power
level.
A. Use microwave-sage cookware only.
B. Completely defrost food.
C. Check to see that oven ventilation
ports are
D. Use correct cooking time, power
level.
not restricted.
Improper
defrosting
A. Materials to be avoided in
microwave oven were used.
B. Cooking time, power level is not
suitable.
C. Food is not turned or stirred.
16
A. use microwave-safe cookware only.
B. Use correct cooking time, power
level.
C. Turn or stir food.
Page 20
WARRANTY
Warranty and Service
This product has been manufactured by Thor International, 4651 E Airport Drive, California 91761
For Customer Service, please call (877) 288 - 8099
For the most up to date warranty and service policy, please refer to our website
WWW.THORKITCHEN.COM/WARRANTY-REGISTRATION
For in-warranty service requests, please visit our website at
WWW.THORKITCHEN.COM/SERVICE
Please Note: You must provide proof of purchase or installation date for any in-warranty
service requests
17
Page 21
WELCOME
TO THE CLUB
You chose THOR Kitchen to enhance your culinary journey and
we’re stoked to have you in the club. Think of it as a secret
society of really savvy people, such as yourself, choosing
professional power and performance at an affordable price.
Register your product by following the steps below.
WARRANTY REGISTRATION
Scan theQR code or visit
thorkitchen.com/warranty
Input your product info
and select register
You’re done.
Let’s get cookin’.
Loading...
