TMD2402
24inch Built-In Microwave Drawer with Mirror finish glass
24INCH 1.2 CUFT
MICROWAVE DRAWER
TMD2402
TABLE OF CONTENTS
1 Safety Warnings
1.1
Precautions To Avoid Possible Exposure To Excessive Microwave Energy
1.2
Specifications
1.3
Important Safety Instructions
1.4
Grounding Instructions
1.5
Radio Interference
1.6
UTENSILS
2 Product Overview
2.1
SETTING UP YOUR OVEN
3 Operation Instructions
3.1
Control Panel and Features
3.2
Power On
Setting the Clock
3.3
3.4
Setting the Kitchen Timer
3.5
Microwave Cooking
3.6
Speedy Cooking
3.7
Defrost by Weight
3.8
Defrost by Time
Auto Menu--Beverage
3.9
3.10
Auto Menu--Popcorn
3.11
Auto Menu-Melt
3.12
Auto Menu--Soften
3.13
Silent mode
3.14
Lock Function for Children
3.15
Inquiring Function
3.16
OTHER SPECIFICATIONS
4 Troubleshooting
5 Warranty
1-3
3-4
10
10
10
10
10
11
12
1
1
4
4
6
7
7
7
8
8
8
9
9
9
9
9
1 SAFETY WARNINGS
1.1 PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
• Do not attempt to operate this oven with the door open since open door
operation can result in harmful exposure to microwave energy. It is important
not to defeat or tamper with the safety interlocks.
• Do not place any object between the oven front face and the door or allows
soil or cleaner residue to accumulate on sealing surfaces.
• Do not operate the oven if it is damaged. It is particularly important that the
oven door close properly and that there is no damage to the:
- DOOR (bent)
- HINGES AND LATCHES (broken or loosened)
- DOOR SEALS AND SEALING SURFACES
• The oven should not be adjusted or repaired by anyone except properly
qualied service personnel.
1.2 SPECIFICATIONS
Model: TMD2402
Rated Voltage 120 V~ 60 Hz
Microwave Input 1500 W
Microwave Output 1000 W
1.3 IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed,
including the following:
WARNING
To reduce the risk of burns, electric shock, re, injury to persons or exposure to
excessive microwave energy:
• Read all instructions before using the appliance.
• Read and follow the specic: "PRECAUTIONS TO AVOID POSSIBLE
• This appliance must be grounded. Connect only to properly grounded outlet.
1
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY" found on page 1.
See "GROUNDING INSTRUCTIONS" found on page 3.
1 SAFETY WARNINGS
• Install or locate this appliance only in accordance with the provided
installation instructions.
• Some products such as whole eggs and sealed containers - for example,
closed glass jars - are able to explode and should not be heated in this oven.
• Use this appliance only for its intended use as described in the manual. Do
not use corrosive chemicals or vapors in this appliance. This type of oven is
specically designed to heat, cook or dry food. It is not designed for industrial
or laboratory use.
• As with any appliance, close supervision is necessary when used by
children.
• Do not operate this appliance if it has a damaged cord or plug, if it is not
working properly, or if it has been damaged or dropped.
• This appliance should be serviced only by qualied service personnel.
Contact nearest authorized service facility for examination, repair, or
adjustment.
• Do not cover or block any openings on the appliance.
• Do not store this appliance outdoors. Do not use this product near water - for
example, near a kitchen sink, in a wet basement, near a swimming pool, or
similar location.
• Do not immerse cord or plug in water.
• Keep cord away from heated surface.
• Do not let cord hang over edge of table or counter.
• When cleaning surfaces of door and oven that comes together on closing the
door, use only mild, nonabrasive soaps, or detergent applied with a sponge
or soft cloth.
• To reduce the risk of re in the oven cavity:
- Do not overcook food. Carefully attend appliance when paper, plastic,
or other combustible materials are placed inside the oven to facilitate
cooking.
- Remove wire twist-ties from paper or plastic bag before placing bag in
oven.
- If mate disconnect the power cord, or shut o power at the fuse or circuit
breaker panel.
- Do not use the cavity for storage purposes. Do not leave paper products,
cookingrial inside of the oven ignite, keep oven door closed, turn oven o,
and utensils, or food in the cavity when not in use.
• Liquids, such as water, coee, or tea are able to be overheated beyond the
boiling point without appearing to be boiling. Visible bubbling or boiling when
the container is removed from the microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER
WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED
INTO THE LIQUID. To reduce the risk of injury to persons:
2
1 SAFETY WARNINGS
- Do not overheat the liquid.
- Stir the liquid both before and halfway through heating it.
- Do not use straight-sided containers with narrow necks.
- After heating, allow the container to stand in the microwave oven for a
short time before removing the container.
- Use extreme care when inserting a spoon or other utensil into the
container.
• Do not operate any heating or cooking appliance beneath the appliance.
(Exception: A microwave oven investigated for use above another heating
appliance.)
• Do not mount unit over or near any portion of heating or cooking appliance.
(Exception: A microwave oven investigated for use above another heating
appliance.)
• Do not mount over sink.
• Do not store anything directly on top of the appliance surface when the
appliance is in operation.
SAVE THESE INSTRUCTIONS
1.4 GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by providing an escape wire for the
electric current. This appliance is equipped with a cord having a grounding wire
with a grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded.
WARNING -
Consult a qualied electrician or serviceman if the grounding instructions are not
completely understood, or if doubt exists as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, use only a 3-wire extension
cord that has a 3-blade grounded plug, and 3-slot receptacle that will accept the
plug on the appliance. The marked rating of the extension cord shall be equal to
or greater than the electrical rating of the appliance.
DANGER -
Touching some of the internal components can cause serious personal injury or
death. Do not disassemble this appliance.
WARNING - Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug into an
outlet until appliance is properly installed and grounded.
3
Improper use of the grounding can result in a risk of electric shock.
Electric Shock Hazard
1 SAFETY WARNINGS
• A short power-supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
• Longer cord sets or extension cords are available and may be used if care is
exercised in their use.
• If a long cord or extension cord is used:
- The marked electrical rating of the cord set or extension cord should be at
least as great as the electrical rating of the appliance.
- The extension cord must be a grounding-type 3-wire cord.
- The longer cord should be arranged so that it will not drape over the
counter top or tabletop where it can be pulled on by children or tripped
over unintentionally.
1.5 RADIO INTERFERENCE
• Operation of the microwave oven may cause interference to your radio, TV
or similar equipment.
• When there is interference, it may be reduced or eliminated by taking the
following measures:
- Clean door and sealing surface of the oven
- Reorient the receiving antenna of radio or television.
- Relocate the microwave oven with respect to the receiver.
- Move the microwave oven away from the receiver.
- Plug the microwave oven into a dierent outlet so that microwave oven
and receiver are on dierent branch circuits.
This device complies with part 18 of the FCC Rules.
1.6 UTENSILS
CAUTION - Personal Injury Hazard
Tightly-closed utensils could explode. Closed containers should be opened and
plastic pouches should be pierced before cooking.
See the instructions on "Materials you can use in microwave oven or to be
avoided in microwave oven."
There may be certain non-metallic utensils that are not safe to use for
microwaving. If in doubt, you can test the utensil in question following the
procedure below.
Utensil Test:
• Fill a microwave-safe container with 1 cup of cold water (250ml) along with
the utensil in question.
• Cook on maximum power for 1 minute.
• Carefully feel the utensil. If the empty utensil is warm, do not use it for
microwave cooking.
• Do not exceed 1 minute cooking time.
4
1 SAFETY WARNINGS
Materials you can use in microwave oven
Utensils Remarks
Browning dish
Dinnerware
Glass jars
Glassware
Oven cooking bags
Paper plates and cups
Paper towels
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic
Plastic wrap
Follow manufacturer* instructions. The bottom of browning dish must be at
least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the
turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use cracked
or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars are
not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim. Do
not use cracked or chipped dishes.
Follow manufacturer* instructions. Do not close with metal tie. Make slits to
allow steam to escape.
Use for short*erm cooking/warming only. Do not leave oven unattended while
cooking.
Use to cover food for reheating and absorbing fat. Use with supervision for a
short-term cooking only.
Microwave-safe only. Follow the manufacturer* instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food inside
gets hot. "Boiling bags" and tightly closed plastic bags should be slit, pierced
or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain moisture. Do
not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam
Wood Wood will dry out when used in the microwave oven and may split or crack.
5
Plastic foam may melt or contaminate the liquid inside when exposed to high
temperature.
2 PRODUCT OVERVIEW
2.1 SETTING UP YOUR OVEN
NAMES OF OVEN PARTS AND ACCESSORIES
(In case of any differences between the appliance and the pictures in this manual, the product shall prevail.)
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
A
J
I
H
G
F
B
A) Control Patch
B) Control Box
C) Right Mounting Plate
D) Cavity
E)
F)
G
H)
I)
J)
C
D
Windows
Door Frame
Automatic putter
Drawer
Hinge Joint Board
Left Mounting Plate
E
Defrosting Rack( Only be used in defrosting function
and do not use for cooking. Do not use without food )
6
3 OPERATION INSTRUCTIONS
3.1 Control Panel and Features
(2)
(1)
(5)
(6)
(3)
(3)
(4) (9) (10)
(7)
(8)
(8)
(11) (12)
(1) Open
(2) Sound
(3) Auto Menu
(4) Weight Defrost
(5) Close
(6) Clock/Kitchen timer
(7) Ti me Defr ost
(8) Number k eys
(9) Power
(10) Start/ +30sec .
(11) Time Cook
(12) Stop/Cancel
3.2 Power On
1. When the microwave oven is plugged into an outlet, buzzer sounds once. Screen displays " WELCOME ". Then
the oven turns into standby mode. The screen displays "00:00".
2. In standby mode, the screen will display the current time if the clock has been set. Otherwise, "00:00" will display.
3. Press " OPEN " to open the drawer, and screen displays " OPEN ". The screen will display " PLEASE CLOSE "
when the drawer is fully opened.
Press " CLOSE " to close the drawer, and the screen displays " CLOSE ". The screen will display the current time
or "00:00" when the drawer is fully closed.
If there are mistakes to open or close the drawer, buzzer will sound five times, and the screen will display
" CLOSE OR OPEN ".
3.3 Setting the Clock
1. Press " CLOCK/KITCHEN TIMER " once. The first hour figure will flash and other "0" will light.
2. Press the number keys to enter the correct time. The input time should be between 01:00-12:59.
3. Press " CLOCK/KITCHEN TIMER " to confirm. The clock is set.
Notes:
1. In the process of clock setting, if the " STOP/CANCEL " is pressed or if there is no operation within 1 minute, the
setting is invalid.
2. To reset the clock, please repeat step 1 to step 3.
3. If the clock is not set,it would not work when powered.
7
3 OPERATION INSTRUCTIONS
3.4 Setting the Kitchen Timer
1. Press " CLOCK/KITCHEN TIMER " twice, "00:00"will display .
2. Press the number keys to enter the time. The maximum cooking time is "99:99".
3. Press " START/+30SEC. " to confirm. The timer starts counting down.
Notes:
1. The kitchen timer is differ from 12-hour system. Kitchen Timer is a timer.
2. Any other program can’t be set during kitchen timer.
3. " STOP/CANCEL " can be pressed to cancel the Kitchen Timer.
3.5 Microwave Cooking
11 power levels are available.
Level Power Display
10 100% PL100
9 90% PL90
8 80% PL80
7 70% PL70
6 60% PL60
5 50% PL50
4 40% PL40
3 30% PL30
2 20% PL20
1 10% PL10
0 0% PL 00
1. Press " TIME COOK " once, "00:00" will display.
Press number keys to enter the cooking time. The maximum cooking time is "99:99".
2. Press " POWER " and then press number keys to adjust the power level.
The 11 power levels are available
3. Press " START/+30SEC. " to start cooking.
Example: To cook the food with PL50 for 15 minutes.
- Press “ TIME COOK ” once.
- Press “1”, “5”, “0”, “0” in order.
- Press “ POWER ” and then press “5” to select PL50.
- Press “ START/+30SEC. ” to start cooking.
Notes:
In the process of setting, if the " STOP/CANCEL" is pressed or if there is no operation within 1 minute, the setting
is invalid.
3.6 Speedy Cooking
1. In standby mode, press “ START/+30SEC. ” to cook food with 100% power level for
30 seconds. Each press on the same key can increase 30 seconds.
2. During microwave cooking and defrosting by time, " START/+30SEC. " can be pressed to increase cooking time.
Each press will increase 30 seconds.
Note:
" START/+30SEC. " cannot be pressed to increase cooking time for defrost by weight and Auto menu.
8
3 OPERATION INSTRUCTIONS
3.7 Defrost by Weight
1. Press " DEFROST WEIGHT " once. " WEIGHT DEFROST " will display.
2. Press numeber keys to input the weight of the food. The input weight should be between 0.1-6.0 lbs.
3. Press " START/+30SEC. " to start defrosting.
4. Once defrosting has finished, the buzzer will sound five times and “ FINISH ” will display.
Note:
The buzzer will sound to remind you to turn the food over during defrosting.
If no operation, the oven will continue working.
3.8 Defrost by Time
1. Press " DEFROST TIME " once, “ TIME DEFROST ” will display.
2. Press number keys to set the desired defrost time. The maximum time value is “99:99”.
3. Press " START/+30SEC. " to start defrosting.
4. Once defrosting has finished, the buzzer will sound five times and “ FINISH ” will display.
Note:
The defrost power is P30.
3.9 Auto Menu--Beverage
1. Press " BEVERAGE " once. The screen displays "1". " AUTO MENU " and " " indicators will light.
2. Continue to press " BEVERAGE ", "1" or "2" will display in order.
3. Press " START/+30SEC. " to start cooking. Buzzer sounds once. The cooking time starts counting down. Once
cooking has finished, buzzer sounds five times and "FINISH" displays.
3.10 Auto Menu--Popcorn
1. Press " POPCORN " once. The screen displays "1.75". " AUTO MENU " and "OZ" indicators will light.
2. Continue to press " POPCORN ", "1.75", "3" or "3.5" will display in order.
3. Press " START/+30SEC. " to start cooking. Buzzer sounds once. The cooking time starts counting down. Once
cooking has finished, buzzer sounds five times and " FINISH " displays.
3.11 Auto Menu-Melt
1. Press " MELT " once. The screen displays " BUTTER ". " AUTO MENU " indicator will light.
2. Continue to press " MELT " , " BUTTER ", " CHOCOLA ", " CHEESE " or " MARSHMA " will display in order.
3. Press " START/+30SEC. " to confirm the selection.
4. Press " MELT " to select the weight. "OZ" will light except butter menu.
5. Press " START/+30SEC. " to start cooking. Buzzer sounds once. "OZ" will go out. The cooking time starts counting
down. Once cooking has finished, buzzer sounds five times and " FINISH " displays.
Menu Display Weight
1(STICH)
Butter/Margarine BUTTER
Chocolate CHOCOLA
Cheese CHEESE
Marshmallows MARSHMA
9
2(STICHS)
3(STICHS)
4
8
8
16
5
10
3 OPERATION INSTRUCTIONS
3.12 Auto Menu--Soften
1. Press " SOFTEN " once. The screen displays " BUTTER ". " AUTO MENU " indicator will light.
2. Continue to press " SOFTEN ", " BUTTER ", " ICE-CRE " or " CHEESE " will display in order.
3. Press " START/+30SEC. " to confirm the selection.
4. Press " SOFTEN "to select the weight. "OZ" will light except butter menu.
5. Press " START/+30SEC. " to start cooking. Buzzer sounds once. "OZ" will go out. The cooking time starts counting
down. Once cooking has finished, buzzer sounds five times and " FINISH " displays.
Menu Display Weight
1(STICH)
Butter BUTTER
Ice cream/ Frozen juice ICE-CRE
Cream Cheese CHEESE
3.13 Silent mode
To activate the silent mode:
1. Press " SOUND " once, the screen displays " BUZ OFF ".
2. Press " START/+30SEC. " . The oven will turn to standby mode. Buzzer is turned off.
No beep will sound.
To deactivate the silent mode:
1. Press " SOUN D " once, the screen displays " BUZ ON ".
2. Press " START/+30SEC. ". The oven will turn to stanby mode. Buzzer is turned on.
Buzzer will sound normally.
2(STICHS)
3(STICHS)
8
16
32
3
8
3.14 Lock Function for Children
You can use this function to prevent children from accidentally turning the oven on. To activate the lock:
In standby mode, press and hold “ STOP/CANCEL ” for three seconds. A beep sounds and the locked icon will display.
To deactivate the lock:
In locked state, press and hold “ STOP/CANCEL ” for three seconds. A beep sounds. Note: The lock function for
children cannot be set when the oven door has opened.
3.15 Inquiring Function
1. If the clock has been set, the current time will display for three seconds by pressing “ CLOCK/KITCHEN TIMER ”
in the cooking state.
2. In the microwave cooking state, press “ POWER ” to inquire the power level.
It will display for three seconds. In defrosting state and auto menu, the power level cannot be inquired.
3.16 OTHER SPECIFICATIONS
1. The buzzer sounds once by efficient press, inefficient press will be no responce.
2. In cooking state, " OPEN " cannot be pressed to open the drawer unless " STOP/CANCEL " is pressed to pause
the cooking. Press " CLOSE " to close the drawer. Then " START/+30SEC. " must be pressed to continue cooking.
3. If the cooking programme has been set , " START/+30SEC. " is not pressed within 1 minute, The setting is invalid.
4. If the oven door is open, the lamp will light until the oven is powered off.
10
4 TROUBLESHOOTING 115 WARRANTY
5.1 Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does
not work properly, contact the nearest authorized service center.
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Oven will not start
Arcing or sparking
Unevenly cooked
foods
Overcooked foods
Undercooked foods
Improper defrosting
• Electrical cord for oven is not
plugged in.
• Door is open.
• Wrong operation is set.
• Materials to be avoided in microwave
oven were used.
• The oven is operated when empty.
• Spilled food remains in the cavity.
• Materials to be avoided in microwave
oven were used.
• Food is not defrosted completely.
• Cooking time, power level is not
suitable.
• Food is not turned or stirred.
• Cooking time, power level is not
suitable.
• Materials to be avoided in microwave
oven were used.
• Food is not defrosted completely.
• Oven ventilation ports are restricted.
• Cooking time, power level is not
suitable.
• Materials to be avoided in microwave
oven were used.
• Cooking time, power level is not
suitable.
• Food is not turned or stirred.
• Plug into the outlet.
• Close the door and try again.
• Check instructions.
• Use microwave-safe cookware only.
• Do not operate with oven empty.
• Clean cavity with wet towel.
• Use microwave-safe cookware only.
• Completely defrost food.
• Use correct cooking time, power level.
• Turn or stir food.
• Use correct cooking time, power level.
• Use microwave-safe cookware only.
• Completely defrost food.
• Check to see that oven ventilation ports
are not restricted.
• Use correct cooking time, power level.
• Use microwave-safe cookware only.
• Use correct cooking time, power level.
• Turn or stir food.
Warranty&Service
This product has been manufactured by Thor International,
For Customer Service, please call (877) 288 - 8099
For the most up to date warranty and service policy, please refer to our website
WWW.THORKITCHEN.COM/WARRANTY-REGISTRATION
For in-warranty service requests, please visit our website at
WWW.THORKITCHEN.COM/SERVICE
Please Note: You must provide proof of purchase or installation date for any inwarranty service requests
4651 E Airport Dr, Ontario, CA 91761
12
WARRANTY REGISTRATION
Scan theQR code or visit
thorkitchen.com/warranty
Input your product info
and select register
You ’r e do ne .
Let’s get cookin’.
You chose THOR Kitchen to enhance your culinary journey and
we’re stoked to have you in the club. Think of it as a secret
society of really savvy people, such as yourself, choosing
professional power and performance at an affordable price.
Register your product by following the steps below.
WELCOME
TO THE CLUB
For additional information and product support, visit thorkitchen.com/service
Loading...
