THOMSON PDP2648-SOFTWARE, PDP2648, PDP2656, PDP2662 User Manual

EN

PDP2648 Software IB EN 3/15/05 10:41 AM Page 1

PDP2648
PDP2656
PDP2662

Software Installation

MusicMatch JukeboxTMSoftware

(mp3, Windows MediaTMAudio)

Installation des software

Logiciel MusicMatch Jukebox

TM

(mp3, Windows MediaTMAudio)

Instalación de logiciel

Software MusicMatch Jukebox

TM

(mp3, Reproductor de Audio

para Windows MediaTM)

It is important to read this instruction book prior to using your new product for the first time.
Es importante leer este manual antes de usar por vez primera su euipo.

user

manual

THOMSON
46, quai Alphonse Le Gallo
92648 Boulogne
Cedex FRANCE
www.thomson.net

56038410

PDP2648 Software IB EN 3/15/05 10:41 AM Page 2

EN

EN

End User License Agreement End User License Agreement

IMPORTANT-READ CAREFULLY: This
End User License Agreement
("Agreement") is a legal agreement
between you and Thomson Inc.
("Thomson") for the Thomson Lyra
device application/driver software
program and associated
documentation, if any ("Program").

ACKNOWLEDGMENT

BY INSTALLING THE SOFTWARE OR
CLICKING ON THE ACCEPTANCE BUTTON
OF THE SOFTWARE, COPYING OR
OTHERWISE USING THE PROGRAM, YOU
ACKNOWLEDGE AND AGREE THAT YOU
HAVE READ THIS AGREEMENT,
UNDERSTAND IT, AND AGREE TO BE
BOUND BY ITS TERMS AND CONDITIONS.
IF YOU DO NOT AGREE TO THE TERMS OF
THIS LICENSE AGREEMENT, CLICK ON THE
REJECTION BUTTON AND/OR DO NOT
INSTALL THE SOFTWARE AND/OR DO NOT
USE THE PROGRAM.

LICENSE

a) You are granted the license (i) to use
the Program on a single workstation and
(ii) to make one (1) copy of the Program
into any machine-readable form for
backup of the Program, provided the
copy contains all of the original
Program's proprietary notices.

b) You may transfer the Program and
license, only as part of the Thomson Lyra
device, to another party if the other party
agrees to accept the terms and conditions
of this Agreement. If you transfer the
Program, you must at the same time
either transfer all copies to the same
party or destroy any copies not
transferred.

LICENSE RESTRICTIONS

a) Except for the licenses expressly
granted to you in this Agreement, no
other licenses are implied.

b) You may not (i) modify, translate,
reverse engineer, decompile, disassemble
(except to the extent that this restriction
is expressly prohibited by law) or create
derivative works based upon the Program
or (ii) copy the Program, except as
expressly permitted herein. You agree
that you shall only use the Program in a
manner that complies with all applicable
laws in the jurisdictions in which you use
the Program, including, but not limited
to, applicable restrictions concerning
copyright and other intellectual property
rights.

c) The Program may contain pre-release
code that does not perform at the level of
a final code release. In this case, the
Program may not operate properly.
Updated versions of the Program can be
downloaded from
www.thomson-lyra.com.

d) Thomson is not obligated to provide
support services for the Program.

e) The Program is provided with
"RESTRICTED RIGHTS". Use, duplication,
or disclosure by the U.S. Government is
subject to restrictions as set forth in
subparagraph (c)(1)(ii) of DFARS 252.227­7013, or FAR 52.227-19, or in FAR 52.227­14 Alt. III, as applicable.

TERM AND TERMINATION

a) The license is effective on the date you
accept this Agreement, and remains in
effect until terminated by either party.

b) You may terminate this license without
any notice or delay, by destroying or
permanently erasing the Program and all
copies thereof.

c) If you use, copy, modify, or transfer the
Program, or any copy, in whole or part,
except as expressly provided for in this
license, your license is automatically
terminated.

d) When the license is terminated, you
must destroy or permanently erase the
Program and all copies thereof.

PDP2648 Software IB EN 3/15/05 10:41 AM Page 4

EN

EN

End User License Agreement

End User License Agreement

WARRANTY DISCLAIMER

THE PROGRAM IS PROVIDED "AS IS"
WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESSED OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, TITLE OR NON­INFRINGEMENT. THE ENTIRE RISK AS TO
THE QUALITY AND PERFORMANCE OF
THE PROGRAM IS WITH YOU. SHOULD
THE PROGRAM PROVE DEFECTIVE, YOU
(AND NOT THOMSON, ITS SUPPLIERS, ITS
AFFILIATES OR ITS DEALERS) ASSUME THE
ENTIRE COST FOR ALL NECESSARY REPAIR
OR CORRECTION.

This exclusion of warranty may not be
allowed under some applicable laws. As a
result, the above exclusion may not apply
to you, and you may have other rights
depending on the law that applies to you.

OWNERSHIP RIGHTS

All title and intellectual property rights in
and to the Program and any copies
thereof are owned by Thomson or its
suppliers. All title and intellectual
property rights in and to the content
which may be accessed through use of
the Program is the property of the
respective content owner and may be
protected by applicable copyright or
other intellectual property laws and
treaties. This license grants you no rights
to use such content.

LIMITATION OF LIABILITY

a) TO THE MAXIMUM EXTENT PERMITTED
BY APPLICABLE LAW, IN NO EVENT SHALL
THOMSON, ITS AFFILIATES, OR ITS
DEALERS BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT OR
CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING, WITHOUT
LIMITATION, DAMAGES FOR LOSS OF
PROFITS, BUSINESS INTERRUPTION,
CORRUPTION OF FILES, LOSS OF BUSINESS
INFORMATION OR ANY OTHER
PECUNIARY LOSS) REGARDLESS OF CAUSE
OR FORM OF ACTION, INCLUDING
CONTRACT, TORT OR NEGLIGENCE,
ARISING OUT OF THE USE OF OR
INABILITY TO USE THE PROGRAM, EVEN
IF THOMSON HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
BECAUSE SOME STATES AND
JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF LIABILITY
OF CONSEQUENTIAL OR INCIDENTAL
DAMAGES, THE ABOVE LIMITATION MAY
NOT APPLY TO YOU.

b) YOU ASSUME RESPONSIBILITY FOR THE
SELECTION OF THE APPROPRIATE
PROGRAM TO ACHIEVE YOUR INTENDED
RESULTS, AND FOR THE INSTALLATION,
USE, AND RESULTS OBTAINED.

WINDOWS MEDIA

This version of the Lyra Personal Digital
Player ("Lyra Player") contains software
licensed from Microsoft that enables you
to play Windows Media Audio (WMA)
files ("WMA Software"). The WMA
Software is licensed to you for use with
the RCA/THOMSON Portable Audio
Device digital music player under the
following conditions. By installing and
using this version of the Lyra Player, you
are agreeing to these conditions. IF YOU
DO NOT AGREE TO THE CONDITIONS OF
THIS END USER LICENSE AGREEMENT, DO
NOT INSTALL OR USE THIS VERSION OF
THE Lyra Player.

PDP2648 Software IB EN 3/15/05 10:41 AM Page 6

EN

EN

End User License Agreement

End User License Agreement

The WMA Software is protected by
copyright and other intellectual property
laws. This protection also extends to
documentation for the WMA Software,
whether in written or electronic form.

GRANT OF LICENSE. The WMA Software is
only licensed to you as follows:
You may use this version of the Lyra
Player containing the WMA Software
only with the Portable Audio Device
player.

You may not reverse engineer, decompile,
or disassemble the WMA Software,
except and only to the extent that such
activity is expressly permitted by
applicable law in spite of this limitation.

You may transfer your right to use this
version of the Lyra Player only as part of a
sale or transfer of your Portable Audio
Device player, on the condition that the
recipient agrees to the conditions in this
End User License Agreement. If the
version of the Lyra Player that you are
transferring is an upgrade, you must also
transfer all prior versions of the Lyra
Player that you have which include the
WMA Software.

MICROSOFT IS NOT PROVIDING ANY
WARRANTY OF ANY KIND TO YOU FOR
THE WMA SOFTWARE, AND MICROSOFT
MAKES NO REPRESENTATION
CONCERNING THE OPERABILITY OF THE
WMA SOFTWARE.

The WMA Software is of U.S. origin. Any
export of this version of the Lyra Player
must comply with all applicable
international and national laws, including
the U.S. Export Administration
Regulations, that apply to the WMA
Software incorporated in the Lyra Player.

THIRD PARTY SOFTWARE

ANY THIRD PARTY SOFTWARE THAT MAY
BE PROVIDED WITH THE PROGRAM IS
INCLUDED FOR USE AT YOUR OPTION. IF
YOU CHOOSE TO USE SUCH THIRD PARTY
SOFTWARE, THEN SUCH USE SHALL BE
GOVERNED BY SUCH THIRD PARTY'S
LICENSE AGREEMENT, AN ELECTRONIC
COPY OF WHICH WILL BE INSTALLED IN
THE APPROPRIATE FOLDER ON YOUR
COMPUTER UPON INSTALLATION OF THE
SOFTWARE. THOMSON IS NOT
RESPONSIBLE FOR ANY THIRD PARTY'S
SOFTWARE AND SHALL HAVE NO
LIABILITY FOR YOUR USE OF THIRD
PARTY SOFTWARE.

GOVERNING LAW

This Agreement is governed by the laws
of France, without regard to its conflict of
laws.

GENERAL TERMS

This Agreement can only be modified by
a written agreement signed by you and
Thomson, and changes from the terms
and conditions of this Agreement made
in any other manner will be of no effect.
If any portion of this Agreement shall be
held invalid, illegal, or unenforceable, the
validity, legality, and enforceability of the
remainder of the Agreement shall not in
any way be affected or impaired thereby.
This Agreement is the complete and
exclusive statement of the agreement
between you and Thomson, which
supersedes all proposals or prior
agreements, oral or written, and all other
communications between you and
Thomson, relating to the subject matter
of this Agreement.

PDP2648 Software IB EN 3/15/05 10:41 AM Page 8

EN

EN

Before You Begin

Table of Contents

End User License Agreement

Table of Contents

Before You Begin . . . . . . . . . . .1

Computer System Requirements . . .1
What’s so special about this mp3

player? . . . . . . . . . . . . . . . . . . . . . . . .2

Getting Started . . . . . . . . . . . .3

Insert the Included CD-ROM into

CD-ROM Drive . . . . . . . . . . . . . . . . . .3

Welcome Screen . . . . . . . . . . . . . .3

Purchased Location . . . . . . . . . . .3

Install the USB Driver (Windows

98SE and Me Only) . . . . . . . . . . . .4

Install Necessary Software . . . . . .4

End User License Agreement . . .5

Install MusicMatch Jukebox . . . .5

Install Additional Services . . . . . .6

Audible Welcome . . . . . . . . . . . . .6

Rebooting the Computer . . . . . .6

Installation Completed . . . . . . . .6

Launch the MusicMatch Software . .7

Transferring Music . . . . . . . . . .7

Connecting the Player to the

Computer . . . . . . . . . . . . . . . . . . . . . .7

Transferring Files to the Lyra

Digital Audio Player . . . . . . . . . . . . .8

Transfer Files via MusicMatch

Jukebox . . . . . . . . . . . . . . . . . . . . . . . .9

Transfer Files via Windows Explorer

(Drag and Drop) . . . . . . . . . . . . . . .10

Disconnecting Your Lyra from

the Computer . . . . . . . . . . . . . . . . . .11

File Management . . . . . . . . . .12

System Tray Applications . . . . . . . .12

Profile . . . . . . . . . . . . . . . . . . . . .12

Troubleshooting Tips . . . . . . .13

Dear Thomson Customer,

Thank you for purchasing the
Thomson Lyra™ Digital Audio Player.
This product will play open mp3 and
Windows Media™ audio (WMA)
content as well as content purchased
from most online music download
services.

After purchasing and downloading
music to your PC, you are now ready
to move content to your player. To
transfer the music, you must use
Windows Media Player or the
application recommended by the
online music download service.

(Note: Services and applications
must be Windows Media audio­compliant and support Digital Rights
Management.)

Computer System
Requirements

• Pentium III 500MHz or higher
recommended
Macintosh iMac G3 or higher

• Windows® 98SE, Me, 2000, or XP
Mac OS X Version 10.1.5 or higher

• Internet Explorer 4.0 or higher

• Internet access

• 100MB free hard disk space for the
software

• 64MB RAM (128 MB recommended)

• CD-ROM drive capable of digital audio
extraction

• USB port (2.0 recommended)

• Sound card

The descriptions and characteristics given in this document are given as a general indication and not as a guarantee. In
order to provide the highest quality product possible, we reserve the right to make any improvement or modification
without prior notice. The English version serves as the final reference on all products and operational details should
any discrepancies arise in other languages.

Warning:

Use of this product is for your
personal use only. Unauthorized
recording or duplication of
copyrighted material may infringe
upon the rights of third parties and
may be contrary to copyright laws.

!

1

Note

Make sure the tracks are encoded in
mp3 or Windows Media formats and
supported bitrates.
Bitrates supported by the player:
mp3 – 32 to 320 kbps
wma – 48 to 192 kbps

PDP2648 Software IB EN 3/15/05 10:41 AM Page 10

EN

EN

Before You Begin

What’s so special about
this mp3 player?

This player is meant to play mp3,
audible and Windows Media

TM

audio
files encoded on a memory card or
recorded in the built-in flash memory.
To do so, you need the use of a
Windows computer with USB port ,
connection cable (included) and a music
management software (MusicMatch
Jukebox).

The Music Management CD that comes
with your Lyra Digital Audio Player
contains all of the necessary software
components you need to make your
Lyra Digital Audio Player work properly.

These components do the following:

• install USB driver for Windows

98SE/Me users. (Refer to page 4)

• enable you to transfer files from your

computer to your Lyra Digital Audio
Player.

•profile the player (Refer to
page 12).

•use the MusicMatch Jukebox
software to organize your music
collection and transfer the music to
your Lyra Digital Audio Player.

The MusicMatch Jukebox™ software
compresses audio files (from music CDs)
to the mp3, mp3PRO or Windows Media
Audio (WMA) format so you can play
them on your Lyra Digital Audio Player.
The MusicMatch software also enables
you to download files from the internet
that are already compressed and then
transfer those files to your Lyra player
(or play the music on your computer).

2

Getting Started

Insert the Included
CD-ROM into CD-ROM
Drive

Turn on your computer and place the
Music Management CD that came with
your Lyra Digital Audio Player into your
computer.

Welcome Screen

If the setup screen does not appear,
double click My Computer, double click
your CD-ROM drive icon, and double
click Install to run the installer.

3

Note

Don’t connect the USB cable to the
PC or Lyra Digital Audio Player
before or during the driver
installation.

Note

•If you’re running Windows
2000/XP no additional drivers
are required.

• If you’re running Windows
98SE/Me, you must install the
USB drivers from the CD-ROM in
order for the Lyra Digital Audio
Player to function properly.

PDP2648 Software IB EN 3/15/05 10:41 AM Page 12

EN

EN

4

Getting Started

Install Necessary Software

Click Install, and follow the on-screen
instructions to install all necessary files.

End User License Agreement

Please read the End User License
Agreement carefully, you can quit the
installation anytime if you do not agree
with it.
Click Accept to continue installation.

Install MusicMatch Jukebox

MusicMatch Jukebox is a music
management software used to organize
and manage digital audio files and can
be used to transfer the music to your
Lyra Digital Audio Player.

1. Click Install to run the MusicMatch
setup program.

Wait while the installation program
begins. It may take up to 20 seconds
for the installer to start.

2. Follow the on-screen instructions to
setup and install MusicMatch Jukebox.

For more information on MusicMatch
Jukebox, click Tutorials on the CD or go
to www

.musicmatch.com.

5

Getting Started

Preferred Language

Select your preferred language, then click
Next to continue.

Install the USB Driver
(Windows 98SE and Me Only)

For Windows 98SE and Me systems, you
need to install a USB driver before your
computer can recognize your Lyra player.

Note

It is recommended to uninstall

any previous installations of
the MusicMatch Jukebox software
before proceeding.
After the uninstall process has been
completed, delete the MusicMatch
folder found under C:\Program Files.

Note

The installation program will
detect whether your system
requires a USB driver. The program
will install the USB driver first,
restart the computer, and then
begin to install the necessary
software.

PDP2648 Software IB EN 3/15/05 10:41 AM Page 14

Connecting the Player to
the Computer

Connect the Lyra Digital Audio Player to
your computer with the USB cable
provided.

Turn on the unit , the Lyra Digital Audio
Player will appear as a Removable Disk
drive.

EN

EN

6

Getting Started

Launch the MusicMatch
software

The MusicMatch software converts audio
files to the mp3, mp3PRO and WMA
formats so you can play them on your
Lyra Digital Audio Player.

1. Remove the Music Management CD
from your computer.

2. Start the MusicMatch Jukebox
software (double click on the
MusicMatch icon in your system
tray or on your desktop).

Getting Started

7

Audible welcome

Click for additional information about
audible.

Install Additional Services

Click for additional digital music services
provided by our partners.

Rebooting the computer

You may need to restart your computern
for software to run properly.

Installation completed

Installation is completed! You can go to
the manufacturer’s website for more
information.

The MusicMatch icon found in
your computer’s system tray.

Note

It might take several seconds for
the device (the Lyra Digital Audio
Player) to be detected, especially in
Windows 2000/XP. Click Refresh in
My Computer or Explorer to make
sure the device has been detected.

The Player

Transferring Music

PDP2648 Software IB EN 3/15/05 10:41 AM Page 16

EN

EN

8

Transferring Music

Transfer Files via
MusicMatch Jukebox

1. Drag and drop desired tracks from the
Music Library to the Playlist display
and save the playlist.

2. From the menu area, select Files/Send

to Portable Device or click Send to
Portable under the copy item on the

left side of the MusicMatch Jukebox
screen to display the Portable
Device Manager screen.

3. Click on Options and select your
portable device under Select Device.
Click OK.
Your device should be listed under
Portable Device.

4. Select the playlist item and drag it to
the active device listed under Portable
Device. Only those playlists saved in
step 1 are displayed on the playlist
window.
The songs in the playlist will now be
automatically transferred to your Lyra
Digital Audio Player.

During transfer a progress indicator
appears in the Portable Device Manager
screen, and "USB Transferring" flashes in
the Lyra player’s LCD.

Transferring Music

9

Transferring Files to the
Lyra Digital Audio Player

You can transfer files to your Lyra Digital
Audio Player via MusicMatch Jukebox or
via Windows Explorer.

If your Lyra Digital Audio Player isn’t
already connected to your computer,
connect it to the computer using the
provided USB cable as illustrated on the
previous page.

Attention

Do not disconnect the USB
cable or remove the memory card
during music download. Doing so may
corrupt system files or the files
being downloaded.

Note

The Lyra Digital Audio
Player is capable of transferring
files at hi-speed mode of USB 2.0.
This is up to 40 times faster than
USB 1.1. If USB 2.0 port is available
on your computer, use it to connect
to your Lyra Digital Audio Player.
The Lyra player is still backward
compatible with the older USB 1.1
ports. However, you will not be able
to take full advantage of the
potential speed increase.

Note

Be sure to save the playlist

or it will not be displayed on
the playlist window of the Portable
Device Manager screen.

Note

Some wma files may be DRM
protected. You must acquire
licenses for DRM protected wma
files before they can be played on
the Lyra player.
For more information, go to
www.microsoft.com/windows/
windowsmedia/drm

Note

Secure music download
files must be transferred to your
Lyra player through Windows Media
Player or the application
recommended by the online music
download service. Please visit the
online music download service’s
website where you purchased your
content from for more details on
transferring secure music to your
player.

For more information on Windows
Media Player, visit
http://www.microsoft.com/windows/
windowsmedia.

PDP2648 Software IB EN 3/15/05 10:41 AM Page 18

EN

11

Transferring Music

Disconnecting Your Lyra
from the Computer

From the System Tray, double click the
left mouse button on the icon and select

Unplug or eject hardware. The Unplug or
Eject Hardware screen appears. Select the

drive corresponding to your Lyra player.

The Stop a Hardware device screen
appears. Select the device to be stopped
again for confirmation and click OK.

You can also stop your Lyra player by
right clicking on the icon from the
system tray and selecting the drive
corresponding to your player.

Note

Before disconnecting the USB cable
from the computer or the Lyra
Digital Audio Player, be sure the
"Safe to unplug" message is
displayed.

EN

10

Transferring Music

Transfer Files via Windows
Explorer (Drag and Drop)

If your Lyra Digital Audio Player isn’t
already connected to your computer,
connect the Lyra Digital Audio Player to
the computer using the provided USB
cable as illustrated on page 7 and turn on
the unit.

From Windows Explorer, highlight all the
files/folders you want to transfer to your
Lyra Digital Audio Player and drag them
to the drive letter that is associated with
it.

Note

If you’re running Windows

2000 you must stop the
device before unplugging it. Click
the icon (the

Unplug or Eject

hardware

icon) from the system
tray and select the USB Mass
Storage device for the drive letter
associated with the Lyra player, and
select the device you want to stop.
See the Windows Help for details
about the Unplug or Eject Hardware
topic.

Note

You must profile your
contents after file transfer in order
for the new files to appear in the
Navigation Menus. Refer to page 12
for profiling details.

Attention

Make sure all data are

transferred to the Lyra
Digital Audio Player before
unplugging the USB cable.

PDP2648 Software IB EN 3/15/05 10:41 AM Page 20

EN

EN

File Management

System Tray Applications

Profile

New files that are transferred to your Lyra
Digital Audio Player using Windows
Explorer (drag and drop) will not appear
in the Navigation Menus until you profile
the contents. If MusicMatch Jukebox was
used to transfer files, profiling may be
done automatically.

1. Connect your Lyra Digital Audio Player
to the computer using the provided
USB cable if it is not already
connected.

2. Right click on the Lyra icon in the
System tray (bottom right hand corner
of the computer screen.

3. Select the Profile Device Content...
item to start the profiling and sorting
contents.

4. Click Done when profiling is complete.

12

Attention

Make sure all data are transferred
to the Lyra Digital Audio Player
before unplugging the USB cable.

If you’re running Windows 2000 you
must stop the device before
unplugging it. Click the icon (the

Unplug or Eject hardware

icon) from
the system tray and select the USB
Mass Storage device for the drive
letter associated with the Lyra
Digital Audio Player, and select the
device you want to stop. See the
Windows Help for details about the

Unplug or Eject Hardware

topic.

Troubleshooting Tips

13

Problem

After connecting the player to computer, "USB
connected" does not appear on the display.

Cannot access the player via Windows 2000
computer.

Cannot playback tracks on the player.

What does the PlaysForSure logo mean?

Checkpoints / Action

•Press ON button to power on the
player after connecting to the
computer.

• Install the Service Pack 3 for
Windows 2000.
Visit
www

.windowsupdate.microsoft.com

to check for the latest updates.

•Make sure audio tracks are encoded
in the mp3 or Windows Media
formats at supported bitrates.
Bitrates support by the player:
mp3 – 32 to 320 kbps
wma – 48 to 192 kbps

• WMA files may be DRM protected
and you don’t have the proper rights
(license) to play the files.

Check the website and/or application help
system of the music download service provider
from where the content was purchased from
for license acquisition details.

For more information on how license
acquisition works, go to
www

.microsoft.com/windowsmedia/drm

PlaysForSure is a new logo program from
Microsoft®. Consumers can match the
PlaysForSure logo on a large selection of
devices and online music stores. If you see the
logo, you’ll know your digital media will play
for sure.

For more information on the Microsoft
PlaysForSure program, visit
www

.PlaysForSure.com.

For more information on RCA PlaysForSure
devices, visit www

.rca.com.

PDP2648 Software IB EN 3/15/05 10:41 AM Page 22
