Thomson 2-5838A Users Manual
5. Use the touch-tone pad on the handset to enter the name (up to 15 characters) and
press the MEM button to save. More than one letter is stored in each of the number
keys. For example, to enter the name Bill Smith, press the 2 key twice for the letter B.
Press the 4 key 3 times for the letter I. Press the 5 key 3 times for the letter L. Wait for
one second. Press the 5 key 3 times for the second letter L. Press the 1 key to insert a
space between the L and the S. Press the 7 key 4 times for the letter S; press the 6 key
once for the letter M; press the 4 key 3 times for the letter I; press the 8 key for the
letter T; press the 4 key twice for the letter H.
6. Press the MEM button to save the name. The display shows
7. Use the touch-tone pad to enter the telephone number you want to store (up to
24 digits).
8. Press MEM again to store the number. You will hear a confirmation tone.
NOTE: If you make a mistake press the DEL/CHAN button to backspace and
erase the wrong character(s) or number(s).
ENTER TEL NUMBR
.
CHANGING A STORED NUMBER
1. Repeat steps 1 through 7 in Storing a Name and Number in Memory.
2. Press the MEM button, and
3. Press the MEM button to store the number. You will hear a confirmation tone.
REPLACE MEMO?
shows in the display.
CHAIN DIALING FROM MEMORY
Use this feature to make calls which require a sequence of numbers, such as calling
card calls to a frequently called long distance number. Each part of the sequence is
dialed from memory. The following example shows you how to use chain dialing to
make a call through a long distance service:
The Number For Memory Location
Long distance access number 7
Authorization code 8
Frequently called long distance number 9
1. Make sure the phone is ON (in TALK mode).
2. Press MEM and then press 7.
3. When you hear the access tone, press MEM and then press 8.
4. At the next access tone, press MEM and then 9.
TIP: Wait for the access tones before pressing the next memory button, or your
call might not go through.
HEADSET AND BELT CLIP OPERATION
STORING A REDIAL NUMBER
1. Repeat steps 1 through 6 in Storing a Name and Number in Memory.
2. Press the REDIAL button.
3. Press the MEM button to store the number. You will hear a confirmation tone.
To replace an old number with a new redial number:
1. Repeat steps 1 through 6 in Storing a Name and Number in Memory.
2. Press the REDIAL button.
3. Press the MEM button, and
4. Press the MEM button again to replace the old number with the new number. You
will hear a confirmation tone.
NOTE: The stored redial number is limited to 24 digits or less.
REPLACE MEMO?
shows in the display.
DIALING A STORED NUMBER
1. Make sure the phone is ON by pressing the TALK/END/CALLBACK button.
2. Press the MEM button.
3. Press the memory location (0-9). The number dials automatically.
- OR -
1. Make sure the phone is OFF (not in TALK mode).
2. Press the MEM button.
3. Use the touch-tone pad or the CALLER ID/VOL (- or +) button to scroll to the
number you want to dial.
4. Press TALK/END/CALLBACK. The number dials automatically.
INSERTING A PAUSE IN THE DIALING SEQUENCE OF A
STORED NUMBER
If a pause is needed to wait for a dial or access tone, press the #PAUSE button to
insert a delay in dialing sequence of a stored number (for example, after you dial 9
for an outside line, or to wait for a computer access tone.) pause shows in the
display as a P, and each pause counts as one digit in the dialing sequence.
REVIEWING AND DELETING STORED NUMBERS
1. To review stored numbers, press the MEM button, and use the CALLER ID/VOL (- or
+) button to scroll to the memory location, or press the corresponding number key for
a desired memory location (0-9).
2. When the data shows in the display, press the DEL/CHAN button. The display
shows
DELETE?
3. Press DEL/CHAN again to delete the data. The display shows
DELETED
.
CONNECTING AN OPTIONAL HEADSET TO THE HANDSET
For hands free operation:
1. Remove the rubber cap covering the
headset jack.
2. Connect the headset to the headset jack on
the handset. The handset receiver is disabled
when the headset is connected.
3. Adjust the headset to rest comfortably on top
of your head and over your ear. Move the
microphone to approximately two to three
inches from your mouth.
4. Press the TALK/END/CALLBACK button on the
handset to answer a call or make calls with
the headset.
5. To return to normal operation, unplug the headset
from the jack.
Headset jack
Headset plug
Slots for belt clip
ATTACHING THE BELT CLIP
To attach the belt clip, insert the sides of the belt clip into the
slots on each side of the handset. Snap the ends of the belt clip
into place.
CHANGING THE BATTERY
Make sure the telephone is OFF (not in TALK mode) before
you replace battery.
1. Remove the battery compartment door.
2. Disconnect the cord attached to the battery pack and
remove the battery pack from the handset.
3. Insert the new battery pack and connect the cord to the jack
inside the battery compartment.
4. Put the battery compartment door back on.
5. Place handset in the base to charge. Allow the handset battery
to properly charge (for 12 hours) prior to first use or when you install
a new battery pack. If you do not properly charge the phone, battery
performance will be compromised.
CAUTION: To reduce the risk of fire or personal injury,
use only the battery listed in the instruction book.
NOTE : If the handset battery pack is not installed or properly connected inside
the battery compartment, the handset displays "NO BATTERY," when the handset
is on the base cradle.
RBRC
Ni-Cd
NOTE: The RBRC seal on the battery used in your
RBRC
ATLINKS USA, Inc. product indicates that we are
participating in a program to collect and recycle Nickel
Cadmium batteries throughout the United States.
Please call 1-800-8-BATTERY for information or contact
your local recycling center.
