Thomson 2-3200A User Manual
Cell Docking System
with 2.4 GHz Cordless Handset
User’s Guide
Please read this manual
before operating product
for the first time.
Model 23200
Important Information
Equipment Approval Information
Your telephone equipment is approved for connection to the Public Switched Telephone Network and
is in compliance with parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for
Telephone Terminal Equipment published by ACTA.
1 Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and Ringer
Equivalence Number (REN) for the equipment. You must, upon request, provide this information to your
telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still
have all of these devices ring when your telephone number is called. In most (but not all) areas, the sum of
the RENs of all devices connected to one line should not exceed 5. To be certain of the number of devices
you may connect to your line as determined by the REN, you should contact your local telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply
with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord
and modular plug is provided with this product. It is designed to be connected to a compatible modular jack
that is also compliant. See installation instructions for details.
Notes
• This equipment may not be used on coin service provided by the telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone
equipment if you are on a party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your telephone from
your line.
• If your home has specially wired alarm equipment connected to the telephone line, ensure the installation
of this product does not disable your alarm equipment. If you have questions about what will disable alarm
equipment, consult your telephone company or a qualified installer.
2 Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone
company shall, where practicable, notify you that temporary discontinuance of service may be required.
Where prior notice is not practicable and the circumstances warrant such action, the telephone company
may temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone
company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity
to correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant
to procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or
procedures where such action is required in the operation of its business and not inconsistent with FCC
Rules and Regulations. If these changes are expected to affect the use or performance of your telephone
equipment, the telephone company must give you adequate notice, in writing, to allow you to maintain
uninterrupted service.
2
Important Information
Interference Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference; and (2) This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is “receiving”
the interference).
• Reorient or relocate and increase the separation between the telecommunications equipment and receiving
antenna.
• Connect the telecommunications equipment into an outlet on a circuit different from that to which the
receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television
technician for additional suggestions. Also, the Federal Communications Commission has prepared a helpful booklet,
“How To Identify and Resolve Radio/TV Interference Problems.” This booklet is available from the U.S. Government
Printing Office, Washington, D.C. 20402. Please specify stock number 004-000-00345-4 when ordering copies.
Licensing
Licensed under US Patent 6,427,009
Hearing Aid Compatibility (HAC)
This telephone system meets FCC standards for Hearing Aid Compatibility.
US NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body. This transmitter must not be co-located or operated
in conjunction with any other antenna or transmitter.
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines
when used with the belt clip supplied with this product. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
3
Table of Contents
EQUIPMENT APPROVAL INFORMATION .....................2
I
NTERFERENCE INFORMATION .................................3
H
EARING AID COMPATIBILITY (HAC) ....................3
FCC RF R
I
NTRODUCTION ...................................................6
P
T
I
NSTALLATION ....................................................8
I
NSTALLATION GUIDELINES ...................................8
I
NSTALLING THE BASE UNIT ................................9
C
C
I
NSTALLING THE HANDSET BATTERY ................... 10
I
NSTALLING THE DOCKING STATION ....................11
C
D
H
B
P
P
ADIATION EXPOSURE STATEMENT ............3
ARTS CHECKLIST ...............................................7
ELEPHONE JACK REQUIREMENTS ...........................8
ONNECTING THE AC (ELECTRICAL) POWER ..........9
ONNECTING THE TELEPHONE LINE .......................9
ONNECTING YOUR CELL PHONE .........................11
OCKING STATION LAYOUT .................................11
ANDSET LAYOUT ........................................... 12
ASE LAYOUT ................................................. 12
ROGRAMMING THE DOCKING STATION ................ 13
P
ROGRAMMING FUNCTIONS ..................................13
S
ET LANGUAGE ....................................................13
R
ESET TIMER (CELL DOCKING STATION CALL TIMER) 14
R
EGISTER DOCKING STATION ................................. 14
ROGRAMMING THE HANDSET ........................... 15
S
TANDBY SCREEN ................................................. 15
P
ROGRAMMING FUNCTIONS ..................................15
ROOM MONITOR .................................................. 15
H
ANDSET SETUP ................................................... 16
Set Language .....................................................16
Handset Name ..................................................16
Ringer Volume ..................................................17
Ringer Tone ........................................................ 17
Set Voicemail .....................................................18
Set Cell (Ringer) Tone .....................................18
Set Cell (Ringer) Volume ................................19
VIP MELODY ................................................. 19
Storing VIP Melody ................................. 19
Changing a Stored VIP Melody Record
20
Reviewing And Deleting Stored VIP
Melody Record ........................................
Area Code ........................................................... 21
Key Tone ..............................................................21
Handset Registration ...................................... 21
20
De-Registration ....................................... 22
Global De-registration ...........................
Default Setting .................................................23
23
DOCKING STATION OPERATION ........................... 24
I
NDICATORS .......................................................... 24
C
ALL TIMER ......................................................... 24
C
HARGING THE CELL PHONE ................................. 24
U
PGRADING THE SYSTEM SOFTWARE ..................... 24
T
ELEPHONE OPERATION .................................... 25
I
NDICATORS .......................................................... 25
M
AKING CALLS .................................................... 25
A
NSWERING CALLS .............................................. 26
C
ALL TIMER ......................................................... 26
P
RE-DIALING ....................................................... 26
A
UTO STANDBY .................................................... 26
R
INGER HI/LOW/OFF ....................................... 26
F
LASH/CALL WAITING .......................................... 27
L
AST NUMBER REDIAL .......................................... 27
E
XIT .................................................................... 27
P
AGE ................................................................... 27
P
AGING FROM THE BASE/GROUP PAGE .................28
HOLD .................................................................. 28
M
UTE .................................................................. 28
R
ECEIVER VOLUME CONTROL ................................28
S
PEAKERPHONE OPERATION ............................... 28
Answering a Call with the Handset ...........28
Making a Call with the Handset .................28
Making a Call with the Handset through
the Cell Network ..............................................29
4
Table of Contents
