Page 1
Actual
Catalog Number: TYS9-280
Product ID:
UPC Number:
EAN Number:
Status:
Multi-Lok 316 Stainless Steel Cable Tie, Uncoated, Length of 225mm (8.8 Inches), Width of
7mm (0.28 Inch), Thickness of 0.25mm (0.01 Inch), Tensile Strength Rating of 1112 Newtons (250 Pounds)
• Application Tools: WTAE200, WTAE201,
North American Specifications (UNSPSC)
UNSPSC 39121703 Cable ties
IGCC 5046 Stainless Steel Ties
Type Stainless Steel
Standard UL E49405
Width 0.28 in ; 7 mm
Length 8.8 in ; 225 mm
Thickness 0.01 in ; 0.25 mm
Bundle Diameter Max 2.8 in ; Max 70 mm
Material 316 Stainless Steel
Color Metallic Gray
Lock Mechanism Multi-Lok
Tensile Strength 250 pounds ; 1112 newtons
7TAG009450R0208
78621091544
05414363068013
A
European Specifications (ETIM)
ETIM EC000046 Cable tie
Band width 7mm
Length belt/tape/tie 225mm
Tie thickness 0.25mm
Max. bundle diameter 70mm
Min. holding force 1112N
Operating temperature -40-+150°C
Model Internal toothing
Band closure Ball latch
Material Metal
Material quality Stainless steel 316 (V4A)
Surface protection Untreated
Halogen free N
Colour Stainless steel
Transparent N
Reflective (fluorescent) N
Text strip None
Solvable fastener N
MIL approval N
UL approval Y
Packaging
Inner Quantity 100
Outer Quantity 1000
Outer Dimensions (inches) 12.5x10x9
Weight Uom 5.63 lbs. per 1000
Documents / Support Tools
Technical Drawing / Data Sheet TDS000433
