Thomas & Betts SSH56-625 Data Sheet

Actual

Catalog Number: SSH56-625
Product ID:
UPC Number:
EAN Number:
Status:

201 Stainless Steel Free-End Clamp, Length of 1422.4mm (56.0 Inches), Width of 15.87mm
(0.625 Inches), Thickness of 0.73mm (0.029 Inches), Single Wrap Tensile Strength Rating
of 7562 Newtons (1700 Pounds), Double Wrap Tensile Strength Rating of 17,793 Newtons
(4000 Pounds)

North American Specifications (UNSPSC)

UNSPSC 39121703 Cable ties
IGCC 5046 Stainless Steel Ties
Type Free-End Clamp
Width 0.625 in ; 15.88 mm
Length 56 in ; 1422.4 mm
Thickness 0.029 in ; 0.73 mm
Material 201 Stainless Steel
Color Metallic
Tensile Strength 1700 pounds ; 7562 newtons

European Specifications (ETIM)

ETIM EC000046 Cable tie
Band width 15.87mm
Length belt/tape/tie 1422.4mm
Tie thickness 0.73mm
Min. holding force 7562N
Material Metal
Material quality Other
Halogen free Y
Colour Stainless steel
Transparent N
Reflective (fluorescent) N
Text strip None
Solvable fastener N
MIL approval N
UL approval N

7TAG009460R0080
78621091578
05414363054153
A

Packaging

Outer Quantity 25
Weight Uom 34.5 lbs. per 100

Documents / Support Tools

Technical Drawing / Data Sheet US Available on Website
