Thomas & Betts BGA200-14-20 Data Sheet

Actual

Catalog Number: BGA200-14-20
Product ID:
UPC Number:
Status:

2 Inch Blackjack Grounding Bushing, Aluminum, Galvanized, Wire Range 14 to 2/0 for Use
with Threaded or Threadless Rigid/IMC Conduit

North American Specifications (UNSPSC)

UNSPSC 39121312 Electrical bushing
IGCC 4442 Electrical bushing
Type Grounding Bushings & Accessories
Application For Use with Rigid/IMC Conduit
Standard UL E3060, CSA
Size 2 Inch
Material Aluminum

European Specifications (ETIM)

ETIM EC002357 Support insulator
Length 17.68mm
Outer diameter 71.88mm

Packaging

Inner Quantity 5
Inner Dimensions (inches) 6x4.5x3
Outer Quantity 25
Outer Dimensions (inches) 15.9x8.6x7.7
Weight Uom 16.5 lbs. per 100

7TAD013050R0019
78621016297
A

Representative

Documents / Support Tools

Technical Drawing / Data Sheet US Available on Website

Header

3D Model Available on Website
