Thomas & Betts 676 Data Sheet

Representative

Catalog Number: 676
Product ID:
UPC Number:
EAN Number:
Status:

3/4 Inch Erickson Coupling, Malleable Iron with Steel and Malleable Iron Ring for Use with
Rigid/IMC Conduit

• To Connect Threaded Metal Conduit to a Threadless Opening in a Box or Enclosure

North American Specifications (UNSPSC)

UNSPSC 39131707 Electrical conduit coupling
IGCC 5548 Electrical conduit coupling
Type Conduit Coupling
Special Features Free Fitting Threads Ensure Easy Assembly
Application To Couple and Effectively Bond Threaded Ends of

Standard UL E23018, CSA
Trade Size 3/4 in
Outside Diameter 1-9/16 in
Length 1-13/32 in
Material Malleable Iron

European Specifications (ETIM)

ETIM EC000939 Coupler for installation tubes
Material Metal
Material quality Other
Model Thread
Two piece N
With inspection opening and cover N

7TAD013180R0000
78621000676
05414363145462
A

Rigid Metal Conduit/Intermediate Conduit Where
Neither Length of Conduit Can Be Roated

Packaging

Inner Quantity 25
Inner Dimensions (inches) 4x5x8
Outer Quantity 50
Outer Dimensions (inches) 8.75x5.5x9
Weight Uom 37.5 lbs. per 100

Documents / Support Tools

Technical Drawing / Data Sheet US Available on Website

Header

3D Model Available on Website
