Thomas & Betts 586AL Data Sheet

Actual

Catalog Number: 586AL
Product ID:
UPC Number:
Status:

5 Inch Insulated Bushing, Aluminum, Blue Insulating Liner In Throat for Use with Rigid/IMC
Conduit

North American Specifications (UNSPSC)

UNSPSC 39121312 Electrical bushing
IGCC 4442 Electrical bushing
Brand Name T&B
Type Insulated Grounding Bushing
Special Features T&B Insulated Fittings Reduce Wire Pulling Ef-

Application For Use with Rigid/IMC Conduit
Standard UL E23018
Size 5 Inch
Material Aluminum

European Specifications (ETIM)

ETIM EC001181 Sealing ring
Model Other
Outer diameter 151.60mm
Material Metal
Fitting for thread size NPT 5.00

7TAD013490R0037
78621080134
Active

fort by As Much As 50 Percent

Representative

Thomas & Betts - USA

Packaging

Outer Quantity 1
Outer Dimensions (inches) 8.5x6.62x4
Weight Uom 55 lbs. per 100

Documents / Support Tools

Technical Drawing / Data Sheet US Available on Website
Technical Drawing / Data Sheet Canada Available on Website

Header

3D Model Available on Website
