INSTRUCTION SHEET
for Ground Grid Connectors
A
WARNING
7/8”
L
D
L
INSTRUCTIONS:
NOTE: Install these connectors on ground rods after the rods have been
driven to their nal depth.
1. Clean cable of all visible dirt with rough cloth or brush and provide a
bright copper nish by wire brushing or similar process.
2. Cable end(s) should protrude at least 3/4” beyond connector.
3. OPTIONAL: Use knurling tool 240-31565-94 on smooth ground rods.
4. Use hydraulic tool 13100A, TBM14CR-LI, TBM14M, TBM15CR-LI,
TBM15, or TBM15I with die marked on part.
© 2015 Thomas & Betts. All Rights Reserved.
RISK OF SHOCK, DISCONNECT
POWER BEFORE INSTALLATION.
B
3/4”
Cat. Nos.
54920LR100 1” 250 MCM-500 MCM 1/2” 2-5/8” 15G121R* 15G126R
54910LR100 1” 2 AWG-250 MCM 1/2” 2-5/8” 15G121R* 15G86R
54900LR34 3/4” 250 MCM-500 MCM 1/2” 2-5/8” 15G121R* 15G126R
54875LR34 3/4” 2 AWG-250 MCM 1/2” 2-5/8” 15G121R* 15G86R
54895LR58 5/8” 250 MCM-500 MCM 5/16” 2-1/2” 15G121R* 15G126R
54865LR58 5/8” 2 AWG-250 MCM 5/16” 2-1/2” 15G121R* 15G86R
54885LR12 1/2” 250 MCM-500 MCM 5/16” 2-1/2” 15G121R* 15G126R
54855LR12 1/2” 2 AWG-250 MCM 5/16” 2-1/2” 15G121R* 15G86R
A
Ground Rod
B
Cable Range
D L
(see Step 4)
A B
Requires 2 crimps
*
Burndy Tools (Crimps)
DIES FOR T&B TOOLS
Cat. Nos.
Y750 Y45 Y46
A B A B A B
54920LR100
54910LR100
54900LR34
54875LR34
54895LR58
54865LR58
54885LR12
54855LR12
WARRANTY: Thomas & Betts sells this product with the understanding that the user will perform all necessary tests to determine
the suitability of this product for the user's intended application. Thomas & Betts warrants that this product will be free from
defects in materials or workmanship for a period of two (2) years following the date of purchase. Upon prompt notication of any
warranted defect, Thomas & Betts will, at its option, repair or replace the defective product. Misuse, misapplication or
modication of Thomas & Betts Products immediately voids all warranties.
Limitations and Exclusions: THE ABOVE WARRANTY IS THE SOLE WARRANTY CONCERNING THIS PRODUCT, AND IS IN
LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WHICH ARE SPECIFICALLY
DISCLAIMED. LIABILITY FOR BREACH OF THE ABOVE WARRANTY IS LIMITED TO COST OF REPAIR OR
REPLACEMENT OF THE PRODUCT, AND UNDER NO CIRCUMSTANCES WILL THOMAS & BETTS BE LIABLE FOR ANY
INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES.
U1011 (2) or
PU998 (1)
U1011 (2) or
PU998 (1)
U1011 (2) or
PU998 (1)
U1011 (2) or
PU998 (1)
U1011 (2) or
PU998 (1)
U1011 (2) or
PU998 (1)
U1011 (2) or
PU998 (1)
U1011 (2) or
PU998 (1)
U1011 (2) or
PU998 (1)
U997 (1)
U1011 (2) or
PU998 (1)
U997 (1)
U1011 (2) or
PU998 (1)
U997 (1)
U1011 (2) or
PU998 (1)
U997 (1)
Thomas & Betts Corporation
S1011 (2) or
PU998 (1)
S1011 (2) or
PU998 (1)
S1011 (2) or
PU998 (1)
S1011 (2) or
PU998 (1)
S1011 (2) or
PU998 (1)
S1011 (2) or
PU998 (1)
S1011 (2) or
PU998 (1)
S1011 (2) or
PU998 (1)
Memphis, Tennessee
www.tnb.com
U1011 (2) or
PU998 (1)
U997 (1)
U1011 (2) or
PU998 (1)
U997 (1)
S998 (1) or
PU998 (1)
U997 (1)
S998 (1) or
PU998 (1)
U997 (1)
P1011 (2) or
PU998 (1)
P1011 (2) or
PU998 (1)
P1011 (2) or
PU998 (1)
P1011 (2) or
PU998 (1)
P1011 (2) or
PU998 (1)
P1011 (2) or
PU998 (1)
P1011 (2) or
PU998 (1)
P1011 (2) or
PU998 (1)
U1011 (2) or
PU998 (1)
U997 (1)
U1011 (2) or
PU998 (1)
U997 (1)
P998 (1) or
PU998 (1)
U997 (1)
P998 (1) or
PU998 (1)
U997 (1)
TA02147 C
