T&B Catalog Number: 256-1157PHBS
UPC Number:
Description:
Status:
General
Material Copper
Finish Tin Plated
Wire Size #8 AWG
Number of Studs 2
Stud Size 3/8
Bolt Hole Spacing 1
Tongue Angle Straight
Barrel Length Long
Barrel Shape Belled End
Tongue Width Standard
Peep Hole Y
Marking Standard
Hole Shape Round
Die Color Red
Die Code 21
Packaging
T&B Inner Pack 10
Package in Units 50
T&B Sold in UOM Each
T&B Weight Per UOM 3 lbs. per 100
Application Support
Overview Available on Website
Connector & Tooling Chart Available on Website
Notes
Certifications
RoHS Compliance Yes
Certifications
78621090842
Copper Two-Hole Lug - Straight Long
Belled End Barrel - max 35KV, #8 AWG
Wire, 3/8" Bolt Size, 1" Hole Spacing, Tin
Plated with Inspection Hole, Red 21
Active
Dimensions given for reference only. Dimensions
may vary up to +/- .030.
File Nbr:
E9809
