Catalog Number: 1350CR
Product ID:
UPC Number:
EAN Number:
Status:
Pipe Spacer, Malleable Iron PVC Coated, Use with Conduit Sizes of 1/2 Inch, 3/4 Inch, and
1 Inch for Use with Rigid/IMC Conduit
• Corrosioin resistance, PVC-coated.
• Pre-mountable and stackable to eliminate offsetting of conduit.
• Prevents conduit rusting from wall condensation.
7TAD013550R0012
78621078737
05415022435320
Active
Actual
North American Specifications (UNSPSC)
UNSPSC 39122105 Electrical spacer
IGCC 5117 Electrical spacer
Brand Name T&B
Type Pipe Spacer
Application Provides Mounting Surface for Conduit Where In-
stallation Requires Air Space Between Conduit and
Supporting Surface.
Standard CSA
Material Iron
Top End Diameter Pole Side Conduit 1/2 to 1 Inch
European Specifications (ETIM)
ETIM EC001494 Spacer for cable protection tube
Model One fold
Suitable for pipe diameter 12.7-25.4mm
Packaging
Inner Quantity 50
Inner Dimensions (inches) 8.25x5.25x4.25
Outer Quantity 100
Outer Dimensions (inches) 8.9x5.7x7
Weight Uom 10.13 lbs. per 100
Documents / Support Tools
Technical Drawing / Data Sheet US Available on Website
Technical Drawing / Data Sheet Canada Available on Website
Header
3D Model Available on Website
