Green Screen Roll-Up 1.5 × 2 m

Safety instructions

Intended use

This device serves as a mobile Chromakey backdrop. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.

Danger for children

Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts from the product. They could swallow the pieces and choke!

Features

Mobile Chromakey backdrop

Easy transport and safe storage thanks to the roll-up system in a stable aluminium case

Quick assembly and disassembly thanks to two hydraulic supports

Quick Start Guide

EN



This quick start guide contains important information on the safe operation of the product. Read and follow the safety advice and instructions given. Retain the manual for future reference. If you pass the product on to others please include this manual.

Where to use the product

Never use the product

in conditions of extreme temperature or humidity

in extremely dusty or dirty areas

in locations where the unit can become wet

on sloping, uneven or insufficiently stable surfaces – risk of falling!

General handling

To prevent damage, never use force when handling the product.

Never immerse the product in water. Just wipe it with a clean dry or moist cloth. Do not use liquid cleaners such as benzene, thinners or flammable cleaning agents.

Stable and durable scissor system

Two foldable feet for a secure stand

No wrinkles thanks to the automatic roll-up

High quality Oxford fabric for optimal colour keying

Setup

Front view

Side view

Rear view

Top view

Follow the steps below to assemble the backdrop: 1. Unfold the feet.

4. Pull up the backdrop evenly and without great effort by the eyelet in the middle.

2.Place the backdrop where you want it.

3.Open the two snap locks and fold the cover back.

5. After use, reverse the order to put the backdrop back together.

Technical specifications

Dimensions backdrop (W × H):

1.5 m × 2.0 m



Transport size (W × H × D):

158 mm × 130 mm × 122 mm



Weight:

9.70 kg

For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. Please follow the notes and markings on the packaging.

Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • info@thomann.de

DocID: 502209_25.11.2020
