Page 1
LED Pot COB 40W
RGB WW
LED PAR
user manual
Page 2
Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: info@thomann.de
Internet: www.thomann.de
20.05.2019, ID: 457316
Page 3
Table of contents
Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 8
2 Safety instructions.................................................................................................................................. 10
3 Features....................................................................................................................................................... 16
4 Installation.................................................................................................................................................. 17
5 Starting up.................................................................................................................................................. 22
6 Connections and controls................................................................................................................... 25
7 Operating.................................................................................................................................................... 31
7.1 Operating mode Auto.................................................................................................................... 31
7.2 Programme mode............................................................................................................................ 32
7.3 Operating mode DMX.................................................................................................................... 35
7.4 Operating mode Slave................................................................................................................... 41
7.5 Dimmer mode................................................................................................................................... 42
LED Pot COB 40W RGB WW
3
Page 4
Table of contents
7.6 Sound control.................................................................................................................................... 43
7.7 Reset to factory defaults................................................................................................................ 43
7.8 Device infos........................................................................................................................................ 44
7.9 Menu overview................................................................................................................................. 45
8 Technical specications....................................................................................................................... 46
9 Plug and connection assignments.................................................................................................. 49
10 Troubleshooting...................................................................................................................................... 50
11 Cleaning....................................................................................................................................................... 52
12 Protecting the environment.............................................................................................................. 53
LED PAR
4
Page 5
1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
LED Pot COB 40W RGB WW
5
Page 6
General information
1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search
Online guides
Personal consultation For personal consultation please contact our technical hotline.
Service
Use the search function in the electronic version to nd the topics of
interest for you quickly.
Our online guides provide detailed information on technical basics
and terms.
If you have any problems with the device the customer service will
gladly assist you.
LED PAR
6
Page 7
1.2 Notational conventions
This manual uses the following notational conventions:
General information
Letterings
Instructions
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
Automatic operation is started.
ð
3. Switch o the device.
LED Pot COB 40W RGB WW
7
Page 8
General information
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
WARNING! This combination of symbol and signal word indicates a pos‐
NOTICE! This combination of symbol and signal word indicates a pos‐
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
sible dangerous situation that can result in death or serious
injury if it is not avoided.
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
LED PAR
8
Page 9
Warning signs Type of danger
Warning – high-voltage.
Warning – dangerous optical radiation.
Warning – suspended load.
Warning – danger zone.
General information
LED Pot COB 40W RGB WW
9
Page 10
Safety instructions
2 Safety instructions
Intended use
10
This device is intended for use as an electronic lighting eect by means of LED technology. The
device is designed for professional use and is not suitable for use in households. Use the
device only as described in this user manual. Any other use or use under other operating con‐
ditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Extend the life of the device by regular breaks in operation and avoid switching it on and o
frequently. This device is not suitable for continuous use.
LED PAR
Page 11
Safety
Safety instructions
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
LED Pot COB 40W RGB WW
11
Page 12
Safety instructions
DANGER!
Electric shock caused by short-circuit
Do not modify the mains cable or the plug. Failure to do so could result in electric
shock/death or re. If in doubt, seek advice from a registered electrician.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
12
LED PAR
Page 13
Safety instructions
NOTICE!
Risk of re
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked ames.
LED Pot COB 40W RGB WW
13
Page 14
Safety instructions
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctua‐
tions and do not switch the device on immediately after it was exposed to tem‐
perature uctuations (for example after transport at low outside temperatures).
Dust and dirt inside can damage the unit. When operated in harmful ambient
conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other
malfunction.
14
LED PAR
Page 15
Safety instructions
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or re.
LED Pot COB 40W RGB WW
15
Page 16
Features
3 Features
Compact LED spotlight with high beam angle
n 1 × COB LED 4in1 RGB WW, 40 W
n Control via DMX, buttons and display on the unit as well as via IR remote control (optional)
n Operating modes:
– DMX
– Master/Slave
– Automatic programme run
– Preset shows
– Sound control
– Static colours
n Noiseless operation due to convection cooling without fan
n Double bracket for up-lighting
For technological reasons, the light output of LEDs decreases over their lifetime. This eect
increases with higher operating temperature. You can extend the service life of the illuminants
by providing adequate ventilation and operating the LEDs with the lowest possible brightness.
16
LED PAR
Page 17
4 Installation
Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
LED Pot COB 40W RGB WW
17
Page 18
Installation
NOTICE!
Risk of overheating
The distance between light output and the illuminated surface must be more
than 1.5 m (19.7in).
Provide sucient ventilation.
The ambient temperature must always be below 40 °C (104 °F).
NOTICE!
Use of stands
When mounting the device onto a stand, ensure that the stand is in a safe and
stable position and that the weight of the device does not exceed the maximum
permissible load capacity of the stand.
18
LED PAR
Page 19
Installation
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
ers.
Mounting options
You can install the unit in hanging or standing position. When in use, the device must always
be attached to a solid surface or an approved truss. Use the openings provided on the twopiece bracket for attaching.
Always work from a stable platform whenever installing, moving or servicing the unit. In doing
so, the area underneath the unit must be cordoned o.
The safety cable must be attached to the bracket.
LED Pot COB 40W RGB WW
19
Page 20
Installation
Please note that this device must not be connected to a dimmer.
20
LED PAR
Page 21
Installation
Inserting the battery into the
remote control
Press the lock of the battery holder to the centre of the housing and pull out the battery holder
like a drawer. Insert the battery. The battery is correct if the positive pole points to the housing
base of the remote control. Slide the battery holder back into the remote until it clicks into
place.
When shipping, the battery is already installed in the remote and protected against discharge
by a transparent plastic foil. Remove the plastic foil prior to rst use.
LED Pot COB 40W RGB WW
21
Page 22
Starting up
5 Starting up
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
22
LED PAR
Page 23
Starting up
Connections in DMX mode
Connect the DMX input of the device to the DMX output of a DMX controller or another DMX
device. Connect the output of the rst DMX device to the input of the second one, and so on
to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain
is terminated with a resistor (110 Ω, ¼ W).
LED Pot COB 40W RGB WW
23
Page 24
Starting up
Connections in master/slave
mode
When you congure a group of devices in master/slave mode, the rst unit will control the
other units for an automatic, sound-activated, synchronized show. This function is ideal when
you want to start a show immediately. Connect the DMX output of the master device to the
DMX input of the rst slave device. Then connect the DMX output of the rst slave device to
the DMX input of the second slave device and so on.
LED PAR
24
Page 25
6 Connections and controls
Connections and controls
LED Pot COB 40W RGB WW
25
Page 26
Connections and controls
1 Infrared sensor for receiving signals from an optionally available remote control.
2 LEDs
3 Locking screws for the two-piece bracket
4 [DMX In]
DMX input
5 Power cord
6 [DMX Out]
DMX output
7 Display and function buttons.
[Mode]
Opens the main menu.
[Setup]
Conrms a selected value or opens a submenu.
26
LED PAR
Page 27
[Down]
Decreases the displayed value by one.
[Up]
Increases the displayed value by one.
Connections and controls
LED Pot COB 40W RGB WW
27
Page 28
Connections and controls
Remote control (optional)
28
LED PAR
Page 29
Connections and controls
8 [AUTO]
Enables the auto mode.
9 [PRG]
Enables the Programme mode. Select the desired programme with the buttons [+] and [–].
10 [ON/OFF]
Activates / deactivates the device.
11 [SPEED]
Activates the setting mode for the programme speed. Adjust the speed using the buttons [+] and [–] .
12 [SOUND]
Activates the sound control.
13 [STROBE]
Turns the strobe function on / o.
14 [+]
Increases the set value.
LED Pot COB 40W RGB WW
29
Page 30
Connections and controls
15 [–]
Decreases the set value.
16 [Dimming]
Enables the dimmer function.
17 [0 … 9]
Numeric buttons for direct selection of a constant colour.
18 [R], [G], [B], [A], [W]
Buttons to select a colour tone for the dimmer mode.
30
LED PAR
Page 31
7 Operating
7.1 Operating mode Auto
Operating
Connect the device to the power supply to start operation. After a few seconds the unit is
ready for use.
Press [Mode] or [Up] | [Down] to open the main menu and select a menu option. Open the indi‐
vidual menus with [Setup] and change the respectively displayed value with [Up] | [Down].
Changed values and settings will immediately take eect. With [Mode] , you return to the pre‐
vious menu level.
Automatic operation can only be activated when the unit is operating in stand alone mode or
as master in a master / slave combination. This setting is only relevant if the device is not con‐
trolled via DMX.
Press [Mode] or [Up] | [Down] repeatedly until the display shows ‘AUTO’ . Conrm with [Setup].
The device now works in automatic stand-alone mode, the programmes ‘Pr.02’ … ‘Pr.14’ run
sequentially at the set programme and strobe speed.
LED Pot COB 40W RGB WW
31
Page 32
Operating
7.2 Programme mode
A preprogrammed automatic show can only be activated when the unit is operating in standalone mode or as master in a master / slave combination. This setting is only relevant if the
device is not controlled via DMX.
Press [Mode] or [Up] | [Down] repeatedly until the display shows ‘Pro’ . Press [Setup] and use
[Up] | [Down] to select one of the programmes ‘Pr.01’ … ‘Pr.14’.
32
LED PAR
Page 33
Operating
Settings for program 01
If you have selected programme 01, you can select one of 15 static colour settings.
1. After selecting the programme, press again [Setup] and adjust the colour with [Up] |
[Down] in a range between ‘Co.01’ … ‘Co.15’ or ‘OFF’ (blackout).
Colour Display
Blackout ‘OFF’
Red ‘Co.01’
Green ‘Co.02’
Blue ‘Co.03’
White ‘Co.04’
Amber ‘Co.05’
Orange ‘Co.06’
Yellow ‘Co.07’
Purple ‘Co.08’
Pink ‘Co.09’
LED Pot COB 40W RGB WW
33
Page 34
Operating
Colour Display
Cyan ‘Co.10’
Light red ‘Co.11’
Light green ‘Co.12’
Light blue ‘Co.13’
Warm white ‘Co.14’
Cold white ‘Co.15’
2. Press again [Setup] and adjust the frequency of the strobe eect with [Up] | [Down] in a
range from ‘FS.00’ … ‘FS.99’ (slow … fast).
Settings for programmes
02 … 14
34
When you have selected one of programmes 02 … 14 you can adjust the following settings:
1. After selecting the programme, press again [Setup] and adjust the programme speed
with [Up] | [Down] in a range from ‘Sp.00’ … ‘Sp.99’ (slow … fast).
2. Press again [Setup] and adjust the frequency of the strobe eect with [Up] | [Down] in a
range from ‘FS.00’ … ‘FS.99’ (slow … fast).
LED PAR
Page 35
7.3 Operating mode DMX
Operating
This setting is only relevant if the device is controlled via a DMX controller.
1. Use [Mode] or [Up] | [Down] to select the menu option ‘d---’ and conrm with [Setup].
2. Use [Up] | [Down] to assign a DMX address in the range from ‘d.001’ … ‘d.512’ to the
device and conrm with [Setup].
3. Use [Up] | [Down] to select the desired DMX mode:
Mode Highest possible DMX address
4-channel 509
6-channel 507
8-channel 505
4. Conrm with [Setup].
LED Pot COB 40W RGB WW
35
Page 36
Operating
7.3.1 Functions in 4-channel DMX mode
Channel Value Function
1 0 … 255 Intensity red (0 % to 100 %)
2 0 … 255 Intensity green (0 % to 100 %)
3 0 … 255 Intensity blue (0 % to 100 %)
4 0 … 255 Intensity white (0 % to 100 %)
7.3.2 Functions in 6-channel DMX mode
Channel Value Function
1 0 … 255 Dimmer (0 % to 100 %)
2 0 … 255 Intensity red (0 % to 100 %)
3 0 … 255 Intensity green (0 % to 100 %)
LED PAR
36
Page 37
Channel Value Function
4 0 … 255 Intensity blue (0 % to 100 %)
5 0 … 255 Intensity white (0 % to 100 %)
6 0 … 10 No function
11 … 255 Stroboscope eect (slow to fast)
7.3.3 Functions in 8-channel DMX mode
Channel Value Function
1 0 … 255 Dimmer (0 % to 100 %)
2 0 … 255 Intensity Red (0 % to 100 %), if channel 6 = 0
3 0 … 255 Intensity Green (0 % to 100 %), if channel 6 = 0
4 0 … 255 Intensity Blue (0 % to 100 %), if channel 6 = 0
Operating
LED Pot COB 40W RGB WW
37
Page 38
Operating
Channel Value Function
5 0 … 255 Intensity white (0 % to 100 %), if channel 6 = 0
6 Programme selection
0 Dimmer
1 … 16 Programme 01
17 … 33 Programme 02
34 … 50 Programme 03
51 … 67 Programme 04
68 … 84 Programme 05
85 … 101 Programme 06
102 … 118 Programme 07
119 … 135 Programme 08
136 … 152 Programme 09
38
153 … 169 Programme 10
LED PAR
Page 39
Channel Value Function
170 … 186 Programme 11
187 … 203 Programme 12
204 … 220 Programme 13
221 … 237 Programme 14
238 … 255 Sound-controlled operation
7 Colour macros programme 01
0 … 15 Red 0 % / green 0 % / blue 0 % / white 0 %, if channel 6 = 1 … 16
16 … 31 Red 255 % / green 0 % / blue 0 % / white 0 %, if channel 6 = 1 … 16
32 … 47 Red 0 % / green 255 % / blue 0 % / white 0 %, if channel 6 = 1 … 16
48 … 63 Red 0 % / green 0 % / blue 255 % / white 0 %, if channel 6 = 1 … 16
64 … 79 Red 0 % / green 0 % / blue 0 % / white 255 %, if channel 6 = 1 … 16
80 … 95 Red 255 % / green 150 % / blue 0 % / white 0 %, if channel 6 = 1 … 16
Operating
96 … 111 Red 255 % / green 180 % / blue 0 % / white 0 %, if channel 6 = 1 … 16
LED Pot COB 40W RGB WW
39
Page 40
Operating
Channel Value Function
112 … 127 Red 255 % / green 255 % / blue 0 % / white 0 %, if channel 6 = 1 … 16
128 … 143 Red 255 % / green 0 % / blue 255 % / white 0 %, if channel 6 = 1 … 16
144 … 159 Red 255 % / green 0 % / blue 140 % / white 0 %, if channel 6 = 1 … 16
160 … 175 Red 0 % / green 255 % / blue 255 % / white 0 %, if channel 6 = 1 … 16
176 … 191 Red 255 % / green 0 % / blue 0 % / white 210 %, if channel 6 = 1 … 16
192 … 207 Red 0 % / green 255 % / blue 0 % / white 210 %, if channel 6 = 1 … 16
208 … 223 Red 0 % / green 0 % / blue 255 % / white 210 %, if channel 6 = 1 … 16
224 … 239 Red 255 % / green 200 % / blue 40 % / white 90 %, if channel 6 = 1 … 16
240 … 255 Red 255 % / green 255 % / blue 255 % / white 255 %, if channel 6 = 1 … 16
0 … 255 Speed, if channel 6 = 17 … 237
0 … 255 Microphone sensitivity, if channel 6 = 238 … 255
8 0 … 10 No function
40
11 … 255 Stroboscope eect (slow to fast)
LED PAR
Page 41
7.4 Operating mode Slave
Operating
This setting is only relevant if the device is not controlled via DMX.
Press [Mode] or [Up] | [Down] repeatedly until the display shows ‘SLAv’ . The device now oper‐
ates in slave mode and follows all processes of the controlling master device.
LED Pot COB 40W RGB WW
41
Page 42
Operating
7.5 Dimmer mode
Dimmer operation can only be activated when the unit is operating in stand alone mode or as
master in a master / slave combination. This setting is only relevant if the device is not con‐
trolled via DMX.
Press [Mode] or [Up] | [Down] repeatedly until the display shows ‘Colr’ . All LEDs light with the
set intensity. Press [Setup] and change the intensity of the four primary colours one by one as
desired:
n Red: ‘r.000’ … ‘r.255’
n Green: ‘g.000’ … ‘g.255’
n Blue: ‘b.000’ … ‘b.255’
n White: ‘u.000’ … ‘u.255’
42
LED PAR
Page 43
7.6 Sound control
Sound control can only be activated when the unit is operating in stand alone mode or as
master in a master / slave combination. This setting is only relevant if the device is not con‐
trolled via DMX. In this operating mode, the device responds to acoustic pulses which are
recorded by the integrated microphone.
Press [Mode] or [Up] | [Down] repeatedly until the display shows ‘Soud’ . Press [Setup] and use
[Up] | [Down] to adjust the microphone sensitivity in a range of ‘SU.00’ … ‘SU.31’.
7.7 Reset to factory defaults
Press [Mode] or [Up] | [Down] repeatedly until the display shows ‘Set’ . Press [Setup], the display
shows ‘-rSt’ . Press again [Setup] to reset the device to the factory default settings. Use [Up] |
[Down] to select either ‘-YES’ to conrm the reset to factory settings, or ‘--NO’, to cancel the
reset to factory settings.
Operating
LED Pot COB 40W RGB WW
43
Page 44
Operating
7.8 Device infos
Device temperature
Firmware version
Press [Mode] or [Up] | [Down] repeatedly until the display shows ‘InFo’ . Press [Setup]. Press [Up]
| [Down] repeatedly until the display shows ‘tEnP’ . Press [Setup]. The device temperature. is dis‐
played.
Press [Mode] or [Up] | [Down] repeatedly until the display shows ‘InFo’ . Press [Setup]. Press [Up]
| [Down] repeatedly until the display shows ‘Ver’ . Press [Setup]. The rmware version of the
device is displayed.
LED PAR
44
Page 45
7.9 Menu overview
Operating
LED Pot COB 40W RGB WW
45
Page 46
Technical specications
8 Technical specications
Light source 1 × 4-in1 COB LED RGB WW, 40 W
Optical properties Beam angle 35° (beam)
Control DMX
Number of DMX channels 4, 6, 8
Input connections DMX control XLR chassis plug, 3-pin
Output connections DMX control XLR chassis socket, 3-pin
Power consumption 37 W
75° (spot)
Buttons and display on the unit
Remote control (optional)
46
Operating supply voltage
Protection class IP20
100 – 240 V 50/60 Hz
LED PAR
Page 47
Technical specications
Mounting options hanging, standing
Dimensions (W × H × D) 165 mm × 130 mm × 262 mm (incl.
locking screws and bracket)
Weight 1.60 kg
Ambient conditions Temperature range 0 °C…40 °C
Relative humidity 50 %, non-condensing
LED Pot COB 40W RGB WW
47
Page 48
Technical specications
Further information
Construction Cannon
Colour mixture RGB WW
LED type COB
Floor housing Yes
Fanless Yes
Remote control Optional
Wireless DMX No
Housing colour black
LED PAR
48
Page 49
9 Plug and connection assignments
Plug and connection assignments
Introduction
DMX connections
This chapter will help you select the right cables and plugs to connect your valuable equip‐
ment so that a perfect light experience is guaranteed.
Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug
ts into a socket, the result of an incorrect connection may be a destroyed DMX controller, a
short circuit or ‘just’ a not working light show!
The unit oers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please
refer to the drawing and table below for the pin assignment of a suitable XLR plug.
Pin Conguration
1 Ground, shielding
2 Signal inverted (DMX–, ‘cold signal’)
3 Signal (DMX+, ‘hot signal’)
LED Pot COB 40W RGB WW
49
Page 50
Troubleshooting
10 Troubleshooting
In the following we list a few common problems that may occur during operation. We give you
some suggestions for easy troubleshooting:
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
ers.
50
LED PAR
Page 51
Symptom Remedy
Troubleshooting
The unit does not work, no
light.
No response to the DMX con‐
troller.
If the procedures recommended above do not succeed, please contact our Service Center. You
can nd the contact information at www.thomann.de.
Check the mains connection and the fuse.
1. Check the DMX ports and cables for proper connection.
2. Check the address settings and the DMX polarity.
3. Try using another DMX controller.
4. Check to see if the DMX cables run near or alongside to
high voltage cables that may cause damage or interfer‐
ence to DMX interface circuits.
LED Pot COB 40W RGB WW
51
Page 52
Cleaning
11 Cleaning
Optical lenses
Fan grids
52
Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the
light output. The frequency of cleaning depends on the operating environment: wet, smoky or
particularly dirty surroundings can cause more accumulation of dirt on the optics of the
device.
n Clean with a soft cloth using our lamp and lens cleaner (item no. 280122).
n Always dry the parts carefully.
The fan grids of the device must be cleaned of any contamination, such as dust, etc. on a reg‐
ular basis. Before cleaning, switch o the device and disconnect mains-operated devices from
the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit
with a slightly damp lint-free cloth.
LED PAR
Page 53
12 Protecting the environment
Disposal of the packaging mate‐
rial
For the transport and protective packaging, environmentally friendly materials have been
chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose these materials with your normal household waste, but make sure that
they are fed to a recovery. Please follow the notes and markings on the packaging.
Disposal of batteries
Batteries must not be disposed of as domestic waste or thrown into re. Dispose of the bat‐
teries according to national or local regulations regarding hazardous waste. To protect the
environment, dispose of empty batteries at your retail store or at appropriate collection sites.
Protecting the environment
LED Pot COB 40W RGB WW
53
Page 54
Protecting the environment
Disposal of your old device
This product is subject to the European Waste Electrical and Electronic Equipment Directive
(WEEE) in its currently valid version. Do not dispose with your normal household waste.
Dispose this device through an approved waste disposal rm or through your local waste
facility. When discarding the device, comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.
54
LED PAR
Page 55
Page 56
Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de
Loading...
