BLS-315 Pro Lighting Stand B speaker / light stand

General information

1 General information

This manual contains important instructions for the safe operation of the product. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the product. If you sell the unit, please make sure that the buyer also receives this manual.

Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de.

BLS-315 Pro Lighting Stand B

speaker / light stand

1.1 Further information

General information

On our website (www.thomann.de) you will nd lots of further information and details on the following points:

Download This manual is also available as PDF le for you to download.

Keyword search

Online guides

Personal consultation For personal consultation please contact our technical hotline.

Service

Use the search function in the electronic version to nd the topics of interest for you quickly.

Our online guides provide detailed information on technical basics and terms.

If you have any problems with the device the customer service will gladly assist you.

BLS-315 Pro Lighting Stand B speaker / light stand

General information

1.2 Notational conventions

This manual uses the following notational conventions:

Instructions

The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow.

Example:

1. Switch on the device.

2. Press [Auto].

3. Switch o the device.

1.3 Symbols and signal words

In this section you will nd an overview of the meaning of symbols and signal words that are used in this manual.

BLS-315 Pro Lighting Stand B

speaker / light stand

Automatic operation is started.

General information

Signal word Meaning

DANGER! This combination of symbol and signal word indicates an

immediate dangerous situation that will result in death or serious injury if it is not avoided.

CAUTION! This combination of symbol and signal word indicates a pos‐

sible dangerous situation that can result in minor injury if it is not avoided.

NOTICE! This combination of symbol and signal word indicates a pos‐

sible dangerous situation that can result in material and environmental damage if it is not avoided.

Warning signs Type of danger

Warning – danger zone.

BLS-315 Pro Lighting Stand B speaker / light stand

Safety notes

2 Safety notes

Intended use

This speaker / light stand is used for stable xing and height-adjustable installation of loud‐ speaker cabinets and lights. Use the product only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.

This product may be used only by persons with sucient physical, sensorial, and intellectual abilities and having corresponding knowledge and experience. Other persons may use this product only if they are supervised or instructed by a person who is responsible for their safety.

BLS-315 Pro Lighting Stand B

speaker / light stand

Safety

Safety notes

DANGER! Danger for children

Ensure that plastic bags, packaging, etc. are properly disposed of and are not in the reach of babies and young children. Choking hazard!

Ensure that children do not detach any small parts (e.g. knobs or the like) from the product. They could swallow the pieces and choke!

Never let children play unattended with the product.

CAUTION! Danger of tipping when transported under load

If the stand is moved without having removed the installed device, the stand may tip over and cause injuries and property damage.

Remove the installed device before transporting the stand.

BLS-315 Pro Lighting Stand B speaker / light stand

Safety notes

CAUTION! Danger of tipping on unsuitable surfaces

When the speaker stand is installed on soft or uneven ground, the stand may tip over and cause injuries and property damage.

Install the stand only on even and solid surfaces.

CAUTION! Danger of tipping due to overload

In case of overload, the stand may tip over and cause injuries and property damage.

Never exceed the maximum load capacity specied for the stand.

BLS-315 Pro Lighting Stand B

speaker / light stand

Safety notes

NOTICE! Possible staining

The plasticiser contained in the rubber feet of this product may possibly react with the coating of your parquet, linoleum, laminate or PVC oor and after some time cause permanent dark stains.

In case of doubt, do not put the rubber feet directly on the oor, but use felt-pad oor protectors or a carpet.

BLS-315 Pro Lighting Stand B speaker / light stand

Features

3 Features

Professional speaker and light stand

n Material: Steel / magnesium compound n Individually reinforced legs for high stability n Height: 150 to 310 cm n Stand space diameter 120 cm n Pipe diameter: 28 mm n 35 mm adapter for suitable speaker box n Centric load capacity up to 30 kg n Made in Europe

BLS-315 Pro Lighting Stand B

speaker / light stand

4 Operating

Operating

Unpack and check carefully there is no transportation damage before using the product. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.

CAUTION! Danger of tipping when transported under load

If the stand is moved without having removed the installed device, the stand may tip over and cause injuries and property damage.

Remove the installed device before transporting the stand.

BLS-315 Pro Lighting Stand B speaker / light stand

Operating

CAUTION! Danger of tipping on unsuitable surfaces

When the speaker stand is installed on soft or uneven ground, the stand may tip over and cause injuries and property damage.

Install the stand only on even and solid surfaces.

CAUTION! Danger of tipping due to overload

In case of overload, the stand may tip over and cause injuries and property damage.

Never exceed the maximum load capacity specied for the stand.

BLS-315 Pro Lighting Stand B

speaker / light stand

Operating

NOTICE! Possible staining

The plasticiser contained in the rubber feet of this product may possibly react with the coating of your parquet, linoleum, laminate or PVC oor and after some time cause permanent dark stains.

In case of doubt, do not put the rubber feet directly on the oor, but use felt-pad oor protectors or a carpet.

Comply with regulations

When installing and operating, make sure to follow the standards and regulations that apply in your country.

BLS-315 Pro Lighting Stand B speaker / light stand

Operating

Setting up

1. Unfold the feet of the stand until the cross braces are in a horizontal position.

2. Fix this position with the safety screw on the slider to which the three feet are attached.

3. Pull out the two safety pin and loosen the two safety screws on the extension tubes.

4. Pull out the upper extension tube to the desired height and slide the safety pin through

the corresponding grid hole.

5. Fix the position of the upper extension tube with the safety screw on the upper tube clamp.

6. Pull out the lower extension tube to the desired height and slide the safety pin through the corresponding grid hole.

7. Fix the position of the lower extension tube with the safety screw on the lower tube clamp.

8. Mount a spotlight or a speaker box. If necessary, screw the supplied adapter rmly to the upper extension tube. Observe the instructions of the respective manufacturers. The maximum load capacity of 30 kg in total must not be exceeded.

BLS-315 Pro Lighting Stand B

speaker / light stand

Operating

Dismounting

1. Remove spotlight or speaker box.

2. Pull out the safety pin on the lower extension tube.

3. Loosen the safety screw on the lower tube clamp and slide the lower extension tube all

the way down.

4. Tighten the safety screw on the lower tube clamp.

5. Pull out the safety pin on the upper extension tube.

6. Loosen the safety screw on the upper tube clamp and slide the lower extension tube all

the way down.

7. Tighten the safety screw on the upper tube clamp.

8. If necessary, take o the adapter.

9. Loosen the safety screw on the slider to which the three feet are attached.

10. Fold up the feet of the stand.

11. Pack all parts of the system in their original package, as possible, and store the package

in a dry place protected against moisture.

BLS-315 Pro Lighting Stand B speaker / light stand

Technical specications

5 Technical specications

Height, max. 3.10 m

Adjustable stand height 1.50 m … 3.10 m

Floor space

Stand tube diameter

Mounting options

Max. load capacity (for centric load) 30 kg

Transport dimensions (W × H × D) 137 mm × 1290 mm × 131 mm

Weight 6.1 kg

Colour Black

BLS-315 Pro Lighting Stand B

speaker / light stand

Æ 1.20 m

Æ 28 mm

Flange, Æ 35 mm

Adapter Æ 35 mm/36 mm

Further information

Stand type Lighting stand

Incl. truss beam No

Crank No

Material Steel / magnesium compound

Technical specications

BLS-315 Pro Lighting Stand B speaker / light stand
