ThinkPad X140e User Manual

UserGuide

ThinkPadX140e

Note:Beforeusingthisinformationandtheproductitsupports,besuretoreadandunderstandthefollowing:

•Safety,Warranty,andSetupGuide

•RegulatoryNotice

•“Importantsafetyinformation”onpagevi

•AppendixE“Notices”onpage135

ThelatestSafety,Warranty,andSetupGuideandtheRegulatoryNoticeareavailableontheLenovoSupport
Websiteat:
http://www.lenovo.com/ThinkPadUserGuides

FirstEdition(October2013)

©CopyrightLenovo2013.

LIMITEDANDRESTRICTEDRIGHTSNOTICE:IfdataorsoftwareisdeliveredpursuantaGeneralServicesAdministration
“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionssetforthinContractNo.GS-35F-05925.

Contents

Readthisrst..............v

Importantsafetyinformation..........vi

Conditionsthatrequireimmediateaction..vii

Safetyguidelines............vii

Chapter1.Productoverview......1

Locatingcomputercontrols,connectors,and

indicators..................1

Frontview................1

Right-sideview..............3

Left-sideview..............4

Bottomview...............5

Statusindicators.............6

Locatingimportantproductinformation......8

Machinetypeandmodellabel........8

FCCIDandICCerticationnumberlabel...9

CerticateofAuthenticitylabel.......9

GenuineMicrosoftlabel.........10

Features.................10

Specications...............11

Operatingenvironment...........12

Lenovoprograms.............12

AccessingLenovoprogramsontheWindows

7operatingsystem...........12

AccessingLenovoprogramsontheWindows

8operatingsystem...........14

AnintroductiontoLenovoprograms....14

Chapter2.Usingyourcomputer...17

Registeringyourcomputer..........17

Frequentlyaskedquestions.........17

Specialkeysandbuttons..........19

Functionkeycombinations........19

Windowskey.............21

UsingtheThinkPadpointingdevice......21

Powermanagement............23

Checkingthebatterystatus........23

Usingtheacpoweradapter........24

Chargingthebattery..........24

Maximizingthebatterylife........24

Managingthebatterypower.......25

Power-savingmodes..........25

Handlingthebattery...........26

Connectingtothenetwork..........28

Ethernetconnections..........28

Wirelessconnections..........28

Presentationsandmultimedia.........31

Changingdisplaysettings........31

Connectingaprojectororanexternal

monitor................31

Usingdualdisplays...........33

Usingaudiofeatures............33

Usingtheintegratedcamera.........34

Usingaashmediacard...........35

Insertingaashmediacard........35

Removingaashmediacard.......35

Chapter3.Youandyourcomputer..37

Accessibilityandcomfort..........37

Ergonomicinformation..........37

Comfort...............38

Accessibilityinformation.........38

Travelingwithyourcomputer.........39

Traveltips...............39

Travelaccessories...........39

Chapter4.Security..........41

Attachingamechanicallock.........41

Usingpasswords..............41

Passwordsandsleepmode........41

Typingpasswords...........41

Power-onpassword...........42

Harddiskpasswords..........42

Supervisorpassword..........44

Harddisksecurity.............46

Noticeondeletingdatafromyourharddiskdrive

orsolid-statedrive.............46

Usingrewalls...............47

Protectingdataagainstviruses........47

Chapter5.Recoveryoverview....49

RecoveryoverviewfortheWindows7operating

system..................49

Creatingandusingarecoverymedia....49

Performingbackupandrecoveryoperations.50

UsingtheRescueandRecoveryworkspace.51

Creatingandusingarescuemedium....52

Reinstallingpreinstalledprogramsanddevice

drivers................53

Solvingrecoveryproblems........53

RecoveryoverviewfortheWindows8operating

system..................54

Refreshingyourcomputer........54

Resettingyourcomputertothefactorydefault

settings................54

©CopyrightLenovo2013

i

Usingtheadvancedstartupoptions....55

RecoveringyouroperatingsystemifWindows

8failstostart.............55

Creatingandusingrecoverymedia.....55

Chapter6.Replacingdevices.....57

Staticelectricityprevention..........57

Replacingthebattery............57

Replacingtheharddiskdriveorsolid-statedrive.59
ReplacingaPCIExpressMiniCardforwireless

LANconnection..............62

Replacingamemorymodule.........64

Replacingthekeyboard...........67

Replacingthebackupbattery.........72

Chapter7.Advancedconguration..75

Installinganewoperatingsystem.......75

Beforeyoubegin............75

InstallingtheWindows7operatingsystem..76
InstallingtheWindows8operatingsystem..77

Installingdevicedrivers...........77

Installingthedriverforthe4-in-1mediacard

reader................77

InstallingthedriverforUSB3.0onthe

Windows7operatingsystem.......77

InstallingtheThinkPadmonitorlefor
Windows2000/XP/Vista/7/8ontheWindows

7operatingsystem...........78

Installingotherdevicedriversandsoftwareon

theWindows7operatingsystem......78

ThinkPadSetup..............78

Mainmenu..............79

Congmenu..............79

Date/Timemenu............83

Securitymenu.............83

Startupmenu.............87

Restartmenu.............90

UpdatingyoursystemUEFIBIOS.....90

Usingsystemmanagement..........90

Systemmanagement..........90

Settingmanagementfeatures.......91

Chapter8.Preventingproblems...93

Generaltipsforpreventingproblems......93

Makingsuredevicedriversarecurrent.....94

Takingcareofyourcomputer.........95

Cleaningthecoverofyourcomputer....96

Chapter9.Troubleshootingcomputer

problems...............99

Diagnosingproblems............99

Troubleshooting..............99

Computerstopsresponding.......99

Spillsonthekeyboard..........100

Errormessages............100

Errorswithoutmessages.........102

Beeperrors..............103

Memorymoduleproblems........103

Networkingproblems..........104

Problemswiththekeyboardandotherpointing

devices................105

Problemswiththedisplayandmultimedia

devices................106

Batteryandpowerproblems.......111

Problemswithdrivesandotherstorage

devices................114

Asoftwareproblem...........114

Problemswithportsandconnectors....115

Chapter10.Gettingsupport....117

BeforeyoucontactLenovo..........117

Gettinghelpandservice...........117

Usingdiagnosticprograms........118

LenovoSupportWebsite.........118

CallingLenovo.............118

FindingThinkPadoptions........119

Purchasingadditionalservices........119

AppendixA.Regulatory

information.............121

Wirelessrelatedinformation.........121

LocationoftheUltraConnectwireless

antennas...............122

Locatingwirelessregulatorynotices....122

Exportclassicationnotice..........123

Electronicemissionnotices..........123

FederalCommunicationsCommission

DeclarationofConformity........123

IndustryCanadaClassBemissioncompliance

statement...............123

EuropeanUnion-Compliancetothe

ElectromagneticCompatibilityDirective...123

GermanClassBcompliancestatement...124

KoreaClassBcompliancestatement....124

JapanVCCIClassBcompliancestatement..125

Japancompliancestatementforproducts

whichconnecttothepowermainswith

ratedcurrentlessthanorequalto20Aper

phase................125

Lenovoproductserviceinformationfor

Taiwan................125

Eurasiancompliancemark..........125

AppendixB.WEEEandrecycling

statements.............127

ImportantWEEEInformation.........127

iiUserGuide

RecyclinginformationforJapan........127

BatteryrecyclinginformationforBrazil.....128

BatteryrecyclinginformationforTaiwan.....128

BatteryrecyclinginformationfortheEuropean

Union..................129

BatteryrecyclinginformationfortheUnitedStates

andCanada................129

AppendixC.ENERGYST ARmodel

information.............131

AppendixD.RestrictionofHazardous

SubstancesDirective(RoHS)....133

EuropeanUnionRoHS...........133

ChinaRoHS................133

TurkishRoHS...............133

UkraineRoHS...............134

IndiaRoHS................134

AppendixE.Notices.........135

Trademarks................136

©CopyrightLenovo2013

iii

ivUserGuide

Readthisrst

Besuretofollowtheimportanttipsgivenheretogetthemostuseandenjoymentoutofyourcomputer.
Failuretodosomightleadtodiscomfortorinjury,orcauseyourcomputertofail.

Protectyourselffromtheheatthatyourcomputergenerates.

Whenyourcomputeristurnedonorthebatteryischarging,thebase,thepalm
rest,andsomeotherpartsmaybecomehot.Thetemperaturetheyreach
dependsontheamountofsystemactivityandthelevelofchargeinthebattery.

Extendedcontactwithyourbody,eventhroughclothing,couldcause
discomfortorevenaskinburn.

•Avoidkeepingyourhands,yourlap,oranyotherpartofyourbodyin
contactwithahotsectionofthecomputerforanyextendedtime.

•Periodicallytakehandsfromusingthekeyboardbyliftingyourhandsfrom
thepalmrest.

Protectyourselffromtheheatgeneratedbytheacpoweradapter.

Whentheacpoweradapterisconnectedtoanelectricaloutletandyour
computer,itgeneratesheat.

Extendedcontactwithyourbody,eventhroughclothing,maycauseaskin
burn.

•Donotplacetheacpoweradapterincontactwithanypartofyourbody
whileitisinuse.

•Neveruseittowarmyourbody.

Preventyourcomputerfromgettingwet.

Toavoidspillsandthedangerofelectricalshock,keepliquidsawayfromyour
computer.

Protectthecablesfrombeingdamaged.

Applyingstrongforcetocablesmaydamageorbreakthem.

Routecommunicationlines,orthecablesofanacpoweradapter,amouse,a
keyboard,aprinter,oranyotherelectronicdevice,sothattheycannotbewalked
on,trippedover,pinchedbyyourcomputerorotherobjects,orinanyway
subjectedtotreatmentthatcouldinterferewiththeoperationofyourcomputer.

©CopyrightLenovo2013

v

Protectyourcomputeranddatawhenmovingit.

Beforemovingacomputerequippedwithaharddiskdrive,dooneofthe
following,andmakesurethatthepowerbuttonisofforisblinking:

•Turnitoff.

•Putitinsleepmode.

•Putitinhibernationmode.

Thiswillhelptopreventdamagetothecomputer,andpossiblelossofdata.

Handleyourcomputergently.

Donotdrop,bump,scratch,twist,hit,vibrate,push,orplaceheavyobjectson
yourcomputer,display,orexternaldevices.

Carryyourcomputercarefully.

•Useaqualitycarryingcasethatprovidesadequatecushioningandprotection.

•Donotpackyourcomputerinatightlypackedsuitcaseorbag.

•Beforeputtingyourcomputerinacarryingcase,makesurethatitisoff,insleep
mode,orinhibernationmode.Donotputacomputerinacarryingcasewhileit
isturnedon.

Importantsafetyinformation

Note:Readtheimportantsafetyinformationrst.

Thisinformationcanhelpyousafelyuseyournotebookcomputer.Followandretainallinformationincluded
withyourcomputer.Theinformationinthisdocumentdoesnotalterthetermsofyourpurchaseagreement
ortheLenovo

®

LimitedWarranty.Formoreinformation,see“WarrantyInformation”intheSafety,Warranty,

andSetupGuidethatcomeswithyourcomputer.

Customersafetyisimportant.Ourproductsaredevelopedtobesafeandeffective.However,personal
computersareelectronicdevices.Powercords,poweradapters,andotherfeaturescancreatepotential
safetyrisksthatcanresultinphysicalinjuryorpropertydamage,especiallyifmisused.T oreducethese
risks,followtheinstructionsincludedwithyourproduct,observeallwarningsontheproductandinthe
operatinginstructions,andreviewtheinformationincludedinthisdocumentcarefully.Bycarefullyfollowing
theinformationcontainedinthisdocumentandprovidedwithyourproduct,youcanhelpprotectyourself
fromhazardsandcreateasafercomputerworkenvironment.

Note:Thisinformationincludesreferencestopoweradaptersandbatteries.Inadditiontonotebook
computers,someproducts(suchasspeakersandmonitors)shipwithexternalpoweradapters.Ifyouhave
suchaproduct,thisinformationappliestoyourproduct.Inaddition,computerproductscontainacoin-sized
internalbatterythatprovidespowertothesystemclockevenwhenthecomputerisunplugged,sothe
batterysafetyinformationappliestoallcomputerproducts.

viUserGuide

Conditionsthatrequireimmediateaction

Productscanbecomedamagedduetomisuseorneglect.Someproductdamageisseriousenough
thattheproductshouldnotbeusedagainuntilithasbeeninspectedand,ifnecessary,repairedby
anauthorizedservicer.

Aswithanyelectronicdevice,paycloseattentiontotheproductwhenitisturnedon.Onveryrare
occasions,youmightnoticeanodororseeapuffofsmokeorsparksventfromyourproduct.Oryou
mighthearsoundslikepopping,crackingorhissing.Theseconditionsmightmerelymeanthatan
internalelectroniccomponenthasfailedinasafeandcontrolledmanner .Or,theymightindicate
apotentialsafetyissue.However,donottakerisksorattempttodiagnosethesituationyourself.
ContacttheCustomerSupportCenterforfurtherguidance.ForalistofServiceandSupportphone
numbers,seethefollowingWebsite:
http://www.lenovo.com/support/phone

Frequentlyinspectyourcomputeranditscomponentsfordamageorwearorsignsofdanger.Ifyou
haveanyquestionabouttheconditionofacomponent,donotusetheproduct.ContacttheCustomer
SupportCenterortheproductmanufacturerforinstructionsonhowtoinspecttheproductand
haveitrepaired,ifnecessary.

Intheunlikelyeventthatyounoticeanyofthefollowingconditions,orifyouhaveanysafetyconcerns
withyourproduct,stopusingtheproductandunplugitfromthepowersourceandtelecommunication
linesuntilyoucanspeaktotheCustomerSupportCenterforfurtherguidance.

•Powercords,plugs,poweradapters,extensioncords,surgeprotectors,orpowersuppliesthatare
cracked,broken,ordamaged.

•Signsofoverheating,smoke,sparks,orre.

•Damagetoabattery(suchascracks,dents,orcreases),dischargefromabattery,orabuildupofforeign
substancesonthebattery.

•Acracking,hissingorpoppingsound,orstrongodorthatcomesfromtheproduct.

•Signsthatliquidhasbeenspilledoranobjecthasfallenontothecomputerproduct,thepowercordor
poweradapter.

•Thecomputerproduct,powercord,orpoweradapterhasbeenexposedtowater.

•Theproducthasbeendroppedordamagedinanyway.

•Theproductdoesnotoperatenormallywhenyoufollowtheoperatinginstructions.

Note:Ifyounoticetheseconditionswithaproduct(suchasanextensioncord)thatisnotmanufacturedfor
orbyLenovo,stopusingthatproductuntilyoucancontacttheproductmanufacturerforfurtherinstructions,
oruntilyougetasuitablereplacement.

Safetyguidelines

Alwaysobservethefollowingprecautionstoreducetheriskofinjuryandpropertydamage.

Serviceandupgrades

DonotattempttoserviceaproductyourselfunlessinstructedtodosobytheCustomerSupportCenteror
yourdocumentation.OnlyuseaServiceProviderwhoisapprovedtorepairyourparticularproduct.

Note:Somecomputerpartscanbeupgradedorreplacedbythecustomer.Upgradestypicallyare
referredtoasoptions.ReplacementpartsapprovedforcustomerinstallationarereferredtoasCustomer
ReplaceableUnits,orCRUs.Lenovoprovidesdocumentationwithinstructionswhenitisappropriatefor
customerstoinstalloptionsorreplaceCRUs.Youmustcloselyfollowallinstructionswheninstallingor
replacingparts.TheOffstateofapowerindicatordoesnotnecessarilymeanthatvoltagelevelsinsidea
productarezero.Beforeyouremovethecoversfromaproductequippedwithapowercord,alwaysmake

©CopyrightLenovo2013

vii

surethatthepoweristurnedoffandthattheproductisunpluggedfromanypowersource.Ifyouhave
anyquestionsorconcerns,contacttheCustomerSupportCenter.

Althoughtherearenomovingpartsinyourcomputerafterthepowercordhasbeendisconnected,the
followingwarningsarerequiredforyoursafety.

CAUTION:
Hazardousmovingparts.Keepngersandotherbodypartsaway.

CAUTION:

BeforereplacinganyCRUs,turnoffthecomputerandwaitthreetoveminutestoletthecomputer
coolbeforeopeningthecover.

Powercordsandpoweradapters

DANGER

Useonlythepowercordsandpoweradapterssuppliedbytheproductmanufacturer.

Thepowercordsshallbesafetyapproved.ForGermany,itshallbeH05VV-F ,3G,0.75mm

2

,or

better.Forothercountries,thesuitabletypesshallbeusedaccordingly.

Neverwrapapowercordaroundapoweradapterorotherobject.Doingsocanstressthecordin
waysthatcancausethecordtofray,crack,orcrimp.Thiscanpresentasafetyhazard.

Alwaysroutepowercordssothattheywillnotbewalkedon,trippedover,orpinchedbyobjects.

Protectpowercordsandpoweradaptersfromliquids.Forinstance,donotleaveyourpowercord
orpoweradapternearsinks,tubs,toilets,oronoorsthatarecleanedwithliquidcleansers.
Liquidscancauseashortcircuit,particularlyifthepowercordorpoweradapterhasbeenstressed
bymisuse.Liquidsalsocancausegradualcorrosionofpowercordterminalsand/ortheconnector
terminalsonapoweradapter,whichcaneventuallyresultinoverheating.

Alwaysconnectpowercordsandsignalcablesinthecorrectorderandensurethatallpowercord
connectorsaresecurelyandcompletelypluggedintoreceptacles.

Donotuseanypoweradapterthatshowscorrosionattheacinputpinsorshowssignsof
overheating(suchasdeformedplastic)attheacinputpinsoranywhereonthepoweradapter.

Donotuseanypowercordswheretheelectricalcontactsoneitherendshowsignsofcorrosionor
overheatingorwherethepowercordappearstohavebeendamagedinanyway.

viiiUserGuide

Topreventpossibleoverheating,donotcoverthepoweradapterwithclothingorotherobjects
whenthepoweradapterispluggedintoanelectricaloutlet.

Extensioncordsandrelateddevices

Ensurethatextensioncords,surgeprotectors,uninterruptiblepowersupplies,andpowerstripsthatyouuse
areratedtohandletheelectricalrequirementsoftheproduct.Neveroverloadthesedevices.Ifpowerstrips
areused,theloadshouldnotexceedthepowerstripinputrating.Consultanelectricianformoreinformation
ifyouhavequestionsaboutpowerloads,powerrequirements,andinputratings.

Plugsandoutlets

DANGER

Ifareceptacle(poweroutlet)thatyouintendtousewithyourcomputerequipmentappearstobe
damagedorcorroded,donotusetheoutletuntilitisreplacedbyaqualiedelectrician.

Donotbendormodifytheplug.Iftheplugisdamaged,contactthemanufacturertoobtain
areplacement.

Donotshareanelectricaloutletwithotherhomeorcommercialappliancesthatdrawlargeamounts
ofelectricity;otherwise,unstablevoltagemightdamageyourcomputer,data,orattacheddevices.

Someproductsareequippedwithathree-prongedplug.Thisplugtsonlyintoagrounded
electricaloutlet.Thisisasafetyfeature.Donotdefeatthissafetyfeaturebytryingtoinsertitinto
anon-groundedoutlet.Ifyoucannotinserttheplugintotheoutlet,contactanelectricianforan
approvedoutletadapterortoreplacetheoutletwithonethatenablesthissafetyfeature.Never
overloadanelectricaloutlet.Theoverallsystemloadshouldnotexceed80percentofthebranch
circuitrating.Consultanelectricianformoreinformationifyouhavequestionsaboutpowerloads
andbranchcircuitratings.

Besurethatthepoweroutletyouareusingisproperlywired,easilyaccessible,andlocatedclose
totheequipment.Donotfullyextendpowercordsinawaythatwillstressthecords.

Besurethatthepoweroutletprovidesthecorrectvoltageandcurrentfortheproductyouare
installing.

Carefullyconnectanddisconnecttheequipmentfromtheelectricaloutlet.

Powersupplystatement

DANGER

Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.

©CopyrightLenovo2013

ix

Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabel
attached.Therearenoserviceablepartsinsidethesecomponents.Ifyoususpectaproblemwith
oneoftheseparts,contactaservicetechnician.

Externaldevices

CAUTION:
DonotconnectordisconnectanyexternaldevicecablesotherthanUSBcableswhilethecomputer
powerison;otherwise,youmightdamageyourcomputer.T oavoidpossibledamagetoattached
devices,waitatleastvesecondsafterthecomputerisshutdowntodisconnectexternaldevices.

Generalbatterynotice

DANGER

PersonalcomputersmanufacturedbyLenovocontainacoincellbatterytoprovidepowerto
thesystemclock.Inaddition,manymobileproducts,suchasnotebookcomputers,utilizea
rechargeablebatterypacktoprovidesystempowerwheninportablemode.Batteriessuppliedby
Lenovoforusewithyourproducthavebeentestedforcompatibilityandshouldonlybereplaced
withapprovedparts.

Neverattempttoopenorserviceanybattery.Donotcrush,puncture,orincineratebatteriesor
shortcircuitthemetalcontacts.Donotexposethebatterytowaterorotherliquids.Onlyrecharge
thebatterypackstrictlyaccordingtoinstructionsincludedintheproductdocumentation.

Batteryabuseormishandlingcancausethebatterytooverheat,whichcancausegassesorame
to“vent”fromthebatterypackorcoincell.Ifyourbatteryisdamaged,orifyounoticeany
dischargefromyourbatteryorthebuildupofforeignmaterialsonthebatteryleads,stopusingthe
batteryandobtainareplacementfromthebatterymanufacturer.

Batteriescandegradewhentheyareleftunusedforlongperiodsoftime.Forsomerechargeable
batteries(particularlyLithiumIonbatteries),leavingabatteryunusedinadischargedstatecould
increasetheriskofabatteryshortcircuit,whichcouldshortenthelifeofthebatteryandalsocan
poseasafetyhazard.DonotletrechargeableLithium-Ionbatteriescompletelydischargeorstore
thesebatteriesinadischargedstate.

Rechargeablebatterynotice

DANGER

Donotattempttodisassembleormodifythebatterypack.Attemptingtodosocancausean
explosion,orliquidleakagefromthebatterypack.Abatterypackotherthantheonespeciedby
Lenovo,oradisassembledormodiedbatterypackisnotcoveredbythewarranty.

Iftherechargeablebatterypackisincorrectlyreplaced,thereisdangerofanexplosion.Thebattery
packcontainsasmallamountofharmfulsubstances.T oavoidpossibleinjury:

•ReplaceonlywithabatteryofthetyperecommendedbyLenovo.

•Keepthebatterypackawayfromre.

•Donotexposeittowaterorrain.

•Donotattempttodisassembleit.

•Donotshort-circuitit.

xUserGuide

•Keepitawayfromchildren.

•Donotdropthebatterypack.

Donotputthebatterypackintrashthatisdisposedofinlandlls.Whendisposingofthebattery,
complywithlocalordinancesorregulations.

Thebatterypackshouldbestoredatroomtemperature,chargedtoapproximately30to50%
ofcapacity.Werecommendthatbatterypackbechargedaboutonceperyeartoprevent
overdischarge.

Lithiumcoincellbatterynotice

DANGER

Dangerofexplosionifbatteryisincorrectlyreplaced.

Whenreplacingthelithiumcoincellbattery,useonlythesameoranequivalenttypethatis
recommendedbythemanufacturer.Thebatterycontainslithiumandcanexplodeifnotproperly
used,handled,ordisposedof.

Donot:

•Throworimmerseintowater

•Heattomorethan100°C(212°F)

•Repairordisassemble

Disposeofthebatteryasrequiredbylocalordinancesorregulations.

ThefollowingstatementappliestousersinthestateofCalifornia,U.S.A.

CaliforniaPerchlorateInformation:

Productscontainingmanganesedioxidelithiumcoincellbatteriesmaycontainperchlorate.

PerchlorateMaterial-specialhandlingmayapply,See
www.dtsc.ca.gov/hazardouswaste/perchlorate

Heatandproductventilation

DANGER

Computers,acpoweradapters,andmanyaccessoriescangenerateheatwhenturnedonandwhen
batteriesarecharging.Notebookcomputerscangenerateasignicantamountofheatduetotheir
compactsize.Alwaysfollowthesebasicprecautions:

•Whenyourcomputeristurnedonorthebatteryischarging,thebase,thepalmrest,andsome
otherpartsmaybecomehot.Avoidkeepingyourhands,yourlap,oranyotherpartofyour
bodyincontactwithahotsectionofthecomputerforanyextendedlengthoftime.Whenyou
usethekeyboard,avoidkeepingyourpalmsonthepalmrestforaprolongedperiodoftime.
Yourcomputergeneratessomeheatduringnormaloperation.Theamountofheatdependson
theamountofsystemactivityandthebatterychargelevel.Extendedcontactwithyourbody,
eventhroughclothing,couldcausediscomfortorevenaskinburn.Periodicallytakebreaks

©CopyrightLenovo2013

xi

fromusingthekeyboardbyliftingyourhandsfromthepalmrest;andbecarefulnottouse
thekeyboardforanyextendedlengthoftime.

•Donotoperateyourcomputerorchargethebatterynearammablematerialsorinexplosive
environments.

•Ventilationslots,fansand/orheatsinksareprovidedwiththeproductforsafety,comfort,and
reliableoperation.Thesefeaturesmightinadvertentlybecomeblockedbyplacingtheproducton
abed,sofa,carpet,orotherexiblesurface.Neverblock,cover,ordisablethesefeatures.

•Whentheacpoweradapterisconnectedtoanelectricaloutletandyourcomputer,itgenerates
heat.Donotplacetheadapterincontactwithanypartofyourbodywhileusingit.Neverusethe
acpoweradaptertowarmyourbody.Extendedcontactwithyourbody,eventhroughclothing,
maycauseaskinburn.

Foryoursafety,alwaysfollowthesebasicprecautionswithyourcomputer:

•Keepthecoverclosedwheneverthecomputerispluggedin.

•Regularlyinspecttheoutsideofthecomputerfordustaccumulation.

•Removedustfromventsandanyperforationsinthebezel.Morefrequentcleaningsmightbe
requiredforcomputersindustyorhigh-trafcareas.

•Donotrestrictorblockanyventilationopenings.

•Donotoperateyourcomputerinsidefurniture,asthismightincreasetheriskofoverheating.

•Airowtemperaturesintothecomputershouldnotexceed35°C(95°F).

Electricalcurrentsafetyinformation

DANGER

Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.

Toavoidashockhazard:

•Donotuseyourcomputerduringalightningstorm.

•Donotconnectordisconnectanycablesorperforminstallation,maintenance,orreconguration
ofthisproductduringanelectricalstorm.

•Connectallpowercordstoaproperlywiredandgroundedelectricaloutlet.

•Connecttoproperlywiredoutletsanyequipmentthatwillbeattachedtothisproduct.

•Wheneverpossible,useonehandonlytoconnectordisconnectsignalcables.

•Neverturnonanyequipmentwhenthereisevidenceofre,water,orstructuraldamage.

•Disconnecttheattachedpowercords,batterypack,andallthecablesbeforeyouopenthe
devicecovers,unlessinstructedotherwiseintheinstallationandcongurationprocedures.

•Donotuseyourcomputeruntilallinternalpartsenclosuresarefastenedintoplace.Neveruse
thecomputerwheninternalpartsandcircuitsareexposed.

xiiUserGuide

DANGER

Connectanddisconnectcablesasdescribedinthefollowingprocedureswheninstalling,moving,
oropeningcoversonthisproductorattacheddevices.

Toconnect:

1.TurneverythingOFF.

2.First,attachallcablestodevices.

3.Attachsignalcablestoconnectors.

4.Attachpowercordstooutlets.

5.TurndevicesON.

Todisconnect:

1.TurneverythingOFF.

2.First,removepowercordsfromoutlets.

3.Removesignalcablesfromconnectors.

4.Removeallcablesfromdevices.

Thepowercordmustbedisconnectedfromthewalloutletorreceptaclebeforeinstallingallother
electricalcablesconnectedtothecomputer.

Thepowercordmaybereconnectedtothewalloutletorreceptacleonlyafterallotherelectrical
cableshavebeenconnectedtothecomputer.

Liquidcrystaldisplay(LCD)notice

CAUTION:
Theliquidcrystaldisplay(LCD)ismadeofglass,androughhandlingordroppingthecomputercan
causetheLCDtobreak.IftheLCDbreaksandtheinternaluidgetsintoyoureyesoronyour
hands,immediatelywashtheaffectedareaswithwaterforatleast15minutes;ifanysymptomsare
presentafterwashing,getmedicalcare.

Note:Forproductswithmercury-containinguorescentlamps(forexample,non-LED),theuorescentlamp

intheLiquidcrystaldisplay(LCD)containsmercury;disposeofaccordingtolocal,state,orfederallaws.

Usingheadphonesorearphones

CAUTION:
Excessivesoundpressurefromearphonesandheadphonescancausehearingloss.Adjustmentof
theequalizertomaximumincreasestheearphoneandheadphoneoutputvoltageandthesound
pressurelevel.Therefore,toprotectyourhearing,adjusttheequalizertoanappropriatelevel.

Excessiveuseofheadphonesorearphonesforalongperiodoftimeathighvolumecanbedangerousifthe
outputoftheheadphoneorearphoneconnectorsdonotcomplywithspecicationsofEN50332-2.The
headphoneoutputconnectorofyourcomputercomplieswithEN50332-2Subclause7.Thisspecication
limitsthecomputer’smaximumwidebandtrueRMSoutputvoltageto150mV.Tohelpprotectagainst
hearingloss,ensurethattheheadphonesorearphonesyouusealsocomplywithEN50332-2(Clause7
limits)forawidebandcharacteristicvoltageof75mV.UsingheadphonesthatdonotcomplywithEN
50332-2canbedangerousduetoexcessivesoundpressurelevels.

IfyourLenovocomputercamewithheadphonesorearphonesinthepackage,asaset,thecombinationof
theheadphonesorearphonesandthecomputeralreadycomplieswiththespecicationsofEN50332-1.
Ifdifferentheadphonesorearphonesareused,ensurethattheycomplywithEN50332-1(Clause6.5
LimitationValues).UsingheadphonesthatdonotcomplywithEN50332-1canbedangerousdueto
excessivesoundpressurelevels.

©CopyrightLenovo2013

xiii

Additionalsafetyinformation

DANGER

Plasticbagscanbedangerous.Keepplasticbagsawayfrombabiesandchildrentoavoiddanger
ofsuffocation.

Noticefortabletpersonalcomputerusers

SafetynoticeforusersinAustralia

DANGER

Donotconnectphonelinewhileusingtabletmode.

NoticeforusersintheU.S.A.

Manypersonalcomputerproductsandaccessoriescontaincords,cablesorwires,suchaspowercordsor
cordstoconnecttheaccessorytoapersonalcomputer.Ifthisproducthassuchacord,cableorwire,then
thefollowingwarningapplies:

WARNING:Handlingthecordonthisproductorcordsassociatedwithaccessoriessoldwiththisproduct
willexposeyoutolead,achemicalknowntotheStateofCaliforniatocausecancer,andbirthdefectsor
otherreproductiveharm.Washhandsafterhandling.

Savetheseinstructions.

xivUserGuide

Chapter1.Productoverview

Thischapterprovidesinformationaboutconnectorlocations,importantproductlabels,computerfeatures,
specications,operatingenvironment,andpreinstalledprograms.

Thischaptercontainsthefollowingtopics:

•“Locatingcomputercontrols,connectors,andindicators”onpage1

•“Locatingimportantproductinformation”onpage8

•“Features”onpage10

•“Specications”onpage11

•“Operatingenvironment”onpage12

•“Lenovoprograms”onpage12

Locatingcomputercontrols,connectors,andindicators

Thissectionintroducesthecomputerhardwarefeaturestogiveyouthebasicinformationyouneedto
startusingthecomputer.

Frontview

Figure1.ThinkPadX140efrontview

1Integratedcamera5T rackPointpointingstick

2Systemstatusindicator(illuminatedThinkPad

®

logo)

6Built-inmicrophone

3T rackPoint

®

buttons7Powerbutton

4Touchpad

©CopyrightLenovo2013

1

1Camera

Usethecameratotakepicturesorholdavideoconference.Formoreinformation,see“Usingtheintegrated
camera”onpage34.

2Systemstatusindicator(illuminatedThinkPadlogo)

TheilluminatedThinkPadlogoonthepalmrestfunctionsasasystemstatusindicator.Yourcomputerhas
severalstatusindicators.Formoreinformation,see“Systemstatusindicators”onpage6.

ThinkPadpointingdevice

3T rackPointbuttons
4T ouchpad
5TrackPointpointingstick

ThekeyboardcontainstheLenovouniqueThinkPadpointingdevice.Pointing,selecting,anddraggingareall
partofasingleprocessthatyoucanperformwithoutmovingyourngersfromatypingposition.Formore
information,see“UsingtheThinkPadpointingdevice”onpage21.

6Microphones

Thebuilt-inmicrophonescapturesoundandvoicewhenusedwithaprogramcapableofhandlingaudio.

7Powerbutton

Usethepowerbuttontoturnonthecomputer.

Toturnoffthecomputer,usetheStartmenushutdownoptionontheWindows

®

7operatingsystem.For
theWindows8operatingsystem,movethecursortothetop-rightorbottom-rightcornerofthescreento
displaythecharms.ThenclickSettings➙Power➙Shutdown.

Ifyourcomputerstopsrespondingandyoucannotturnitoff,pressandholdthepowerbuttonforfour
secondsormore.Ifthecomputerstillisnotresponding,removetheacpoweradapterandthebattery
toresetthecomputer.

Youalsocanprogramthepowerbuttonsothatbypressingthepowerbuttonyoucanshutdownthe
computerorputitintosleeporhibernationmode.T oachievethis,youneedtochangeyourpowerplan
settings.Toaccesspowerplansettings,dothefollowing:

•ForWindows7:StartthePowerManagerprogramandthenclickthePowerPlantab.Forinstructionson

howtostartthePowerManagerprogram,see“AccessingLenovoprogramsontheWindows7operating
system”onpage12

.

•ForWindows8:ClickthebatterystatusiconintheWindowsnoticationareaandclickMorepower

options.ThenclickChoosewhatthepowerbuttonsdo.

2UserGuide

Right-sideview

Figure2.ThinkPadX140eright-sideview

1Mediacardreaderslot4Power-statusindicator

2HDMIport5Powerconnector

3AlwaysOnUSBconnector6Security-lockslot

1Mediacardreaderslot

Dependingonthemodels,yourcomputermighthaveamediacardreaderslot.Formoreinformationabout
thesupportedcards,see“Usingaashmediacard”onpage35.

2HDMIport

Yourcomputersupportsthehigh-denitionmultimediainterface(HDMI)port,adigitalaudioandvideo
interfacethatcanconnectacompatibledigitalaudiodeviceorvideomonitor,suchasanHDTV.

3AlwaysonUSBconnector

Bydefault,theAlwaysOnUSBconnectorenablesyoutochargesomemobiledigitaldevicesand
smartphoneswhenyourcomputerisinsleeporhibernationmode.

Ifyouwanttochargethesedeviceswhenyourcomputeristurnedoff,dothefollowing:

1.Connectthecomputertoanacpowersupply.

2.GotoThinkPadSetupandenableAlwaysOnUSBChargeinoffmode.Formoreinformation,see
“Congmenu”onpage79.

3.Dooneofthefollowing:

•ForWindows7:StartthePowerManagerprogramandclicktheGlobalPowerSettingstab.Then

selecttheEnableAlwaysOnUSBcheckbox.

•ForWindows8:PresstheWindowskeytogototheStartscreen.ClickLenovoSettings➙Power.

ThenselecttheEnablewhenthecomputerisoffcheckbox.

Chapter1.Productoverview3

4Power-statusindicator

Yourcomputerhasapowerstatusindicatortoshowtheacpoweradapterstatusofyourcomputer.For
moreinformation,see“Powerstatusindicator”onpage7.

5Powerconnector

Connecttheacpoweradaptertothepowerconnectortoprovideacpowertothecomputerandcharge
thebattery.

Anindicatortotheleftoftheconnectorshowsthestatusofacpower.Whentheacpoweradapteris
connected,theindicatorislit.Ifabatteryisinstalledinthecomputer,theindicatorisgreenwhenthe
batterycharges.

6Security-lockslot

Purchaseasecuritycablelockthattsthiskeyholetolockyourcomputertoastationaryobjecttoprotect
yourcomputerfromtheft.

Left-sideview

Figure3.ThinkPadX140eleft-sideview

1Videographicsarray(VGA)connector

4Ethernetconnector

2Fanlouver

5Comboaudioconnector

3USB3.0connectors

1Videographicsarray(VGA)connector

AttachaVGAcompatiblemonitororprojectortoyourcomputertodisplaythecomputeroutput.

2Fanlouver

Thefanlouversandtheinternalfanenableairtocirculateinthecomputertoensurepropercooling,
especiallythecoolingofthemicroprocessor.

4UserGuide

Note:Toensureproperairow,donotplaceanyobstaclesinfrontofthefanlouvers.

3USB3.0connectors

TheUniversalSerialBus(USB)3.0connectorsareusedforconnectingdevicescompatiblewithaUSB
interface,suchasaUSBprinteroradigitalcamera.

Note:WhenyouattachaUSBcabletotheconnector,makesurethattheUSBmarkisfacingupward.
Otherwisetheconnectormightbedamaged.

4Ethernetconnector

ConnectyourcomputertoaLANwiththeEthernetconnector.

DANGER

Toavoidtheriskofelectricalshock,donotconnectthetelephonecabletotheEthernetconnector.
YoucanonlyconnectanEthernetcabletothisconnector.

Twoindicators,totheupperrightandleftoftheconnector,showthestatusofthenetworkconnection.
WhenyourcomputerconnectstoaLANandasessionwiththenetworkisavailable,theupperleftindicator
issteadygreen.Whiledataisbeingtransmitted,theupperrightindicatorblinksyellow.

5Comboaudioconnector

Tolistentothesoundfromyourcomputer,connectaheadphoneoraheadsetthathasa3.5mm4-poleplug
tothecomboaudioconnector.

Notes:

•Ifyouareusingaheadsetwithafunctionswitch,donotpressthisswitchwhileusingtheheadset.If
youpresstheswitch,theheadsetmicrophonewillbedisabled,andtheintegratedmicrophoneson
thecomputerwillbeenabledinstead.

•Thecomboaudioconnectordoesnotsupportaconventionalmicrophone.Formoreinformation,see
“Usingaudiofeatures”onpage33.

Bottomview

Figure4.ThinkPadX140ebottomview

Chapter1.Productoverview5

1Battery3WirelessLANcardslot

2Memoryupgradeslot4Harddiskdriveorsolid-statedrive

1Battery

Useyourcomputerwiththebatterypowerwheneveracpowerisunavailable.

2Memory-upgradeslot

Youcanincreasetheamountofmemoryinyourcomputerbyinstallingamemorymoduleinthe
memory-upgradeslot.MemorymodulesareavailableasoptionsfromLenovo.

3WirelessLANcardslot

Yourcomputerincludesawirelesslocalareanetwork(LAN)cardforyoutoestablishwirelessLAN
connections.

4Harddiskdriveorsolid-statedrive

Dependingonmodels,yourcomputermighthavealarge-capacity,customer-upgradableharddiskdrive
thatcanmeetavarietyofstoragedemands.

Somemodelsareequippedwithasolid-statedrivefordatastorage,makingyourcomputerlighter,smaller,
andfaster.

Note:Thehiddenservicepartitionisthereasonwhythereislessfreespacethanexpectedonyourhard
diskdriveorsolid-statedrive.Thisreductionismorenoticeableonthesolid-statedrivebecauseofits
smallercapacity.

Statusindicators

Thestatusindicatorsshowthecurrentstatusofyourcomputer.

Systemstatusindicators

TheilluminateddotintheThinkPadlogoontheouterlidofyourcomputerandonthepalmrestworks
asasystemstatusindicator.

6UserGuide

Themeaningoftheindicatorisasfollows:

•Red:Thecomputerison(innormalmode).

•Fastblinkingred:Thecomputerisenteringsleeporhibernationmode.

•Slowblinkingred:Thecomputerisinsleepmode.

•Off:Thecomputerisofforinhibernationmode.

Wirelessstatusindicator

Thewirelessstatusindicatorislocatedontheouterlidofthecomputer.

Themeaningoftheindicatorisasfollows:

•Solidgreen:Thewirelessfeaturesofthecomputerareon.

•Off:Thewirelessfeaturesofthecomputerareoff.

Powerstatusindicator

Yourcomputerhasanindicatorthatshowsthestatusofacpower.

Chapter1.Productoverview7

Themeaningoftheindicatorisasfollows:

•Green:Theacpoweradapterisconnected.

•Off:Theacpoweradapterisnotconnected.

CapsLockindicator

PresstheCapsLockkeytoenabletheCapsLockmodetotypeallalphabeticcharacters(A-Z)inuppercase
directly.WhentheCapsLockmodeisenabled,theCapsLockindicatorisdisplayedonthescreen.

Locatingimportantproductinformation

Thissectionprovidesinformationtohelpyoulocateyourmachinetypeandmodellabel,FCCIDandIC
Certicationlabel,andtheMicrosoft

®

CerticateofAuthenticity(COA)label.

Machinetypeandmodellabel

Themachinetypeandmodellabelidentiesyourcomputer.WhenyoucontactLenovoforhelp,themachine
typeandmodelinformationhelpssupporttechnicianstoidentifyyourcomputerandprovidefasterservice.

Youcanndthemachinetypeandmodelofyourcomputeronthelabelasshownbelow:

8UserGuide

FCCIDandICCerticationnumberlabel

ThereisnoFCCIDorICCerticationnumberforthePCIExpressMiniCardshownontheenclosureof
yourcomputer.TheFCCIDandICCerticationnumberlabelisafxedonthecardinstalledinthePCI
ExpressMiniCardslotofyourcomputer.

Note:OnlyLenovoauthorizedwirelessLANcardsareallowedtobeusedinyourcomputer.Ifyouinstallan
unauthorizedPCIExpressMiniCardthatisnotapprovedforuseinyourcomputer,thecomputerwillnot
start,butwillonlydisplayanerrormessageandemitaudiblebeeps.

CerticateofAuthenticitylabel

TheCerticateofAuthenticitylabelforthepreinstalledoperatingsystemisattached.Printedonthislabelare
theproductIDandtheproductkeyinformationforyourcomputer.Recordthisinformationandkeepitina
safeplace.Youmightneedthesenumberstostartyourcomputerorreinstalltheoperatingsystem.

Note:TheCerticateofAuthenticitylabelappliesonlytocomputerspreinstalledwiththeWindows7
operatingsystem.

Chapter1.Productoverview9

TheCerticateofAuthenticitylabelofyourcomputerisshownasbelow:

GenuineMicrosoftlabel

TheGenuineMicrosoftlabelisprovidedonmodelsthatarelicensedtouseaWindows8operatingsystem.
TheversionoftheWindows8operatingsystemisprintedonthelabel.Ifyourcomputermodelislicensedto
usetheWindows8Prooperatingsystem,thatlicensealsopermitsyoutousetheWindows7Professional
operatingsysteminplaceoftheWindows8Prooperatingsystemifyouprefer.Lenovocomputersthatare
licensedforusewithaWindows8operatingsystemareshippedwiththeWindows8licensekeydigitally
encodedintothecomputerhardware.Dependingonthecomputermodel,theGenuineMicrosoftlabelcan
beonthecomputercover,underthebattery,oronthepoweradapter.

FormoreinformationabouttheGenuineMicrosoftlabel,goto:
http://www.microsoft.com/en-us/howtotell/Hardware.aspx

ThefollowinggureshowsthelocationoftheGenuineMicrosoftlabelonthecomputercover:

Features

Thistopicliststhefeaturesofyourcomputer.

Processor

•Toviewtheprocessorinformationofyourcomputer,dothefollowing:

–ForWindows7:ClickStart,right-clickComputer.ThenclickProperties.
–ForWindows8:Movethecursortothetop-rightorbottom-rightcornerofthescreentodisplaythe

charms.ThenclickSettings➙PCinfo.

Memory

•Doubledatarate3synchronousdynamicrandomaccessmemorymodules(DDR3SDRAM)

10UserGuide

Storagedevice

•2.5-inch(7mmheight)harddiskdriveor2.5-inch(7mmheight)solid-statedrive

Display

ThecolordisplayusestheTFTtechnology.

•Size:11.6inches(294.64mm)

•Resolution:

–LCD:Upto1366x768
–Externalmonitor:Upto2048x1536(VGA)orupto2560x1600(HDMI)

•Brightnesscontrol

•Integratedcamera

Keyboard

•6-rowkeyboard

•ThinkPadpointingdevice(T rackPointandmulti-touchtouchpad)

•Fnkey

Interface

•Externalmonitorconnectors(VGAconnectorandHDMIconnector)

•Comboaudioconnector

•TwoUSB3.0connectors

•OneAlwaysonUSBconnector

•RJ45Ethernetconnector

•4-in-1digitalmediacardreader

Wirelessfeatures

•IntegratedwirelessLAN

•IntegratedBluetooth(onsomemodels)

Specications

Thissectionliststhephysicalspecicationsforyourcomputer.

Size

•Width:293.4mm(11.55inches)

•Depth:216mm(8.50inches)

•Height:32.3mm(1.27inches)

Heatoutput

•65W(222Btu/hr)maximum

Powersource(acpoweradapter)

•Sine-waveinputat50to60Hz

•Inputratingoftheacpoweradapter:100to240Vac,50to60Hz

Chapter1.Productoverview11

Batterypack

•Lithium-ion(Li-Ion)batterypack

Batterylife

•Forthepercentageofremainingbatterypower,checkthebatterystatusiconintheWindowsnotication
area.

Operatingenvironment

Thissectionprovidesinformationaboutyourcomputeroperatingenvironment.

Environment:

•Maximumaltitudewithoutpressurization:3048m(10000ft)

•Temperature

–Ataltitudesupto2438m(8000ft)

–Operating:5.0°Cto35.0°C(41°Fto95°F)
–Storage:5.0°Cto43.0°C(41°Fto109°F)

–Ataltitudesabove2438m(8000ft)

–Maximumtemperaturewhenoperatingundertheunpressurizedcondition:31.3°C(88°F)

Note:Whenyouchargethebatterypack,itstemperaturemustbeatleast10°C(50°F).

•Relativehumidity:

–Operating:8%to80%
–Storage:5%to95%

Ifpossible,placeyourcomputerinawell-ventilatedanddryareawithoutdirectexposuretosunshine.

Keepelectricalappliancessuchasanelectricfan,radio,airconditioner,andmicrowaveovenawayfrom
yourcomputerbecausethestrongmagneticeldsgeneratedbytheseappliancescandamagethemonitor
anddataontheharddiskdrive.

Donotplaceanybeveragesontopoforbesidethecomputerorotherattacheddevices.Ifliquidisspilledon
orinthecomputeroranattacheddevice,ashortcircuitorotherdamagemightoccur.

Donoteatorsmokeoveryourkeyboard.Particlesthatfallintoyourkeyboardcancausedamage.

Lenovoprograms

YourcomputercomeswithLenovoprogramstohelpyouworkmoreeasilyandsecurely.Dependingon
theWindowsoperatingsystempreinstalled,theprogramsmightvary.

TolearnmoreabouttheprogramsandothercomputingsolutionsofferedbyLenovo,goto
http://www.lenovo.com/support.

AccessingLenovoprogramsontheWindows7operatingsystem

OntheWindows7operatingsystem,youcanaccessLenovoprogramsfromeithertheLenovoThinkVantage
ToolsprogramorfromControlPanel.

12UserGuide

AccessingLenovoprogramsfromtheLenovoThinkVantageT oolsprogram
ToaccessLenovoprogramsfromtheLenovoThinkVantageToolsprogram,clickStart➙AllPrograms➙

LenovoThinkVantageT ools.Thendouble-clickaprogramicontoaccesstheprogram.

Note:IfaprogramiconintheLenovoThinkVantageToolsprogramnavigationwindowisdimmed,it

indicatesthatyouneedtoinstalltheprogrammanually.T oinstalltheprogrammanually,double-clickthe
programicon.Then,followtheinstructionsonthescreen.Whentheinstallationprocesscompletes,the
programiconwillbeactivated.

Table1.ProgramsintheLenovoThinkVantageToolsprogram

ProgramIconname

AccessConnections™InternetConnection

ClientSecuritySolutionEnhancedSecurity

CommunicationsUtilityWebConferencing

GPSEnablerGPS

LenovoSolutionCenterSystemHealthandDiagnostics

PasswordManagerPasswordVault

PowerManager

PowerControls

RecoveryMediaFactoryRecoveryDisks

RescueandRecovery

®

EnhancedBackupandRestore

SystemUpdate

UpdateandDrivers

Note:Dependingonyourcomputermodel,someoftheprogramsmightnotbeavailable.

AccessingLenovoprogramsfromControlPanel

ToaccessLenovoprogramsfromControlPanel,clickStart➙ControlPanel.Thendependingonthe
programyouwanttoaccess,clickthecorrespondingsectionandthenclickthecorrespondinggreentext.

Note:IfyoudonotndtheprogramyouneedinControlPanel,opentheLenovoThinkVantageTools
programnavigationwindowanddouble-clickthedimmedicontoinstalltheprogramyouneed.Then,
followtheinstructionsonthescreen.Whentheinstallationprocesscompletes,theprogramiconwillbe
activated,andyoucanndtheprograminControlPanel.

TheprogramsandthecorrespondingsectionsandgreentextsinControlPanelarelistedinthefollowing
table.

Table2.ProgramsinControlPanel

Program

ControlPanelsectionGreentextinControlPanel

AccessConnections

NetworkandInternet

Lenovo-InternetConnection

ClientSecuritySolutionSystemandSecurityLenovo-EnhancedSecurity

CommunicationsUtilityHardwareandSoundLenovo-WebConferencing

GPSEnabler

NetworkandInternet

Lenovo-GPS

LenovoSolutionCenterSystemandSecurityLenovo-SystemHealthand

Diagnostics

MessageCenterPlus

Programs

MessagesfromLenovo

Chapter1.Productoverview13

Table2.ProgramsinControlPanel(continued)

Program

ControlPanelsectionGreentextinControlPanel

PasswordManager

SystemandSecurity
UserAccountsandFamilySafety

Lenovo-PasswordVault

PowerManager

HardwareandSound
SystemandSecurity

Lenovo-PowerControls

RecoveryMedia

SystemandSecurity

Lenovo-FactoryRecoveryDisks

SystemUpdateSystemandSecurity

Lenovo-UpdateandDrivers

RescueandRecovery

SystemandSecurity

Lenovo-EnhancedBackupand
Restore

Note:Dependingonyourcomputermodel,someoftheprogramsmightnotbeavailable.

AccessingLenovoprogramsontheWindows8operatingsystem

IfyourcomputerispreinstalledwiththeWindows8operatingsystem,youcanaccessLenovoprogramsby
doingeitherofthefollowing:

•ClicktheLenovoQuickLaunchiconfromthetaskbar.Alistofprogramsisdisplayed.Double-clicka
Lenovoprogramtolaunchit.Ifadesiredprogramisnotinthelist,clicktheplusicon+.

•PresstheWindowskeytogototheStartscreen.ClickaLenovoprogramtolaunchit.Ifyoucannotnd
theprogramyouneed,Movethecursortothetop-rightorbottom-rightcornerofthescreentodisplaythe
charms.ThenclicktheSearchcharmtosearchforthedesiredprogram.

YourcomputersupportsthefollowingLenovoprograms:

•LenovoCompanion

•LenovoSettings

•LenovoMobileAccess

•LenovoSolutionCenter

•LenovoQuickLaunch

•LenovoSupport

•LenovoThinkVantageTools

•PasswordManager

•SystemUpdate

Note:ThePasswordManagerprogramisnotpreinstalledonyourWindows8computers.Youcandownload
itfromtheLenovoSupportWebsitehttp://www.lenovo.com/support.

Foranintroductiontotheseprograms,see“AnintroductiontoLenovoprograms”onpage14

.

AnintroductiontoLenovoprograms

ThistopicprovidesabriefintroductiontosomeLenovoprograms.

Note:Dependingonyourcomputermodel,someoftheprogramsmightnotbeavailable.

•AccessConnections
TheAccessConnectionsprogramisaconnectivityassistantprogramforcreatingandmanaginglocation

proles.EachlocationprolestoresallthenetworkandInternetcongurationsettingsneededfor
connectingtoanetworkinfrastructurefromaspeciclocationsuchasahomeoranofce.

14UserGuide

Byswitchingbetweenlocationprolesasyoumoveyourcomputerfromplacetoplace,youcanquickly
andeasilyconnecttoanetworkwithnoneedtorecongureyoursettingsmanuallyandrestartthe
computereachtime.

•ClientSecuritySolution
TheClientSecuritySolutionprogramprotectsyourcomputerbysecuringclientdataanddeecting

securitybreachattempts.Italsocanhelpmanageyourpasswords,recoveraforgottenpassword,
monitorsecuritysettingsonyourcomputer,andsuggesthowtoenhanceyourcomputersecurity.

•CommunicationsUtility
UsetheCommunicationsUtilityprogramtoconguresettingsfortheintegratedcameraandaudiodevices.

•GPSEnabler
IfthePCIExpressMiniCardinstalledinyourcomputersupportsGPS,yourcomputercanreceivesignals

fromGPSsatellitesanddetermineitslocation.IfyourcomputerisconnectedtotheInternet,youcannd
yourlocationonareal-timemapprovidedbyGoogleMapsorMicrosoftBing™Maps.

•LenovoCompanion
ThroughtheLenovoCompanionprogram,youcangettheinformationabouttheaccessoriesforyour

computer,viewbolgsandarticlesaboutyourcomputer,andcheckforotherrecommendedprograms.

•LenovoSettings
UsetheLenovoSettingsprogramtoenhanceyourcomputingexperiencebyturningyourcomputerintoa

portablehotspot,conguringcameraandaudiosettings,optimizingyourpowersettings,andcreating
andmanagingmultiplenetworkproles.

•LenovoMobileAccess
TheLenovoMobileAccessprogramenablesyoutomanageyourmobilebroadbandconnection.You

cancreateanaccount,addmoneytotheaccount,andpurchasemobilebroadbandsessionsusing
youraccount.

•LenovoSolutionCenter
TheLenovoSolutionCenterprogramenablesyoutotroubleshootandresolvecomputerproblems.It

combinesdiagnostictests,systeminformationcollection,securitystatus,andsupportinformation,along
withhintsandtipsformaximumsystemperformance.

•LenovoQuickLaunch
TheLenovoQuickLaunchprogramprovidesyouwithquickaccesstoprogramsinstalledonyour

computer,includingLenovoprograms,Microsoftprograms,andotherthirdpartyprograms.

•LenovoSupport
TheLenovoSupportprogramenablesyoutoregisteryourcomputerwithLenovo,checkthecomputer

healthconditionandbatterystatus,downloadandviewusermanualsforyourcomputer,getthewarranty
informationofyourcomputer,andexplorehelpandsupportinformation.

•LenovoThinkVantageTools
TheLenovoThinkVantageT oolsprogramhelpsyouworkmoreeasilyandsecurelybyprovidingeasy

accesstovariousprograms,suchasLenovoSolutionCenter.

•MessageCenterPlus
TheMessageCenterPlusprogramautomaticallydisplaysmessagestoinformyouaboutimportantnotices

fromLenovo,suchasalertsonsystemupdatesandalertsonconditionsthatrequireyourattention.

•PasswordManager
ThePasswordManagerprogramautomaticallycapturesandllsinauthenticationinformationfor

WindowsprogramsandWebsites.

•PowerManager

Chapter1.Productoverview15

ThePowerManagerprogramprovidesconvenient,exible,andcompletepowermanagementforyour
computer.Itenablesyoutoadjustyourcomputerpowersettingstoachievethebestbalancebetween
performanceandpowersaving.

•RecoveryMedia
TheRecoveryMediaprogramenablesyoutorestorethecontentsoftheharddiskdrivetothefactory

defaultsettings.

•RescueandRecovery
TheRescueandRecoveryprogramisaone-buttonrecoveryandrestoresolutionthatincludesasetof

self-recoverytoolstohelpyoudiagnosecomputerproblems,gethelp,andrecoverfromsystemcrashes,
evenifyoucannotstarttheWindowsoperatingsystem.

•SystemUpdate
TheSystemUpdateprogramhelpsyoukeepthesoftwareonyourcomputerup-to-datebydownloading

andinstallingsoftwareupdatepackages(Lenovoprograms,devicedrivers,UEFIBIOSupdates,and
otherthirdpartyprograms).

16UserGuide

Chapter2.Usingyourcomputer

Thischapterprovidesinformationonusingsomeofthecomputercomponents.

Thischaptercontainsthefollowingtopics:

•“Registeringyourcomputer”onpage17

•“Frequentlyaskedquestions”onpage17

•“Specialkeysandbuttons”onpage19

•“UsingtheThinkPadpointingdevice”onpage21

•“Powermanagement”onpage23

•“Connectingtothenetwork”onpage28

•“Presentationsandmultimedia”onpage31

•“Usingaudiofeatures”onpage33

•“Usingtheintegratedcamera”onpage34

•“Usingaashmediacard”onpage35

Registeringyourcomputer

Whenyouregisteryourcomputer,informationisenteredintoadatabase,whichenablesLenovotocontact
youincaseofarecallorothersevereproblem.AfteryouregisteredyourcomputerwithLenovo,youwill
alsoreceivequickerservicewhenyoucallLenovoforhelp.Inaddition,somelocationsofferextended
privilegesandservicestoregisteredusers.

ToregisteryourcomputerwithLenovo,dooneofthefollowing:

•Gotohttp://www.lenovo.com/registerandfollowtheinstructionsonthescreentoregisteryourcomputer.

•ConnectyourcomputertotheInternetandregisteryourcomputerthroughapreinstalledregistration
program:

–ForWindows7:ThepreinstalledLenovoProductRegistrationprogramlaunchesautomaticallyafteryou

haveusedyourcomputerforatime.Followtheinstructionsonthescreentoregisteryourcomputer.

–ForWindows8:OpentheLenovoSupportprogram.ThenclickRegistrationandfollowtheinstructions

onthescreentoregisteryourcomputer.

Frequentlyaskedquestions

Thefollowingareafewtipsthatwillhelpyouoptimizetheuseofyourcomputer.

Toensurethatyoureceivethebestperformancefromyourcomputer,gotothefollowingWebpage
tondinformationsuchasaidsfortroubleshootingandanswerstofrequentlyaskedquestions:
http://www.lenovo.com/support/faq

CanIgetmyuserguideinanotherlanguage?

•Todownloadtheuserguideinanotherlanguage,goto:http://www.lenovo.com/support.Thenfollow
theinstructionsonthescreen.

Howtousethebatterypowermoreeffectively?

©CopyrightLenovo2013

17

•Toconservepower,ortosuspendoperationwithoutexitingprogramsorsavingles,see“Power-saving
modes”onpage25.

•Toachievethebestbalancebetweenperformanceandpowersaving,changepowerplansettings.

•Ifyourcomputerwillbeturnedoffforanextendedperiodoftime,youcanpreventbatterypower
fromdrainingbyremovingthebattery.Lookformoreinformationaboutusingthebatteryin“Power
management”onpage23.

Concernedaboutsecurityorneedtosecurelydisposeofdatastoredonyourharddiskdriveor
solid-statedrive?

•StudyChapter4“Security”onpage41

tondouthowyoucanprotectyourcomputerfromtheftand

unauthorizeduse.

•UsethePasswordManagerprogramtoprotectthedatastoredonyourcomputer.Fordetails,seethe
helpinformationsystemoftheprogram.

•Beforeyoudisposeofthedataontheharddiskdriveorsolid-statedrive,besuretoread“Noticeon
deletingdatafromyourharddiskdriveorsolid-statedrive”onpage46.

Isgettingconnectedindifferentlocationsachallenge?

•Totroubleshootawirelessnetworkingissue,goto:
http://www.lenovo.com/support/faq

•TakeadvantageofthenetworkingfeaturesprovidedbytheAccessConnectionsprogram(onthe
Windows7operatingsystem)orLocationAwarenessintheLenovoSettingsprogram(ontheWindows8
operatingsystem).

•Tolearnmoreaboutusingthewirelessfeaturesofyourcomputer,referto“Wirelessconnections”on
page28

.

•Totravelmorecondently,besuretocheckthetipsin“Travelingwithyourcomputer”onpage39.

•PressFn+F5toenableordisablethewirelessfeatures.

Needtogivepresentationsorattachanexternalmonitoroften?

•Makesurethatyoufollowtheprocedurefor“Attachinganexternalmonitor”onpage31

.

•WiththeExtenddesktopfunction,youcandisplayoutputonboththecomputerdisplayandanexternal
monitor.

Needtoattachorreplaceadevice?

•SeeChapter6“Replacingdevices”onpage57

formoreinformationaboutreplacingthedevicesof

yourcomputer.

Ihavebeenusingyourcomputerforsometimealready,anditisgettingslower?

•Follow“Generaltipsforpreventingproblems”onpage93.

•Youcandiagnoseproblemsyourselfbyusingthepreinstalleddiagnosticsoftware.

•CheckforrecoverysolutionsinChapter5“Recoveryoverview”onpage49

.

Printthefollowingsectionsandkeepthemwithyourcomputerincaseyouareunabletoaccessthisonline
userguidewhennecessary.

•“Installinganewoperatingsystem”onpage75

•“Computerstopsresponding”onpage99

•“Powerproblems”onpage112

18UserGuide

Specialkeysandbuttons

Yourcomputerhasseveralspecialfunctionkeysandbuttonstohelpyouworkmoreeasilyandeffectively.

Functionkeycombinations

TousetheFnfunctionkeycombinations,pressandholdtheFnkey1;thenpressoneofthefunction
keys2.Releasebothkeys.

Volumeandmutebuttons

Toquicklyadjustthevolumeofthesoundfromyourcomputer,mutethesoundentirely,orsetthe
microphonetomute,pressoneofthefollowingkeycombinations.

•Fn+Esc:Speakermute

•Fn+F1:Speakervolumedown

•Fn+F2:Speakervolumeup

•Fn+F3:Microphonemute

Note:Ifyoumutethesoundbeforeyouturnoffthecomputer,thesoundwillremainmutedwhenyou
turnonyourcomputeragain.Tounmutethesound,pressthespeakervolumeuporspeakervolume
downkeycombination.

Powerconservation

•Fn+F4

Putyourcomputerintosleepmode.Toreturntonormaloperation,presstheFnkeyonly.

Ifyouwanttousethecombinationtoputthecomputerintohibernationmode,youneedtochangeyour
powerplansettings.Toaccesspowerplansettings,dothefollowing:

•ForWindows7:StartthePowerManagerprogramandthenclickthePowerPlantab.Forinstructionson
howtostartthePowerManagerprogram,see“AccessingLenovoprogramsontheWindows7operating
system”onpage12

.

•ForWindows8:Right-clickthebatterystatusiconfromtheWindowsnoticationareaandclickPower
Options.ThenclickChangeplansettingsthatisnexttoyourpowerplan.

Chapter2.Usingyourcomputer19

Wirelessfeatures

•Fn+F5

Enableordisablethebuilt-inwirelessnetworkingfeatures.

Launchingthecameraandaudiosettings

•Fn+F6

–ForWindows7:OpentheCommunicationssettingswindow,inwhichyoucanpreviewyourvideo

image,takeasnapshotofyourcurrentimage,andchangethecameraandaudiosettings.

–ForWindows8:StarttheLenovoSettingsprogram.Tousethecameraorchangethecamerasettings,

clickCamera.Toadjusttheaudiosettings,clickAudio.

Switchingthedisplayoutputlocation

•Fn+F7

PressFn+F7toswitchbetweenthecomputerdisplayandanexternalmonitor.Afteryoupressthiskey
combination,thefollowingoptionswillbedisplayed:

•Computerdisplayonly(LCD)

•Computerdisplayandexternalmonitor(duplicatedimage)

•Computerdisplayandexternalmonitor(theExtendeddesktopfunction)

•Externalmonitoronly

Note:TheWindows+PkeycombinationcanachievethesamefunctionalityasFn+F7.

Adjustingthebrightnesslevelofthecomputerdisplay

•Fn+F8:Thecomputerdisplaybecomesdimmer.

•Fn+F9:Thecomputerdisplaybecomesbrighter.

Note:Thisfunctionchangesthebrightnessleveltemporarily.Tochangethedefaultbrightnesslevel,change
thesettingsthroughthePowerManagerprogram.

Multimediacontrols

•Fn+F10:Previoustrack/scene

•Fn+F11:Playorpause

•Fn+F12:Nexttrack/scene

Legacyfunctionkeys

•Fn+B:HasthesamefunctionsastheBreakkeyontheconventionalkeyboard.

•Fn+K:HasthesamefunctionsastheScrLkkeyontheconventionalkeyboard.

•Fn+P:HasthesamefunctionsasthePausekeyontheconventionalkeyboard.

•Fn+S:HasthesamefunctionsastheSysRqkeyontheconventionalkeyboard.

20UserGuide

Windowskey

OntheWindows7operatingsystem,presstheWindowskeytoopentheStartmenu.OntheWindows8
operatingsystem,presstheWindowskeytoswitchbetweenthecurrentworkspaceandtheStartscreen.

YoualsocanusetheWindowskeytogetherwithanotherkeytoachieveotherfunctions.Formore
information,refertothehelpinformationsystemoftheWindowsoperatingsystem.

UsingtheThinkPadpointingdevice

YourcomputercomeswiththeThinkPadpointingdevice.TheThinkPadpointingdeviceconsistsofthe
TrackPointpointingdeviceandthetouchpad,eachofwhichisitselfapointingdevicewithbothbasicand
extendedfunctions.Y oucancongurebothdevicesbychoosingthesettingsyoupreferasfollows:

•SetboththeT rackPointpointingdeviceandthetouchpadaspointingdevices.
ThissettingenablestheuseofallthebasicandextendedfunctionsoftheTrackPointpointingdevice

andthetouchpad.

•SettheTrackPointpointingdeviceasthemainpointingdeviceandthetouchpadforextended

functionsonly.

ThissettingenablestheuseofallbasicandextendedfunctionswiththeTrackPointpointingdevicewhile
limitingtheuseofthetouchpadtoscrolling,tapzones,andslow-motionpointerfunctions.

•SettheTrackPointpointingdeviceasthemainpointingdevice,anddisablethetouchpad.

•Setthetouchpadasthemainpointingdevice,anddisabletheTrackPointpointingdevice.

UsingtheT rackPointpointingdevice

TheT rackPointpointingdeviceconsistsofapointingstick1onthekeyboardandthreeclickbuttonsatthe
bottomofthekeyboard.T omovethepointer

5onthescreen,youapplypressuretothenonslipcaponthe

pointingstickinanydirectionparalleltothekeyboard;thepointingstickitselfdoesnotmove.Thespeedat
whichthepointermovesdependsonthepressureyouapplytothepointingstick.Thefunctionsoftheleft4
andright2clickbuttonscorrespondtothoseoftheleftandrightmousebuttonsonaconventionalmouse.
TheT rackPointcenterbutton3,calledthescrollbar,enablesyoutoscrollWebpagesordocumentsinany
directionwithnoneedtousethegraphicscrollbarsonthesideofthewindow.

Chapter2.Usingyourcomputer21

IfyouarenotfamiliarwiththeTrackPointpointingdevice,theseinstructionswillhelpyougetstarted:

1.Placeyourhandsinthetypingposition,andpressgentlywithanindexngeroramiddlengeronthe
pointingstickinthedirectioninwhichyouwantthepointertomove.

Tomovethepointer,pressthepointingstickawayfromyoutomoveitup,towardyoutomoveit
down,toonesideortheothertomoveitsideways.

Note:Thepointermightdrift.Thisisnotadefect.StopusingtheT rackPointpointingdeviceforafew
seconds;thepointerwillstopmoving.

2.T oselectanddragasrequiredbyyoursoftware,presstheleftorrightclickbuttonwitheitherthumb
andmovetheTrackPointpointingstick.

Usingthetouchpad

Thetouchpadisapad1belowtheTrackPointbuttonsatthebottomofthekeyboard.Tomovethepointer

2onthescreen,slideyourngertipoverthepadinthedirectioninwhichyouwantthepointertomove.

Theleftandrightbottomofthepadworkasclickbuttons.Thefunctionscorrespondtothoseoftheleft
andrightmousebuttonsonaconventionalmouse.

CustomizingtheThinkPadpointingdevice

YoucancustomizetheThinkPadpointingdevicetoachievetheextendedfunctionsoftheThinkPad
pointingdevice.

TocustomizetheThinkPadpointingdevice,dothefollowing:

1.GotoControlPanel.

22UserGuide

2.ClickHardwareandSound➙Mouse➙ThinkPad.

3.Followtheinstructionsonthescreen.

Replacingthecap

Thecap1ontheendoftheTrackPointpointingstickisremovable.Youcanreplaceitasshownin
thedrawing.

Note:Ifyoureplacethekeyboard,anewkeyboardisshippedwiththedefaultcap.Ifyouwish,youcan
keepthecapfromyouroldkeyboardanduseitonthenewone.

Powermanagement

Whenyouneedtouseyourcomputerawayfromelectricaloutlets,youdependonbatterypowertokeep
yourcomputerrunning.Differentcomputercomponentsconsumepoweratdifferentrates.Themoreyou
usethepower-intensivecomponents,thefasteryouconsumebatterypower.

SpendmoretimeunpluggedwithThinkPadbatteries.Mobilityhasrevolutionizedbusinessbyallowing
youtotakeyourworkwhereveryougo.WithThinkPadbatteries,youwillbeabletoworklongerwithout
beingtiedtoanelectricaloutlet.

Checkingthebatterystatus

ThebatterystatusiconintheWindowsnoticationareadisplaysthepercentageofbatterypowerremaining.

Therateatwhichyouusebatterypowerwilldeterminehowlongyoucanusethebatteryofyourcomputer
betweencharges.Becauseeachcomputeruserhasdifferenthabitsandneeds,itisdifculttopredicthow
longabatterychargewilllast.Therearetwomainfactors:

•Howmuchenergyisstoredinthebatterywhenyoubegintowork.

•Thewayyouuseyourcomputer.Forexample:

–Howoftenyouaccesstheharddiskdrive.
–Howbrightyoumakethecomputerdisplay.
–Howoftenyouusethewirelessfeatures.

Tocheckfordetailedbatterystatusinformation,dothefollowing:

•ForWindows7:OpenthePowerManagerprogramandclicktheBatterytab.

Chapter2.Usingyourcomputer23

•ForWindows8:OpentheLenovoSupportprogramandclickBatteryHealth,oropentheLenovo
SettingsprogramandclickPower.

Usingtheacpoweradapter

Thepowertorunyourcomputercancomeeitherfromthelithium-ion(Li-ion)batterypackprovidedwithit,
orfromacpowerthroughtheacpoweradapter.Whileyouuseacpower,thebatterychargesautomatically.

Theacpoweradapterthatcomeswithyourcomputerhastwobasiccomponents:

•Thetransformerpackthatconvertsacpowerforusewiththecomputer.

•Thepowercordthatplugsintotheacoutletandintothetransformerpack.

Attention:Usinganimproperpowercordcouldcauseseveredamagetoyourcomputer.

Connectingtheacpoweradapter

Tousetheacpoweradapter,dothefollowing.Besuretotakethesestepsintheorderinwhichtheyare
givenhere.

1.Connectthepowercordtoanelectricaloutlet.

2.Connectthepowercordtothetransformerpack.

3.Connecttheacpoweradaptertothepowerconnectorofthecomputer.

Tipsonusingtheacpoweradapter

Youcancheckthestatusofyourbatteryatanytimebylookingatthebatterymeteratthebottomofyour
display.

•Whentheacpoweradapterisnotinuse,disconnectitfromtheelectricaloutlet.

•Donotbindthepowercordtightlyaroundtheacpoweradaptertransformerpackwhenitisconnectedto
thetransformer.

•Beforeyouchargethebattery,makesurethatitstemperatureisatleast10°C(50°F).

•Youcanchargethebatterywhentheacpoweradapterisconnectedtothecomputerandthebatteryis
installed.Youneedtochargeitinanyofthefollowingconditions:

–Whenyoupurchaseanewbattery
–Ifthebatterymeteratthebottomofyourdisplayshowsthebatterychargeislow
–Ifthebatteryhasnotbeenusedforalongtime

Chargingthebattery

Whenyoucheckbatterystatusandndthatthepercentageofpowerremainingisloworwhenthepower
alarmalertsyouthattheremainingpowerislow,youneedtochargeyourbatteryorreplaceitwitha
chargedbattery.

Ifanacoutletisconvenient,plugtheacpoweradapterintoit,andtheninsertthejackintothecomputer.
Thebatterywillbefullychargedinaboutthreetosixhours.Thisisaffectedbythebatterysizeandthe
physicalenvironment.Thebatterystatusindicatorwillletyouknowthatthebatteryischarging,andwill
alsonotifyyouwhenthebatteryisfullycharged.

Note:Toincreasethelifeofthebattery,thecomputerdoesnotstartrechargingthebatteryiftheremaining
powerisgreaterthan95%.

Maximizingthebatterylife

Tomaximizethelifeofthebattery,dothefollowing:

24UserGuide

•Usethebatteryuntilthechargeiscompletelydepleted;thatis,usethebatteryuntilthebatterystatus
indicatorstartsblinkingorange.

•Rechargethebatterycompletelybeforeusingit.Thebatteryisfullychargedifthebatteryindicatorshows
greenwhentheacpoweradapterispluggedin.

•Alwaysusepowermanagementfeaturessuchaspowermodes,screenblank,sleep,andhibernation.

Managingthebatterypower

Toachievethebestbalancebetweenperformanceandpowersaving,adjustyourpowerplansettings.
Toaccesspowerplansettings,dothefollowing:

•ForWindows7:StartthePowerManagerprogramandthenclickthePowerPlantab.Forinstructionson
howtostartthePowerManagerprogram,see“AccessingLenovoprogramsontheWindows7operating
system”onpage12.

•ForWindows8:Right-clickthebatterystatusiconfromtheWindowsnoticationareaandclickPower
Options.ThenclickChangeplansettingsthatisnexttoyourpowerplan.

Formoreinformation,refertothehelpinformationsystemoftheprogram.

Power-savingmodes

Thereareseveralpower-savingmodesthatyoucanuseatanytimetoconservepower.Thissection
introduceseachmodeandgivestipsontheeffectiveuseofthebatterypower.

Introducingthepower-savingmodes

•Screenblank(fortheWindows7operatingsystemonly)
Thecomputerdisplayrequiresconsiderablebatterypower.Toturnoffpowertothedisplay,dothe
following:

1.Right-clickthePowerManagerbatterygaugeonthetaskbar.

2.SelectPoweroffdisplay.

•Sleep
Insleepmode,yourworkissavedtomemory,andthenthesolid-statedriveortheharddiskdriveandthe
computerdisplayareturnedoff.Whenyourcomputerwakesup,yourworkisrestoredwithinseconds.To
putyourcomputerintosleepmode,pressFn+F4.T oreturnfromsleepmode,pressFnkey.

•Hibernation
Byusingthismode,youcanturnoffyourcomputercompletelywithoutsavinglesorexitingfromany
programsthatarerunning.Whenthecomputerentershibernation,allopenprograms,folders,andles
aresavedtotheharddisk,andthenthecomputerturnsoff.

Toputthecomputerintohibernationmode,changeyourpowerplansettings.Toaccesspowerplan
settings,dothefollowing:

–ForWindows7:StartthePowerManagerprogramandthenclickthePowerPlantab.Forinstructions

onhowtostartthePowerManagerprogram,see“AccessingLenovoprogramsontheWindows7
operatingsystem”onpage12

.

–ForWindows8:Right-clickthebatterystatusiconfromtheWindowsnoticationareaandclickPower

Options.ThenclickChangeplansettingsthatisnexttoyourpowerplan.

•Wirelessoff
Whenyouarenotusingthewirelessfeatures,suchasBluetoothorwirelessLAN,turnthemoff.Thiswill
helpconservepower.Toturnoffthewirelessfeatures,pressFn+F5orusethewirelessradioswitch.

Chapter2.Usingyourcomputer25

Enablingthewakeupfunction

Ifyouputyourcomputerintohibernationmode,andthewakeupfunctionisdisabled(thisisthedefault
setting),thecomputerdoesnotconsumeanypower.Ifthewakeupfunctionisenabled,itconsumesa
smallamountofpower.

Toenablethefunction,dothefollowing:

1.GotoControlPanelandclickSystemandSecurity➙AdministrativeT ools.

2.Double-clickTaskScheduler.Ifyouarepromptedforanadministratorpasswordorconrmation,type
thepasswordorprovideconrmation.

3.Fromtheleftpane,selectthetaskfolderforwhichyouwanttoenablethewakeupfunction.The
scheduledtasksaredisplayed.

4.Clickascheduledtask,andthenclicktheConditionstab.

5.UnderPower,selectthecheckboxforWakethecomputertorunthistask.

EnablingthebatteryalarmontheWindows7operatingsystem

FortheWindows7operatingsystem,youcanprogramyourcomputersothatwhenthebatterypowerfalls
belowacertainlevel,threeeventsoccur:

•Thealarmgoesoff.

•Awarningmessageisdisplayed.

•TheLCDisturnedoff.

Toenablethebatteryalarm,dothefollowing:

1.StartthePowerManagerprogram.

2.ClicktheGlobalPowerSettingstab.

3.ForLowbatteryalarmorCriticallylowbatteryalarm,setthepercentageofthepowerlevelandset
theaction.

Note:Ifyourcomputerenterssleeporhibernationmodewhenthebatteryislow,butthealarmmessage
hasnotyetbeendisplayed,themessagewillbedisplayedwhenthecomputerresumes.Toresumenormal
operation,clickOK.

Handlingthebattery

ThissystemsupportsonlybatteriesspeciallydesignedforthisspecicsystemandmanufacturedbyLenovo
oranauthorizedbuilder.Thesystemdoesnotsupportunauthorizedbatteriesorbatteriesdesignedforother
systems.Ifanunauthorizedbatteryorabatterydesignedforanothersystemisinstalled,thesystemwill
notcharge.

Attention:Lenovohasnoresponsibilityfortheperformanceorsafetyofunauthorizedbatteries,and
providesnowarrantiesforfailuresordamagearisingoutoftheiruse.

Note:Ifanunauthorizedbatteryisinstalled,thefollowingmessagewillbedisplayed:“Thebatteryinstalled
isnotsupportedbythissystemandwillnotcharge.PleasereplacethebatterywiththecorrectLenovo
batteryforthissystem.”

26UserGuide

DANGER

Donotattempttodisassembleormodifythebatterypack.

Attemptingtodosocancauseanexplosion,orliquidleakagefromthebatterypack.

AbatterypackotherthantheonespeciedbyLenovo,oradisassembledormodiedbattery
packisnotcoveredbythewarranty.

DANGER

Iftherechargeablebatterypackisincorrectlyreplaced,thereisdangerofanexplosion.Thebattery
packcontainsasmallamountofharmfulsubstances.T oavoidpossibleinjury:

•ReplaceonlywithabatteryofthetyperecommendedbyLenovo.

•Keepthebatterypackawayfromre.

•Donotexposeittoexcessiveheat.

•Donotexposeittowaterorrain.

•Donotshort-circuitit.

•Storeitinacooldryplace.

•Keepitawayfromchildren.

Thebatterypackisaconsumablesupply.Ifyourbatterybeginstodischargetooquickly,replacethe
batterypackwithanewoneofthetyperecommendedbyLenovo.Formoreinformationonreplacingthe
batterypack,contactyourCustomerSupportCenter.

DANGER

Donotdrop,crush,puncture,orsubjecttostrongforces.Batteryabuseormishandlingcancause
thebatterytooverheat,whichcancausegassesorameto“vent”fromthebatterypackorcoin
cell.Ifyourbatteryisdamaged,orifyounoticeanydischargefromyourbatteryorthebuildup
offoreignmaterialsonthebatteryleads,stopusingthebatteryandobtainareplacementfrom
thebatterymanufacturer.

DANGER

Onlyrechargethebatterypackstrictlyaccordingtoinstructionsincludedintheproduct
documentation.

DANGER

Donotputthebatterypackintrashthatisdisposedofinlandlls.Whendisposingofthebattery,
complywithlocalordinancesorregulationsandyourcompany'ssafetystandards.

Chapter2.Usingyourcomputer27

DANGER

Thereisadangerofanexplosionifthebackupbatteryisincorrectlyplaced.Thelithiumbattery
containslithiumandcanexplodeifitisnotproperlyhandled,ordisposedof.Replaceonlywitha
batteryofthesametype.Toavoidpossibleinjuryordeath,donot:(1)throworimmerseintowater,
(2)allowittoheattomorethan100°C(212°F),or(3)attempttorepairordisassembleit.Disposeof
itasrequiredbylocalordinancesorregulationsandyourcompany'ssafetystandards.

Connectingtothenetwork

YourcomputerhasoneormorenetworkadaptersforconnectingtotheInternetortoyourcompany'swired
LANorwirelessLANnetwork.

Ethernetconnections

YoucanconnecttoyourlocalnetworkorabroadbandconnectionbyuseoftheEthernetfeaturebuiltinto
yourcomputer.IfyouareusingtheWindows7operatingsystem,theAccessConnectionsprogramalso
enablesyoutomanageyourlocationproles.Formoreinformation,see“AccessingLenovoprograms
ontheWindows7operatingsystem”onpage12

.

DANGER

YourcomputerhasanEthernetconnector.Toavoidtheriskofelectricalshock,donotconnect
thetelephonecabletotheEthernetconnector.

Wirelessconnections

Wirelesscommunicationisthetransferofdatawithouttheuseofcablesbutbymeansofradiowavesonly.

Dependingonthewirelessdeviceusedinyourcomputer,youmightbeabletoconnecttothefollowing
categoriesofwirelessnetworks.

WirelessLAN

Awirelesslocalareanetwork(LAN)coversarelativelysmallgeographicarea,suchasanofcebuildingora
house.Devicesbasedonthe802.11standardscanconnecttothisnetwork.

Yourcomputercomeswithabuilt-inwirelessnetworkcardandacongurationutilitytohelpyoumake
wirelessconnectionsandmonitorthestatusofyourconnection,sothatyoucanstayconnectedtoyour
networkwhileyouareintheofce,inameetingroom,orathome,withnoneedforawiredconnection.

TipsforusingthewirelessLANfeature

Toachievethebestconnection,usethefollowingguidelines:

•PlaceyourcomputersothatthereareasfewobstaclesaspossiblebetweenthewirelessLANaccess
pointandthecomputer.

•Openyourcomputerdisplaytoanangleofslightlymorethan90degrees.

•Ifyouusethewirelessfeature(the802.11standard)ofyourcomputersimultaneouslywithaBluetooth
option,thedatatransmissionspeedcanbedelayedandtheperformanceofthewirelessfeaturecanbe
degraded.

28UserGuide

Bluetooth

Bluetoothisoneofanumberoftechnologiesusedtocreateawirelesspersonalareanetwork.Bluetooth
canconnectdevicesashortdistancefromoneanother,andiscommonlyusedforconnectingperipheral
devicestoacomputer,transferringdatabetweenhand-helddevicesandapersonalcomputer,orremotely
controllingandcommunicatingwithdevicessuchasmobilephones.

Establishingawirelessconnection

Toestablishawirelessconnection,dothefollowing:

1.PressFn+F5toturnonthewirelessfeature.

2.ClickthewirelessnetworkconnectionstatusiconintheWindowsnoticationarea.Alistofavailable
wirelessnetworksisdisplayed.

3.Double-clickanetworktoconnecttoit.Providerequiredinformationifneeded.

Ifyouneedtoconnecttodifferentwirelessnetworksindifferentlocations,usethefollowingsoftwareto
managemultiplenetworkprolessothatthecomputerconnectstoanavailablenetworkautomaticallywhen
thelocationchanges:

•ForWindows7:UsetheAccessConnectionsprogram.ForinstructionsonhowtostarttheAccess
Connectionsprogram,see“AccessingLenovoprogramsontheWindows7operatingsystem”onpage12

.

•ForWindows8:OpentheLenovoSettingsprogramandclickLocationAwareness.

Attention:

•Ifyouwanttousethewirelessfeaturesonanairplane,checkthewirelessserviceswiththeairlinebefore
boardingtheairplane.

•Iftherearerestrictionsontheuseofcomputerwirelessfeaturesonanairplane,youneedtodisableyour
computerwirelessfeaturesbeforeboarding.Todisablethewirelessfeatures,see“Enablingordisabling
thewirelessfeatures”onpage31

.

UsingBluetooth

SomemodelsareequippedwithaBluetoothcardthatiscompliantwithBluetoothSpecication4.0.

ToenabletheBluetoothfeatureontheWindows7operatingsystem,pressFn+F5toopenthewireless
radioswitchboard.ThenturnontheBluetoothradio.FortheWindows8operatingsystem,theBluetooth
featureisonbydefault.

SendingdatatoaBluetooth-enableddevice

TosenddatatoaBluetooth-enableddevice,dothefollowing:

1.EnabletheBluetoothfeature.

2.Right-clickthedatathatyouwanttosend.

3.SelectSendTo➙BluetoothDevices.

4.SelectaBluetoothdeviceandthenfollowtheinstructionsonthescreen.

Note:Ifyouusethewirelessfeature(the802.11standard)ofyourcomputersimultaneouslywithaBluetooth
option,thedatatransmissionspeedcanbedelayedandtheperformanceofthewirelessfeaturecanbe
degraded.

FormoreinformationaboutusingtheBluetoothfeature,refertotheWindowshelpinformationsystemand
theBluetoothhelpinformationsystem.

Chapter2.Usingyourcomputer29

Checkingthewirelessnetworkconnectionstatus

Youcancheckyourcomputerwirelessnetworkconnectionstatusandwirelesssignalstrengththroughthe
wirelessnetworkconnectionstatusiconintheWindowsnoticationarea.Themorebarsencompassed,the
betterthesignal.

FortheWindows7operatingsystem,youalsocanchecktheAccessConnectionsgauge,theAccess
Connectionsstatusicon,ortheAccessConnectionswirelessnetworkconnectionstatusiconinthe
Windowsnoticationarea.

AccessConnectionsgauge

OntheWindows7operatingsystem,theAccessConnectionsgaugeintheWindowsnoticationarea
displaysthestatusandsignalstrengthofyourwirelessconnection.

Youcanndmoredetailedinformationaboutthestatusandsignalstrengthofyourwirelessconnection
byopeningtheAccessConnectionsprogramorbyright-clickingtheAccessConnectionsgaugeinthe
WindowsnoticationareaandselectingViewStatusofWirelessConnection.

•AccessConnectionsgaugestates:wirelessLAN

–Powertothewirelessradioisoffornosignal.

–Powertothewirelessradioison.Thesignalstrengthofthewirelessconnectionispoor.To

improvethesignalstrength,moveyourcomputerclosertothewirelessaccesspoint.

–Powertothewirelessradioison.Thesignalstrengthofthewirelessconnection

ismarginal.

–

Powertothewirelessradioison.Thesignalstrengthofthewirelessconnectionis

excellent.

AccessConnectionsstatusicon

TheAccessConnectionsstatusicondisplaysgeneralconnectionstatus.

•AccessConnectionsstatusiconstates

–Nolocationproleisactiveornoneexists.

–Currentlocationproleisdisconnected.

–

Currentlocationproleisconnected.

AccessConnectionswirelessstatusicon

TheAccessConnectionswirelessstatusicondisplaysthestatusandsignalstrengthofyourwireless
connection.

Youcanndmoredetailedinformationaboutthestatusandsignalstrengthofyourwirelessconnection
eitherbyopeningtheAccessConnectionsprogramorbydouble-clickingtheAccessConnectionswireless
statusiconintheWindowsnoticationarea.

•Wirelessstatusiconstates:wirelessLAN

–

Powertothewirelessradioisoff.

–Powertothewirelessradioison.Noassociation.

–Powertothewirelessradioison.Nosignal.

–Powertothewirelessradioison.Thesignalstrengthofthewirelessconnectionisexcellent.

–

Powertothewirelessradioison.Thesignalstrengthofthewirelessconnectionismarginal.

30UserGuide

–Powertothewirelessradioison.Thesignalstrengthofthewirelessconnectionispoor.Toimprove

thesignalstrength,moveyourcomputerclosertothewirelessaccesspoint.

Note:Ifyouhavetroubleinmakingaconnection,trymovingyourcomputerclosertoyourwirelessaccess
point.

Enablingordisablingthewirelessfeatures

Toenableordisablethewirelessfeatures,dooneofthefollowing:

•ForWindows7:PressFn+F5toopenthewirelessradioswitchboard.Turnonorturnoffthewireless
featureasdesired.

•ForWindows8:PressFn+F5toenableordisabletheAirplanemode.WhentheAirplanemodeisenabled,
allofyourwirelessdevicesareturnedoff.

Youalsocanusethewirelessradioswitchtoturnonorturnoffthewirelessradiosofallthewirelessdevices
onyourcomputer.

Presentationsandmultimedia

Youcanconnectyourcomputertoaprojectortogivepresentationsoryoucanconnectyourcomputer
toanexternalmonitortoexpandyourworkspace.

Changingdisplaysettings

Youcanchangethedisplaysettings,suchasthedisplayresolution,fontsize,andsoon.

Tochangethedisplaysettings,dothefollowing:

1.OpenControlPanelandclickAppearanceandPersonalization.

2.ClickDisplayforfurtherconguration.

Connectingaprojectororanexternalmonitor

Thistopicprovidesinformationaboutconnectingaprojectororanexternalmonitor.

Attachinganexternalmonitor

Note:Ifyouattachanexternalmonitor,avideointerfacecablewithaferritecoreinstalledonthecable

isrequired.

Yourcomputercansupportamaximumvideoresolutionofupto2048x1536(withanexternalmonitor
attachedtotheVGAconnector)orupto2560x1600(withanexternalmonitorattachedtotheHDMI
connector),providedthattheexternalmonitoralsosupportsthatresolution.Formoredetails,referto
themanualsprovidedwithyourmonitor.

Youcansetanyresolutionforeitherthecomputerdisplayortheexternalmonitor.Whenyouusebothatthe
sametime,theresolutionofbothisthesame.Ifyousetahigherresolutionforthecomputerdisplay,you
canseeonlypartofthescreenatatime.YoucanseeotherpartsbymovingtheimagewiththeTrackPoint
pointingdeviceoranotherpointingdevice.

Youcanswitchthedisplayoutputbetweenthecomputerdisplayandtheexternalmonitor,orevenoutput
thedisplaytobothofthecomputerdisplayandtheexternalmonitorbychangingthecongurationin
theDisplaySettingswindow.

Connectinganexternalmonitor

Toattachanexternalmonitor,dothefollowing:

Chapter2.Usingyourcomputer31

1.Connecttheexternalmonitortothemonitorconnector;thenconnectthemonitortoanelectricaloutlet.

2.T urnontheexternalmonitor.

3.ChangethedisplayoutputlocationbypressingFn+F7.Thisenablesyoutoswitchbetweenviewing
outputontheexternalmonitor,thecomputermonitor,andbothmonitors.

Note:Ifyourcomputercannotdetecttheexternalmonitor,right-clickonthedesktop,thenselectScreen
resolution.ClicktheDetectbutton.

Settingthemonitortype

Tosetyourmonitortype,dothefollowing:

1.Connecttheexternalmonitortothemonitorconnector,andthenconnectthemonitortoanelectrical
outlet.

2.T urnontheexternalmonitor.

3.Right-clickonthedesktop,andclickScreenresolution.

Note:Ifyourcomputercannotdetecttheexternalmonitor,clicktheDetectbutton.

4.Clicktheiconforthedesiredmonitor(theMonitor-2iconisfortheexternalmonitor).

5.SetResolution.

6.ClickAdvancedSettings.

7.ClicktheMonitortab.Checkthemonitorinformationwindowtomakesurethatthemonitortypeis
correct.Ifitis,clickOKtoclosethewindow;otherwiseproceedwiththefollowingsteps.

8.Ifmorethantwomonitortypesaredisplayed,selectGenericPnPMonitororGenericNon-PnP
Monitor.

9.ClickProperties.Ifyouarepromptedforanadministratorpasswordorconrmation,typethepassword
orprovideconrmation.

10.ClicktheDrivertab.

11.ClickUpdateDriver.

12.ClickBrowsemycomputerfordriversoftware,andthenclickLetmepickfromalistofdevice
driversonmycomputer.

13.CleartheShowcompatiblehardwarecheckbox.

14.SelectManufacturerandModelforyourmonitor.Ifyoucannotndyourmonitoronthelist,stopthe
installationofthisdriverandusethedrivershippedwithyourmonitor.

15.Afterupdatingthedriver,clickClose.

16.FortheWindows7operatingsystem,tochangethecolorsettings,right-clickonthedesktop,andclick
Screenresolution.ClickAdvancedSettings,selecttheMonitortab,thensetColors.

17.ClickOK.

Considerationsforattachinganexternalmonitor

•Wheninstallinganoperatingsystem,youmustinstallthedisplaydriverforyourmonitorthatissupplied
withthecomputer,andthemonitorINFlethatissuppliedwiththeexternalmonitor.

•Ifyousetaresolutionhigherthantheresolutionyouareusingonthecomputermonitor,andusean
externalmonitorthatdoesnotsupportthatresolution,takeadvantageofthevirtualscreenfunction,
whichenablesyoutodisplayonlyapartofthehigh-resolutionscreenimageyourcomputerproduces.
YoucanseeotherpartsoftheimagebymovingthescreenwiththeTrackPointpointingdeviceoranother
pointingdevice.

•Iftheexternalmonitoryouareusingisoutdated,theresolutionandtherefreshratemightbelimited.

32UserGuide

Usingdualdisplays

ThissectionintroducestheExtenddesktopfunctionthatenablesyoutodisplayoutput(thesameordifferent)
onboththecomputerdisplayandanexternalmonitor.

UsingtheExtenddesktopfunction

YourcomputersupportsafunctionnamedtheExtenddesktop.WiththeExtenddesktopfunction,you
candisplayoutputonboththecomputerdisplayandanexternalmonitor.Y oualsocandisplaydifferent
desktopimagesoneachmonitor.

YoucanusetheExtenddesktopfunctionwithoutchanginganysettings.Ifthefunctiondoesnotwork,refer
to“EnablingtheExtenddesktopfunction”onpage33

toenableit.

ConsiderationsforusingtheExtenddesktopfunction

•IfyouwanttoshowDOSfull-screenwhileintheExtenddesktopmode,onlytheprimarydisplayshows
DOS;theotherdisplayisblackedout.

•Youcandesignatetheotherdisplayastheprimarydisplaybydoingthefollowing:

1.Right-clickonthedesktop,thenselectScreenresolution.

2.SelectExtendthesedisplaysinMultipleDisplays.

3.Changethesettingtodesignatetheprimarydisplay.

•WhenaprogramusingDirectDraworDirect3Displayedinfull-screenmode,itisshownonlyonthe
primarydisplay.

•YoucannotusethedisplayswitchingfunctionwhenyouareintheExtenddesktopmode.

EnablingtheExtenddesktopfunction

ToenabletheExtenddesktopfunction,dothefollowing:

1.Connecttheexternalmonitortothemonitorconnector;thenconnectthemonitortoanelectricaloutlet.

2.T urnontheexternalmonitor.

3.PressFn+F7,thenselectExtend.

Tochangetheresolutionforeachmonitor,dothefollowing:

1.Right-clickonthedesktop,andclickScreenresolution.

2.ClicktheMonitor-1icon(fortheprimarydisplay,thecomputerdisplay).

3.Settheresolutionfortheprimarydisplay.

4.ClicktheMonitor-2icon(forthesecondarydisplay,theexternaldisplay).

5.Settheresolutionforthesecondarydisplay.

6.Placetheiconsforthemonitorssothattheytouch.

Note:Youcansetthemonitorsinanyrelativeposition,buttheiconsmusttoucheachother.

7.ClickOKtoapplythechanges.

Note:Tochangethecolorsettings,right-clickonthedesktop,andclickScreenresolution.ClickAdvanced
Settings,selecttheMonitortab,thensetColors.

Usingaudiofeatures

Yourcomputerisequippedwiththefollowing:

•Comboaudioconnector,1/8inch(3.5mm)indiameter

Chapter2.Usingyourcomputer33

•Built-instereospeakers

•Built-indigitalmicrophone

Yourcomputeralsohasanaudiochipthatenablesyoutoenjoyvariousmultimediaaudiofeatures:

•RecordingandplaybackofPCMandWAVlesin16-bitor24-bitformat

•PlaybackofaWAVleatasamplerateof44.1KHzto192KHz

•PlaybackofMIDIlesthroughaWavetablesynthesizerunderMicrosoftWindowsoperatingsystems

•PlaybackofMP3lesthroughtheWindowsMediaPlayerorasoftwareMP3player

•Recordingfromvarioussoundsources

Note:Thecomboaudioconnectordoesnotsupportaconventionalmicrophone.

Thefollowingtableshowswhichfunctionsoftheaudiodevicesattachedtotheconnectoronyourcomputer
aresupported.

Table3.Audiofeaturelist

Connector

Headsetwitha3.5mm
4-poleplug

ConventionalheadphoneConventionalmicrophone

Comboaudioconnector

Headphoneand
microphonefunctions
supported

Headphonefunction
supported

Notsupported

Conguringforsoundrecording

Tocongurethemicrophoneforoptimizedsoundrecording,usetheRealtekHDAudioManagerprogram.To
starttheprogram,gotoControlPanelandclickHardwareandSound➙RealtekHDAudioManager.

Usingtheintegratedcamera

Ifyourcomputerhasanintegratedcamera,youcanusethecameratopreviewyourvideoimageand
takeasnapshotofyourcurrentimage.

Tostartthecamera,dothefollowing:

•ForWindows7:PressFn+F6toopentheCommunicationssettingswindow.

•ForWindows8:PressFn+F6tostarttheLenovoSettingsprogram.ThenclickCamera.

Whenthecameraisstarted,thegreencamera-in-useindicatorturnson.

Youalsocanusetheintegratedcamerawithotherprogramsthatprovidefeaturessuchasphotographing,
videocapturing,andvideoconferencing.Tousetheintegratedcamerawithotherprograms,openoneofthe
programsandstartthephotographing,videocapturing,orvideoconferencingfunction.Then,thecamera
willstartautomaticallyandthegreencamera-in-useindicatorwillturnon.Formoreinformationaboutusing
thecamerawithaprogram,refertothehelpinformationsystemoftheprogram.

Conguringcamerasettings

Youcancongurethecamerasettingstomeetyourneeds,suchasadjustingthequalityofthevideooutput.

Tocongurethecamerasettings,dothefollowing:

•ForWindows7:PressFn+F6.TheCommunicationssettingswindowopens.ClicktheManageSettings
buttonandcongurethecamerasettingsasdesired.

•ForWindows8,dooneofthefollowing:

34UserGuide

–Congurethecamerasettingsdirectlyfromtheprogramthatisusingthecamera.Fordetails,seethe

helpinformationsystemoftheprogram.

–ClickLenovoSettingsfromtheStartscreen.ThenclickCamera.Followtheinstructionsonthe

screentocongurethecamerasettingsasdesired.

Usingaashmediacard

Yourcomputerhasonemediacardreaderslot.

Themediacardreaderslotsupportsthefollowingfourtypesofcards:

•SecureDigital(SD)card

•SecureDigitalHigh-Capacity(SDHC)card

•SecureDigitaleXtended-Capacity(SDXC)card

•MultiMediaCard(MMC)

Note:Whiletransferringdatatoorfromamediacard,suchasanSDcard,donotputyourcomputerinto
sleeporhibernationmodebeforethedatatransferiscomplete;otherwise,yourdatacouldbecomedamaged.

Formoreinformationaboutashmediacards,refertoanyofthefollowingtopics:

•“Insertingaashmediacard”onpage35

•“Removingaashmediacard”onpage35

Insertingaashmediacard

Attention:Beforeyoustartinstallinganyofthefollowingcards,touchametaltableoragroundedmetal

object.Thisactionreducesanystaticelectricityfromyourbody.Thestaticelectricitycoulddamagethecard.

•SDcard

•SDHCcard

•SDXCcard

•MultiMediaCard

Toinsertaashmediacardintothe4-in-1mediacardreaderslot,dothefollowing:

1.Makesurethatthecardiscorrectlyoriented.

2.Insertthecardrmlyintothe4-in-1mediacardreaderslot.Thecardmightstopbeforeitiscompletely
installedintotheslot.

Iftheashmediacardisnotplugandplay,dothefollowing:

1.OpenControlPanel.

2.ClickHardwareandSound.

3.ClickDeviceManager.Ifyouarepromptedforanadministratorpasswordorconrmation,typethe
passwordorprovideconrmation.

4.FromtheActionmenu,selectAddlegacyhardware.TheAddHardwareWizardstarts.

5.Followtheinstructionsonthescreen.

Removingaashmediacard

Toremoveaashmediacard,dothefollowing:

Chapter2.Usingyourcomputer35

1.ClickthetriangulariconintheWindowsnoticationareatoshowhiddenicons.Then,right-clickthe
SafelyRemoveHardwareandEjectMediaicon.

2.SelectthecorrespondingitemtoejectthecardfromtheWindowsoperatingsystem.

3.Pressthecardtoejectitfromyourcomputer.

4.Removethecardfromyourcomputerandstoreitsafelyforfutureuse.

Note:IfyoudonotremovethecardfromyourcomputerafteryouejectthecardfromtheWindows
operatingsystem,thecardcannolongerbeaccessed.Toaccessthecard,youmustremoveitonce,
theninsertitagain.

36UserGuide

Chapter3.Youandyourcomputer

Thischapterprovidesinformationaboutaccessibility,comfort,andtravelingwithyourcomputer.

Accessibilityandcomfort

Goodergonomicpracticeisimportanttogetthemostfromyourpersonalcomputerandtoavoiddiscomfort.
Arrangeyourworkplaceandtheequipmentyouusetosuityourindividualneedsandthekindofwork
thatyouperform.Inaddition,usehealthyworkhabitstomaximizeyourperformanceandcomfortwhile
usingyourcomputer.

Thefollowingtopicsprovideinformationaboutarrangingyourworkarea,settingupyourcomputer
equipment,andestablishinghealthyworkhabits.

Lenovoiscommittedtoprovidingthelatestinformationandtechnologytoourcustomerswithdisabilities.
Refertoouraccessibilityinformationwhichoutlinesoureffortsinthisarea.

Ergonomicinformation

Workinginthevirtualofcemightmeanadaptingtofrequentchangesinyourenvironment.Forexample,
adaptingtothesurroundinglightsources,properseating,andtheplacementofyourcomputerhardware
canhelpyouimproveyourperformanceandachievegreatercomfort.

Thisexampleshowssomeoneinaconventionalsetting.Evenwhennotinsuchasetting,youcanfollow
manyofthesetips.Developgoodhabits,andtheywillserveyouwell.

Generalposture:Makeminormodicationsinyourworkingposturetodetertheonsetofdiscomfortcaused
bylongperiodsofworkinginthesameposition.Frequent,shortbreaksfromyourworkalsohelptoprevent
minordiscomfortassociatedwithyourworkingposture.

Display:Positionthedisplaytomaintainacomfortableviewingdistanceof510-760mm(20-30inches).
Avoidglareorreectionsonthedisplayfromoverheadlightingoroutsidesourcesoflight.Keepthedisplay
screencleanandsetthebrightnesstolevelsthatenableyoutoseethescreenclearly.PressFn+F8
orFn+F9toadjustdisplaybrightness.

©CopyrightLenovo2013

37

Headposition:Keepyourheadandneckinacomfortableandneutral(vertical,orupright)position.

Chair:Useachairthatgivesyougoodbacksupportandseatheightadjustment.Usechairadjustmentsto

bestsuityourdesiredposture.

Armandhandposition:Ifavailable,usechairarmrestsoranareaonyourworkingsurfacetoprovide
weightsupportforyourarms.Keepyourforearms,wrists,andhandsinarelaxedandneutral(horizontal)
position.Typewithasofttouchwithoutpoundingthekeys.

Legposition:Keepyourthighsparalleltotheoorandyourfeetatontheoororonafootrest.

Whatifyouaretraveling?

Itmightnotbepossibletoobservethebestergonomicpracticeswhenyouareusingyourcomputerwhile
onthemoveorinacasualsetting.Regardlessofthesetting,trytoobserveasmanyofthesetipsas
possible.Sittingproperlyandusingadequatelighting,forexample,willhelpyoumaintaindesirablelevels
ofcomfortandperformance.

Questionsaboutvision?

ThevisualdisplayscreensofThinkPadnotebookcomputersaredesignedtomeetthehigheststandards
andtoprovideyouwithclear,crispimagesandlarge,brightdisplaysthatareeasytosee,yeteasyonthe
eyes.Ofcourse,anyconcentratedandsustainedvisualactivitycanbetiring.Ifyouhavequestionsoneye
fatigueorvisualdiscomfort,consultavisioncarespecialistforadvice.

Comfort

Observethefollowingguidelinestoachievegreatercomfortandimproveperformance.

Activesittingandrestbreaks:Thelongeryousitandworkwithyourcomputer,themoreimportantitisto
observeyourworkingposture.Follow“Ergonomicinformation”onpage37

andpractice“activesitting”to
avoiddiscomfortassociatedwithyourworkingpostures.Makingminorvoluntaryposturalchangesand
takingshortfrequentworkbreaksarethekeyingredientsforhealthycomputing.Y ourcomputerislightand
mobile;youcaneasilyrepositionyourworkingsurfacetoaccommodatemanyposturemodications.

Workareasetupoptions:Familiarizeyourselfwithallofyourofcefurnituresothatyouknowhowto
adjustyourworksurface,seat,andotherworktoolstoaccommodateyourpreferencesforcomfort.
Ifyourworkareaisnotinanofcesetting,besuretotakespecialnoteofemployingactivesitting
andtakingworkbreaks.ManyThinkPadproductsolutionsareavailabletohelpyoumodifyandexpand
yourcomputertobestsuityourneeds.AccessthefollowingWebsitetoviewsomeoftheseoptions:
http://www.lenovo.com/accessories/services/index.html.Exploreyouroptionsfordockingsolutionsand
externalproductsthatprovidetheadjustabilityandfeaturesthatyouwant.

Accessibilityinformation

Lenovoiscommittedtoprovidingpeoplewithdisabilitiesgreateraccesstoinformationandtechnology.
Asaresult,thefollowinginformationprovideswaystohelpusersthathavehearing,vision,andmobility
limitationsgetthemostoutoftheircomputerexperience.

Assistivetechnologiesenableuserstoaccessinformationinthemostappropriateway.Someofthese
technologiesarealreadyprovidedinyouroperatingsystem.Otherscanbepurchasedthroughvendors,or
accessedthroughtheWorldWideWebhttp://www.lenovo.com/healthycomputing.

38UserGuide

Assistivetechnologies

SomeaccessibilitytechnologiesareavailablethroughtheAccessibilityOptionsprogram.Depending
onyouroperatingsystem,thenumberofaccessibilityoptionsavailablevaries.Ingeneral,accessibility
optionsenhancethewayuserswithhearing,vision,ormobilitylimitationsnavigateandusetheircomputer.
Forexample,someusersmightnothavethenemotorskillsrequiredtouseamouseorselectkey
combinations.Otherusersmightrequirelargerfontsorhigh-contrastdisplaymodes.Insomecases,
magniersandbuilt-inspeechsynthesizersareavailable.Fordetailedinformationabouteachofthese
features,consulttheMicrosofthelpinformationsystem.

TousetheAccessibilityOptionsprogram,openControlPanelandclickEaseofAccess➙Easeof

AccessCenter.

Screen-readertechnologies

Screen-readertechnologiesareprimarilyfocusedonsoftwareprograminterfaces,helpinformationsystems,
andavarietyofonlinedocuments.However,inthecasewhereascreenreadercannotreaddocuments,
thedocumentmustrstgothroughaconversionprocess.OnesolutionconvertsAdobePDFlesintoa
formatthatisreadbythescreen-readerprograms.ThissolutionisaWeb-basedserviceprovidedbyAdobe
SystemsIncorporated.Throughhttp://access.adobe.com,AdobePDFdocumentscanbeconvertedto
HTMLorplaintextinmanylanguages.OneconversionoptionconvertsPDFdocumentsontheInternet.A
secondoptionenablesuserstosubmittheURLofanAdobePDFlethroughe-mailtoconvertittoHTMLor
ASCIItext.AdobePDFlesonalocalharddiskdrive,localCD-ROM,orLANalsocanbeconvertedby
attachingtheAdobePDFletoane-mailmessage.

Travelingwithyourcomputer

Thistopicprovidesinformationtohelpyouworkwithyourcomputerwhenyouaretraveling.

Traveltips

Usethefollowingtraveltipstotravelmorecondentlyandefcientlywithyourcomputer.

•Althoughitissafetoallowyourcomputertogothroughthex-raymachinesatairportsecuritystations,it
isimportanttokeepyoureyesonthecomputeratalltimestopreventtheft.

•Considerbringinganelectricaladapterforuseinanairplaneorautomobile.

•Ifyoucarryanacpoweradapter,detachtheaccordfromittoavoiddamagingthecord.

Traveltipsonairplanes

Ifyoucarryyourcomputerintoanairplane,takenoteofthefollowingtips:

•Ifyouintendtouseyourcomputerorwirelessservices(suchasInternetandBluetooth),checkwiththe
airlineforrestrictionsandavailabilityofservicesbeforeboardingtheairplane.Iftherearerestrictions
ontheuseofcomputerswithwirelessfeaturesontheairplane,youmustabidebythoserestrictions.If
necessary,disablewirelessfeaturesbeforeboarding.

•Becarefulabouttheseatinfrontofyouonairplanes.Angleyourcomputerdisplaysothatitdoesnotget
caughtwhenthepersoninfrontofyouleansback.

•Whentakingoff,remembertoturnoffyourcomputerorputitintohibernationmode.

Travelaccessories

Thefollowingisachecklistofitemstoconsiderpackingwhenyouaregoingtotravel:

•ThinkPadacpoweradapter

•ThinkPadAC/DCComboAdapter

Chapter3.Y ouandyourcomputer39

•Externalmouse,ifyouareaccustomedtousingone

•Ethernetcable

•Extrabattery,charged

•Aqualitycarryingcasethatprovidesadequatecushionandprotection

•Externalstoragedevice

Ifyouaretravelingtoanothercountry,youmightwanttoconsideranacpoweradapterforthecountryto
whichyouaretraveling.

Topurchasetravelaccessories,gotohttp://www.lenovo.com/accessories.

40UserGuide

Chapter4.Security

Thischapterprovidesinformationabouthowtoprotectyourcomputerfromtheftandunauthorizeduse.

•“Attachingamechanicallock”onpage41

•“Usingpasswords”onpage41

•“Harddisksecurity”onpage46

•“Noticeondeletingdatafromyourharddiskdriveorsolid-statedrive”onpage46

•“Usingrewalls”onpage47

•“Protectingdataagainstviruses”onpage47

Attachingamechanicallock

Youcanattachamechanicallocktoyourcomputertohelppreventitfrombeingremovedwithoutyour
permission.

Attachamechanicallocktothekeyholeofthecomputer;thensecurethechainonthelocktoastationary
object.Refertotheinstructionsshippedwiththemechanicallock.

Note:Y ouareresponsibleforevaluating,selecting,andimplementingthelockingdevicesandsecurity
features.Lenovomakesnocomments,judgments,orwarrantiesaboutthefunction,quality,orperformance
oflockingdevicesandsecurityfeatures.

Usingpasswords

Byusingpasswords,youcanhelppreventyourcomputerfrombeingusedbyothers.Onceyouseta
password,apromptisdisplayedonthescreeneachtimeyouturnonthecomputer.Enteryourpasswordat
theprompt.Y oucannotusethecomputerunlessyouenterthevalidpassword.

Passwordsandsleepmode

Ifyouhavesetpasswordsandyouputyourcomputerintosleepmode,theprocedureforresuming
operationisasfollows:

•Youarenotpromptedtotypethepasswordwhenresumingoperation.

•Ifanyharddiskdriveorsolid-statedrivehasapassword,itisunlockedautomaticallywhenyouresume
operation.

Note:IfaWindowspasswordhasbeenset,youwillbepromptedtoenterit.

Typingpasswords

Ifthisiconisdisplayed,typeapower-onpasswordorasupervisorpassword.

Ifthisiconisdisplayed,typeauserharddiskpassword.Ifyouwanttotypeamasterharddisk

password,dothefollowing:

1.PressF1.Theiconchangestothis:

2.T ypethemasterharddiskpassword.

©CopyrightLenovo2013

41

Note:Toreturntotheicon,pressF1again.

Note:PresstheBackspacekeyifyouenterawrongpasswordwhileyouaretypingyourpassword.

Power-onpassword

Youcansetapower-onpasswordtohelpprotectyourcomputeragainstaccessbyunauthorizedusers.

Ifyousetapower-onpassword,thepasswordpromptisdisplayedonthescreenwheneveryouturnonthe
computer.Youmustenterthecorrectpasswordtostartusingthecomputer.

Settingapower-onpassword

1.Printtheseinstructions.

2.Saveallopenles,andexitallprograms.

3.T urnyourcomputeroffandthenturnitonagain.

4.Whenthelogoscreenisdisplayed,pressF1.TheThinkPadSetupprogrammainmenuopens.

5.SelectSecurity,usingthecursordirectionalkeystomovedownthemenu.

6.SelectPassword.

7.SelectPower-onPassword.

8.IntheEnterNewPasswordeld,typeadesiredpassword,andpressEnter.

9.IntheConrmNewPasswordeld,retypethepasswordandpressEnter.

Attention:Youmightwanttonotedownyourpower-onpasswordinasafeplace.Otherwise,ifyou
forgetit,youhavetotakeyourcomputertoaLenovoreselleroramarketingrepresentativetohave
thepasswordcanceled.

10.IntheSetupNoticewindowthatisdisplayed,pressEntertocontinue.

11.PressF10.TheSetupConrmationwindowopens.SelectYestosavecongurationchangesandexit.

Changingorremovingthepower-onpassword
Tochangethepower-onpassword,followsteps1through7.Enteryourcurrentpassword.WhentheEnter

NewPasswordeldisdisplayed,typeanewpasswordintheeldandthenretypeittoverify.T oremove

thepassword,followsteps1through7.Typeyourcurrentpassword.WhentheEnterNewPasswordeld
isdisplayed,leaveitblankandpressEntertwice.

Harddiskpasswords

Twotypesofharddiskpasswordshelpprotecttheinformationstoredontheharddiskdrive:

•Userharddiskpassword

•Masterharddiskpassword,whichrequiresauserharddiskpassword

Ifauserharddiskpasswordhasbeenset,butnomasterharddiskpasswordhasbeen,theusermustenter
theuserharddiskpasswordinordertogainaccesstolesandprogramsontheharddiskdrive.

Themasterpasswordcanbesetandusedonlybyasystemadministrator.Likeamasterkey,itenablesthe
administratortogetaccesstoanyharddiskdriveinasystem.Theadministratorsetsthemasterpassword;
nooneelseknowsit.Thentheadministratorsetsauserpasswordforeachcomputerinthenetwork,and
tellseachuserthepasswordforhisorhercomputer.Theusercanthenchangetheuserpasswordas
desired,buttheadministratorstillcangetaccessbyusingthemasterpassword.

42UserGuide

Note:Whenamasterharddiskpasswordisset,onlytheadministratorcanremovetheuserharddisk
password.

Settingaharddiskpassword

1.Printtheseinstructions.

2.Saveallopenles,andexitallprograms.

3.T urnyourcomputeroffandthenonagain.

4.Whenthelogoscreenisdisplayed,pressF1.TheThinkPadSetupprogrammainmenuopens.

5.SelectSecurity,usingthecursordirectionalkeystomovedownthemenu.

6.SelectPassword.

7.SelectHardDisk1Password.

8.Apasswordwindowopens.Y ouarepromptedtoselectUserorUser+Master.SelectUserifyouwant
tosetonlyoneharddiskpassword.Ifyouareanadministratororsupervisor,youcanselectUser+
Mastertosettwopasswords.(Theusercanchangetheuserpasswordlater.)

•IfyouselectUser+Master,dothefollowing:

a.Whenawindowfortypingthenewuserharddiskpasswordopens,typeyournewpasswordin

theEnterNewPasswordeld.PressEnter.
b.IntheConrmNewPasswordeld,retypethepasswordyoujustenteredtoverifyit.PressEnter.
c.Amessagewindowopensandpromptsyoutosetthemasterharddiskpassword.PressEnterto

continue.
d.Awindowfortypingthenewmasterharddiskpasswordopens.T ypeyournewpasswordin

theEnterNewPasswordeld.PressEnter.
e.IntheConrmNewPasswordeld,retypethepasswordyoujustenteredtoverifyit.PressEnter.

•IfyouselectUseronly,dothefollowing:
a.Whenawindowfortypingthenewpasswordopens,typeyournewpasswordintheEnterNew

Passwordeld.PressEnter.

Notes:

–YoucansettheminimumlengthofaharddiskpasswordthroughtheSecuritymenu.
–Ifyousetaharddiskpasswordofoversevencharacters,theharddiskdrivecanbeusedonly

withacomputerthatcanrecognizeaharddiskpasswordofoversevencharacters.Ifyouthen
installtheharddiskdriveinacomputerthatcannotrecognizeaharddiskpasswordthat
containsmorethansevencharacters,youcannotgetaccesstothedrive.

b.IntheConrmNewPasswordeld,retypethepasswordyoujustenteredtoverifyit.PressEnter.

Attention:Youmightwanttonotedownyourpasswordsandkeeptheminasafeplace.Otherwise,if
youforgettheuserpassword,orbothuserandmasterpasswords,Lenovocannotresetyourpasswords
orrecoverdatafromtheharddiskdrive.Y oumusttakeyourcomputertoaLenovoresellerora
marketingrepresentativetohavetheharddiskdrivereplaced.Proofofpurchaseisrequired,andafee
willbechargedforpartsandservice.

9.IntheSetupNoticewindowthatisdisplayed,pressEntertocontinue.

10.PressF10.TheSetupConrmationwindowopens.SelectYestosavecongurationchangesandexit.

Thenexttimeyouturnonyourcomputer,youwillhavetotypetheuserormasterharddiskpasswordin
ordertostartyourcomputerandgetaccesstoyouroperatingsystem.

Chapter4.Security43

Changingorremovingaharddiskpassword

Followsteps1through7in“Settingaharddiskpassword”onpage43,typingyourpasswordtogetaccess
totheThinkPadSetupprogram.

Tochangeorremovetheuserharddiskpassword,dothefollowing:

•Tochangetheharddiskpassword,typethecurrentpasswordintheEnterCurrentPasswordeld.Then
typethenewpasswordintheEnterNewPasswordeld,andretypethepasswordyoujustenteredto
verifyitintheConrmNewPasswordeld.PressEnter,andaSetupNoticewindowisdisplayed.Press
EntertoexitfromtheSetupNoticewindow.Theuserharddiskpasswordwillbechanged.

•Toremovetheharddiskpassword,typethecurrentpasswordintheEnterCurrentPasswordeld.Then
leavetheEnterNewPasswordandConrmNewPasswordeldsblank,andpressEnter.ASetup
Noticewindowisdisplayed.PressEntertoexitfromtheSetupNoticewindow.Theuserharddisk
passwordwillberemoved.

TochangeorremovetheUser+Masterharddiskpasswords,selectUserHDPorMasterHDP.

IfyouchooseUserHDP,dothefollowing:

•Tochangetheuserharddiskpassword,typethecurrentuserharddiskpasswordorthecurrentmaster
harddiskpasswordintheEnterCurrentPasswordeld.Thentypethenewuserharddiskpasswordin
theEnterNewPasswordeld,andretypethepasswordyoujustenteredtoverifyitintheConrmNew
Passwordeld.PressEnter,andaSetupNoticewindowisdisplayed.PressEntertoexitfromtheSetup
Noticewindow.Theuserharddiskpasswordischanged.

•Toremovetheuserharddiskpassword,typethecurrentmasterharddiskpasswordintheEnterCurrent
Passwordeld.ThenleavetheEnterNewPasswordandConrmNewPasswordeldsblank,and
pressEnter.ASetupNoticewindowisdisplayed.PressEntertoexitfromtheSetupNoticewindow.Both
theuserandmasterharddiskpasswordswillberemoved.

IfyouchooseMasterHDP,dothefollowing:

•Tochangethemasterharddiskpassword,typethecurrentmasterharddiskpasswordintheEnter
CurrentPasswordeld.ThentypethenewmasterharddiskpasswordintheEnterNewPassword
eld,andretypethepasswordyoujustenteredtoverifyitintheConrmNewPasswordeld.Press
Enter,andaSetupNoticewindowisdisplayed.PressEntertoexitfromtheSetupNoticewindow.The
masterharddiskpasswordischanged.

•Toremovethemasterharddiskpassword,typethecurrentmasterharddiskpasswordintheEnter
CurrentPasswordeld.ThenleavetheEnterNewPasswordandConrmNewPasswordeldsblank,
andpressEnter.ASetupNoticewindowisdisplayed.PressEntertoexitfromtheSetupNoticewindow.
Boththeuserandmasterharddiskpasswordswillberemoved.

Supervisorpassword

ThesupervisorpasswordprotectsthesysteminformationstoredinThinkPadSetup.Withoutit,noonecan
changethecongurationofthecomputer.Itprovidesthefollowingsecurityfeatures:

•Ifasupervisorpasswordisset,apasswordpromptisdisplayedwhenyoutrytostarttheThinkPadSetup
program.Unauthorizeduserscannotgetaccesstocongurationdata.

•Thesystemadministratorcanusethesupervisorpasswordtogetaccesstoacomputereveniftheuserof
thatcomputerhassetapower-onpassword.Thesupervisorpasswordoverridesthepower-onpassword.

•Ifbothasupervisorpasswordandapower-onpasswordareset,youcandothefollowingonlyifyou
havethesupervisorpassword:

–Deletingthepower-onpassword
–Changingordeletingthesupervisorpassword

44UserGuide

–EnablingordisablingtheWakeonLAN
–EnablingordisablingtheInternalNetworkOptionROMfeature
–Changingdateandtime
–EnablingordisablingtheLockUEFIBIOSSettingsfeature
–EnablingordisablingthePasswordatunattendedbootfeature
–Specifyingtheminimumlengthforpower-onpasswordsandharddiskpasswords
–EnablingordisablingtheBootDeviceListF12Optionfeature
–EnablingordisablingtheBootOrderLockfeature
–EnablingordisablingtheFlashBIOSUpdatingbyEnd-Usersfeature
–Enablingordisablingtheinternalnetworkdevice
–Enablingordisablingtheinternalwirelessdevice
–EnablingordisablingtheinternalBluetoothdevice
–EnablingordisablingtheSecuritymode

Notes:

•ThesystemadministratorcansetthesamesupervisorpasswordonmanyThinkPadnotebookcomputers
tomakeadministrationeasier.

•ByenablingtheLockUEFIBIOSSettingsfeatureonthePasswordmenuwhenyousetthesupervisor
password,youmakeitimpossibleforanyonebutyoutomakechanges.

Setting,changing,orremovingasupervisorpassword

Onlyasystemadministratorcanset,change,orremoveasupervisorpassword.

Toset,change,orremoveasupervisorpassword,dothefollowing:

1.Printtheseinstructions.

2.Saveallopenles,andexitallprograms.

3.T urnyourcomputeroffandthenturnitonagain.

4.Whenthelogoscreenisdisplayed,pressF1.TheThinkPadSetupprogrammainmenuopens.

5.SelectSecurity,usingthecursordirectionalkeystomovedownthemenu.

6.SelectPassword.

7.SelectSupervisorPassword.

8.Awindowopens,promptingyoutoenteranewpassword.Dependingonyourneeds,dooneofthe
following:

•Tosetapassword,dothefollowing:

a.IntheEnterNewPasswordeld,typeadesiredpasswordandpressEnter.
b.IntheConrmNewPasswordeld,retypethepasswordandpressEnter.

•Tochangeapassword,dothefollowing:

a.IntheEnterCurrentPasswordeld,typethecurrentsupervisorpasswordandpressEnter.
b.IntheEnterNewPasswordeld,typethenewsupervisorpassword;thenretypethepassword

youjustenteredtoverifyitintheConrmNewPasswordeld.PressEnter.

•Toremoveapassword,dothefollowing:

a.IntheEnterCurrentPasswordeld,typethecurrentsupervisorpasswordandpressEnter.
b.LeavetheEnterNewPasswordandConrmNewPasswordeldsblank.PressEnter.

Chapter4.Security45

Attention:Youmightwanttonotedownyourpasswordandkeepitinasafeplace.Ifyouforgetyour
supervisorpassword,Lenovocannotresetyourpassword.YoumusttakeyourcomputertoaLenovo
reselleroraLenovomarketingrepresentativetohavethesystemboardreplaced.Proofofpurchaseis
required,andafeewillbechargedforpartsandservice.

9.IntheSetupNoticewindowthatisdisplayed,pressEntertocontinue.

10.PressF10.TheSetupConrmationwindowopens.SelectYestosavecongurationchangesandexit.

ThenexttimeyouopentheThinkPadSetupprogram,youwillbepromptedtotypeyourpasswordtoproceed.

Harddisksecurity

Toprotectpasswordsfromunauthorizedsecurityattacks,severalofthelatesttechnologiesandalgorithms
areintegratedintoUEFIBIOSandhardwaredesignofThinkPadnotebookcomputers.

Tomaximizesecurity,dothefollowing:

1.Setapower-onpasswordaswellasaharddiskpasswordforyourinternalsolid-statedriveorharddisk
drive.Refertotheproceduresin“Power-onpassword”onpage42and“Harddiskpasswords”onpage
42

.Forsecurity,alongerpasswordisrecommended.

2.IfaDiskEncryptionharddiskdriveoraDiskEncryptionsolid-statedriveisinstalledinyourcomputer,
besuretoprotectthecontentsofyourcomputermemoryfromunauthorizedaccessesbyuseofdrive
encryptionsoftware.

3.Beforeyoudisposeof,sell,orhandoveryourcomputer,besuretodeletedatastoredonit.Referto
“Noticeondeletingdatafromyourharddiskdriveorsolid-statedrive”onpage46.

Note:TheharddiskdrivebuiltintoyourcomputercanbeprotectedbyUEFIBIOS.

DiskEncryptionharddiskdriveandEncryptionsolid-statedrive

SomemodelscontaintheDiskEncryptionharddiskdriveorEncryptionsolid-statedrive.Thisfeature
helpstoprotectyourcomputeragainstsecurityattacksonmedia,NANDashordevicecontrollersbyuse
ofahardwareencryptionchip.Fortheefcientuseoftheencryptionfeature,besuretosetaharddisk
passwordfortheinternalstoragedevice.

Noticeondeletingdatafromyourharddiskdriveorsolid-statedrive

Ascomputersspreadintoeverycorneroflife,theyprocessmoreandmoreinformation.Thedataonyour
computer,someofwhichmightbesensitive,isstoredonaharddiskdriveorsolid-statedrive.Beforeyou
disposeof,sell,orhandoveryourcomputer,besuretodeletedatastoredonit.

Handingyourcomputerovertosomeoneelsewithoutdeletingtheloadedsoftware,suchasoperating
systemsandprogramsoftware,mightevenviolatelicenseagreements.Youareadvisedtocheckthe
termsandconditionsofthoselicenseagreements.

Therearemethodsthatseemtodeletethedata:

•Movethedatatotherecyclebin,andthenemptytheRecycleBin.

•Deletethedata.

•Formatyourharddiskdriveorsolid-statedrive,usingthesoftwareforinitializingit.

•UsetherecoveryprogramprovidedbyLenovotobringtheharddiskdriveorsolid-statedrivebackto
thefactorydefaultsettings.

Theseoperations,however,onlychangetheleallocationofthedata;theydonotdeletethedataitself.In
otherwords,thedataretrievalprocessingisdisabledunderanoperatingsystemsuchasWindows.The

46UserGuide

dataisstillthere,eventhoughitseemstobelost.Thus,itissometimespossibletoreadthedatabyuseof
specialsoftwarefordatarecovery.Thereisariskthatpeopleofbadfaithmightreadandmisusethecritical
dataonharddiskdrivesorsolid-statedrivesforunexpectedpurposes.

Topreventleakageofdata,itbecomesveryimportantthatyoutakeresponsibilityfordeletingallthedata
fromtheharddiskdriveorsolid-statedrivewhenyoudisposeof,sell,orhandoveryourcomputer.Y ou
candestroythedataphysicallybysmashingtheharddiskdriveorsolid-statedrivewithahammer,or
magneticallybymeansofstrongmagneticpower,thusmakingthedataunreadable.Butwerecommend
thatyoumakeuseofthesoftware(payware)orservice(payservice)specicallydevelopedforthepurpose.

Fordisposingofdataontheharddiskdriveorsolid-statedrive,LenovoprovidestheSecureDataDisposal
tool.Todownloadtheprogram,goto:
http://www.lenovo.com/support

Note:Runningeitherprogramwilltakeacoupleofhours.

Ifyouusesoftwaredesignedforusewiththeharddiskdrivetodeletedatastoredonthesolid-statedrive,it
willeraseonlydatathatisaccessiblebynormaloperation.Itmaynoterasethehiddenareaoftheash
chip.Therefore,sometimesitmaystillbepossibletoreadthedatabyuseofspecialequipmentora
specialtool.T opreventleakageofdatafromthesolid-statedrive,itisrecommendedthatyoudelete
alldataontheashchipsbyuseofaprogramprovidedbyLenovo.ThisprogramcalledtheThinkPad
SetupMenuExtensionUtilitymakesitpossibletoeraseallthedataontheashchipsofthesolid-state
drivefromtheThinkPadSetupwithinaminute.Todownloadthisprogram,gototheLenovoWebsite
http://www.lenovo.com/support.

IfEncryptionsolid-statedriveorDiskEncryptionharddiskdriveissupportedandinstalledinyourcomputer,
youcanlogicallydisposeofallthedataonadeviceinaveryshorttimebyerasingthecryptographickey.
Thedataencryptedwiththeoldkeyisnotphysicallyerasedbutremainsonthedisk;however,itcannotbe
decryptedwithouttheoldkey.ThisfeatureisenabledbytheThinkPadSetupMenuExtensionUtilityandis
availableasamenuitemintheThinkPadSetup.

Usingrewalls

Ifyoursystemispreinstalledwitharewallprogram,itprotectsagainstcomputerInternetsecuritythreats,
unauthorizedaccesses,intrusions,andInternetattacks.Italsoprotectsyourprivacy.

Formoreinformationabouthowtousetherewallprogram,refertothehelpinformationsystemthat
comeswiththeprogram.

Protectingdataagainstviruses

Yourcomputerispreinstalledwithanantivirusprogramsoyoucandetectandeliminateviruses.The
antivirusprogramisdesignedtohelpyoudetectandeliminateviruses.

Lenovoprovidesafullversionofantivirussoftwareonyourcomputerwithafree30-daysubscription.After
30days,youmustrenewthelicensetocontinuereceivingtheantivirussoftwareupdates.

Formoreinformationabouthowtouseyourantivirussoftware,refertothehelpinformationsystemof
yourantivirussoftware.

Chapter4.Security47

48UserGuide

Chapter5.Recoveryoverview

Thischapterprovidesinformationabouttherecoverysolutions.

•“RecoveryoverviewfortheWindows7operatingsystem”onpage49

•“RecoveryoverviewfortheWindows8operatingsystem”onpage54

RecoveryoverviewfortheWindows7operatingsystem

ThissectionprovidesinformationabouttherecoverysolutionsprovidedbyLenovoontheWindows7
operatingsystem.

Notes:

•Thereareavarietyofmethodstochoosefromwhenconsideringhowtorecoverintheeventofa
software-relatedorhardware-relatedproblem.Somemethodsvarydependingonthetypeofyour
operatingsystem.

•Theproductontherecoverymediamightbeusedonlyforthefollowingpurposes:

–Restoretheproductpreinstalledonyourcomputer
–Reinstalltheproduct
–ModifytheproductusingtheAdditionalFiles

Notes:Topreventpotentialperformancerisksorunexpectedbehaviorthatmightbecausedbythenew
harddiskdrivetechnology,itisrecommendedthatyouuseoneofthefollowingback-upsoftwareprograms:

•ThinkVantageRescueandRecoveryversion4.3orlater

•SymantecNortonGhostversion15orlater

Notes:Tousethisprogram,dothefollowing:

1.ClickStart➙Run.TheRunwindowopens.

2.T ypecmdintheeld.ThenclickOK.

3.T ypeghost-align=1mbandpressEnter.

•AcronisTrueImage2010orlater

•ParagonBackup&Recovery10Suiteorlater,ParagonBackup&Recovery10Homeorlater

Creatingandusingarecoverymedia

Youcanuserecoverymediatorestoretheharddiskdrivetothefactorydefaultsettings.Recoverymedia
areusefulifyoutransferthecomputertoanotherarea,sellthecomputer,recyclethecomputer,orputthe
computerinanoperationalstateafterallothermethodsofrecoveryhavefailed.Asaprecautionarymeasure,
itisimportanttocreaterecoverymediaasearlyaspossible.

Note:Therecoveryoperationsyoucanperformusingrecoverymediavarydependingontheoperating
systemfromwhichtherecoverymediawerecreated.Therecoverymediamightcontainabootmedium
andadatamedium.YourMicrosoftWindowslicensepermitsyoutocreateonlyonedatamedium,soitis
importantthatyoustoretherecoverymediainasafeplaceafteryouhavemadethem.

Creatingrecoverymedia

Thissectionprovidesinstructionsonhowtocreaterecoverymedia.

©CopyrightLenovo2013

49

Note:YoucancreaterecoverymediausingdiscsorexternalUSBstoragedevices.

Tocreaterecoverymedia,clickStart➙AllPrograms➙LenovoThinkVantageTools➙FactoryRecovery

Disks.Then,followtheinstructionsonthescreen.

Usingrecoverymedia

Youcanuserecoverymediatorestorethecomputertothefactorydefaultsettingsonly.Youcanuse
recoverymediatoputthecomputerinanoperationalstateafterallothermethodsofrecoveryhavefailed.

Attention:Whenyouuserecoverymediatorestorethecomputertothefactorydefaultsettings,alltheles
currentlyontheharddiskdrivewillbedeletedandreplacedbythefactorydefaultsettings.

Touserecoverymedia,dothefollowing:

1.Dependingonthetypeofyourrecoverymedia,connectthebootmedium(memorykeyorotherUSB
storagedevice)tothecomputer,orinsertthebootdiscintotheexternalopticaldrive.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhentheBootMenuwindow
opens,releasetheF12key.

3.SelectthedesiredstartupdeviceandpressEnter.Therestoreprocessbegins.

4.Followtheinstructionsonthescreentocompletetheoperation.

Notes:

1.Afterrestoringyourcomputertothefactorydefaultsettings,youmighthavetoreinstalldevicedrivers
forsomedevices.See“Reinstallingpreinstalledprogramsanddevicedrivers”onpage53.

2.SomecomputerscomewithMicrosoftOfceorMicrosoftWorkspreinstalled.Ifyouneedtorecover
orreinstallyourMicrosoftOfceorMicrosoftWorksprograms,youmustusetheMicrosoftOfceCD
orMicrosoftWorksCD.ThesediscsareprovidedonlywithcomputerspreinstalledwithMicrosoft
OfceorMicrosoftWorks.

Performingbackupandrecoveryoperations

TheRescueandRecoveryprogramenablesyoutobackupallyourharddiskdrivecontentsincludingthe
operatingsystem,datales,softwareprograms,andpersonalsettings.Youcandesignatewherethe
RescueandRecoveryprogramstoresthebackup:

•Inaprotectedareaofyourharddiskdrive

•OnanattachedexternalUSBharddiskdrive

•Onanetworkdrive

•Onrecordablediscs(arecordableopticaldriveisrequiredforthisoption)

Afteryouhavebackedupthecontentsontheharddiskdrive,youcanrestorethecompletecontentsofthe
harddiskdrive,restoreonlytheselectedles,orrestoreonlytheWindowsoperatingsystemandprograms.

Performingabackupoperation

ThissectionprovidesinstructionsonhowtoperformabackupoperationusingtheRescueandRecovery
program.

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙LenovoThinkVantageT ools➙Enhanced
BackupandRestore.TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoverymainwindow,clicktheLaunchadvancedRescueandRecoveryarrow.

3.ClickBackupyourharddriveandselectbackupoperationoptions.Then,followtheinstructionson
thescreentocompletethebackupoperation.

50UserGuide

Performingarecoveryoperation

ThissectionprovidesinstructionsonhowtoperformarecoveryoperationusingtheRescueandRecovery
program.

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙LenovoThinkVantageT ools➙Enhanced
BackupandRestore.TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoveryprogrammainwindow,clicktheLaunchadvancedRescueandRecovery
arrow.

3.ClicktheRestoreyoursystemfromabackupicon.

4.Followtheinstructionsonthescreentocompletetherecoveryoperation.

FormoreinformationaboutperformingarecoveryoperationfromtheRescueandRecoveryworkspace,see
“UsingtheRescueandRecoveryworkspace”onpage51.

UsingtheRescueandRecoveryworkspace

TheRescueandRecoveryworkspaceresidesinaprotected,hiddenareaofyourharddiskdrivethat
operatesindependentlyfromtheWindowsoperatingsystem.Thisenablesyoutoperformrecovery
operationsevenifyoucannotstarttheWindowsoperatingsystem.Y oucanperformthefollowingrecovery
operationsfromtheRescueandRecoveryworkspace:

•Rescuelesfromyourharddiskdriveorfromabackup
TheRescueandRecoveryworkspaceenablesyoutolocatelesonyourharddiskdriveandtransfer

themtoanetworkdriveorotherrecordablemedia,suchasaUSBdeviceoradisc.Thissolutionis
availableevenifyoudidnotbackupyourlesorifchangesweremadetothelessinceyourlastbackup
operation.YoualsocanrescueindividuallesfromaRescueandRecoverybackuplocatedonyourlocal
harddiskdrive,aUSBdevice,oranetworkdrive.

•RestoreyourharddiskdrivefromaRescueandRecoverybackup
IfyouhavebackedupyourharddiskdriveusingtheRescueandRecoveryprogram,youcanrestorethe

harddiskdrivefromaRescueandRecoverybackup,evenifyoucannotstarttheWindowsoperating
system.

•Restoreyourharddiskdrivetothefactorydefaultsettings
TheRescueandRecoveryworkspaceenablesyoutorestorethecompletecontentsofyourharddiskdrive

tothefactorydefaultsettings.Ifyouhavemultiplepartitionsonyourharddiskdrive,youhavetheoption
torestorethefactorydefaultsettingstotheC:partitionandleavetheotherpartitionsintact.Becausethe
RescueandRecoveryworkspaceoperatesindependentlyfromtheWindowsoperatingsystem,youcan
restorethefactorydefaultsettingsevenifyoucannotstarttheWindowsoperatingsystem.

Attention:IfyourestoretheharddiskdrivefromaRescueandRecoverybackuporrestoretheharddisk
drivetothefactorydefaultsettings,alllesontheprimaryharddiskdrivepartition(usuallydriveC:)willbe
deletedintherecoveryprocess.Ifpossible,makecopiesofimportantles.Ifyouareunabletostartthe
Windowsoperatingsystem,youcanusetherescuelesfeatureoftheRescueandRecoveryworkspaceto
copylesfromyourharddiskdrivetoothermedia.

TostarttheRescueandRecoveryworkspace,dothefollowing:

1.Makesurethatthecomputeristurnedoff.

2.RepeatedlypressandreleasetheF11keywhenturningonthecomputer.Whenyouhearbeepsor
seealogoscreen,releasetheF11key.

3.IfyouhavesetaRescueandRecoverypassword,typeyourpasswordwhenprompted.TheRescue
andRecoveryworkspaceopensafterashortdelay.

Note:IftheRescueandRecoveryworkspacefailstoopen,see“Solvingrecoveryproblems”onpage53

.

Chapter5.Recoveryoverview51

4.Dooneofthefollowing:

•Torescuelesfromyourharddiskdriveorfromabackup,clickRescuelesandfollowthe
instructionsonthescreen.

•TorestoreyourharddiskdrivefromaRescueandRecoverybackuportorestoreyourharddiskdrive
tothefactorydefaultsettings,clickRestoreyoursystemandfollowtheinstructionsonthescreen.

FormoreinformationaboutthefeaturesoftheRescueandRecoveryworkspace,clickHelp.

Notes:

1.Afterrestoringyourharddiskdrivetothefactorydefaultsettings,youmighthavetoreinstalldevice
driversforsomedevices.See“Reinstallingpreinstalledprogramsanddevicedrivers”onpage53.

2.SomecomputerscomewithMicrosoftOfceorMicrosoftWorkspreinstalled.Ifyouneedtorecover
orreinstallyourMicrosoftOfceorMicrosoftWorksprograms,youmustusetheMicrosoftOfceCD
orMicrosoftWorksCD.ThesediscsareprovidedonlywithcomputerspreinstalledwithMicrosoft
OfceorMicrosoftWorks.

Creatingandusingarescuemedium

Witharescuemedium,suchasadiscoraUSBharddiskdrive,youcanrecoverthecomputerfromfailures
thatpreventyoufromgainingaccesstotheRescueandRecoveryworkspaceonyourharddiskdrive.

Notes:

1.Therecoveryoperationsyoucanperformusingarescuemediumvarydependingontheoperating
system.

2.Therescuedisccanbestartedinalltypesofexternalopticaldrives.

Creatingarescuemedium

Thissectionprovidesinstructionsonhowtocreatearescuemedium.

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙LenovoThinkVantageT ools➙Enhanced
BackupandRestore.TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoverymainwindow,clicktheLaunchadvancedRescueandRecoveryarrow.

3.ClicktheCreateRescueMediaicon.TheCreateRescueandRecoveryMediawindowopens.

4.IntheRescueMediaarea,selectthetypeoftherescuemediumyouwanttocreate.Youcancreatea
rescuemediumusingadiscoraUSBharddiskdrive.

5.ClickOKandfollowtheinstructionsonthescreentocreatearescuemedium.

Usingarescuemedium

Thissectionprovidesinstructionsonhowtousetherescuemediumyouhavecreated.

•Ifyouhavecreatedarescuemediumusingadisc,usethefollowinginstructionstousetherescuemedium:

1.T urnoffyourcomputer.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhentheBootMenu
windowopens,releasetheF12key.

3.IntheBootMenuwindow,selectthedesiredopticaldriveastherstbootdevice.Then,insertthe
rescuediscintotheexternalopticaldriveandpressEnter.Therescuemediumstarts.

•IfyouhavecreatedarescuemediumusingaUSBharddiskdrive,usethefollowinginstructionsto
usetherescuemedium:

1.AttachtheUSBharddiskdrivetooneoftheUSBconnectorsonyourcomputer.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhentheBootMenu
windowopens,releasetheF12key.

52UserGuide

3.IntheBootMenuwindow,selecttheUSBharddiskdriveastherstbootdeviceandpressEnter.
Therescuemediumstarts.

Whentherescuemediumstarts,theRescueandRecoveryworkspaceopens.Thehelpinformationfor
eachfeatureisavailablefromtheRescueandRecoveryworkspace.Followtheinstructionstocomplete
therecoveryprocess.

Reinstallingpreinstalledprogramsanddevicedrivers

Yourcomputerhasprovisionsthatenableyoutoreinstallselectedfactory-installedprogramsanddevice
drivers.

Reinstallingpreinstalledprograms

Toreinstallselectedprograms,dothefollowing:

1.T urnonyourcomputer.

2.GototheC:\SWTOOL Sdirectory.

3.OpentheAPPSfolder.Initareseveralsubfoldersnamedforthevariouspreinstalledprograms.

4.Openthesubfolderfortheprogramyouarereinstalling.

5.Double-clickSetup,andthenfollowtheon-screenstepstoreinstalltheprogram.

Reinstallingpreinstalleddevicedrivers
Attention:Whenyoureinstalldevicedrivers,youarechangingthecurrentcongurationofyourcomputer.

Reinstalldevicedriversonlywhenitisnecessarytocorrectaproblemwithyourcomputer.

Toreinstalladevicedriverforafactory-installeddevice,dothefollowing:

1.T urnonyourcomputer.

2.GototheC:\SWTOOL Sdirectory.

3.OpentheDRIVERSfolder.WithintheDRIVERSfolderareseveralsubfoldersnamedforthevarious
devicesinstalledinyourcomputer(forexample,AUDIOandVIDEO).

4.Openthesubfolderforthedevice.

5.Reinstallthedevicedriverbyoneofthefollowingmethods:

•Inthesubfolderforthedevice,lookforatextle(alewiththeextension.txt).Thetextlecontains

informationonhowtoreinstallthatdevicedriver.

•Ifthesubfolderforthedevicecontainsaleofsetupinformation(alewiththeextension.inf),you

canusetheAddNewHardwareprogram(intheWindowsControlPanel)toreinstallthedevicedriver.
Notalldevicedriverscanbereinstalledbyuseofthisprogram.IntheAddNewHardwareprogram,
whenpromptedforthedevicedriveryouwanttoinstall,clickHaveDiskandBrowse.Thenselect
thedevicedriverlefromthedevicesubfolder.

•Inthesubfolderforthedevice,lookfortheexecutablele(alewiththeextension.exe).Double-click

thele,andfollowtheinstructionsonthescreen.

Attention:Ifyouneedupdateddevicedrivers,donotdownloadthemfromtheWindowsUpdateWebsite.
ObtainthemfromLenovo.Formoreinformation,see“Makingsuredevicedriversarecurrent”onpage94.

Solvingrecoveryproblems

IfyouareunabletoaccesstheRescueandRecoveryworkspaceortheWindowsenvironment,doone
ofthefollowing:

•UsearescuemediumtostarttheRescueandRecoveryworkspace.See“Creatingandusingarescue
medium”onpage52.

Chapter5.Recoveryoverview53

•Userecoverymediaifallothermethodsofrecoveryhavefailedandyouneedtorestoretheharddisk
drivetothefactorydefaultsettings.See“Creatingandusingarecoverymedia”onpage49.

Note:IfyouareunabletoaccesstheRescueandRecoveryworkspaceortheWindowsenvironmentfrom
arescuemediumorrecoverymedia,youmightnothavetherescuedevice(aninternalharddiskdrive,a
disc,aUSBharddiskdrive,orotherexternaldevices)setastherstbootdeviceinthestartupdevice
sequence.Y oumustrstmakesurethatyourrescuedeviceissetastherstbootdeviceinthestartup
devicesequenceintheThinkPadSetupprogram.See“Startupmenu”onpage87

fordetailedinformation

abouttemporarilyorpermanentlychangingthestartupdevicesequence.

Itisimportanttocreatearescuemediumandasetofrecoverymediaasearlyaspossibleandstorethem
inasafeplaceforfutureuse.

RecoveryoverviewfortheWindows8operatingsystem

ThissectionprovidesinformationabouttherecoverysolutionsfortheWindows8operatingsystem.

AWindowsrecoveryimageispreinstalledintherecoverypartitiononyourcomputer.TheWindowsrecovery
imageenablesyoutorefreshyourcomputer,orresetyourcomputertothefactorydefaultsettings.

YoucancreaterecoverymediaasbackupsorreplacementfortheWindowsrecoveryimage.Withthe
recoverymedia,youcantroubleshootandxtheproblemsonyourcomputerevenifyoucannotstartthe
Windows8operatingsystem.Itisrecommendedthatyoucreaterecoverymediaasearlyaspossible.For
moreinformation,see“Creatingandusingrecoverymedia”onpage55.

Refreshingyourcomputer

Ifyourcomputerdoesnotperformwellandtheproblemmightbecausedbyarecentlyinstalledprogram,
youcanrefreshyourcomputerwithoutlosingyourpersonallesorchangingyoursettings.

Attention:Ifyourefreshyourcomputer,theprogramsthatcamewithyourcomputerandtheprogramsthat
youinstalledfromWindowsStorewillbereinstalled,butallotherprogramswillberemoved.

Torefreshyourcomputer,dothefollowing:

1.Moveyourcursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms.Click
Settings➙ChangePCsettings➙General.

2.IntheRefreshyourPCwithoutaffectingyourlessection,clickGetstarted.

3.Followtheinstructionsonthescreentorefreshyourcomputer.

Resettingyourcomputertothefactorydefaultsettings

Ifyouwanttorecycleyourcomputerorjuststartover,youcanresetyourcomputertothefactorydefault
settings.Resettingthecomputerwillreinstalltheoperatingsystem,reinstallalltheprogramsthatcamewith
yourcomputer,andresetallthesettingstothefactorydefaultsettings.

Attention:Ifyouresetthecomputertothefactorydefaultsettings,allyourpersonallesandsettingswillbe
deleted.Toavoiddataloss,makeabackupcopyofallthedatathatyouwanttokeep.

Toresetyourcomputertothefactorydefaultsettings,dothefollowing:

1.Moveyourcursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms.Click
Settings➙ChangePCsettings➙General.

2.IntheRemoveeverythingandreinstallWindowssection,clickGetstarted.ThenclickNextto
conrmtheoperation.

3.Dependingonyourneeds,dooneofthefollowing:

54UserGuide

•Toperformaquickformat,clickJustremovemylestostarttheprocess.Theprocesswilltake
severalminutes.

•Toperformacompleteformat,clickFullycleanthedrivetostarttheprocess.Theprocesswill
takeseveralhours.

4.Followtheinstructionsonthescreentoresetyourcomputertothefactorydefaultsettings.

Usingtheadvancedstartupoptions

Withtheadvancedstartupoptions,youcanchangethermwaresettingsofthecomputer,changethe
startupsettingsoftheWindowsoperatingsystem,startthecomputerfromanexternaldevice,orrestorethe
Windowsoperatingsystemfromasystemimage.

Tousetheadvancedstartupoptions,dothefollowing:

1.Moveyourcursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms.Click
Settings➙ChangePCsettings➙General.

2.IntheAdvancedstartupsection,clickRestartnow➙Troubleshoot➙Advancedoptions.

3.Selectadesiredstartupoption,thenfollowtheinstructionsonthescreen.

RecoveringyouroperatingsystemifWindows8failstostart

TheWindowsrecoveryenvironmentonyourcomputeriscapableofoperatingindependentlyfromthe
Windows8operatingsystem.Thisenablesyoutorecoverorrepairtheoperatingsystemevenifthe
Windows8operatingsystemfailstostart.

Aftertwoconsecutivefailedbootattempts,theWindowsrecoveryenvironmentstartsautomatically.Then
youcanchooserepairandrecoveryoptionsbyfollowingtheinstructionsonthescreen.

Note:Ensurethatyourcomputerisconnectedtoacpowerduringtherecoveryprocess.

Creatingandusingrecoverymedia

YoucancreaterecoverymediaasbackupsfortheWindowsrecoveryenvironmentandtheWindows
recoveryimage.Ifyoucannotstartthecomputer,youcanuserecoverymediatotroubleshootandxthe
problemsonyourcomputer.

Itisrecommendedthatyoucreaterecoverymediaasearlyaspossible.Onceyoucreaterecoverymedia,
keeptheminasafeplaceanddonotusethemtostoreotherdata.

Creatingrecoverymedia

Tocreaterecoverymedia,youneedaUSBdrivewithatleast8GBofstorage.TherequiredUSBcapacity
dependsonthesizeoftherecoveryimage.

Attention:CreatingrecoverymediawilldeleteanythingstoredontheUSBdrive.Toavoiddataloss,makea
backupcopyofallthedatathatyouwanttokeep.

Tocreaterecoverymedia,dothefollowing:

Note:Ensurethatyourcomputerisconnectedtoacpower.

1.Moveyourcursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms,and
clickSearch.

2.T yperecoveryintheSearcheldandclickSettings.ThenclickCreatearecoverydrive.

3.ClickYesintheUserAccountControlwindowtoallowtheRecoveryMediaCreatorprogramtostart.

Chapter5.Recoveryoverview55

4.EnsurethatyouselecttheCopytherecoverypartitionfromthePCtotherecoverydrive.option.
ThenclickNext.

Important:IfyoucleartheCopytherecoverypartitionfromthePCtotherecoverydrive.option,
youwillcreaterecoverymediawithouttherecoverypartitioncontent.Youstillcanstartthecomputer
fromtherecoverymedia,butyoumightbeunabletorecoveryourcomputeriftherecoverypartitionon
yourcomputerisdamaged.

5.ConnectaproperUSBdrivethenclickNext.

6.ClickCreateintheRecoveryDrivewindow.Thecreationoftherecoverymediastarts.

7.Whenthecreationoftherecoverymedianishes,dooneofthefollowing:

•Tokeeptherecoverypartitiononyourcomputer,clickFinish.

•Todeletetherecoverypartitiononyourcomputer,clickDeletetherecoverypartition.

Attention:Ifyoudeletetherecoverypartitiononyourcomputer,dokeeptherecoverymediaina
safeplace.TheWindowsrecoveryimagewillnotbestoredinyourcomputeranymore,andyouwill
needtherecoverymediatorefreshorresetyourcomputer.

8.RemovetheUSBdrive.Therecoverymediaarecreatedsuccessfully.

Usingrecoverymedia

Ifyoucannotstartyourcomputer,orifyoucannotstarttheWindowsrecoveryimageonyourcomputer,use
recoverymediatorecoveryourcomputer.

Touserecoverymedia,dothefollowing:

Note:Ensurethatyourcomputerisconnectedtoacpower.

1.T urnonorrestartthecomputer.BeforetheWindowsoperatingsystemstarts,repeatedlypresstheF12
key.TheBootMenuwindowopens.

2.Selecttherecoverydriveasthebootdevice.

3.Selectapreferredlanguageandthenselectapreferredkeyboardlayout.

4.ClickTroubleshoottodisplaytheoptionalrecoverysolutions.

5.Selectacorrespondingrecoverysolutionaccordingtoyoursituation.Forexample,selectResetyour
PCifyouwanttoresetyourcomputertothefactorydefaultsettings.

FormoreinformationabouttherecoverysolutionsprovidedbytheWindows8operatingsystem,goto:
http://go.microsoft.com/fwlink/?LinkID=263800

56UserGuide

Chapter6.Replacingdevices

Thischapterprovidesinstructionsonhowtoinstallorreplacehardwareforyourcomputer.

•“Staticelectricityprevention”onpage57

•“Replacingthebattery”onpage57

•“Replacingtheharddiskdriveorsolid-statedrive”onpage59

•“ReplacingaPCIExpressMiniCardforwirelessLANconnection”onpage62

•“Replacingamemorymodule”onpage64

•“Replacingthekeyboard”onpage67

•“Replacingthebackupbattery”onpage72

Staticelectricityprevention

Staticelectricity,althoughharmlesstoyou,canseriouslydamagecomputercomponentsandoptions.
Improperhandlingofstatic-sensitivepartscancausedamagetothepart.Whenyouunpackanoptionor
aCRU,donotopenthestatic-protectivepackagecontainingthepartuntiltheinstructionsdirectyou
toinstallit.

WhenyouhandleoptionsorCRUs,orperformanyworkinsidethecomputer,takethefollowingprecautions
toavoidstatic-electricitydamage:

•Limityourmovement.Movementcancausestaticelectricitytobuilduparoundyou.

•Alwayshandlecomponentscarefully.Handleadapters,memorymodules,andothercircuitboardsbythe
edges.Nevertouchexposedcircuitry.

•Preventothersfromtouchingcomponents.

•Whenyouinstallastatic-sensitiveoptionorCRU,touchthestatic-protectivepackagecontainingthe
parttoametalexpansion-slotcoverorotherunpaintedmetalsurfaceonthecomputerforatleasttwo
seconds.Thisreducesstaticelectricityfromthepackageandyourbody.

•Whenpossible,removethestatic-sensitivepartfromthestatic-protectivepackagingandinstallthepart
withoutsettingitdown.Whenthisisnotpossible,placethestatic-protectivepackagingonasmooth,
levelsurfaceandplacethepartonit.

•Donotplacethepartonthecomputercoverorothermetalsurface.

Replacingthebattery

Beforeyoustart,printtheseinstructions.

ThissystemsupportsonlybatteriesspeciallydesignedforthisspecicsystemandmanufacturedbyLenovo
oranauthorizedbuilder.Thesystemdoesnotsupportunauthorizedbatteriesorbatteriesdesignedforother
systems.Ifanunauthorizedbatteryorabatterydesignedforanothersystemsisinstalled,thesystemwill
notcharge.

Attention:Lenovohasnoresponsibilityfortheperformanceorsafetyofunauthorizedbatteries,and
providesnowarrantiesforfailuresordamagearisingoutoftheiruse.

Note:Ifanunauthorizedbatteryisinstalled,thefollowingmessagewillbedisplayed:“Thebatteryinstalled
isnotsupportedbythissystemandwillnotcharge.PleasereplacethebatterywiththecorrectLenovo
batteryforthissystem.”

©CopyrightLenovo2013

57

DANGER

Iftherechargeablebatterypackisincorrectlyreplaced,thereisdangerofanexplosion.Thebattery
packcontainsasmallamountofharmfulsubstances.Toavoidinjury:

•ReplaceonlywithabatteryofthetyperecommendedbyLenovo.

•Keepthebatterypackawayfromre.

•Donotexposethebatterytoexcessiveheat.

•Donotexposethebatterytowaterorrain.

•Donotshort-circuitthebattery.

•Donotdrop,crush,puncture,orsubjecttostrongforces.Batteryabuseormishandlingcan
causethebatterytooverheat,whichcancausegassesorameto“vent”fromthebattery
packorcoincell.

Toreplacethebattery,dothefollowing:

1.T urnoffthecomputer,orenterhibernationmode.Thendisconnecttheacpoweradapterandallcables
fromthecomputer.

2.Closethecomputerdisplayandturnthecomputerover.

3.Unlockthebatterylatch1.Holdingthebatterylockleverintheunlockedpositionandremovethe
batterypack2.

58UserGuide

4.Insertafullychargedbatteryuntilitclicksintoplace1,andthenslidethebatterylatchtothelocked
position2.

5.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Replacingtheharddiskdriveorsolid-statedrive

Beforeyoustart,printtheseinstructions.

Attention:Theharddiskdriveorsolid-statedriveisverysensitive.Incorrecthandlingcancausedamage
andpermanentlossofdata.Observethefollowingguidelines:

•Replacetheharddiskdriveorsolid-statedriveonlyifyouupgradeitorhaveitrepaired.Theconnectors
andslotoftheharddiskdriveorsolid-statedrivearenotdesignedforfrequentchanges,ordrive
swapping.

•Donotdropthedriveorsubjectittophysicalshocks.Putthedriveonamaterial,suchassoftcloth,that
absorbsanyphysicalshocks.

•Donotapplypressuretothecoverofthedrive.

•Donottouchtheconnector.

•Beforeremovingtheharddiskdriveorsolid-statedrive,makeabackupcopyofalltheinformation
onit,andthenturnthecomputeroff.

•Neverremovethedrivewhilethecomputerisoperating,insleepmode,orinhibernationmode.

Toreplacetheharddiskdriveorsolid-statedrive,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.

2.Closethecomputerdisplay,andturnthecomputerover.

3.Removethebattery.See“Replacingthebattery”onpage57.

Chapter6.Replacingdevices59

4.Loosenthescrews1,andthenremovethecover2.

5.Removethescrews1,andthenslidetheharddiskdriveorsolid-statedriveout2.

6.Removetheharddiskdriveorsolid-statedrivebyliftingitsleftside.

60UserGuide

7.Placethenewharddiskdriveorsolid-statedriveintotheharddiskdriveorsolid-statedrivebay.

8.Slidetheharddiskdriveorsolid-statedrivermlyintotheconnector1,andthenreinstallthescrews2.

9.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

10.Reinstallthebattery.See“Replacingthebattery”onpage57.

11.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Chapter6.Replacingdevices61

ReplacingaPCIExpressMiniCardforwirelessLANconnection

Beforeyoustart,printtheseinstructions.

DANGER

Duringelectricalstorms,donotconnectthecabletoordisconnectitfromthetelephoneoutlet
onthewall.

DANGER

Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.T oavoidshock
hazard,disconnectthecablesbeforeopeningthecoverofthisslot.

Attention:BeforeyoustartinstallingaPCIExpressMiniCard,touchametaltableoragroundedmetal

object.Thisactionreducesanystaticelectricityfromyourbody.Thestaticelectricitycoulddamagethecard.

ToreplacethePCIExpressMiniCardforwirelessLANconnection,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.Wait
threetoveminutestoletthecomputercool.

2.Closethecomputerdisplay,andturnthecomputerover.

3.Removethebattery.See“Replacingthebattery”onpage57.

4.Loosenthescrews1,andthenremovethecover2.

62UserGuide

5.Ifatoolforremovingconnectorsisincludedinthepackagewiththenewcard,useittodisconnectthe
cablesfromthecard.Ifnosuchtoolisincluded,disconnectthecablesbypickinguptheconnectors
withyourngersandgentlyunpluggingthem.

6.Removethescrew1.Thecardpopsup2.Removethecard.

7.AlignthecontactedgeofthenewPCIExpressMiniCardwiththecorrespondingsocket1.Pivotthe
carduntilyoucansnapitintoplace.Securethecardwiththescrew2.

Chapter6.Replacingdevices63

8.ConnecttheantennacablestothenewPCIExpressMiniCard.Besuretoattachthegraycabletothe
connectormarked“MAIN”or“M”onthecard,andtheblackcabletotheconnectormarked“AUX”or“A.”

9.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

10.Reinstallthebattery.See“Replacingthebattery”onpage57.

11.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Replacingamemorymodule

Beforeyoustart,printtheseinstructions.

Increasingmemorycapacityisaneffectivewaytomakeprogramsrunfaster.Toreplaceoraddamemory
module,readthefollowingprerequisites,andthentheinstructions.

Whenreplacingamemorymodule,besuretofollowtheprecautions.

Note:Theoperatingspeedofthememorymodulehasdependencyonthesystemconguration.Insome
conditions,thememorymoduleinyourcomputermightnotbeabletooperateatthemaximumspeed.

Attention:Beforeyoustartinstallingamemorymodule,touchametaltableoragroundedmetalobject.This
actionreducesanystaticelectricityfromyourbody.Thestaticelectricitycoulddamagethememorymodule.

64UserGuide

Toreplaceamemorymodule,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.

2.Closethecomputerdisplay,andturnitover.

3.Removethebattery.See“Replacingthebattery”onpage57.

4.Loosenthescrews1,andthenremovethecover2.

5.Iftwomemorymodulesarealreadyinthememoryslots,pressoutonthelatchesonbothedgesof
thesocketatthesametime

1,andthenremoveamemorymodule2tomakeroomforthenewone.

Savetheremovedmemorymoduleforfutureuse.

6.Findthenotchonthecontactedgesideofthememorymoduleyouareinstalling.

Attention:Toavoiddamagingthememorymodule,donottouchitscontactedge.

Chapter6.Replacingdevices65

7.Withthenotchedendofthememorymoduletowardthecontactedgesideofthesocket,insertthe
memorymodule1intothesocketatanangleofabout20degrees;thenpressitinrmly2.

Important:Ifonlyonememorymoduleisinstalled,ensurethatyouinstallitintheslot2.

8.Pivotthememorymoduledownwarduntilitsnapsintoplace.

9.Makesurethatthememorymoduleisrmlyinstalledintheslotandcannotbemovedeasily.

66UserGuide

10.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

11.Reinstallthebattery.See“Replacingthebattery”onpage57.

12.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Replacingthekeyboard

Beforeyoustart,printtheseinstructions.

DANGER

Duringelectricalstorms,donotconnectthecabletoordisconnectitfromthetelephoneoutlet
onthewall.

DANGER

Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.T oavoidshock
hazard,disconnectthecablesbeforeopeningthecoverofthisslot.

Removingthekeyboard

Toremovethekeyboard,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.

2.Closethecomputerdisplay,andturnthecomputerover.

3.Removethebattery.See“Replacingthebattery”onpage57.

Chapter6.Replacingdevices67

4.Loosenthescrews1,andthenremovethecover2.

5.Removethescrewsthatsecurethekeyboard.

6.T urnthecomputeroverandopenthedisplay.

68UserGuide

7.Pushhardinthedirectionshownbythearrows1tounlatchthefrontsideofthekeyboard.The
keyboardwillbedetachedslightly2.

8.Removethecables2and4byippingtheconnectors1and3upwards.Removethekeyboard.

Installingthekeyboard

Toinstallthekeyboard,dothefollowing:

Chapter6.Replacingdevices69

1.Attachthecables1and3byippingtheconnectors2and4downwards.

2.Insertthekeyboard.Makesurethattherearedgeofthekeyboardisundertheframe.

70UserGuide

3.Slidethekeyboardinthedirectionshownbythearrows,untilthekeyboardissecuredinplace.

4.Reinstallthescrews.

5.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

Chapter6.Replacingdevices71

6.Reinstallthebattery.See“Replacingthebattery”onpage57.

7.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Replacingthebackupbattery

Beforeyoustart,printtheseinstructions.

Prerequisitesfortheprocedure

DANGER

Ifthebackupbatteryisincorrectlyreplaced,thereisdangerofanexplosion.Thebackupbattery
containsasmallamountofharmfulsubstances.Toavoidpossibleinjury:

•ReplaceonlywithabatteryofthetyperecommendedbyLenovo.

•Keepthebatterypackawayfromre.

•Donotexposeittoexcessiveheat.

•Donotexposeittowaterorrain.

•Donotshort-circuitit.

•Donotdrop,crush,puncture,orsubjecttostrongforces.Batteryabuseormishandlingcan
causethebatterytooverheat,whichcancausegassesorameto“vent”fromthebattery
packorcoincell.

Toremovethebackupbattery,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.Wait
threetoveminutestoletthecomputercool.

2.Closethecomputerdisplay,andturnthecomputerover.

3.Removethebattery.See“Replacingthebattery”onpage57.

4.Loosenthescrew1,andthenremovethecover2.

72UserGuide

5.Detachtheconnector1.Thenremovethebackupbattery2.

Toinstallthebackupbattery,dothefollowing:

1.Installthebackupbattery1.Thenattachtheconnector2.

2.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

Chapter6.Replacingdevices73

3.Reinstallthebattery.See“Replacingthebattery”onpage57.

4.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

74UserGuide

Chapter7.Advancedconguration

Whileitisimportanttoprotectles,data,andsettingsthatareontheharddiskdriveorsolid-statedrive,
youalsomightneedtoinstallanewoperatingsystem,installnewdevicedrivers,updateyoursystemUEFI
BIOS,orrecoverpreinstalledsoftware.Thisinformationwillhelpyouhandleyourcomputerwithproper
careandkeepitintopworkingshape.

•“Installinganewoperatingsystem”onpage75

•“Installingdevicedrivers”onpage77

•“ThinkPadSetup”onpage78

Installinganewoperatingsystem

Ifyouinstallanewoperatingsystemonyourcomputer,youneedtoinstallthesupplementlesand
ThinkPaddevicedriversforitatthesametime.

•IfyouinstallanewWindows7operatingsystem,thenecessarylesarelocatedinthefollowingdirectories
onyoursolid-statedriveorharddiskdrive:

–ThesupplementlesfortheoperatingsystemsupportedareintheC:\SWTOOLS\OSFIXESdirectory.
–ThedevicedriversfortheoperatingsystemsupportedareintheC:\SWTOOLS\DRIVERSdirectory.
–ThepreloadedsoftwareprogramsareintheC:\SWTOOLS\APPSdirectory.

Note:Ifyoucannotndthesupplementles,thedevicedrivers,andprogramsoftwareyouneedon
yourharddiskdrive,orifyouwanttoreceiveupdatesandthelatestinformationaboutthem,goto
http://www.lenovo.com/ThinkPadDrivers.

•IfyouinstallanewWindows8operatingsystem,gotohttp://www.lenovo.com/ThinkPadDriversto
downloadandinstallthelatestdevicedrivers.

Note:Theprocessofinstallingthenewoperatingsystemdeletesallthedataonyourharddiskdrive,
includingbackupsorimagesthatwerestoredinahiddenfolderbyuseoftheRescueandRecoveryprogram.

Beforeyoubegin

Beforeyouinstalltheoperatingsystem,dothefollowing:

•IfyouaregoingtoinstallanewWindows7operatingsystem,copyallthesubdirectoriesandlesinthe
C:\SWTOOLSdirectorytoaremovablestoragedevice,toavoidlosinglesduringtheinstallation.

•Printtheinstructionsyouwilluse.Gotothesectionfortheoperatingsystemyouareusing:

–“InstallingtheWindows7operatingsystem”onpage76
–“InstallingtheWindows8operatingsystem”onpage77

Notes:

–TheUEFIBIOSfeaturesaresupportedontheWindows7operatingsystem(64-bit)andtheWindows8

operatingsystem(64-bit).EnsurethattheUEFI/LegacyBootsettinginThinkPadSetupissettoyour
preferencetobootthedesiredoperatingsystem.

–Afterinstallingtheoperatingsystem,youshouldnotchangetheinitialUEFI/LegacyBootsettingin

ThinkPadSetup.TheUEFI/LegacyBootsettingmustbethesameasitwaswhentheWindows
operatingsystemimagewasinstalled.Otherwise,theoperatingsystemwillnotbootcorrectly.

Forthecountryorregioncoderequiredintheinstallation,useoneofthefollowing:

©CopyrightLenovo2013

75

Countryorregion:Code

China:SC
Denmark:DK
Finland:FI
France:FR
Germany:GR
Italy:IT
Japan:JP
Netherlands:NL
Norway:NO
Spain:SP
Sweden:SV
TaiwanandHongKong:TC
UnitedStates:US

InstallingtheWindows7operatingsystem

Beforeyoustart,printtheseinstructions.

ToinstalltheWindows7operatingsystemanditsrelatedsoftwareonyourcomputer,dothefollowing:

1.StartThinkPadSetup.

2.SelectStartup.

3.SelectUEFI/LegacyBoot.

4.Dooneofthefollowing:

•IfyouwanttoinstalltheWindows7(32–bit)operatingsystem,selectLegacyOnlyorBoth.

•IfyouwanttoinstalltheWindows7(64–bit)operatingsysteminLegacymode,selectLegacyOnly.

•IfyouwanttoinstalltheWindows7(64–bit)operatingsysteminUEFImode,selectUEFIOnly.

5.PressF10tosavethechangesandrestartthesystem.

6.InserttheWindows7operatingsysteminstallationDVDintotheexternalDVDdrive,andrestartthe
computer.

7.RestoreC:\SWTOOLSfromthebackupcopyyoumadebeforestartingtheinstallation.

8.InstalltheThinkPadAMDSMBusDriverforWindows7andtheThinkPadAMDSATAControllerDriver
forWindows7.

9.Installdevicedrivers.See“InstallingotherdevicedriversandsoftwareontheWindows7operating
system”onpage78.

InstallingtheregistrypatchesforWindows7

Gotohttp://www.lenovo.com/supportandinstallthefollowingregistrypatches:

•RegistrypatchenablingWakeUponLANfromStandbyforEnergyStar

•FixforIssueofHDDwithHDDetection

InstallingtheWindows7xmodules

TheWindows7xmodulesareinthefollowingdirectory:

C:\SWTOOLS\OSFIXES\

Thenameofeachsubfolderisthenumberofaxmodule.Forinformationabouteachxmodule,goto
theMicrosoftKnowledgeBasehomepageathttp://support.microsoft.com/,typethenumberofthex
moduleyouneedinthesearcheld,andclickSearch.

76UserGuide

Toinstallaxmodule,runtheEXEleinasubfolderandfollowtheinstructionsonthescreen.

Note:Ifyouremovetheharddiskdrivefromthecomputerwithasingle-coreprocessorandinstallitona
computerwithadual-coreprocessor,youcangetaccesstotheharddiskdrive.Theopposite,however,is
nottrue:Ifyouremovetheharddiskdrivefromacomputerwithadual-coreprocessorandinstallitona
computerwithasingle-coreprocessor,youcannotgetaccesstotheharddiskdrive.

InstallingtheWindows8operatingsystem

Beforeyoustart,printtheseinstructions.

ToinstalltheWindows8operatingsystemanditsrelatedsoftwareonyourcomputer,dothefollowing:

1.StartThinkPadSetup.

2.SelectStartup➙Boot.

3.ChangethebootpriorityordertobootyourcomputerfromthedrivethatcontainstheWindows
8operatingsysteminstaller.

4.PressF10.

5.ConnectthedrivethatcontainstheWindows8operatingsysteminstallertoyourcomputer,and
restartthecomputer.

6.Installdevicedrivers.See“Installingdevicedrivers”onpage77.

InstallingtheWindows8xmodules

TodownloadandinstallaWindows8xmodule,gototheMicrosoftKnowledgeBasehomepageat
http://support.microsoft.com/,typethenumberofthexmoduleyouneedinthesearcheld,andclick

Search.

Installingdevicedrivers

Thedevicedriversareavailableathttp://www.lenovo.com/ThinkPadDrivers.Clickyourcomputerproduct
nametoviewallthedevicedriversforyourcomputer.

Attention:Alwaysgotohttp://www.lenovo.com/ThinkPadDriversforthelatestdevicedrivers.Donot
downloadthemfromtheWindowsUpdateWebsite.

Installingthedriverforthe4-in-1mediacardreader

Tousethe4-in-1mediacardreader,youneedtodownloadandinstalltheRealtekCardReaderDriverfrom
theLenovoSupportWebsiteat:
http://www.lenovo.com/support

InstallingthedriverforUSB3.0ontheWindows7operatingsystem

IfyourcomputersupportsUSB3.0,andyouhavereinstalledtheoperatingsystem,youneedtodownload
andinstalltheUSB3.0drivertousetheUSB3.0bydoingthefollowing:

1.Gotohttp://www.lenovo.com/support.Findyourmodelanddisplaythedriverlinks.

2.SelecttheUSB3.0driverforthe32-bitor64-bitoperatingsystemandextractittoyourlocalhard
diskdrive.

3.Double-clicktheSetup.exeleintheC:\DRIVERS\WIN\USB3.0\directory.

4.ClickNext.Ifthedevicedriverisalreadyinstalled,clickCancel.Followtheinstructionsonthescreen
untiltheinstallationisnished.

Chapter7.Advancedconguration77

InstallingtheThinkPadmonitorleforWindows2000/XP/Vista/7/8on
theWindows7operatingsystem

TheThinkPadmonitorleforWindows2000/XP/Vista/7/8isinthefollowingdirectory:

C:\SWTOOLS\DRIVERS\MONITOR

Note:Ifyoucannotndthisdirectoryonyourharddiskdriveorsolid-statedrive,downloadtheThinkPad
monitorleforWindows2000/XP/Vista/7/8fromtheThinkPadWebsiteat:
http://www.lenovo.com/ThinkPadDrivers

Note:Beforeyouinstallthisle,makesurethatthecorrectvideodriverhasbeeninstalled.

1.Right-clickonthedesktop,andclickPersonalize.

2.ClickDisplayattheleft.

3.ClickChangedisplaysettings.

4.ClickAdvancedSettings.

5.ClicktheMonitortab.

6.ClickProperties.

7.ClicktheDrivertab.

8.ClickUpdateDriver.

9.SelectBrowsemycomputerfordriversoftware,andthenclickLetmepickfromalistofdevice
driversonmycomputer.

10.ClickHaveDisk.

11.SpecifypathC:\SWTOOLS\DRIVERS\MONITORtothismonitorINFle.Then,clickOpen.

12.ClickOK.

13.Conrmthecorrectdisplaytype,thenclickNext.

14.Wheninstallationcompletes,clickClose.

15.ClickClosetoclosetheDisplayPropertieswindow.

16.ClickOKontheMonitortab.

17.ClickOKandclosetheDisplaySettingswindow.

InstallingotherdevicedriversandsoftwareontheWindows7operating
system

ThedevicedriversareprovidedintheC:\SWTOOL S\DRIVERSdirectoryonyourharddiskdrive.Youwillalso
needtoinstallprogramsoftware,whichisprovidedintheC:\SWTOOLS\APPSdirectoryonyourharddiskdrive.
Todothis,refertotheinstructionsin“Reinstallingpreinstalledprogramsanddevicedrivers”onpage53

.

Note:IfyoucannotndtheSupplementles,devicedrivers,andprogramsoftwareyouneedon
yourharddiskdrive,orifyouwanttoreceiveupdatesandthelatestinformationaboutthem,goto
http://www.lenovo.com/ThinkPadDrivers.

ThinkPadSetup

YourcomputercomeswiththeThinkPadSetupprogramtoenableyoutoselectvarioussetupparameters.

TostartThinkPadSetup,dothefollowing:

1.T urnonthecomputer.Whenthelogoscreenisdisplayed,presstheF1key.theThinkPadSetup
programmainmenuopens.

Ifyouhavesetasupervisorpassword,theThinkPadSetupprogrammainmenuwillbedisplayed
afteryouenterthepassword.Y oucanstartThinkPadSetupbypressingEnterinsteadofenteringthe

78UserGuide

supervisorpassword.However,youcannotchangetheparametersthatareprotectedbythesupervisor
password.Formoreinformation,referto“Usingpasswords”onpage41.

2.Usingthecursorkeys,movetoanitemyouwanttochange.Whentheitemishighlighted,press
Enter.Asubmenuisdisplayed.

3.Changetheitemsyouwishtochange.Tochangethevalueofanitem,pressthefollowingkeys:

•F5or–:Changetoalowervalue.

•F6orthecombinationofShiftand+:Changetoahighervalue.
Iftheitemhasasubmenu,youcandisplayitbypressingEnter.

4.PressEsctoexitfromthesubmenu.

5.Ifyouareonanestedsubmenu,pressEscrepeatedlyuntilyoureachtheThinkPadSetupprogram
mainmenu.

Note:Ifyouneedtorestorethesettingstotheiroriginalstateasofthetimeofpurchase,pressF9to
loadthedefaultsettings.Y oualsocanselectanoptionontheRestartsubmenutoloadthedefault
settingsordiscardthechanges.

6.SelectRestart.Movethecursortotheoptionyouwantforrestartingyourcomputer;thenpressEnter.
Yourcomputerrestarts.

Note:Dependingontheoperatingsystemyouareusing,somemenuitemslistedinthischaptermightnot
beavailableonyourcomputer,andsomemenuitemsmightbeslightlydifferentfromtheactualmenuitems
displayedonyourcomputer.

Mainmenu

TheMainmenuistherstinterfaceyouseeafteryouenterThinkPadSetup.Itdisplaysthefollowing
congurationofyourcomputer:

•UEFIversion

•UEFIdate

•Embeddedcontrollerversion

•Machinetypemodel

•System-unitserialnumber

•Systemboardserialnumber

•Assettag

•CPUtype

•CPUspeed

•Installedmemory

•UUID

•MACaddress(InternalLAN)

•Preinstalledoperatingsystemlicense

•UEFISecureBoot

Congmenu

Ifyouneedtochangethecongurationofyourcomputer,selectCongfromtheThinkPadSetupprogram
mainmenu.

Thefollowingsubmenuisdisplayed:

•Network:SettheLANrelatedfunctions.

Chapter7.Advancedconguration79

•USB:EnableordisableUSBrelatedfunctions.

•Keyboard/Mouse:Setthekeyboardandmouserelatedfunctions.

•Display:Specifythesettingsfordisplayoutput.

•Power:Setpowermanagementrelatedfunctions.

•BeepandAlarm:Enableordisabletheaudiorelatedfunctions.

•SerialAT A(SAT A):Specifythesettingsfortheharddiskdrive.

Notes:

•Thedefaultsettingsarealreadyoptimizedforyou.Ifyouconsiderchangingthecomputerconguration,
proceedwithextremecaution.Settingthecongurationincorrectlymightcauseunexpectedresults.

•Oneachsubmenu,youcanenableafunctionbyselectingEnabled,ordisableitbyselectingDisabled.

ThefollowingtableshowsthecontentsoftheCongmenu.

Notes:

•Someitemsaredisplayedonthemenuonlyifthecomputersupportsthecorrespondingfeatures.

•Defaultvaluesareinboldface.

Table4.Congmenuitems

Menuitem

SubmenuitemSelectionComments

WakeOnLAN

•Disabled

•ACOnly

•ACandBattery

Enablethesystemtopower
onwhentheEthernet
controllerreceivesamagic
packet.

IfyouselectACOnly,the
WakeonLANfunctionis
enabledonlywhentheac
poweradapterisattached.

IfyouselectACand
Battery,theWakeonLAN
functionisenabledwithany
powersources.

Notes:

•Themagicpackettype
WakeonLANrequiresac
power.

•TheWakeonLAN
functiondoesnot
workwhenaharddisk
passwordisset.

EthernetLANOptionROM
(forLegacyOnlyboot
modeorBothwithLegacy
rst)

•Disabled

•Enabled

Congurewhethertoload
theEthernetLANOption
ROMtoenablestartup
fromanintegratednetwork
device.Thisoptionmustbe
enabledtodisplaytheMAC
Addressfortheintegrated
networkdevice.

Network

80UserGuide

Table4.Congmenuitems(continued)

Menuitem

SubmenuitemSelectionComments

UEFIIPv4NetworkStack
(forUEFIOnlybootmode
orBothwithUEFIrst)

•Disabled

•Enabled

EnableordisableInternet
ProtocolVersion4(IPv4)
networkstackforUEFI
environment.

UEFIIPv6NetworkStack

(forUEFIOnlybootmode
orBothwithUEFIrst)

•Disabled

•Enabled

EnableordisableInternet
ProtocolVersion6(IPv6)
networkstackforUEFI
environment.

UEFIPXEBootPriority

(forBothwithUEFIrst
bootmode,andIPv6
andIPv4stacksareboth
enabled.)

•IPv6First

•IPv4First

Selectnetworkstack
priorityforUEFIPXEboot.

WirelessLANRadio

•On

•Off

IfyouselectOn,theinternal
wirelessradioisturnedon.
IfyouselectOff,theinternal
wirelessradioisturnedoff.

AlwaysOnUSB

•Disabled

•Enabled

IfyouselectDisabled,
theexternalUSBdevices
cannotbechargedthrough
USBconnectors.

ChargeinBatteryOperation

•Disabled

•Enabled

IfyouselectEnabled,the
AlwaysOnUSBconnector
enablesyoutocharge
somemobiledigitaland
smartphoneswhenthe
computerispoweredoff
andinbatteryoperation.

USB

USB3.0Mode

•Disabled

•Enabled

SettheUSB3.0controller
modefortheconnectors
sharedbetweenUSB2.0
andUSB3.0controllers.

IfyouselectEnabled,it
enablesUSB3.0mode
andallowsUSB3.0tobe
supportedintheoperating
system.

IfyouselectDisabled,it
disablesandhidestheUSB

3.0controller,andUSB3.0
connectorswillworkinUSB

2.0mode.

Chapter7.Advancedconguration81

Table4.Congmenuitems(continued)

Menuitem

SubmenuitemSelectionComments

FnandCtrlKeyswap

•Disabled

•Enabled

IfyouselectEnabled,the
FnkeyworksastheCtrl
key,andtheCtrlkeyworks
astheFnkey.

Note:EvenwhenEnabled
isselected,youneedto
presstheFnkeytoresume
thecomputerfromsleep
modetonormaloperation.

Keyboard/Mouse

FnKeyLock•Disabled

•Enabled

IfyouselectEnabled,you
canpresstheFnkeyonceto
activatetheFnkeyfunction,
asifthekeyiskeptina
pressedcondition,andthen
pressthedesiredfunction
key.Theactionisequivalent
topressingtheFnkeyand
thedesiredfunctionkey
simultaneously.Ifyoupress
theFnkeytwice,theFn
keyiskeptinapressed
conditionuntilyoupress
theFnkeyagain.

DisplayBootDisplayDevice

•ThinkPadLCD

•Analog(VGA)

•DigitalonThinkPad

Selectthedisplaydevice
thatistobeactivatedat
boottime.Thisselection
iseffectiveforboottime,
passwordprompt,and
ThinkPadSetup.

CPUPowerManagement

•Disabled

•Enabled

Unlessthispower-saving
featureisdisabled,it
stopstheprocessorclock
automaticallywhenthere
isnosystemactivity.Y ou
usuallydonotneedto
changethisfunction.

Power

AdaptiveS4

•Disabled

•Enabled

Enableordisableafeature
thatpowersonthesystem
whenACisattached.

IfyouselectEnabled,the
systemispoweredonwhen
theacpoweradapteris
attached.Whenthesystem
isinhibernatestate,the
systemresumes.

IfyouselectDisabled,the
systemisnotpoweredon
norresumedwhentheac
poweradapterisattached.

82UserGuide

Table4.Congmenuitems(continued)

Menuitem

SubmenuitemSelectionComments

PasswordBeep•Disabled

•Enabled

Enablesordisablesthe
passwordbeepwhenthe
systemispromptingfor
thepower-on,harddisk,or
supervisorpasswordtobe
typed.

BeepandAlarm

KeyboardBeep•Disabled

•Enabled

Enablesordisablesthe
keyboardbeepwhen
unmanageablekey
combinationsarepressed.

SerialAT A(SAT A)SATAControllerMode

Option

•Compatibility

•AHCI

SelectsSATAcontroller
operationmode.Ifyou
selectCompatibility,the
SATAcontrolleroperatesin
compatibilitymode.

Date/Timemenu

Ifyouneedtosetthecurrentdateandtimeofyourcomputer,selectDate/TimefromtheThinkPadSetup
programmainmenu.Thefollowingsubmenuisdisplayed:

•SystemDate

•SystemTime

Tochangethedateandtime,dothefollowing:

1.Usingtheupanddownarrowkeys,selecttheitemtochangethedateortime.

2.PressT ab,Shift+Tab,orEntertoselectaeld.

3.T ypethedateortime.

Notes:Anotherwaytoadjustthedateandtimeispressingthefollowingkeys:

•F5or–:Changetoalowervalue.

•F6orthecombinationofShiftand+:Changetoahighervalue.

4.PressF10tosavethechangesandrestartthesystem.

Securitymenu

Ifyouneedtosetthesecurityfeaturesofyourcomputer,selectSecurityfromtheThinkPadSetupprogram
mainmenu.

Notes:

•Thedefaultsettingsarealreadyoptimizedforyou.Ifyouconsiderchangingthecomputerconguration,
proceedwithextremecaution.Settingthecongurationincorrectlymightcauseunexpectedresults.

•Oneachsubmenu,youcanenableafunctionbyselectingEnabled,ordisableitbyselectingDisabled.

Thefollowingsubmenuisdisplayed:

•Password:Setapassword.

•UEFIBIOSUpdateOption:SpecifythesettingsforFlashUEFIBIOSupdate.

•MemoryProtection:SpecifythesettingsfortheDataExecutionPreventionfeature.

•Virtualization:EnableordisablethesettingsforAMD-V™Technology(formodelswithanAMDCPU).

Chapter7.Advancedconguration83

•I/OPortAccess:EnableordisabletheaccesstoindividualI/Oports.

•Anti- Theft:EnableordisabletheUEFIBIOSinterfacetoactivateanti-theftservices,suchasComputrace.

•SecureBoot:ConguretheSecureBootfunction.

ThefollowingtableshowsthecontentsoftheSecuritymenu.

Notes:

•Someitemsaredisplayedonthemenuonlyifthecomputersupportsthecorrespondingfeatures.

•Defaultvaluesareinboldface.

Table5.Securitymenuitems

Menuitem

SubmenuitemSelectionComments

SupervisorPassword

•Enter

Referto“Supervisor
password”onpage44

.

LockUEFIBIOSSettings

•Disabled

•Enabled

Enablesordisablesthe
functionthatprotects
itemsintheThinkPad
Setupprogramfrom
beingchangedbyauser
whodoesnothavethe
supervisorpassword.
Bydefault,thisissetto
Disabled.Ifyousetthe
supervisorpasswordand
enablethisfunction,no
onebutyoucanchange
anyitemsintheThinkPad
Setupprogram.

Passwordatunattended
boot

•Disabled

•Enabled

Ifyouselectandenable

Passwordatunattended
boot,apasswordprompt

isdisplayedwhenthe
computeristurnedon,
fromeitherapower-off
stateorhibernationstate.
IfyouselectDisabled,
nopasswordpromptis
displayed;thecomputer
goesaheadandloads
theoperatingsystem.
Topreventunauthorized
access,settheuser
authenticationonthe
operatingsystem.

Passwordatrestart•Disabled

•Enabled

Ifyouselectandenable
Passwordatrestart,
apasswordpromptis
displayedwhenyourestart
thecomputer.Ifyouselect
Disabled,nopassword
promptisdisplayed;the
computergoesaheadand
loadstheoperatingsystem.
Topreventunauthorized
access,settheuser

Password

84UserGuide
