Products: USB Extenders
USB 1.1 Extender
and
USB 2.0 Extender
MAN-000012 1 REVISION G
1. Introduction
1.1. Contents
1.1.1. USB Extender
When you receive your Thinklogical™ USB Extender (1.1 or 2.0 Model), you should find the following
items:
USB Extender – Transmitter
USB Extender – Receiver
AC Power Supply (PWR-000022-R) – Quantity 2
USB Cable, 6 Feet (CBL000015-006FR)
USB and 1394b Extender Product Manual
NOTE: T he USB 2.0 Extender is recommended for video transfer applications; the USB 1. 1
Extender is recommended for all other applications.
NOTE: For USB camera applications which limit power, we recommend the Thinklogical™ USB 2.0
EP Series. The EP Series is only available in the USB 2.0 Model.
1.2. Product Overview
1.2.1. USB Extender
The USB Extender (1.1 and 2.0 Models) is a fiber optic extender designed to extend USB 1.1 or 2.0
interface signals up to 1000 meters (3280 feet) over a standard duplex multimode fiber. With the USB
Extender, all high speed USB 1.1 or 2.0 peripherals can be conveniently located while operating at
optimal speed. The USB 2.0 Extender effectively supports not only USB 2.0 peripherals but USB 1.1 low
speed and full speed devices as well.
The USB Extender transmitter connects to the host computer with a standard USB cable and the
receiver provides four ports for connection of peripheral devices. External power is required for both the
transmitter and receiver units and two universal power supplies are included. Plug-and-play with no
adjustments makes setting up the USB Extender fast and easy. As an added bonus, LEDs provide link
performance at a glance. The USB Extender successfully and effectively delivers USB peripherals when
and where you need them.
1.2.2. USB Camera
For USB camera applications which limit power, we recommend the Thinklogical™ USB 2.0 EP Series.
The EP (Enhanced Power) Series is only available in the USB 2.0 Model. This optional feature can
handle additional power that USB cameras require.
MAN-000012 2 REVISION G
LASER RADIATION
DO NOT VIEW DIRECTLY WITH OPTICAL
INSTRUMENTS
1.3. Ordering Information
All models listed are available from Thinklogical™:
USB-000001-SCTX USB 1.1 EXTENDER TRANSMITTER, SC
USB-000001-SCRX USB 1.1 EXTENDER RECEIVER, SC
USB-000001-STTX USB 1.1 EXTENDER TRANSMITTER, ST
USB-000001-STRX USB 1.1 EXTENDER RECEIVER, ST
USB-000002-SCTX USB 2.0 EXTENDER TRANSMITTER, SC
USB-000002-SCRX USB 2.0 EXTENDER RECEIVER, SC
USB-000002-STTX USB 2.0 EXTENDER TRANSMITTER, ST
USB-000002-STRX USB 2.0 EXTENDER RECEIVER, ST
USB-EP0002-SCTX USB 2.0 EXTENDER, ENHANCED POWER, TRANSMITTER, SC
USB-EP0002-SCRX USB 2.0 EXTENDER, ENHANCED POWER, RECEIVER, SC
USB-EP0002-STTX USB 2.0 EXTENDER, ENHANCED POWER, TRANSMITTER, ST
USB-EP0002-STRX USB 2.0 EXTENDER, ENHANCED POWER, RECEIVER, ST
1.4. Laser Information
CAUTION: In order to avoid possible exposure to laser energy, it is good practice to attach the fiber optic
cables prior to applying power to the USB EXTENDER. If the fiber optic cable should become
disconnected, DO NOT attempt to look into the cable or the panel mounted connector.
MAN-000012 3 REVISION G
2. System Features
Storage Temperature
-20 to 85 °C (-4 to 185 °F)
Supply Voltage
5.0 VDC ±5%. Adapter has Universal AC Power Input
Power Consumption
5 Watts
Laser Output Specifications
Meets Laser Class 1M Specifications
Panel Connectors
Transmitter: (1) USB Type B connector
Optical Cable
Duplex Fiber, multi-mode, 50 micron or 62.5 micron. (Fiber Cable
Operating Temperature and
Humidity
0 to 50 °C (32 to 122 °F); 10 to 95% RH, non-condensing
Enclosure Dimensions
6.61in x 4.00in x 1.09in (167.89mm x 101.60mm x 27.61mm)
Weight
1lb (0.45kg) each
Shipping Weight
Transmitter and Receiver: 4lbs (1.81kg)
Copper Cables
(1) USB Type A to USB Type B Cable, 6 Feet
2.1. General System Features
Extends Hi-Speed USB 1.1 or 2.0 connection up to 1000 meters (3280 feet)
Four port Class A device
Installation is Plug-and-Play, no adjustments are necessary
Supports USB 1.1 low-speed /full-speed and USB 2.0 hi-speed devices
Uses standard duplex multi-mode fiber optic cable
LEDs provide link performance status
Available with your choice of ST or SC fiber connectors
2.2. Technical Specifications
Polarity: Positive Tip Part Number: PWR-000022-R
(1) Dual Fiber connector (SC or ST)
(1) 2.5mm power connector
Receiver: (4) USB Type A connectors
(1) Dual Fiber connector (SC or ST)
(1) 2.5mm power connector
is either customer-supplied or can be ordered from Thinklogical.)
Tolerance: ± 0.039in (1mm)
Part Number: CBL000015-006FR
MAN-000012 4 REVISION G
CCD Camera
2.3. Product Overview - USB Extender
MAN-000012 5 REVISION G
5VDC
POWER LINK
T R
HOST
2.3.1. USB 1.1 Transmitter
MAN-000012 6 REVISION G
2.3.2. USB 1.1 Receiver
5VDC
POWER LINK
T R
1
2 3 4
MAN-000012 7 REVISION G
5VDC
POWER LINK
T R
HOST
2.3.3. USB 2.0 Transmitter
MAN-000012 8 REVISION G
2.3.4. USB 2.0 Receiver
5VDC
POWER LINK
T R
1
2 3 4
MAN-000012 9 REVISION G
2.3.5. Cables
2 Fibers
Up to 1000 meters
(USB 2.0)
2.3.5.1. Fiber Optic Cables
Fiber Optic cables for the USB Extender system are not included, but are available for purchase. Please
contact Thinklogical™ for a quotation on your required cable length.
When connecting the fiber optic cables, you must be sure to:
Connect the fiber connector labeled „T‟ on the Transmitter to the fiber connector
labeled „R‟ on the Receiver.
Connect the fiber connector labeled „R‟ on the Transmitter to the fiber connector
labeled „T‟ on the Receiver.
*Note: Place Transmitter and Receiver units with the fiber panels facing each other. When you connect
the fibers, THE FIBER CABLE SHOULD NOT BE CROSSED.
2.3.5.2. USB Type A – Receiver
Connect up to four devices(s) into any of the device port(s) labeled 1,2,3,4 on the
Receiver unit. The cable that was provided with your USB device should be able to
connect to the USB Type A ports on the Receiver.
MAN-000012 10 REVISION G
2.3.5.3. USB Type B – Transmitter
Connect your PC to the location labeled Host on the Transmitter unit using the USB
Type A to USB Type B Cable (CBL000015-006FR) that was provided with your USB
Extender system.
2.3.6. Power Supply –PWR-000022-R (Quantity 2)
Universal Input: 100 – 240 VAC 50/60Hz Nominal
Continuous Short Circuit Protection
Over Voltage Protection
Conductive EMI Meets CISPR/FCC Class B high efficiency, 75% Typical
AC Plug Can Be Changed
AC Power Supply (PN: PWR-000022-R) shown with optional AC plugs
2.3.7. Power Supply – PWR-000047-R (Quantity 2)
NOTE: PWR-000047-R is supplied for the EP (enhanced power).
MAN-000012 11 REVISION G
Separate wall-pack AC/DC adapters (part number PWR-000022-R) are included. A single power jack
accepts the 5VDC input.
Universal Input: 100 – 240 VAC 50/60Hz Nominal
Continuous Short Circuit Protection
Over Voltage Protection
Conductive EMI Meets CISPR/FCC Class B high efficiency, 75% Typical
AC Plug Can Be Changed
MAN-000012 12 REVISION G
3. Installation
LED Label
Status
Power
LED is ON (solid green) when power supply is properly connected
Host
LED is ON (solid green) when the PC (USB Type B Connector labeled
Host) is properly connected
Link
Shows the status of the connection
LED is ON (solid green) when the Power, Host has enumarated, and Fiber
are properly connected
LED is BLINKING (blinking green) when the Fiber are properly connected
and until the Host enumerates
1. Plug fiber into T location labeled on the Transmitter unit. Plug that corresponding end of fiber into
R location labeled on the Receiver unit.
2. Plug fiber into R location labeled on the Transmitter unit. Plug that corresponding end of fiber
into T location labeled on the Receiver unit.
3. Connect the power supply to the Transmitter and plug corresponding end into a suitable AC
power source.
4. Connect the power supply to the Receiver and plug corresponding end into a suitable AC power
source.
5. Connect your PC to the Host location (USB Type B Connector) labeled on the Transmitter unit.
6. Connect your devices(s) into the device port(s) (USB Type A Connector) labeled 1,2,3,4 on the
Receiver unit.
Your USB (1.1 or 2.0) Extender System is now properly connected.
3.1. LED Status
3.1.1. Transmitter
MAN-000012 13 REVISION G
3.1.2. Receiver
LED Label
Status
Power
LED is ON (solid green) when power supply is properly connected
Device Ports labeled
1, 2, 3, 4
LED is ON (solid green) when the device(s) is (are) properly connected
and once the unit enumerates
Link
Shows the status of the connection
LED is ON (solid green) when the Power, device port(s), and Fiber are
properly connected
LED is BLINKING (blinking green) when the Fiber are properly
connected and until the Host enumerates
MAN-000012 14 REVISION G
Product: Firewire 800 Extender
MAN-000012 15 REVISION G
1. Introduction
LASER RADIATION
DO NOT VIEW DIRECTLY WITH OPTICAL
INSTRUMENTS
1.1. Contents
1.1.1. Firewire (1394b)
When you receive your Thinklogical™ 1394b Extender, you should find the following items:
1394b Extender – Transmitter
1394b Extender – Receiver
AC Power Supply (PWR-000033-R) – Quantity 2
AC Power Cord (PWR-000008-R) – Quantity 2
1394 Bilingual to 6 Pin 1394, 6 Feet (CBL000100-006FR) – Quantity 2
1394 Beta to Beta 9 Pin, 6 Feet (CBL000101-006FR) – Quantity 2
USB and 1394b Extender Product Manual
1.1.2. Firewire (1394b) Extender
All models listed are available from Thinklogical™:
FIR-000001-SCTX 1394b EXTENDER TRANSMITTER WITH SC
FIR-000001-SCRX 1394b EXTENDER REC EIVER WITH SC
FIR-000001-STTX 1394b EXTENDER TRANSMITTER WITH ST
FIR-000001-STRX 1394b EXTENDER RECEIVER WI TH ST
1.2. Laser Information
CAUTION: In order to avoid possible exposure to laser energy, it is good practice to attach the fiber optic
cables prior to applying power to the Firewire EXTENDER. If the fiber optic cable should become
disconnected, DO NOT attempt to look into the cable or the panel mounted connector.
MAN-000012 16 REVISION G
2. System Features
Storage Temperature
-20 to 85 °C (-4 to 185 °F)
Supply Voltage
Power Consumption
P/N: PWR-000033-R (12V 5.5A Desktop Power Supply)
Laser Output Specifications
Meets Laser Class 1M Specifications
Panel Connectors
1394b connectors are rated
Transmitter: (2) 1394b connectors
Optical Cable
Duplex Fiber, multi-mode, 50 micron or 62.5 micron. (Fiber Cable
Operating Temperature and
Humidity
0 to 50 °C (32 to 122 °F); 10 to 95% RH, non-condensing
Enclosure Dimensions
Weight
Shipping Weight
Transmitter and Receiver: 4lbs (1.81kg)
Copper Cables
(2) 1394 Bilingual to 6 Pin 1394, 6 Feet
2.1. General System Features
Extends Firewire 800 (1394b) connection up to 1000 meters (3280 feet )
Compliant with IEEE 1394a (400) & IEEE 1394b (800)
Installation is Plug-and-Play, no adjustments are necessary
Uses standard duplex multi-mode fiber optic cable
LEDs provide link performance status
Available with your choice of ST or SC fiber connectors
2.2. Technical Specifications
12 VDC ±5%. Adapter has Universal AC Power Input
Polarity: Positive Tip
6 Watt Minimum; 36 Watt Maximum
*Note:
at 1.5A per connector
MAN-000012 17 REVISION G
Receiver: (2) 1394b connector s
(1) Dual Fiber connector (SC or ST)
is either customer-supplied or can be ordered from Thinklogical.)
6.61in x 4.00in x 1.09in (167.89mm x 101.60mm x 27.61mm)
Tolerance: ± 0.039in (1mm)
1lb (0.45kg) each
Part Number: CBL000100-006FR
(2) 1394 Beta to Beta, 6 Feet
Part Number: CBL000101-006FR
(1) Dual Fiber connector (SC or ST)
(1) 2.5mm power connector
(1) 2.0mm power connector
2.3. Product Overview – Firewire 800 Extender
CCD Camera
CCD Camera
MAN-000012 18 REVISION G
12V DC
POWER LINK
T R
Transmitter
IEEE-1394b Fiber Optic Extension System
800
Firewire Extender
The Future of Access and Control
Model Firewire 800
CABLE
POWER
CABLE
POWER
2.3.1. Firewire 800 Transmitter
MAN-000012 19 REVISION G
2.3.2. Firewire 800 Receiver
12V DC
POWER LINK
T R
Receiver
IEEE-1394b Fiber Optic Extension System
800
Firewire Extender
The Future of Access and Control
Model Firewire 800
CABLE
POWER
CABLE
POWER
MAN-000012 20 REVISION G
2 Fibers
Up to 1000 meters
2.3.3. Cables
2.3.3.1. Fiber Optic Cables
When connecting the fiber optic cables, you must be sure to:
Connect the fiber connector labeled „T‟ on the Transmitter to the fiber connector
labeled „R‟ on the Receiver.
Connect the fiber connector labeled „R‟ on the Transmitter to the fiber connector
labeled „T‟ on the Receiver.
*Note: Place Transmitter and Receiver units with the fiber panels facing each other. When you connect
the fibers, THE FIBER CABLE SHOULD NOT BE CROSSED.
2.3.3.2. USB Type A – Receiver
2.3.3.3. USB Type B – Transmitter
MAN-000012 21 REVISION G
2.3.4. Power Supply – PWR-000033-R (Quantity 2)
Universal Input: 90 – 264 VAC
Continuous Short Circuit Protection
Meets EN55022 Class “B”, Conducted
High Efficiency, 85% Typical
MAN-000012 22 REVISION G
3. Installation
1. Plug fiber into T location labeled on the Transmitter unit. Plug that corresponding end of fiber into
R location labeled on the Receiver unit.
2. Plug fiber into R location labeled on the Transmitter unit. Plug that corresponding end of fiber
into T location labeled on the Receiver unit.
3. Connect the power supply to the Receiver and plug corresponding end into a suitable AC power
source.
4. Connect your PC to one of the Firewire locations on the Transmitter unit.
a. Connect your local Firewire device (if applicable) to the other Cable Link location
(Firewire Connector) labeled on the Transmitter unit.
5. Connect the power supply to the Transmitter and plug corresponding end into a suitable AC
power source (OPTIONAL, depending on your power consumption)
6. Connect your devices(s) into the device port(s) ( Firewire Connectors) on the Receiver unit.
Note: Please allow up to one minute for the CPU to recognize the Firewire system.
Your Firewire 800 Extender System is now properly connected.
MAN-000012 23 REVISION G
3.1. LED Status
LED Label
Status
Power
LED is ON (solid green) when power supply is properly connected and
sufficient power is provided.
LED is OFF when power consumption is too high and the supplied power
supply is necessary.
Link
Shows the status of the connection.
LED is ON (solid green) when fiber are properly connected.
Cable Power
LED is ON (solid green) when enough power is supplied.
LED is OFF when power consumption is too high and the supplied power
supply is necessary.
LED Label
Status
Power
LED is ON (solid green) when power supply is properly connected and
sufficient power is provided.
Link
Shows the status of the connection.
LED is ON (solid green) when fiber are properly connected.
Cable Power
LED is ON (solid green) when power is properly connected.
3.1.1. Transmitter
3.1.2. Receiver
MAN-000012 24 REVISION G
Product Identification
1. Markings
1.1. Product Serial Number
The USB and FIREWIRE EXTENDER products have a unique serial number, imprinted on a small silver
label that is placed on the bottom of the chassis. The serial number includes a date-code. The format
for the date-code is two digits for the month; two digits for the day and four digits for the year and two or
three digits for a unique unit number. This serial number is also found on the original shipping carton.
1.2. Symbols Found on Product
Markings and labels on the product follow industry-standard conventions. Regulatory markings found on
the products comply with requirements.
MAN-000012 25 REVISION G
Safety Standards
1. Laser Module
Approval standard and any approvals it carries:
Class 1 Laser Safety per FDA/CDRH and EN60825-1
Electrical Safety per EN60950
Certified by TUV and CSA
2. External Fiber Connector
Flammability Rating UL94V0
3. USB 1.1 and 2.0 Power Supply
Thinklogical™ Part Number: PWR-000022-R
UL File Number: E176177
4. Firewire 800 Power Supply
Thinklogical™ Part Number: PWR-000033-R
UL File Number: E176177
MAN-000012 26 REVISION G
How to Contact Us
1. Customer Support
Thank you to our customers for choosing a Thinklogical™ product for your application. We appreciate
your business and are interested in helping you successfully use our product. Thinklogical™ is here to
help you. To contact Thinklogical™, use the following telephone numbers and internet-based methods.
1.1. Website
Check out our website for current product offerings, support information and general information about
all of the Thinklogical™ we offer.
Our internet website offers product information on all current systems, including technical specification
sheets and installation guides (for viewing online or for download), product diagrams showing physical
connections and other information you might need. We are constantly updating our website, so be sure
to “refresh” your browser when visiting the Thinklogical™ website to see the most up-to-date information.
Internet: www.thinklogical.com
*NOTE: Most online documents are stored as Adobe Acrobat “PDF” files. If you do not have the Adobe
Acrobat reader needed to view PDF files, visit www.adobe.com for a download.
1.2. Email
Thinklogical™ is staffed Monday through Friday from 8:30am to 5:30pm, Eastern Time Zone. We will try
to respond to your email inquiries promptly, use the following email addresses for your different needs:
info@thinklogical.com – Information on Thinklogical™and our products.
sales@thinklogical.com – Sales Department - orders, questions or issues.
support@thinklogical.com – Product support, technical issues or questions, product
repairs and request for Return Authorization.
MAN-000012 27 REVISION G
1.3. Telephone
Telephone Sales: Contact our expert technically oriented sales staff via telephone in Milford, CT at (203)
647-8700 or if in the continental US, you may use our toll-free number (800) 291-3211. We are here
Monday through Friday from 9:00am to 5:00pm, Eastern Time Zone. Ask for their direct dial phone
number when you call.
Telephone Product Support: Contact Product Support via telephone in Milford, CT at (203) 647-8700.
The support lines are manned Monday through Friday, 9am to 5pm, Eastern Time Zone.
International Sales: Please contact our US sales staff in Milford, CT at (203) 647-8700. We are here
Monday through Friday, 8:30am to 5:30pm, Eastern Time Zone (same as New York City). If leaving a
voice message, please provide a “best time to call back” so we may reach you at your convenience.
Our switchboard attendant will direct your call during regular business hours. We have an automated
attendant answering our main telephone switchboard after regular business hours and holidays. You
can leave voice messages for individuals at any time. Our Sales Representatives have direct numbers
to speed up your next call to us.
1.4. Fax
Our company facsimile number is (203) 783-9949. Please indicate the nature of the fax on your cover
sheet and provide return contact information.
MAN-000012 28 REVISION G
2. Product Support
Thinklogical‟s support personnel are available Monday through Friday from 8:30am to 5:30pm, Eastern
Time Zone. If your application might require assistance at some time outside of our normal business
hours, please contact us beforehand and we will do our best to make arrangements to help you with your
Thinklogical™ products.
2.1. Warranty
Thinklogical, LLC (“Thinklogical”) warrants this product against defects in materials and workmanship for
a period of one (1) year from the date of delivery (ordinary wear and tear excluded). This limited
warranty does not cover defects resulting from (i) use of the product other than as described in the
applicable documentation for the product; (ii) modifications to or repairs of the product that are made by
any party other than Thinklogical or a party acting on Thinklogical‟s behalf, or (iii) combination of the
product with third party products that is not consented to by Thinklogical. Occurrences of events
described in (i) – (iii) shall void the foregoing warranty. This warranty gives you specific legal rights, and
you may also have other rights which vary from state to state.
Except for the express warranty set forth above, to the fullest extent permitted under applicable
law, Thinklogical, LLC and its suppliers disclaim any and all other warranties, express and
implied, including without limitation the implied warranties of merchantability, fitness for a
particular purpose, title and non-infringement.
If the defective product is returned to the authorized dealer within one (1) year of the delivery date, repair
or replacement of the product will be made. Repairs may be made with refurbished parts. If repair or
replacement is not possible, Thinklogical may keep the defective product and refund the amount that you
paid for the defective product. These are Thinklogical‟s sole obligations, and your exclusive remedies,
for a breach of the limited warranty set forth above.
To return a defective product, contact the Thinklogical authorized dealer from whom you purchased the
product. Do not return a product directly to Thinklogical without prior authorization from your dealer.
If you have received prior authorization from your dealer and are returning a product directly to
Thinklogical:
1. Contact your sales representative, or call Customer Support at (800)291–3211 or + (203)647–
8700.
2. Describe the defect with the product and Customer Support will issue a Return Merchandise
Authorization Number (RMA#).
3. Pack the product in all of its original packing, if possible, and write the RMA number on the box.
4. Return the product to:
Thinklogical, LLC
Attn: RMA# [Insert the RMA# issued to you, by Thinklogical, here.]
100 Washington Street
Milford, CT 06460 USA
MAN-000012 29 REVISION G
2.2. Our Address
If you have any issue with the product, have product questions or need technical assistance with your
USB or FIREWIRE EXTENDER system, please call us at (203) 647-8700 and let us help.
If shipping something with an RA # or if you‟d like to write us, we are located at:
Thinklogical™ Inc.
100 Washington Street
Milford, CT 06460 USA
MAN-000012 30 REVISION G
Appendix A - Dimensions
Transmitter
USB 2.0 Hi-Speed Extension System
2.0
USB EXTENDER
The Future of Access and Control
Model USB-2
HOST
5VDC
POWER LINK
T R
3.0"
(76.25mm)
6.11" (155.19mm)
5.61" (142.49mm)
6.61" (167.89mm)
1.09" (27.61mm)
.50"
(12.70mm)
4.0"
(101.60mm)
.25" (6.35mm) (4X)
.25" (6.35mm)
Dia. (4X)
Tolerance: ± 0.039" (1mm)
1. USB 1.1 and 2.0 Transmitter
MAN-000012 31 REVISION G
Rec eiver
1
2 3 4
5VDC
POWER LINK
T R
4.0"
3.0"
6.11" (155.19mm)
6.61" (167.89mm)
.25" (6.35mm)
Dia. (4X)
.50"
(12.70mm)
1.09"
(27.61mm)
5.61" (142.49mm)
Receiver
USB 2.0 Hi-Speed Extension System
2.0
USB EXTENDER
The Future of Access and Control
Model USB-2
.25" (6.35mm) (4X)
3.0"
(76.25mm)
4.0"
(101.60mm)
Tolerance: ± 0.039” (1mm)
2. USB 1.1 and 2.0 Receiver
MAN-000012 32 REVISION G
12V DC
POWER LINK
T R
CABLE
POWER
CABLE
POWER
Transmitter
IEEE-1394b Fiber Optic Extension System
800
Firewire Extender
The Future of Access and Control
Model Firewire 800
6.61" (167.89mm)
1.09"
(27.61mm)
.25" (6.35mm)
Dia. (4X)
.25" (6.35mm) (4X)
.50"
(12.70mm)
5.61" (142.49mm)
6.11" (155.19mm)
3.0"
(76.25mm)
4.0"
(101.60mm)
Tolerance: ± 0.039" (1mm)
3. Firewire 800 Transmitter
MAN-000012 33 REVISION G
Receiver
IEEE-1394b Fiber Optic Extension System
800
Firewire Extender
The Future of Access and Control
Model Firewire 800
12V DC
POWER LINK
T R
CABLE
POWER
CABLE
POWER
6.61" (167.89mm)
1.09"
(27.61mm)
.25" (6.35mm)
Dia. (4X)
.25" (6.35mm) (4X)
.50"
(12.70mm)
5.61" (142.49mm)
6.11" (155.19mm)
4.0"
(101.60mm)
3.0"
(76.25mm)
Tolerance: ± 0.039" (1mm)
4. Firewire 800 Receiver
MAN-000012 34 REVISION G
For Your Notes:
MAN-000012 35 REVISION G
Loading...
