It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
Warning ! This model is not a toy.
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
* Specifications are subject to change without notice.*
www thewingsmaker com. .
SpecificationsSpecifications
Before commencing assembly please read these instructions thoroughly , .
INSTRUCTION MANUAL
Wing Span: 48.8 in / 1240 mm
Wing Area: 338 sq in / 21.8 sq dm
Flying Weight: 25.8 oz / 730 g
Fuselage Length: 33.8 in / 858 mm
Requires: 4-channel radio w/ 5 mini servos
Outrunner Motor KM28251025 w/ Propeller Adaptor
HW2340100 20A Brushless ESC,9x6 Propeller,
3 cells 11.1V 1800 mAh Li-Po battery & charger.
(
GM082XM
)
GM082XMPO30231403
Check all parts. If you find any defective or missing parts contact your local dealer. Please
DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly.
Any parts you find to be defective after the gluing process may be difficult to remove for
warranty replacement. The manufacturer will replace any defective parts, but will not extend
to the parts that are good before gluing to defective parts during assembly. Warranty will
not cover any parts modified by customer. For pre-assembled kits, please check proper
functions of all servos on the ground before flying. Servo gears could be damaged when
control surfaces are hit during transportation of models. The manufacturer will replace any
servos due to manufacturer`s defect, but will not cover plane crashes due to damaged
servos not detected before flying.
Symbols used throughout this instruction manual comprise of the following :-
Read through the manual before you begin, so you will have an overall idea of what to do.
1
2
3
INDEX
BEFORE YOU BEGIN
BEFORE YOU BEGIN
PARTS LIST
ASSEMBLY
SAFETY PRECAUTIONS
P.1
P.2
P.3-P.15
P.16
P.1
Cut off shaded portion.
Ensure smooth non-binding
movement while assembling.
Apply instant glue
(C.A.glue, super glue.)
Assemble left and right
sides the same way.
Peel off shaded portion
covering film.
Pay close attention here!
Apply epoxy glue.
Must be purchased separately !
Drill holes with the specified
diameter (here: 3mm).
Pierce the shaded portion
covering film.
3mm
Do not overlook this symbol !
Warning!
Apply thread locker
GM082XMPO30231403
P.2
Parts List
1.DECALS: GM082XM DEC -- 1 set
MAIN WING -- 1 pair
STABILIZER -- 1 set
FUSELAGE -- 1 set
2.STABILIZER & ELEVATOR -- 1 set
HINGES PL4115050 -- 4 pcs
3.VERTICAL FIN & RUDDER -- 1 set
HINGES PLL4115050-- 3 pcs
4.DECALS FOR RUDDER - 1 set
5.HORN PL4113103 -- 1 pc.
PLASTIC BRACKET -- 2 pcs
6.FUEL TUBE D2xD4x4mm -- 2 pcs
CLEVIS PL4112105 --1 pc.
STRAPER PL4112106 -- 1 pc.
PUSHROD Ø1.4x45mm w/ Threads (For Rudder) -- 1 pc.
7.HORN PL4113103 -- 1 pc.
PLASTIC BRACKET -- 2 pcs
8.FUEL TUBE D2xD4x4mm -- 2 pcs
CLEVIS PL4112105 --1 pc.
STRAPER PL4112106 -- 1 pc.
PUSHROD Ø1.4x60mm w/ Threads (For Elevator) -- 1 pc.
9.TAIL LANDING GEAR PL3410030 --1 set
SCREW PA2x8mm -- 2 pcs
TAIL WHEEL Ø23mm PL3510230 -- 1 pc.
10.MAIN LANDING GEAR Ø2.5mm -- 1 set
COLLAR Ø2.6mm w/ Set Screw -- 2 sets
MAIN WHEEL Ø40mm PL3116040 -- 2 pcs
SCREW PA2.3x8mm -- 1 pc.
PLYWOOD 21x26x2.5mm (For Main Landing Gear) -- 1 pc.
11.SOCKET HEAD SCREW M3x8mm -- 4 pcs
WASHER d3xD7mm -- 4 pcs
12.HORN PL4113103 -- 2 pcs
HINGES PLL4115050-- 8 pcs
PLASTIC BRACKET -- 4 pcs
13.FUEL TUBE D2xD4x4mm -- 4 pcs
CLEVIS PL4112105 --2 pcs
STRAPER PL4112106 -- 2 pcs
PUSHROD Ø1.4x65mm w/ Threads (For Aileron) -- 2 pcs
14.WING TUBE Ø6x715mm -- 1 pc.
NYLON BOLT M3x20mm -- 2 pcs
15.RECEIVER TIE 130mm -- 1 pc.
17.BATTERY TIE 200mm-- 1 pc.
BATTERY MAT 2x50x150mm-- 2 pcs
20.SPINNER Ø36mm SP27036FR0 -- 1 set
9x6 PROPELLERS PL6314050 -- 1 set
SCREW PM2x12mm -- 2 pcs
SCREW PA1.7x8mm -- 2 pcs
21.BATTERY COVER -- 1 pc.
GM082XMPO30231403
P.3
Decals
1
Bottom View
Top View
Cut out decal sheet, peel off backing sheet and
apply on fuselage, stabilizer and wings.
Decal
Main wings
Bottom View
Top View
Left View
Right View
Stabilizer
Fuselage
Bottom View
Top View
Stabilizer
Left View
Right View
Bottom View
Top View
GM082XMPO30231403
P.4
Stabilizer & Elevator
2
Vertical Fin & Rudder
3
Decals for Rudder
4
Hinge Setting
Hinge
Section View Completed
Bottom View
Hinge
Right View
Hinge
Hinge Setting
Hinge
Section View Completed
Transparent decals to
reinforce stabilizer.
For pre-assembled version, the hinges are factory glued.
For pre-assembled version, the hinges are factory glued.
Apply decal sheets on both sides to fasten rudder. Make sure no decal sheet cover the hinge gap. Check free movement of rudder
before hooking up with rudder pushrod.
GM082XMPO30231403
P.5
Elevator Servo & Horn
7
Rudder Servo & Horn
5
Servo wire
Plastic Bracket
Horn
Horn
Rudder Pushrod
6
Clevis
Pushrod
Ø1.4x45mm
Horn
Fuel Tube
d2xD4x4mm
Servo wire
Plastic Bracket
Plastic Stand
Straper
Fuel Tube
d2xD4x4mm
For pre-assembled version, the horn is factory
glued and servo installed.
For pre-assembled version, the horn is factory glued and servo installed.
GM082XMPO30231403
P.6
Elevator Pushrod
8
Tail Landing Gear
9
Main Landing Gear
10
Wheel Ø23mm
PA2x8mm
Plastic
Collar
1.2mm
Clevis
Pushrod
Ø1.4x60mm
Horn
Fuel Tube
d2xD4x4mm
PA2x8mm Screw
2
PA2.3x8mm Screw
1
Bottom View
10
0
Landing Gear
Fuselage
M3x3mm
Set Screw
3.1mm Collar
Wheel Ø40mm
Landing Gear
PA2.3x8mm
Plywood
21x26x2.5mm
Plastic Stand
Straper
GM082XMPO30231403
P.7
Motor & ESC
11
4
d3xD7mm Washer
4
M3x8mm
Socket Head Screw
Solder
Solder
TWM
KP0011310
ESC
Motor
Brushless ESC
EZ Connector
2-Pin EZ Connector
d3xD7mm Washer
M3x8mm
Aileron Servo & Horn
12
Horn
Servo wire
Plastic Bracket
Hinge Setting
Hinge
Section View Completed
Bottom View
Hinge
Bottom View
For pre-assembled version, the hinges and horn are pre-glued, and servo installed.
GM082XMPO30231403
P.8
Main Wing
14
Insert carbon fiber wing tube into right wing, align the anchor holes and apply the nylon bolt.
Insert the right wing into the Fuselage. Inset the left wing onto the carbon wing tube, press
the wings against the fuselage align the anchor holes and apply the nylon bolt.
Nylon Bolt M3x20mm
Nylon Bolt M3x20mm
Servo wire
Wing Tube
Ø6x715mm
Aileron Pushrod
13
Clevis
Pushrod
Ø1.4x65mm
Horn
Fuel Tube
d2xD4x4mm
Plastic Stand
Straper
Fuel Tube
d2xD4x4mm
Bottom View
15°
GM082XMPO30231403
P.9
Radio
16
Install battery
Elevator ElevatorThrottle
Aileron Rudder
Mode 1 Mode 2
Switch on radio
The power LED should turn on
AileronRudder
Radio
15
1
2
3
4
5
6
ID
SET
Aileron Servo (L)
180mm Y-Cord
Aileron Servo (R)
Rudder Servo
Receiver
Elevator Servo
ESC
Plug in the Aileron Servos wire to channel 1
Plug in the Elevator Servo wire to channel 2
Plug in the ESC Throttle wire to channel 3
Plug in the Rudder Servo wire to channel 4
Receiver Tie 130mm
GM082XMPO30231403
P.10
Battery & Motor Setting
17
Mode 1 Mode 2
Mode 1 Mode 2
Pull throttle
stick all the
way back.
Plug in battery wait a few
seconds for the transmiter
and receiver to bind.
1
2
Advance throttle stick, the motor should start running,
check motor shaft for rotating direction. The motor should be turning counter-clock wise. If rotating direction is not
correct, unplug the 3-pin plug connecting the motor and ESC, swivel 180
°
and plug back, the rotation will be reversed.
3
Solder Solder
ESC
Battery
TWM
KP0011210
Battery Tie 200mm
Battery Mat
Servos Setting
18
The left aileron should move down, and the right aileron
should move up, the plane will bank right when flying.
The left aileron should move up, and the right aileron
should move down, the plane will bank left when flying.
Move aileron stick to
right side
Move aileron stick to
right side
Move aileron stick to
left side
Move aileron stick to
left side
Mode 1 Mode 2
Mode 1 Mode 2
Red
Black
Red
Black
Plug in with red+ / black- reversed will damage the ESC.
Please move the servo reverse switch for Aileron, AIL up to the REV position, and check the following.
( For WMT6 radio only. Please refer to respective
instruction manual if you are using other radio system. )
GM082XMPO30231403
P.11
Servos Setting
19
Pull back Elevator stick Pull back Elevator stickElevator should move up, plane will pull up when
flying.
Push foward Elevator stick Push foward Elevator stick
Elevator should move down, plane will dive down
when flying.
Move Rudder stick to
right side
Move Rudder stick to
right side
Move Rudder stick to
left side
Move Rudder stick to
left side
Mode 1 Mode 2
Mode 1 Mode 2
Mode 1 Mode 2
Mode 1 Mode 2
The rudder should move to left, the plane will turn
to left when flying.
The rudder should move to right, the plane will turn
to right when flying.
GM082XMPO30231403
P.12
Propeller
20
Unplug battery
1
Switch off transmiter
2
Charge battery
3
The battery is ready for use when
all the lights turn from red to green.
*
Make sure you have unplugged the battery before working on the propeller.
Install the propeller
4
PA1.7x8mm
Ø36mm Spinner
M5 Nut
9x6 Propeller PL6314050
PM2x12mm
Propeller Adaptor
(d3xD5) HW2340100
TWM HW3111400
PROPELLER ADAPTOR WRENCH
EZ Connector Puller
GM082XMPO30231403
P.13
C.G.
21
Install battery onto the battery tray. Don`t plug in the battery yet. Put on the battery check C.G. mark underneath wings.
Support the model by two fingers on the C.G. mark, move battery position if necessary to balance the model on the
C.G. marks.
GM082XMPO30231403
P.14
Get Ready to fly
22
1
Turn on transwitter, throttle stick at low position.
2
Plug in battery.
3
Wait a few seconds for the receiver to bind with transmitter.
4
Make sure the propeller is cleared of any object.
5
Check movement of Ailerons, Elevator and Rudder by moving the sticks as shown in Step 18 and Step 19.
Advance throttle stick
slowly to check totation
of propeller.
Mode 1
Mode 2
Mode 1
Mode 2
Red
Black
Red
Black
Plug in with red+ / black- reversed will damage the ESC.
GM082XMPO30231403
P.15
Flying
23
1
Fine tune Elevator and Rudder with sub-trim tab.
2
Fine tune Ailerons with sub-trim tab.
Move Elevator Sub-trim tab up or down to bring elevator in a straight line with horizontal stabilizer.
Move Aileron Sub-trim tab to bring Ailerons in a straight line with Wings.
Move Rudder Sub-trim tab left or right to bring rudder in a straight line with vertical stabilizer.
Try to get an experienced flyer to check through your installation before flying. Ask him/her to do
the first flight for you. He/she can trim out the control surfaces for you so the model can fly straight
and level with control sticks in neutral positions and throttle stick about half throttle. You will get a
much higher successful rate with the help from an experienced flyer.
Before you fly, try to fine fune the control surfaces with Sub-trim tab.
Mode 1 Mode 2
Mode 1 Mode 2
Mode 1 Mode 2
GM082XMPO30231403
P.16
Important Safety Precautions
# First time flyer should never fly by himself / herself. Assistance from experienced flyer
is absolutely necessary.
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly
pre-adjusted aircraft.
# is specially designed to be powered by
KM28251025
Outrunner Motor.
# Make sure the air field is spacious, never fly the plane too close to people and never get
too close to a running propeller. Extreme caution should be exercised when working with
electric powered models. Make sure the propeller is cleared of all objects, especially your
hands before connecting the battery to the model. Make sure you understand the
operation of the ESC (Electronic Speed Control) by studying the ESC manual. Once you
plug in the battery for electric powered model, always treat the propeller as a rotating one,
as accidental movement of the throttle stick will spin the propeller and could cause injuries.
# Check and re-tighten up all factory assembled screws, use thread locker if necessary.
Warning!
GM082XMPO30231403
Large Clevis
Small Clevis
Pl8210010
180mm Y-Cord
Code No. Size Package
KW0021800 180mm 1 pc
Outrunner Motor
KM28251025
-Kv (rpm/V): 1025
-Operating Power: 110W
-Operating Voltage: 2-3S Li-Po
-Operating Current: 10A
-Peak Current: 15A (max. 15 sec.)
-Internal Resistance: 50 m ohms
-Diameter: 27.6mm
-Length: 25mm
-Weight: 40g
-Shaft Diameter: 3mm
-Shaft Length: 14 mm
-Mounting Screw:
M3 (Front)
-Distance of Mounting Holes:
16mm and 19mm
EZ Connector Puller
Code No. Size Package
PL8210030 1 set
GM082XMPO30231403
GM082XMPO30231403
THE WINGS MAKER
www.thewingsmaker.com
GM082XMPO30231403
Loading...
