The Wings Maker GM040P Instruction Manual

It is designed for maximum performance. Please seek advice if one is not familiar with this kind of electric powered precision model. Operating this model without prior preparation may cause injuries. Remember, safety is the most important thing. Always keep this instruction manual at hand for quick reference.
Warning ! This model is not a toy.
THE WINGS MAKER
FACTORYPRE-FABRICATED ALMOST-READY-TO-FLY(ARF) SERIES
MADE INCHINA
* Specifications are subject to change without notice.*
www thewingsmaker com. .
SpecificationsSpecifications
Before commencing assembly please read these instructions thoroughly, .
INSTRUCTION MANUAL
Wing Span: 39.5 in / 1000 mm Wing Area: 292 sq in / 18.8 sq dm Flying Weight: 27 oz / 760 g Fuselage Length: 40.5 in / 1030 mm Requires: 4-channel radio w/ 4 micro servos. Outrunner
Motor KM0283010 w/ Propeller Adaptor HW2340100 20A Brushless ESC, 3 cells 11.1V 15C 1800 mAh Li-Po battery & charger.
sunrise ep
GM040PO27791202
INDEX
BEFORE YOU BEGIN
BEFORE YOU BEGIN PARTS LIST ASSEMBLY SAFETY PRECAUTIONS
P.1 P.2 P.3-P.9
P.9
Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly. Any parts you find to be defective after the gluing process may be difficult to remove for warranty replacement. The manufacturer will replace any defective parts, but will not extend to the parts that are good before gluing to defective parts during assembly. Warranty will not cover any parts modified by customer.
Symbols used throughout this instruction manual comprise of the following :-
Read through the manual before you begin, so you will have an overall idea of what to do.
1
2
3
P.1
Cut off shaded portion.
Ensure smooth non-binding movement while assembling.
Apply instant glue (C.A.glue, super glue.)
Assemble left and right sides the same way.
Peel off shaded portion covering film.
Pay close attention here!
Apply epoxy glue.
Must be purchased separately !
Drill holes with the specified diameter (here: 3mm).
Pierce the shaded portion covering film.
3mm
Do not overlook this symbol !
Warning!
Apply thread locker
sunrise ep
GM040PO27791202
P.2
Parts List
1.MAIN WING -- 1 pair MICRO AILERON SERVO MOUNT PL5310020 -- 1 pair STRAPER PL4112106 -- 2 pcs CLEVIS PL4112105 -- 2 pcs FUEL TUBE d2xD4x4mm -- 4 pcs HORN PL4113103 -- 2 pcs PUSHROD Ø1.4x65mm w/ Threads (For Aileron) -- 2 pcs SCREW PA1.7x8mm -- 8 pcs
FIBRE TAPE 17x300mm -- 2 pcs PLYWOOD 36.7x36.7x3mm -- 2 pcs
2.FUSELAGE -- 1 set STABILIZER & ELEVATOR -- 1 set FIBRE TAPE 17x380mm -- 1 pc.
3.VERTICAL FIN & RUDDER -- 1 set FIBRE TAPE 17x175mm -- 1 pc. PLYWOOD 36.7x36.7x3mm -- 1 pc.
4.TAIL LANDING GEAR PL3410030 --1 set SCREW PA2x8mm -- 2 pcs PLYWOOD 36.7x36.7x3mm -- 1 pc.
5.MAIN LANDING GEAR -- 1 set MAIN WHEEL Ø40mm PL3116040 -- 2 pcs WOODEN COLLAR Ø2.6mm -- 2 pcs COLLAR Ø2.6mm w/ Set Screw -- 2 sets SCREW PA2x8mm -- 1 pc. SCREW PWA2x6mm -- 4 pc. PLYWOOD 48x35.7x2.5mm (For Main Landing Gear) -- 1 pc. MOUNTING PLATE 12x20mm -- 2 pcs WHEEL PANTS -- 1 pair LANDING GEAR COVERS -- 2 pcs
6.MICRO AILERON SERVO MOUNT PL5310020 -- 1 pc. SCREW PA1.7x8mm -- 4 pcs FUEL TUBE d2xD4x4mm -- 2 pcs CLEVIS PL4112105 --1 pc.
STRAPER PL4112106 -- 1 pc. HORN PL4113103 -- 1 pc. PUSHROD Ø1.4x135mm w/ Threads (For Elevator) -- 1 pc.
7.MICRO AILERON SERVO MOUNT PL5310020 -- 1 pc. SCREW PA1.7x8mm -- 4 pcs FUEL TUBE d2xD4x4mm -- 2 pcs CLEVIS PL4112105 --1 pc.
STRAPER PL4112106 -- 1 pc. HORN PL4113103 -- 1 pc. PUSHROD Ø1.4x130mm w/ Threads (For Rudder) -- 1 pc.
8.SOCKET HEAD SCREW M3x6mm -- 4 pcs SCREW PM2x12mm -- 2 pcs SCREW PA2.6x8mm -- 2 pcs WASHER d3xD7mm -- 4 pcs SPINNER Ø45mm SP27045BKO -- 1 pc. 10x6 FOLDING PROPELLER SET PL6314020 -- 1 set
9.WING TUBE Ø6x458mm -- 1 pc. RUBBER BAND 4x30mm -- 2 pcs
10.COCKPIT -- 1 pc. BATTERY TIE 200mm-- 1 pc.
SPONGE 10x50x150mm (For Radio Equipment & Battery) -- 2 pcs
DOUBLE-SIDED TAPE 30x35mm (For Brushless ESC) -- 1 pc.
11.DECALS: GM040 DEC -- 1 set
GM040PO27791202
P.3
Bottom View Bottom View
Bottom View
Please choose either (02L&02R) or (03L&03R) or (04L&04R) that suits your servo.
Aileron Servo
1
PA1.7x8mm Screw
8
Fibre Tape
17x300 mm
Plywood
36.7x36.7x3mm Servo(For Aileron)
Aileron Servo Lead
Fibre Tape
Bottom
Straper
Fuel Tube d2xD4x4mm
PA1.7x8mm
PA1.7x8mm
02L
03L 04L
02R 03R 04R
TWM PL8210010 CLEVIS WRENCH
Clevis
Pushrod Ø1.4x65mm
Fuel Tube
d2xD4x4mm
Horn
GM040PO27791202
P.4
0
Vertical Fin & Rudder
3
Completed
0
Tail Landing Gear
4
Bottom View
PA2x8mm Screw
2
Fibre Tape
17x175 mm
Fibre Tape
Plastic Collar
Wheel Ø23mm
PA2x8mm
1.2mm
Bottom View
Stabilizer & Elevator
2
Fibre Tape
17x380 mm
Fibre Tape
Bottom
Joining surfaces should be clean and dry. Slightly roughen surfaces with sandpaper for best results.
Joining surfaces should be clean and dry. Slightly roughen surfaces with sandpaper for best results.
Plywood
36.7x36.7x3 mm
Plywood
36.7x36.7x3mm
GM040PO27791202
Main Landing Gear
Elevator Pushrod
5
6
Bottom ViewCompleted
Bottom View
P.5
Bottom View
PA2x8mm Screw
1
PWA2x6mm Screw
4
Plywood
48x35.7x2.5mm
Landing Gear Covers
2.6mm 2
PA1.7x8 mm Screw
4
TWM PL8210010 CLEVIS WRENCH
Straper
Fuel Tube d2xD4x4mm
PA1.7x8mm
02L 03L 04L
02R 03R 04R
Please choose either (02L&02R) or (03L&03R) or (04L&04R) that suits your servo.
10
0
Bottom View
Landing Gear
Bottom View
PA2x8mm
Collar w/ Set Screw
M3x3mm Set Screw
2.6mm Collar
2.6mm Collar
Wheel Ø40mm
Wheel Pants
PWA2x6mm
12x20mm
Mounting Plate
Landing Gear
Landing Gear
Fuselage
Clevis
Pushrod Ø1.4x135mm
Fuel Tube
d2xD4x4mm
Horn
GM040PO27791202
Outrunner Motor 28/ 30 KM0283010
Propeller Adaptor (d3xD5) HW2340100
Rudder Pushrod
Outrunner Motor / Spinner
7
8
P.6
PA2.6x8mm Screw
2
M3x6mm
Socket Head Screw
4
PM2x12mm Screw
2
d3xD7mm Washer
4
Don’t over-tighten the PM2 screws, let the propeller blades align themselves when spinning.
3
PM2x12mm
Folding Propeller Set PL
6314020
PM2x12mm
Make sure rotating motor casing is not in contact with wirings or anything.
Optional Parts
TWM PL8210010 CLEVIS WRENCH
2
d3xD7mm Washer
M3x6mm
Don't over-tighten the M3 screws, too much stress on the screws could split the firewall.
1
Brushless ESC
EZ Connector
Solde r
Solde r
TWM KM0283010
ESC
Motor
4 5
M5 Nut
Ø45mm
PA2.6x8mm
TWM HW3111400 PROPELLER ADAPTOR WRENCH
Completed
Straper
Fuel Tube d2xD4x4mm
PA1.7x8mm
02L 03L 04L
02R 03R 04R
Please choose either (02L&02R) or (03L&03R) or (04L&04R) that suits your servo.
PA1.7x8 mm Screw
4
Clevis
Pushrod
Ø1.4x130mm
Fuel Tube
d2xD4x4mm
Horn
GM040PO27791202
P.7
Main Wing
9
Rubber Band
Wing Tube
Aileron Servo Lead
Ø6x458mm
Radio Equipment
10
Battery
Install and arrange the equipment as shown in the picture.
Outrunner Motor
Battery Tie
Sponge
Receiver
Front
Brushless ESC
Double Sided Tape
Completed
Fuselage Bottom
Cockpit
Completed
GM040PO27791202
P.8
Bottom View
Top View
Control Throws
12
Elevator
Rudder
Ailerons
Adjust the control throws as shown in the diagram. These throws are good for general flying. You can adjust according to your personal preference.
12mm
12mm
10mm 10mm
25mm 25mm
Decals
11
GM040PO27791202
P.9
Important Safety Precautions
# First time flyer should never fly by himself / herself. Assistance from experienced flyer is absolutely necessary.
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft.
# is specially designed to be powered by KM0283010 Outrunner Motor. # Make sure the air field is spacious, never fly the plane too close to people and never get
too close to a running propeller. Extreme caution should be exercised when working with electric powered models. Make sure the propeller is cleared of all objects, especially your
hands before connecting the battery to the model. Make sure you understand the operation of the ESC (Electronic Speed Control) by studying the ESC manual. Once you plug in the battery for electric powered model, always treat the propeller as a rotating one, as accidental movement of the throttle stick will spin the propeller and could cause injuries.
# Check and re-tighten up all factory assembled screws, use thread locker if necessary.
Warning!
sunrise ep
C.G.
13
The ideal C.G. position is 95mm (3.75in.) behind the leading edge measured at where the wing meets the fuselage. In order to obtain the C.G. specified, add weight to the fuselage or move the battery position. Check the C.G. before flying.
95mm
3.75in
C.G.
http://www.thewingsmaker.com/instructionManuals.php
GM040PO27791202
Large Clevis
Small Clevis
Pl8210010
-Kv(rpm/V): 1010
-Operating Power: 225W
-Operating Voltage: 6-15V
-Operating Current: 15A
-Peak Current: 20A(max.15 sec.)
-Internal Resistance: 102 m ohms
-Diameter: 28mm
-Length: 32mm
-Weight: 60g
-Shaft Diameter: 3mm
-Shaft Length: 15mm
-Mounting Screw: M3(Front) and M2(Back)
-Distance of Mounting Holes: 16mm and 19mm(Front), 12mm(Back)
KM02832R1
Outrunner 28/ 32 Deluxe (25% higher power)
GM040PO27791202
THE WINGS MAKER
www.thewingsmaker.com
GM040PO27791202
Pattern Flying Practice Guide
Wind Direction
1
2
3
4
5
6
7
9
10
11
12
13
14
15
16
17
x
3
x
3
