ThermoWorks TW8060 User Manual

TW8060

Two-Channel

Thermocouple With Alarm

Operating Instructions

Thank you for purchasing the TW8060 2-Channel
Thermocouple Alarm Thermometer. You’ve purchased a
professional thermocouple meter capable of measuring two
type K thermocouple inputs simultaneously, with one channel
configurable to alarm when preset limits are met. Alarm limits
are user programmable. It includes two mini-thermocouple
input jacks so most standard type K thermocouple probes can
be attached for use.

Please take a few minutes to review the information in this
booklet.

Start by examining the items included in the TW8060
packaging:

• One TW8060 2-Channel Thermocouple Alarm Thermometer

• Three type-AAA 1.5V batteries

• One wrist lanyard

• This instruction manual

SPECIFICATIONS

Display:

Accuracy:

LCD display with 4 digits per channel

-328 to 2372°F (-200 to 1300°C)

Range:

-148 to 2372°F: ± 0.1% reading + 1.4°F
(-100 to 1300°C: ± 0.1% reading + 0.7°C)

Resolution:

Auto Off:

Sample Rate:

Battery:

Below 1000°F/C: 0.1° / Above 1000°F/C: 1°

2 channels, channel 1 for alarm

Inputs:

After 20 minutes (may be disabled)

1 second

Type K thermocouples

Probe:

3 x AAA, 50 hrs normal mode, 10 hrs with
continuous alarm.*

Operating Environment:

Storage Environment:

Dimensions and Weight:

32 to 122°F (0 to 50°C), 0 ~ 80% RH

-4 to 140°F ( -20 to 60°C), 0 ~ 80% RH

4.8 H x 2.4 W x 1.2 D inches
(121 H x 60 W x 30 D mm), 180 grams

*Battery life is significantly extended when used with the optional Duracell Pro
batteries. Continuous use in normal mode is approx. 100 hours and with continuous
alarm 25 to 30 hours.
Available at www.thermoworks.com.

FEATURES

Meter

1. Sensor Cover

2. Type K Input Connections

3. LCD Display

4. Function Keys

1

2

3

4
