User Manual

for model

Premix condensing boiler

EKR 18

ENGLISH

USER INSTRUCTIONS

1

BOILER OPERATING INSTRUCTIONS

Make sure that the authorised technician who tested the boiler has stamped the guarantee booklet.

During the installation, the technician must carry out the following checks:

■ The data on the data plate must correspond to that of the mains supply networks (gas, electricity, water).

■ The boiler must be regulated according to its designed use and performance.

■ The flue gas exhaust and combustion air intake system must be correctly installed and operational.

■ The exhaust gas discharge and ventilation systems must comply with the requirements of national and local

standards regardless of whether the boiler is installed indoors, outdoors or in its own cabinet (see section
“Reference standards”.

General warnings



If there is any doubt as to whether the appliance has been tested by an authorised technician, do not attempt
to start it. All maintenance and gas conversion operations MUST BE CARRIED OUT BY PROFESSIONALLY
QUALIFIED PERSONNEL, registered in accordance with current legislation.



Make sure that the requirements relating to the air intake and ventilation of the room in which the
boiler is to be installed have been complied with.



The boilers can be installed outdoors in a partially protected location, in accordance with current
standards and where the minimum external temperature does not fall below –10°C. The manufacturer
will not be held responsible for installation in locations where the temperature falls to below –10°C.



The boiler is fitted with an antifreeze system. If the boiler is installed in a location where there is a risk of
freezing, the anti-freeze system will only come into operation if the power is on and the gas supply valve is
open (the frost protection is active even with the ON/OFF switch in OFF position). The manufacturer will not
be held responsible for damage to the boiler caused by non-compliance with this instruction.



Should any part of the boiler freeze-up, do not attempt to light it under any circumstances, but instead call the
Service Centre immediately.



The appliance’s combustion system must be checked every two years. This check includes testing the
efficiency of the boiler and must be carried out by authorised personnel possessing the qualifications as
required by current law.



Do not obstruct the ventilation openings in rooms where there are gas-burning appliances installed (boiler,
cooker, etc.).

The installation, first start-up, regulation and maintenance operations must be carried out exclusively by
qualified personnel (e.g. THERMOSTAHL authorised Service Centres). Incorrect installation can cause

damage to property and injury to persons or animals, for which the manufacturer will not be held responsible.

USER INSTRUCTIONS

2

If you smell gas …



DO NOT ACTIVATE ANY ELECTRIC SWITCHES, TELEPHONES OR ANY OTHER DEVICE THAT MAY
GENERATE ELECTRICAL DISCHARGES OR SPARKS.



OPEN DOORS AND WINDOWS IMMEDIATELY TO CREATE A CURRENT OF AIR THAT WILL RAPIDLY
CLEAR THE ROOM.



CLOSE ALL GAS TAPS AND VALVES.



CALL FOR PROFESSIONALLY QUALIFIED PERSONNEL.

Boiler controls - Control panel

LEGEND

1. ON/OFF SWITCH

2.

HEATING TEMPERATURE CONTROL KNOB

3. D.H.W TEMPERATURE CONTROL KNOB.

4. D.H.W TEMPERATURE DISPLAY BUTTON. (KEEP PRESSED FOR 5 SECONDS TO DISPLAY OUTSIDE

TEMPERATURE -ONLY WITH OPTIONAL OUTDOOR SENSOR)

5. SERVICE BUTTON.

6. SUMMER, WINTER OR SUMMER/WINTER MODE SELECTION BUTTON.

7. TERMINAL BOARD FOR EXTERNAL WIRING.

8. TEMPERATURE, ERROR CODE AND OPERATING STATUS DISPLAY.

Fig. 1

6 754321

8

USER INSTRUCTIONS

3

Starting - up the boiler

• Open the gas Isolation valve located under
the boiler.

• Switch on the boiler by placing the ON/OFF
switch (1) in the ON position (see “Control
panel”).

• The boiler will light automatically (with the
WINTER mode selected and room thermostat
connected).

• Check that there are no flashing numbers on
the display 8 (see error codes). If code H2O
appears on the display 8 this denotes that
there is no water in the boiler. Consequently,
fill the system as described in section “Filling
the system”.

■ “SUMMER” mode

To switch boiler operation to “SUMMER” mode, press button 6 (see fig. 1). The boiler will only work for the D.H.W
system. The “SUMMER” mode setting of the boiler is signalled by the symbol

lit continuously on the control

panel.
The automatic ignition system will light the burner every time there is a demand for domestic hot water. In this
case, the symbol

on the control panel will flash.

■ “WINTER” mode

To switch boiler operation to “WINTER” mode, press button 6 (see fig. 1). The boiler will only work for the central
heating system. The “WINTER” mode setting of the boiler is signalled by the symbol

lit continuously on the

control panel.
The automatic ignition system will light the burner every time there is a demand for room heating. In this case, the
symbol

on the control panel will flash.

■ “SUMMER-WINTER” mode

To switch boiler operation to “SUMMER/WINTER” mode, press button 6 (see fig. 1). The boiler will work for both
central heating/D.H.W systems. The “SUMMER/WINTER” mode setting of the boiler is signalled by the symbols

lit continuously on the control panel.
The automatic ignition system will light the burner every time there is a demand for room heating or domestic hot
water, the functioning is signalled by the symbols

flashing continuously on the control panel.

■ Regulating the heating temperature

The heating temperature is regulated by knob 2 (see fig.1).

• Rotating the knob anticlockwise reduces the temperature.

• Rotating the knob clockwise increases the temperature.

• The range of temperature settings for the central heating runs from a minimum of 30°C to a maximum of

80°C, or, in the case of low temperature operation, from a minimum of 25°C to a maximum of 59°C.

■

D.H.W temperature control

The domestic hot water temperature is regulated by knob 3 (see “Control panel”).

• Rotating the knob anticlockwise reduces the temperature.

• Rotating the knob clockwise increases the temperature.

•

The range of temperature settings for the domestic hot water runs from a minimum of 35°C to a maximum of

60°C.

6 754321

8

Fig. 1

USER INSTRUCTIONS

4

3

2

GREEN AREA

1.2 bar

0.5 bar

1.5 bar
3 bar

MR

■ Topping-up the system with water

The water pressure in the central heating circuit must be
checked during the entire period of operation of the boiler.
In this respect, the reading on the pressure gauge M (fig.

2), located on the lower part of the boiler, must not be less
than 1 bar.

If there is insufficient water in the boiler, the code H2O will
flash on the display (see fig 2).

To bring the system back up to pressure, open the
external filling tap R (fig. 2) and use the pressure gauge M
(fig. 2) to check that the systems pressure reaches the
middle of the green area (equal to 1,2 bar, see fig. 3) and
that the code H2O lights up.

When the operation is complete, close the fill tap.

Diagnostics – Error codes:

This paragraph contains a list of error codes that the boiler
may generate on the display 8 (see “Control panel”)
together with the relative indications and the operations
that the user can carry out to reset the boiler.

If the problem re-occurs after the following
actions have been taken, call an authorised
Service Centre.

_E01

E01E01

E01_ Ionisation block

Code E01 lit continuously on the display.
 Check that the gas valve on the boiler and gas meter are open and that there is gas in the mains supply (or in

the tank).

 Switch off then switch on the appliance using switch 1 (see “Control panel”) on the control panel.
 When the error code on the display disappears, the boiler will restart.

If the problem persists, Call the Service Centre.

_E02

E02E02

E02_ Safety Thermostat tripped

Code E02 lit continuously on the display. Call the Service Centre.

_E03

E03E03

E03_ Flue Gas Thermostat tripped

Code E03 lit continuously on the display. Call the Service Centre.

_h2o

h2oh2o

h2o_ Water Pressure Switch tripped

Code H2O lit continuously on the display.
 Check the water pressure in the central heating circuit. The reading on the pressure gauge M (see fig. 3),

located on the lower part of the boiler, must not be less than 1 bar .

 If the pressure is less than 1 bar, top-up the system as described in paragraph “Filling the system”.
 The boiler will restart automatically.

If the problem persists, Call the Service Centre.

USER INSTRUCTIONS

5

_E05

E05E05

E05_ Heating Sensor malfunction

Code E05 lit continuously on the display. Call the Service Centre.

_E06

E06E06

E06_ D.H.W Sensor malfunction

Code E06 lit continuously on the display. Call the Service Centre.

_EEEE11116666_ Electric Fan Malfunction

Code E16 lit continuously on the display. Call the Service Centre.

_E22

E22E22

E22_ Parameter programming request

Code E22 lit continuously on the display. Call the Service Centre.

N.B. If the boiler is to be left unused for a long period of time, the user must do one of the following:

 Make the boiler safe by disconnecting all the power supplies (electricity and gas), and draining the heating

system and the condensate trap.

 Leave the boiler in standby, leaving the electricity and gas supplies connected and, consequently the anti-freeze

function.
