Thermo Scientific SHKA4000-1CE, 4322, 4323, SHKA4000-6CE, 4320 Operating Manual

MaxQ 4000 Incubated and

User Manual

Refrigerated Shakers

Models SHKE4000 and SHKA4000

Operating Manual and Parts List 057-287-00 (7004342) Rev. 16

Visit us online to register your warranty
www.thermoscientific.com/labwarranty

odels covered in this manual

M

Model number Voltage

SHKA4000 (4320) 120V

SHKA4000-1CE (4321) 220-240V

SHKA4000-5 (4322) 120V

SHKA4000-6CE (4323) 220-240V

SHKA4000-7 (4338) 120V

SHKA4000-8CE (4339) 220-240V

SHKE4000 (4328) 120V

SHKE4000-1CE (4329) 220-240V

SHKE4000-5 (4330) 120V

Preface

SHKE4000-6CE (4331) 220-240V

SHKE4000-7 (4342) 120V

SHKE4000-7JPN (4343) 100V

SHKE4000-8CE (4344) 220-240V

MANUAL NUMBER 057-287-00 (7004342)

16 40722 7/10/17 Added gas springs section to Maitinence bpg

15 41343 5/02/17 Added F-Gas statement, removed declaration of certification bpg

14 40673 4/20/17 Updated voltage information bpg

13 40453 9/13/16 Circuit breaker P/N in Replacement Parts from 330-250 & 330-399 to 330-138-00 ccs

12 40139 4/15/15 Updated warranty information ccs

11 31361 7/18/14 Removed CE reference from pg 2-5 ccs

10 31164/OS-775 7/9/14 Added care and cleaning of acrylic lid to Section 3 ccs

9 30954 4/10/14 Updated Setting TImer for Continuous Shaking Step 3 - pg 5-6 ccs

Thermo Scientific

Incubated and Refrigerated Shakers i

Preface

Contains Parts and Assemblies

Susceptible to Damage by

E

lectrostatic Discharge (ESD)

CAUTION

Preface

Important Read this instruction manual. Failure to read, understand and follow the instructions in this manual
may result in damage to the unit, injury to operating personnel, and poor equipment performance.

s

Caution All internal adjustments and maintenance must be performed by qualified service personnel. s

Material in this manual is for information purposes only. The contents and the product it describes are subject
to change without notice. Thermo Fisher Scientific makes no representations or warranties with respect to this
manual. In no event shall Thermo be held liable for any damages, direct or incidental, arising out of or related to
the use of this manual.

©2010 Thermo Fisher Scientific. All rights reserved.

Thermo Scientificii Incubated and Refrigerated Shakers

Preface

Important operating and/or maintenance instructions. Read the accompanying text carefully.

Potential electrical hazards. Only qualified persons should perform procedures associated with this
symbol.

Equipment being maintained or serviced must be turned off and locked off to prevent possible injury.

Hot surface(s) present which may cause burns to unprotected skin, or to materials which may be
damaged by elevated temperatures.

WEEE Compliance: Thermo Fisher Scientific has contracted with companies for recycling/disposal in
each EU Member State. For further information, send an email to [e-mail].

4 Always use the proper protective equipment (clothing, gloves, goggles, etc.)

4 Always dissipate extreme cold or heat and wear protective clothing.

4 Always follow good hygiene practices.

4 Each individual is responsible for his or her own safety.

Thermo Scientific

Incubated and Refrigerated Shakers iii

Preface

Do You Need Information or Assistance on

Thermo Scientific Products?

If you do, please contact us 8:00 a.m. to 6:00 p.m. (Eastern Time) at:

1-740-373-4763 Direct
1-800-438-4851 Toll Free, U.S. and Canada
1-877-213-8051 FAX
http://www.thermofisher.com Internet Worldwide Web Home Page
[e-mail] Tech Support Email Address

Certified Service Web Pagewww.unitylabservices.com

Our staff can provide information on pricing and give you quotations. We canSales Support

take your order and provide delivery information on major equipment items or make
arrangements to have your local sales representative contact you. Our products are listed on the
Internet and we can be contacted through our Internet home page.

Our staff can supply technical information about proper setup, operation orService Support
troubleshooting of your equipment. We can fill your needs for spare or replacement parts or
provide you with on-site service. We can also provide you with a quotation on our Extended
Warranty for your Thermo Scientific products.

Whatever Thermo Scientific products you need or use, we will be happy to discuss your
applications. If you are experiencing technical problems, working together, we will help you
locate the problem and, chances are, correct it yourself...over the telephone without a service
call.

When more extensive service is necessary, we will assist you with direct factory trained
technicians or a qualified service organization for on-the-spot repair. If your service need is
covered by the warranty, we will arrange for the unit to be repaired at our expense and to your
satisfaction.

Regardless of your needs, our professional telephone technicians are available to assist you
Monday through Friday from 8:00 a.m. to 6:00 p.m. Eastern Time. Please contact us by
telephone or fax. If you wish to write, our mailing address is:

Thermo Fisher Scientific (Asheville) LLC
401 Millcreek Road, Box 649
Marietta, OH 45750

International customers, please contact your local Thermo Scientific distributor.

Thermo Scientificiv Incubated and Refrigerated Shakers

Table of Contents

Section 1

Section 2

Section 3

Section 4

Section 5

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Control Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

A-Class Control Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

E-Class Control Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Unpacking and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Platform Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Test Tube Rack Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Flask Clamp Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

A-Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

Temp Controller -Setting Temperature . . . . . . . . . . . . . . . . . . . . . . . 5-2

Temperature Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

E-Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4

Temperature Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5

AC Power Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5

Setting Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5

Setting Timer for Continuous Shaking . . . . . . . . . . . . . . . . . . . . . . . 5-6

Setting Timer for Timed Shaking . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

RS232 Communication Configuration . . . . . . . . . . . . . . . . . . . . . . . 5-7

RS232 Interface Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Setting High-Limit Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8

Optional Refrigeration System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9

Setting Low-Limit Control (Refrigerated) . . . . . . . . . . . . . . . . . . . . . 5-9

Optional Refrigeration System . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10

Defrost Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11

Incubated and Refrigerated Shakers vThermo Scientific

Table of Contents

Section 6

Section 7

Section 8

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Gas Springs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Platform Mounting Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Platform Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2

For A-Class Series Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Care and Cleaning of Acrylic Lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1

Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1

Ordering Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

vi Incubated and Refrigerated Shakers Thermo Scientific

Section 1 Safety Information

This manual contains important operating and safety information. The
user must carefully read and understand the contents of this manual prior
to the use of this equipment.

Your Thermo Scientific MaxQ 4000 Shaker has been designed with
function, reliability, and safety in mind. It is your responsibility to install
it in conformance with local electrical codes. For safe operation, pay
attention to Notes, Cautions, Warnings throughout the manual.

Warnings

To avoid electrical shock, always:

1. Use a properly grounded electrical outlet of correct voltage and current
handling capacity.

2. Disconnect from the power supply prior to maintenance and servicing.

To avoid personal injury:

1. Do not use in the presence of flammable or combustible materials; fire
or explosion may result. This device contains components which may
ignite such materials. Not rated for use in hazardous atmospheres.

2. Wear appropriate eye and hand protection when handling hazardous
chemicals.

3. Refer servicing to qualified personnel.

4. Do not modify construction and/or assembly of equipment.

5. Do not remove tags, labels, decals, or other information from the unit.

6. Stand clear of equipment when it is operating.

7. If shaking action will result in the evolution of gases or fumes, carry
out the operation in a well-ventilated laboratory hood.

Incubated and Refrigerated Shakers 1-1Thermo Scientific

Section 1

Safety Information

To avoid personal injury (continued):

8. Use equipment only for its intended purpose. Use only the accessories
and attachments that are shipped with the equipment or are specified
for it. Substituting other attachments or accessories can produce
hazards or make the unit inoperative.

9. Perform regular maintenance service as specified in this manual and
keep unit in good repair. Do not operate with known defects.

10. Do not use the shaker to mix flammable materials or where the
transfer of mechanical energy to glass could cause glass breakage.

1-2 Incubated and Refrigerated Shakers Thermo Scientific

Section 2 General Specifications

Model

number

Exterior Unit Dimensions

Length 32” (81.3 cm) 32” (81.3 cm) 32” (81.3 cm) 32” (81.3 cm)

Width 22.5” (57.2 cm) 22.5” (57.2 cm) 22.5” (57.2 cm) 22.5” (57.2 cm)

Height 22” (55.9 cm) 22” (55.9 cm) 22” (55.9 cm) 22” (55.9 cm)

Electrical - Standard Temperature

Voltage AC 120 220-240 120 220-240

Amperage 5.0 3.0 5.0 2.5

Wattage 625 725 625 625

Frequency 60 50/60 60 50/60

High Temperature

All Analog
“A” Series units

All Analog
“A” Series units

All Digital
“E” Series units

All Digital
“E” Series units

Voltage AC 120 220-240 120 220-240

Amperage 9.0 5.0 9.0 4.5

Wattage 1100 1200 1100 1100

Frequency 50/60 50/60 50/60 50/60

Refrigerated

Voltage AC 120 220-240 120 220-240

Amperage 14.0 7.0 14.0 7.0

Wattage 1500 1500 1500 1500

Frequency 60 50 60 50

Incubated and Refrigerated Shakers 2-1Thermo Scientific

Section 2

General Specifications

Model number

peed Accuracy

S

Timer

Display

Mutable Alarms None None

Motor Permanent Magnet DC Permanent Magnet DC Solid State Brushless DC Solid State Brushless DC

All Analog

A” Series units

“

0 to 400 rpm, ±10 rpm

4

Continuous or timed opera-

tion from 1-60 min.

3 individual LED displays
indicate temperature in 1°C
increments. Analog
tachometer displays speed
in rpm.

All Analog

A” Series units

“

0 to 400 rpm, ±10 rpm

4

Continuous or timed opera-

tion from 1-60 min.

3 individual LED displays
indicate temperature in 1°C
increments. Analog
tachometer displays speed
in rpm.

All Digital

E” Series units

“

5 to 500 rpm, ±1 rpm

1

Continuous or timed operation

0.1-999 hours or 0.1-999 mins.

3 individual LED displays indi­cate temperature, time and
speed simultaneously. 3 charac­ters height 1/2 inch (1.27 cm)

Audible portion of the alarm
can be silenced for a period of
1 hour without deactivating the
actual alarm condition by
depressing any key.

All Digital

E” Series units

“

5 to 500 rpm, ±1 rpm

1

Continuous or timed operation

0.1-999 hours or 0.1-999 mins.

3 individual LED displays indi­cate temperature, time and
speed simultaneously. 3 charac­ters height 1/2 inch (1.27 cm)

Audible portion of the alarm can
be silenced for a period of 1
hour without deactivating the
actual alarm condition by
depressing any key.

Soft Start Feature None None

RS232 Interface * None None

Recorder Output * None None

Intended Use

Orbital shakers are designed to provide increased aeration in a stable
temperature environment.

Unintended Use

1) Not intended for use in Class I or II applications as defined in 21 CFR

2) Not intended for mixtures of flammable materials

Software algorithms prevent

sudden start/stops.

Monitor speed, temperature in

°C and time with a computer.

10 mv/°C output monitors tem­perature with external chart
recorder.

Software algorithms prevent

sudden start/stops.

Monitor speed, temperature in

°C and time with a computer.

10 mv/°C output monitors tem­perature with external chart
recorder

2-2 Incubated and Refrigerated Shakers Thermo Scientific

Section 2

General Specifications

Model number

peed

S

All Analog

A” Series units

“

one

N

All Analog

A” Series units

“

one

N

Speed Shut off None None

Timer None None

Unbalanced Load None None

All Digital

E” Series units

“

Audible with flashing
LED indicate when
speed deviates more
than 10% of set point.

When speed deviates
10% of set point, unit
will shut down immedi­ately.

Beeps twice when
time has expired.
Shaking motion stops.

If the unit is running
in an unbalanced con­dition, an alarm will
sound and the shaker
will stop until the end
user corrects the condi­tion. The speed display
will flash “bAL” on
speed panel LED.

All Digital

E” Series units

“

Audible with flashing
LED indicate when
speed deviates more
than 10% of set point

When speed deviates
10% of set point, unit
will shut down immedi­ately.

Beeps twice when
time has expired.
Shaking motion stops.

If the unit is running
in an unbalanced con­dition, an alarm will
sound and the shaker
will stop until the end
user corrects the condi­tion. The speed display
will flash “bAL” on
speed panel LED.

Optional Platform Dimensions - in. (cm)

Catalog Number L xW

30110 Universal 18” x 18” (45.7 x 45.7 cm)

Incubated and Refrigerated Shakers 2-3Thermo Scientific

Section 2

General Specifications

The MaxQ 4000 series of bench top, incubated and refrigerated shakers
are available in either analog or digital control configurations:

• A-Class shakers: SHKA4000, SHKA4000-1CE, SHKA4000-5,
SHKA4000-6CE, SHKA4000-7, SHKA4000-8CE: control
temperature by a Proportional/Integral/Derivative (PID)
microprocessor-based controller. Solid-state control maintains time and
speed and is adjustable with rotary dials. Analog tachometer displays
speed in RPM, verifying accuracy of speed setting. Refrigerated units
feature environmentally safe CFC free insulation and coolant.

• E-Class shakers: SHKE4000, SHKE4000-1CE, SHKE4000-5,
SHKE4000-6CE, SHKE4000-7, SHKE4000-8CE: control
temperature, time and speed by a Proportional/Integral/Derivative
(PID) microprocessor-based controller that is adjustable with switches
on a keypad in 1 rpm increments. Refrigerated units feature
environmentally safe CFC free insulation and coolant. Flashing display
indicates power interruption. Pressing any key will clear display. Non­volatile memory maintains speed and time set points in the event of a
power interruption. Speed and time set points are automatically
reactivated after power is restored.

• Temperature range and accuracy follow. All units have a uniformity of
±0.5°C at 37°C in flask:

Standard Temperature: SHKA4000, SHKA4000-1CE, SHKE4000,

SHKE4000-1CE,
10°C above ambient to 60°C, ±0.1°C at 37°C in flask.

High Temperature: SHKA4000-5, SHKA4000-6CE, SHKE4000-5,

SHKE4000-6CE,
10°C above ambient to 80°C, ±0.1°C at 37°C in flask.

Refrigerated: SHKA4000-7, SHKA4000-8CE, SHKE4000-7,

SHKE4000-8CE,
15°C below ambient to 60°C, ±0.1°C at 37°C in flask. Refrigeration
system needs to be turned off whenever the set point is at or above
32°C.

2-4 Incubated and Refrigerated Shakers Thermo Scientific

Section 2

General Specifications

In addition, all versions offer:

• Space efficient tubular heaters.

• Drive interrupt halts shaking action when lid is opened.

• All set points are retained by non-volatile memory that automatically
reactivates after power is restored.

• Visual, user adjustable over-temperature safety signal with independent
thermostat controls the heat if main controller fails.

• 3/4 inch (1.9 cm) triple eccentric orbital drive.

• 6 permanently lubricated ball bearings.

• 50 lb (22.7 kg) platform load capacity at safe speeds less than 400 rpm
for A-Class shakers and less than 500 rpm for E-Class shakers.

Environmental Operating Conditions

Pollution Degree 2**

Installation Category II**

Altitude . . . . . . 2000 meters MSL (Mean Sea Level)

Relative Humidity . . .20% to 80% maximum, non-condensing

Electrical Supply . . . . . . . . . . 120 VAC or 240 VAC

Voltage Tolerance . . . . . . +10% of normal rated line

Temperature . . . . . . . . . . . . . . . . . . . . 15°C to 32°C

Product Usage . . . . . . . . . . . . . . . . . Indoor use only

**Refer to IEC 664-1

Caution Operation of the shaker in a CO2 enriched atmosphere is not
recommended. The formation of carbonic acid could cause electrical
failures.

s

Incubated and Refrigerated Shakers 2-5Thermo Scientific
