COMP 5 Smooth-Star
Door Panel Dimensions
6/8 Smooth-Star Doors ..................................................................................................................................5.3
6/8 Smooth-Star Flush-Glazed Doors ........................................................................................................5.22
6/8 Smooth-Star Raised Panel Doors ........................................................................................................5.24
8/0 Smooth-Star Doors ................................................................................................................................5.26
8/0 Smooth-Star Flush-Glazed Doors ........................................................................................................5.34
6/8 Smooth-Star Noise Reduction Doors ..................................................................................................5.35
8/0 Smooth-Star Noise Reduction Doors ..................................................................................................5.36
Smooth-Star Door Panel Dimensions
Comp 5 2014 (U1 REVISED) 5.1
5.2 2014 (U1 REVISED) Comp 5
6/8 Smooth-Star Doors
A
B
C
4-19/32”
2 Panel Soft Arch (Slab-SS002U1) (Impact-SS002HU1)
Smooth-Star Door Panel
37-5/32”
6-3/16”
21-13/16”
9-19/64”
79-3/64”
Size A B C 2/6 29-13/16” 4-13/32” 21”
2/8 31-13/16” 4-11/32” 23-1/8”
2/10 33-13/16”” 5-11/32” 23-1/8”
3/0 35-13/16” 6-11/32” 23-1/8”
Dimensions
Flush Panel (Slab-SS010U1) (Impact-SS010HU1)
Size A *2/0 23-13/16" *2/4 27-13/16"
2/6 29-13/16" 2/8 31-13/16"
2/10 33-13/16"
3/0 35-13/16" 3/6 41-13/16"
*Impact slab not available.
Height B
76-23/32"
*6/6
6/8 79-3/64"
A
B
Comp 5 2014 (U1 REVISED) 5.3
6/8 Smooth-Star Doors
A
”
B
21-31/32”
6-1/2
Full Oval Flush (103, 200, 2056) (Slab - SS010U1)
Daylight Opening: 19-7/32" x 55-11/32"
(846 sq.in.)
79-3/64”
58-3/32
14-29/64”
”
Size A B
2/8 31-13/16” 4-15/16”
2/10 33-13/16” 5-15/16”
3/0 35-13/16” 6-15/16”
1/3 Lite Flush (105, 215, 2227) (Slab-SS010U1)
Daylight Opening: 21-1/8" x 26-1/8"
(552 sq.in.)
Size A B
2/6 29-13/16” 2-31/32” 2/8 31-13/16” 3-31/32”
2/10 33-13/16” 4-31/32”
3/0 35-13/16” 5-31/32”
A
4-5/32
28-7/8
79-3/64”
46-1/64
”
”
”
B
23-7/8
”
5.4 2014 (U1 REVISED) Comp 5
6/8 Smooth-Star Doors
A
B
C
G
Full Lite Flush (Impact - 140H, 141H, 1464H) (108N, 118N, 128N, 1664, 2064, 2264) (108, 118, 128, 916, 2264) (Slab-SS010U1) (Impact-SS010HU1)
Daylight Opening: 12-13/16" x 62-13/16"
F
E
D
Note: For Optional Grille Locations, See Arch 1.
Hei ght F G
*6/6 76- 23/32" 4-5/ 32"
6/8 79- 3/64" 4- 5/32" 7/0 83- 3/64" 7- 1/2"
Size A B C D (6/8) D (6/6) E *2/0 23- 13/16" 4-1/ 32" 15-3/ 4" 9- 9/64" 6-13/ 16" 65-3/ 4" *2/4 27- 13/16" 4-31/32" 17-7/ 8" 9- 1/64" 6- 11/16" 65- 7/8"
2/6 29- 13/16" 3-31/32" 21- 7/8" 9-1/64" 6-11/ 16" 65- 7/8" 2/8 31- 13/16" 3-31/32" 21- 7/8" 9-1/64" 6-11/ 16" 65- 7/8"
2/10 33- 13/16" 4-31/32" 23- 7/8" 9-1/64" 6-11/ 16" 65- 7/8"
3/0 35- 13/16" 4-31/32" 23- 7/8" 9-1/64" 6-11/ 16" 65- 7/8"
Daylight Opening: 18-29/32" x 62-29/32"
Daylight Opening: 20-15/16" x 62-15/16"
*Impact sl ab not available.
(1464) (805 sq.in.)
(2064) (1189 sq.in.)
(2264) (1317 sq.in.)
Smooth-Star Door Panel Dimensions
Half L ite F l ush (Glass - 2236, 104, 137) (2036, 104N) (Impact Glass - 104H) (Sla b - SS010U1) (Imp act S lab - SS010H U1)
Daylight Opening: 19-1/8" x 35-1/8"
(2036) (672 sq.in.)
Daylight Opening: 20-29/32" x 34-29/32"
(2236) (729 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
Size A B C
2/6 29-13/16" 3-31/32" 21-29/32" 2/8 31-13/16" 3-31/32" 23-29/32"
2/10 33-13/16" 4-31/32" 23-29/32"
3/0 35-13/16" 5-31/32" 23-29/32"
A
B C
4-5/32"
37-29/32"
79-3/64"
Comp 5 2014 (U1 REVISED) 5.5
6/8 Smooth-Star Doors
A
B C
D E
F
4 5/32"
37 29/32"
79-3/64"
21 13/16"
9 3/8"
Half Lite 2 Panel (2/6N Glass - 104N, 612N, 2036) (Glass - 104, 137, 612, 904, 2236) (Impact Glass - 104H, 612H, 904H) (Slab - SO2236U1, SS060U1, SS400U1, SS020U1, SS060NU1) (Impact Slab - SS060HU1, SS060NHU1)
Daylight Opening: 19-1/8" x 35-1/8"
(2036) (672 sq.in.)
Daylight Opening: 20-29/32" x 34-29/32"
(2236) (729 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
Size A B C D E F
2/6N 29-13/16" 3-31/32" 21-29/32" 4-13/32" 8-13/16" 21"
2/8 31-13/16" 3-31/32" 23-29/32" 4-11/32" 9-1/8" 23-1/8"
2/10 3 3-13/16" 4-31/32" 23-29/32" 5-11/32" 9-1/8" 23-1/8"
3/0 35-13/16" 5-31/32" 23-29/32" 6-11/32" 9-1/8" 23-1/8"
Half Lite RT 2 Panel (150, 151, 2236R) (Slab - SS020U1)
Daylight Opening: 21-1/8" x 35-1/8"
(694 sq.in.)
Size A B C
2/8 31-13/16” 3-13/16” 4-3/64”
2/10 33-13/16” 4-31/32” 5-3/64”
3/0 35-13/16” 5-31/32” 6-3/64”
B
C
9-1/2
A
”
”
23-7/8
”
4-1/8”
4-5/32
37-7/8
5-27/32
21-13/16”
9-3/8”
”
79-3/64”
”
5.6 2014 (U1 REVISED) Comp 5
6/8 Smooth-Star Doors
A
B
23-1/8”
4-9/16”
7
”
3 Panel (Slab-SS030U1) (Impact-SS030HU1)
4”
”
37-1/8
79-3/64”
13”
9-11/32”
Half Lite 1 Panel Top & Bottom (Glass - 104, 612, 904, 2236) (Impact Glass - 104H, 612H, 904H) (Sla b - SS030U1) (Impact Slab - SS030H U1)
Smooth-Star Door Panel Dimensions
Size A B 2/8 31-13/16” 4-11/32”
2/10 33-13/16” 5-11/32”
3/0 35-13/16” 6-11/32”
A
B 23 1/8"
4 9/16"
7"
3 9/16"
Daylight Opening: 20-29/32" x 34-29/32"
(729 sq.in.)
37 29/32"
Note: For Optional Grille Locations, See Arch 1.
Size A B C
2/8 31-13/16" 4-11/32" 3-31/32"
2/10 33-13/16" 5-11/32" 4-31/32"
3/0 35-13/16" 6-11/32" 5-31/32"
23 29/32"C
79-3/64"
13"
9 11/32"
Comp 5 2014 (U1 REVISED) 5.7
6/8 Smooth-Star Doors
A
4-5/32
23-7/8
B
”
”
3/4 Lite 1 Panel (2247) (Impact - 2247H) (Slab - SS030U1, SS200U1) (Impact - SS030HU1, SS200HU1)
C
23-1/8
”
Twin Half Lite 2 Panel (Glass - 0836, 210, 910) (Sla b - SS400U1)
48-7/8
13”
9-3/8”
”
79-3/64”
Daylight Opening: 21-1/8" x 46-1/8"
(974 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
Size A B C
2/8 31-13/16” 3-31/32” 4-11/32”
2/10 33-13/16” 4-31/32” 5-11/32”
3/0 35-13/16” 5-31/32” 6-11/32”
A
9 1/2"
B
4 1/2"
4 5/32"
Daylight Opening: 6-29/32" x 34-29/32" (per lite)
(Total 482 sq.in.)
Size A B C
2/8 31-13/16" 4-1/4" 4-11/32"
2/10 33-13/16" 5-1/4" 5-11/32"
3/0 35-13/16" 6-1/4" 6-11/32"
C
9 1/8"
23 1/8"
37 29/32"
79-3/64"
21 13/16"
9 11/32"
5.8 2014 (U1 REVISED) Comp 5
6/8 Smooth-Star Doors
A
C B
D
4-17/32”
7-3/16”
4-15/16”
25”
79-3/64”
Size A C
2/6N 29-13/16” 4-13/32” 8-13/16” 3-13/32”
*2/6 29-13/16” 3-11/32” 9-1/8” 4-7/8”
21-13/16”
2/8 31-13/16” 4-11/32” 9-1/8” 4-7/8”
2/10 33-13/16” 5-11/32” 9-1/8” 4-7/8”
3/0 35-13/16” 6-11/32” 9-1/8” 4-7/8”
E
9-3/8”
6 Panel (Slab-SS060U1, SS060NU1) (Impact-SS060HU1, SS060NHU1)
*Impact slab not available.
BDE
3-13/32”
21-1/32”
23-1/8” 23-1/8” 23-1/8” 23-1/8”
Smooth-Star Door Panel Dimensions
4 Lite Scallop 4 Panel (335, 2206) (Slab-SS060U1)
Daylight Opening: 5-1/8" x 21-1/8"
(98 sq.in.)
Size A B C
2/8 31-13/16” 3-31/32” 4-11/32”
2/10 33-13/16” 4-31/32” 5-11/32”
3/0 35-13/16” 5-31/32” 6-11/32”
B
C
9-1/8”
A 23-7/8” 23-1/8”
4-7/8”
3-1/32”
9-3/32”
4-17/32”
25”
79-3/64”
21-13/16”
9-3/8”
Comp 5 2014 (U1 REVISED) 5.9
6/8 Smooth-Star Doors
B 23-27/32”
C
9-1/8”
A
23-1/8”
4-7/8”
4-1/8”
7-7/8”
4-21/32”
25”
21-13/16”
9-3/8”
79-3/64”
4 Lite 4 Panel (444) (Slab-SS060U1)
Daylight Opening: 21-1/8" x 5"
(93 sq.in.)
Size A B C
2/8 31-13/16” 4-1/16” 4-11/32”
2/10 33-13/16” 5-1/16” 5-11/32”
3/0 35-13/16” 6-1/16” 6-11/32”
2 Lite 4 Panel (Glass - 296, 996, 0806) (Slab - SS060U1)
Daylight Opening: 6-15/16" x 4-15/16" (per lite)
Size
2/6N 29-13/16” 3-7/8” 4-13/32” 2-11/32”
2/6 29-13/16” 2-31/32” 3-11/32” 4-1/8” 2/8 31-13/16” 3-31/32” 4-11/32” 4-1/8”
2/10 33-13/16” 4-31/32” 5-11/32” 4-1/8”
3/0 35-13/16” 5-31/32” 6-11/32” 4-1/8”
Size A B C D E F
*2/6N 29-13/16" 3-27/32" 4-13/32" 2-9/32" 8-13/16" 19-29/32"
2/6 29-13/16" 2-15/16" 3-5/16" 4-1/8" 9-1/8" 23-5/32" 2/8 31-13/16" 3-15/16" 4-5/16" 4-1/8" 9-1/8" 23-5/32"
2/10 33-13/16" 4-15/16 " 5-5/16" 4-1/8" 9-1/8" 23-5/32"
3/0 35-13/16" 5-15/16" 6-5/16" 4-1/8" 9-1/8" 23-5/32"
2 Lite 4 Panel (296, 996, 0806) (Slab-SS060U1)
(Total 68 sq.in.)
AB
*Impac t s lab not available.
CDEF
8-13/16”
9-1/8” 9-1/8” 9-1/8” 9-1/8”
9 15/16"
B
3-3/8”
4-7/8” 4-7/8”
4-7/8”
4-7/8”
9-7/8”
B
C
C E
A
A
D
D
23-1/8”
E
F
F
4-3/16”
4 5/32"
7-7/8”
7 15/16"
4 19/32"
4-19/32”
25”
25"
6-3/16”
21-13/16”
21 13/16"
9 3/8"
9-25/64”
79-3/64”
79-3/64"
5.10 2014 (U1 REVISED) Comp 5
6/8 Smooth-Star Doors
A
23-1/8
B
”
4-9/16”
2 Panel 3/4 Top (Slab-SS200U1) (Impact-SS200HU1)
48-1/8
”
13
9-3/8”
”
79-3/64”
Size
2/8 31-13/16” 4-11/32”
2/10 33-13/16” 5-11/32”
3/0 35-13/16” 6-11/32”
AB
Smooth-Star Door Panel Dimensions
2 Panel Craftsman (Slab - SS203U1) (Impact - SS203HU1)
Size A B
2/8 31-13/16” 4-3/4”
2/10 33-13/16” 5-3/4”
3/0 35-13/16” 6-3/4”
B
8-29/32”
A
22-11/32”
4-17/32”
4-17/32”
16-3/32”
79-3/64”
43-23/32”
9-23/64”
Comp 5 2014 (U1 REVISED) 5.11
6/8 Smooth-Star Doors
C B
13-27/32”
8-29/32”
A
23-3/32”
22-11/32”
20-3/32”
4-17/32”
3-25/32”
16-27/32”
43-23/32”
9-23/64”
79-3/64”
Craftsman Lite 2 Panel - 1 Lite (2115) (Slab - SS203U1)
Daylight Opening: 13-27/32" x 20-3/32"
(278 sq.in.)
Size A
2/8 31-13/16” 4-3/4”
2/10 33-13/16” 5-3/4”
3/0 35-13/16” 6-3/4”
BC
4-23/64” 5-23/64” 6-23/64”
25-3/8”
4 Block Dentil Shelf (Shelf-DSW4BLK)
1-5/16”
1-5/16” 2-5/8”
2-5/8”
5.12 2014 (U1 REVISED) Comp 5
6/8 Smooth-Star Doors
A
B 23 29/32"
C 23 1/8"
4 5/32"
37 29/32"
21 13/16"
9 3/8"
79-3/64"
Half Lit e 1 P anel Plan k (Glass - 104, 137, 6 12, 904, 2236) (Impact Glass - 104 H, 612H, 904H) (Slab - SS205U1) (Impact Slab - SS205HU1)
Daylight Opening: 20-29/32" x 34-29/32"
(729 sq .in.)
Note: For Optional Grille Locations, See Arch 1.
Size A B C
2/8 31 -13 /16" 3-31/3 2" 4-11/32"
2/10 33-13/16" 4-31/32" 5-11/32"
3/0 35 -13 /16" 5-31/3 2" 6-11/32"
Smooth-Star Door Panel Dimensions
2 Panel Plank Soft Arch (Slab - SS205U1) (Impact - SS205HU1)
Size
2/8 31-13/16” 4-11/32”
2/10 33-13/16” 5-11/32”
3/0 35-13/16” 6-11/32”
AB
A
B
23-1/8”
4-19/32”
37-5/32”
79-3/64”
21-13/16”
9-3/8”
Comp 5 2014 (U1 REVISED) 5.13
6/8 Smooth-Star Doors
A
B
23-1/8”
4-19/32”
37-5/32”
21-13/16”
2 Panel Square Top (Slab - SS220U1) (Impact - SS220HU1)
79-3/64”
Size A B
2/8 31-13/16” 4-11/32”
2/10 33-13/16” 5-11/32”
3/0 35-13/16” 6-11/32”
9-11/32”
Half Lite 1 Panel (Glass - 104, 137, 612, 904, 2236) (Impact Glass - 104H, 612H, 904H) (Sla b - SS220U1) (Impact Slab - SS220H U1)
Daylight Openi ng: 20-29/32" x 34-29/32"
(729 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
A
B 23 29/32"
4 5/32"
37 29/32"
79-3/64"
21 13/16"
Size A B C
2/8 31-13/16" 3 -31/32" 4-11/32"
2/10 33-13/16" 4-31/32" 5-11/32"
3/0 35-13/16" 5 -31/32" 6-11/32"
C 23 1/8"
9 11/32"
5.14 2014 (U1 REVISED) Comp 5
6/8 Smooth-Star Doors
B
15”
39-1/2”
7-1/2”
5-9/16”
A
24-1/8”
11-1/16”
4-23/32”
43”
79-3/64”
66”
2”
8 Panel (Slab - SS300U1) (Impact - SS300HU1)
Smooth-Star Door Panel Dimensions
Size A B
12-13/16”
2/8 31-13/16” 3-27/32”
2/10 33-13/16” 4-27/32”
3/0 35-13/16” 5-27/32”
8-11/32”
9”
Center Arch 7 Panel (0842) (Slab-SS300U1)
Daylight Opening: 6-15/16" x 40-15/16"
(292 sq.in.)
Size
2/8 31-13/16” 3-27/32”
2/10 33-13/16” 4-27/32”
3/0 35-13/16” 5-27/32”
AB
15”
39-1/2”
9-7/8”
7-1/2”
5-9/16”
A
B
24-1/8”
11-1/16”
9”
4-23/32”
43-7/8”
79-3/64”
66”
1-3/4”
12-13/16”
8-11/32”
Comp 5 2014 (U1 REVISED) 5.15
6/8 Smooth-Star Doors
A
4-17/32
41-25/32”
17-23/32
”
B
23-1/8
”
”
48-1/8
79-3/64”
3/4 Captured Oval 2 Panel (1640) (Slab - SO751U1)
Daylight Opening: 14-23/32" x 38-25/32"
(442 sq.in.)
”
9-9/16
”
4”
3/4 Lite 2 Panel (2247) (Impact - 2247HU1) (Slab - SO751U1)
Daylight Opening: 21-1/8" x 46-1/8"
(974 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
Size A B C
2/8 31-13/16” 3-31/32” 4-11/32”
2/10 33-13/16” 4-31/32” 5-11/32”
3/0 35-13/16” 5-31/32” 6-11/32”
13”
9-25/64
Size A B
2/8 31-13/16” 4-11/32”
2/10 33-13/16” 5-11/32”
”
B
3/0 35-13/16” 6-11/32”
A
”
23-7/8
23-1/8”
4-5/32”
48-7/8
”
79-3/64”
”
13
9-25/64
C
9-9/16”
4”
”
5.16 2014 (U1 REVISED) Comp 5
6/8 Smooth-Star Doors
A
B
24-1/8”
4-13/32”
9-19/32”
38-3/32”
79-3/64”
4-3/32”
3 Panel Scroll (Slab-SS755U1) (Impact-SS755HU1)
Smooth-Star Door Panel Dimensions
10-1/16”
4”
3/4 Deluxe Oval 2 Panel (1640) (Slab-SS755U1)
Daylight Opening: 14-23/32" x 38-25/32"
(442 sq.in.)
17-15/16”
9-21/64”
41-25/32”
B
17-23/32”
Size A B
2/8 31-13/16” 3-27/32”
2/10
33-13/16” 4-27/32”
3/0 35-13/16” 5-27/32”
A 24-1/8”
4-13/32”
38-3/32”
9-19/32”
79-3/64”
4-3/32”
Size A B
2/8 31-13/16” 3-27/32”
17-15/16”
2/10 33-13/16” 4-27/32”
3/0 35-13/16” 5-27/32”
9-21/64”
10-1/16”
4”
Comp 5 2014 (U1 REVISED) 5.17
6/8 Smooth-Star Doors
A
B
C
4-5/32”
Full Lite w/ Stile Lines (108N, 118N, 128N, 198N, 916N, 2064) (Impact - 108NH, 118NH, 128NH, 916NH) (Slab - SO2064U1, SS060NU1) (Impact - SS060NHU1)
Daylight Opening: 18-29/32" x 62-29/32"
(1189 sq.in. )
E
Note:
65-7/8”
*Impact slab not available.
Size A B C
2/6 29-13/16” 3-31/32” 21-7/8”
2/8N 31-13/16” 4-31/32” 21-7/8”
Height D E
*6/6 6-11/16” 76-23/32”
FG
D
6/8 9-1/64” 79-3/64”
For Optional Grille Locations, See Arch 1.
F
21”
23-1/8”
G
4-13/32” 4-11/32”
Full Lite w/ Stile Lines (108, 118, 128, 198, 916, 2264) (Impact - 108H, 118H, 128H, 198H, 916H) (Slab - SO2264U1, SS060U1, SS400U1, SS020U1) (Impact - SS060HU1, SS400HU1)
Daylight Opening: 20-15/16" x 62-15/16"
(1317 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
*Impact slab not available.
Size A B C
2/8 31-13/16” 3-31/32” 23-7/8”
2/10 33-13/16” 4-31/32” 23-7/8”
3/0 35-13/16” 5-31/32” 23-7/8”
Height D E
*6/6 6-11/16” 76-23/32”
6/8 9-1/64” 79-3/64”
F 4-11/32” 5-11/32” 6-11/32”
A
B
C
23-1/8”F
4-5/32”
E
65-7/8”
D
5.18 2014 (U1 REVISED) Comp 5
A
24"B
2-15/32"
11-29/32"
6/8 Smooth-Star Doors
Fan Lite 4 P an el - Cutout (Glass - 2210R) (Slab - SS020U1)
2-5/16"
25"
79-3/64"
21-13/16"
9-11/32"
C
9-1/8"
23-1/8"
Fan Lite 4 Panel - Molded Open (Glass - 2210R) (Slab - SO020U1)
Daylight Opening: 8-29/32" x 21"
(140 sq.in.)
Size A B C
2/8 31-13/16" 3-29/32" 4-11/32"
2/10 33-13/16" 4-29/32" 5-11/32"
3/0 35-13/16" 5-29/32" 6-11/32"
A
B
24"
4 1/8"
Smooth-Star Door Panel Dimensions
11 29/32"
4 11/32"
Daylight Opening: 8-29/32" x 21"
(140 sq.i n.)
Size A B C
2/8 31-13/16" 3-29/32" 4-11/32"
2/10 33-13/16" 4-29/32" 5-11/32"
3/0 35-13/16" 5-29/32" 6-11/32"
C 9 1/2"
23 1/8"
21 5/16"
79-3/64"
21 13/16"
9 3/8"
Comp 5 2014 (U1 REVISED) 5.19
6/8 Smooth-Star Doors
A
B
8 29/32"
20 29/32"
23 29/32"
11 29/32"
3 9/32"
1 1/2"
Camber Top Lite 4 Panel (Glass - 2210A) (Slab - SS060U1, SS020U1)
Daylight Opening: 20-29/32" x 8-29/32"
(170 sq.in.)
C
9 1/8"
23 1/8"
Center Lite 2-Panel 3/4 Top (Glass - 0836) (Slab - SS200U1)
25"
79 3/64"
21 13/16"
9 3/8"
Note: For Optional Grille Locations, See Arch 1.
Size A B C
2/8 31-13/16" 3-31/32" 4-11/32'
2/10 33-13/16" 4-31/32" 5-11/32"
3/0 35-13/16" 5-31/32" 6-11/32"
A
23 1/8"
9 29/32" 6 29/32" B
4 17/32"
37 29/32"
48 1/8"
79 3/64"
Size A B
2/8 31 13/16 4 11/32 "
2/10 33 13/16" 5 11/32 "
3/0 35 13/16" 6 11/32 "
Total Daylight Opening: 241 sq. in.
34 29/32"
13"
8 1/4"
5.20 2014 (U1 REVISED) Comp 5
6/8 Smooth-Star Doors
A
B
23-1/8”
4-9/16”
4 Panel Square Top (Slab-SS400U1) (Impact-SS400HU1)
37-1/8”
79-3/64”
21-13/16”
9-23/64”
Size A B
2/8 31-13/16” 4-11/32”
2/10 33-13/16” 5-11/32”
3/0 35-13/16” 6-11/32”
Smooth-Star Door Panel Dimensions
9-1/8”
4-7/8”
This space intentionally left blank.
Comp 5 2014 (U1 REVISED) 5.21
6/8 Smooth-S tar Flush-Glazed Doors
A
Full Lite Flush-Glazed
B
4-17/32”
(Slab - SN_3025U1, SN_2125U1, SN_2820U1, SN_2620U1)
Daylight Opening: 20-1/32" x 63-1/8"
(2064) (1264 sq.in.)
Daylight Opening: 24-5/32" x 63-1/8"
63-1/8”
Note:
C
64-3/8”
D
For Optional Grille Locations, See Arch 1.
Size A B C
2/6 29-13/16” 4-9/32” 20-1/32” 2/8 31-13/16” 5-9/32” 20-1/32”
2/10 33-13/16” 4-7/32” 24-5/32”
3/0 35-13/16” 5-7/32” 24-5/32”
F
E
(2564) (1524 sq.in.)
F 21-1/4” 21-1/4” 25-3/8” 25-3/8”
Height D E
6/6 76-23/32” 7-13/16” 6/8 79-3/64” 10-9/64”
Full Lite Flush-Glazed (Slab - SN_2014)
Daylight Opening: 14-1/4" x 63-1/8"
(899 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
Height A B
6/6 76-23/32” 7-5/8” 6/8 79-3/64” 9-61/64”
14-1/4”
23-13/16”
63-1/8”
15-1/2”4-5/32”
4-23/32”
A
B
5.22 2014 (U1 REVISED) Comp 5
6/8 Smooth-S tar Flush-Glazed Doors
B
9-1/8””
22-3/8”
35-1/8”
21-1/8”
A
Half Lite 2 Panel Flush-Glazed
4-15/32”
(Slab - SNF3022U1, SNF2822U1, SNF2622U1)
Daylight Opening: 21-3/32" x 35-1/8"
4-1/8”
36-3/8”
7”
21-13/16”
9-25/64”
(741 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
79-3/64”
Size A B
2/6 29-13/16” 3-23/32” 2/8 31-13/16” 4-23/32” 3/0 35-13/16” 6-23/32”
Smooth-Star Door Panel Dimensions
3/4 Lite 1 Panel Flush-Glazed (Slab - SNF3048U1, SNF2148U1, SNF2848U1, SNF2648U1)
Daylight Opening: 20-3/32" x 46-7/8"
(2148) (943 sq.in.)
Daylight Opening: 24-3/32" x 46-7/8"
(2548) (1130 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
Size A B C D
2/6 29-13/16” 21-11/32” 20-1/8” 4-7/32” 2/8 31-13/16” 21-11/32” 20-1/8” 5-7/32”
2/10 33-13/16” 5-11/32” 24-1/8” 4-7/32”
3/0 35-13/16” 25-11/32” 24-1/8” 5-7/32”
A
D
B
46-7/8”
4-3/8
48-1/8
”
”
C
79-3/64”
4”
13
”
9-35/64”
Comp 5 2014 (U1 REVISED) 5.23
6/8 Smooth-S tar Raised Panel Doors
B
A
23-7/8
”
4-1/8
”
Raised 5 Panel Flush (DP1024SS) (Slab-SS010U1)
”
9-7/8
”
4
79-3/64”
Size A B
2/8 31-13/16” 3-31/32”
2/10 33-13/16” 4-31/32”
3/0 35-13/16” 5-31/32”
9-35/64”
Raised 8 Panel Flush (DP1010SS) (Slab - SS010U1)
Size A B C
2/6 29-13/16” 3-7/8” 2-5/16” 2/8 31-13/16” 3-31/32” 4-1/8”
2/10 33-13/16” 4-31/32” 4-1/8”
3/0 35-13/16” 5-31/32” 4-1/8”
9-7/8
A
”
B
C
4-1/8
10-1/2
7-25/32
79-3/64”
9-35/64”
”
”
”
5.24 2014 (U1 REVISED) Comp 5
6/8 Smooth-S tar Raised Panel Doors
9-7/8
A
”
B
C
4-1/8”
10-1/2
3-7/32
79-3/64”
”
”
Size A B C
2/6 29-13/16” 3-7/8” 2-5/16” 2/8 31-13/16” 3-31/32” 4-1/8”
2/10 33-13/16” 4-31/32” 4-1/8”
3/0 35-13/16” 5-31/32” 4-1/8”
Raised 10 Panel Flush (DP1010SS) (Slab - SS010U1)
Smooth-Star Door Panel Dimensions
9-35/64”
This space intentionally left blank.
Comp 5 2014 (U1 REVISED) 5.25
8/0 Smooth-S tar Doors
A
B
C
5-7/16
5
”
39-1/2
23-3/4”
”
7-3/16”
95-3/64”
”
*Impact slab not available.
Size A B C
*2/6 29-13/16” 3-13/32” 8-13/16” 3-3/8”
2/8 31-13/16” 4-11/32” 9-1/8” 4-7/8”
2/10 33-13/16” 5-11/32” 9-1/8” 4-7/8”
3/0 35-13/16” 6-11/32” 9-1/8” 4-7/8”
D
8’ 6 Panel (Slab - S8060U1) (Impact - S8060HU1)
D
21” 23-1/8” 23-1/8” 23-1/8”
E
A
B
E
23-1/8”
8-13/32”
8’ 2 Panel Soft Arch (Slab - S8002U1) (Impact - S8002HU1)
Size A B
2/8 31-13/16” 4-11/32”
2/10 33-13/16” 5-11/32”
3/0 35-13/16” 6-11/32”
8-3/16”
48-3/4”
23-3/4”
8-9/64”
95-3/64”
5.26 2014 (U1 REVISED) Comp 5
8/0 Smooth-S tar Doors
A
B
C
E
8’ Full Lite w/ Stile Lines (808, 818, 828, 2280, 808N, 818N, 828N, 2080) (Impact - 808H, 808NH, 828H, 818H,
Daylight Opening: 18-15/16" x 78-15/16"
(2080 for 1" glass) (1495 sq.in.)
Daylight Opening: 19-1/8" x 79-1/8"
(2080 for 1/2" glass) (1513 sq.in.)
Daylight Opening: 20-15/16" x 78-15/16"
(2280 for 1" glass) (1653 sq.in.)
Daylight Opening: 21-1/8" x 79-1/8"
(2280 for 1/2" glass) (1672 sq.in.)
E
22-1/8” 82-1/8”
5-1/8” 5-1/4” 5-1/8” 5-1/4” 5-1/8” 5-1/4”
21”
21” 23-1/8” 23-1/8” 23-1/8” 23-1/8” 23-1/8” 23-1/8”
A
9 15/16"
D
4-13/32” 4-13/32” 4-11/32” 4-11/32” 5-11/32” 5-11/32” 6-11/32“ 6-11/32”
Smooth-Star Door Panel Dimensions
H 7-51/64” 7-55/64”
7-51/64” 7-55/64” 7-51/64” 7-55/64”
7-51/64”
7-55/64”
D
95-3/64”
818NH, 828NH) (Slab - S8060U1) (Impact - S8060HU1)
Note: For Optional Grille Locations, See Arch 1.
*Impact slab not available.
Size A C
*2/6 3-27/32” 22-1/8” 82-1/8”
*2/6 Impact
2/8
2/8 Impact 4-31/32” 21-7/8” 81-7/8”
2/10 5-1/32” 24-1/8” 82-1/8”
2/10 Impact 4-31/32” 23-7/8” 81-7/8”
3/0 6-1/32” 24-1/8” 82-1/8” 5-1/8”
3/0 Impact 5-31/32” 23-7/8” 81-7/8” 5-1/4”
29-13/16” 29-13/16” 31-13/16” 31-13/16” 33-13/16” 33-13/16” 35-13/16” 35-13/16”
B
BDFG
3-31/32” 21-7/8” 81-7/8”
4-27/32”
FG
H
8' 2 Lite 4 Panel (Glass - 296, 0806) (Slab - S8060U1)
Daylight Opening: 6-15/16" x 4-15/16" (per lite)
(Total 68 sq.in.)
Size A B C D E F
2/6 29-13/16" 3-27/32" 8-13/16" 2-9/32" 21" 4-13/32" 2/8 31-13/16" 3-15/16" 9-1/8" 4-1/16" 23-1/8" 4-11/32"
2/10 33-13/16" 4-15/16" 9-1/8" 4-1/16" 23-1/8" 5-11/32"
3/0 35-13/16" 5-15/16" 9-1/8" 4-1/16" 23-1/8" 6-11/32"
F
5 3/32"
7 15/16"
4 9/16"
39 1/2"
95-3/64"
23 3/4"
8 3/16"
C
E
Comp 5 2014 (U1 REVISED) 5.27
8/0 Smooth-S tar Doors
A
B
23-1/8”
5-7/16”
8’ 3 Panel (Slab - S8030U1) (Impact - S8030HU1)
10”
5-3/32”
48-1/8”
95-3/64”
13”
B
8-15/64”
Size A B
2/8 31-13/16” 4-11/32”
2/10 33-13/16” 5-11/32”
3/0 35-13/16” 6-11/32”
A
23-1/8”
5-7/16”
8’ Half Lite 1 Panel Top & Bottom (2247) (Impact - 2247H) (Slab - S8030U1) (Impact - S8030HU1)
Daylight Opening: 21-1/8" x 46-1/8"
(974 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
Size A B C
2/8 31-13/16” 4-11/32” 3-31/32”
2/10
3/0 35-13/16” 6-11/32” 4-31/32”
33-13/16” 5-11/32” 4-31/32”
23-7/8”
10”
C
4-23/32
48-7/8”
13
8-15/64”
”
95-3/64”
”
5.28 2014 (U1 REVISED) Comp 5
8/0 Smooth-S tar Doors
A
B
23-7/8”
5-1/4”
8’ 3/4 Lite 1 Panel (128, 108, 118, 916, 198, 2264) (Impact - 128H, 108H, 118H, 916H, 198H)
(Slab-S8030U1)
(Impact-S8030HU1)
C
Smooth-Star Door Panel Dimensions
65-7/8”
2-11/16”
13”
95-3/64”
Daylight Opening: 20-15/16" x 62-15/16"
(1317 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
Size A B C
2/8 31-13/16” 3-31/32”
2/10 33-13/16” 4-31/32”
3/0 35-13/16” 5-31/32”
4-11/32” 5-11/32” 6-11/32”
A
23-1/8”
8’ Flush Panel (Slab - S8010U1) (Impact - S8010HU1)
*Impact slab not available.
Size A
*2/0 23-13/16” *2/6 29-13/16”
2/8 31-13/16”
2/10 33-13/16”
3/0 35-13/16”
8-15/64”
95-3/64”
Comp 5 2014 (U1 REVISED) 5.29
8/0 Smooth-S tar Doors
B
8 29/32"
20 29/32"
A
23 29/32" 2 13/32"
11 29/32"
3 5/16"
39 1/2"
95 3/64"
23 3/4"
8 3/16"
8' Camber Top Lite 4 Panel (Glass - 2210A) (Slab - S8060U1)
Daylight Opening: 20-29/32" x 8-29/32"
(170 sq.i n.)
Size A B C
2/8 31-13/16" 3-31/32" 4-11/32"
2/10 33-13/16" 4-31/32" 5-11/32"
3/0 35-13/16" 5-31/32" 6-11/32"
C 9 1/8"
23 1/8"
8' Center Lite 3 Panel (Glass - 0836) (Slab - S8030U1)
Size A B
2/8 31 13/16" 4 11/32 "
2/10 33 13/16" 5 11/32 "
3/0 35 13/16" 6 11/32 "
Total Daylight Opening: 241 sq. in.
9 29/32"
6 29/32"
A
23 1/8"
B
5 7/16"
10"
5 3/32"
37 29/32"
34 29/32"
13"
48 1/8"
95 3/64"
8 1/4"
5.30 2014 (U1 REVISED) Comp 5
8/0 Smooth-S tar Doors
A
B
23-1/8”
5-15/32”
51-11/16”
95-3/64”
Size A B
2/8 31-13/16" 4-11/32”
2/10 33-13/16" 5-11/32"
3/0 35-13/16" 6-11/32"
6”
8’ 2 Panel Square Top (Slab - S8220U1) (Impact - S8220HU1)
Smooth-Star Door Panel Dimensions
23-3/4”
8-9/64”
8’ 2 Panel Plank Soft Arch (Slab - S8205U1) (Impact - S8205HU1)
Size A B
2/8 31-13/16" 4-11/32”
2/10 33-13/16" 5-11/32"
3/0 35-13/16" 6-11/32"
A
B
23-1/8”
5-15/32”
8-13/32”
48-3/4”
6”
23-3/4”
95-3/64”
8-9/64”
Comp 5 2014 (U1 REVISED) 5.31
8/0 Smooth-S tar Doors
A
B
22-11/32”
5-7/16”
8’ 2 Panel Craftsman (Slab - SS8203U1, SH8203U1) (Impact - SS8203HU1)
16-3/32”
5-11/32”
95-3/64”
Size A B
60”
C B
2/8 31-13/16” 4-3/4”
2/10 33-13/16” 5-3/4”
3/0 35-13/16” 6-3/4”
A
23-3/32”
22-11/32”
4-11/16”
8-29/32”
4-17/32”
8’ Craftsman Lite 2 Panel - 1 Lite (2115) (Slab - SS8203U1)
Daylight Opening: 13-27/32" x 20-3/32"
(278 sq.in.)
Size A
2/8 31-13/16” 4-3/4”
2/10 33-13/16” 5-3/4”
3/0 35-13/16” 6-3/4”
BC
8 11/64”
4-23/64” 5-23/64” 6-23/64”
13-27/32”
8-29/32”
20-3/32”
4-17/32”
16-27/32”
5-11/32”
95-3/64”
60”
8-11/64”
5.32 2014 (U1 REVISED) Comp 5
8/0 Smooth-S tar Doors
4 Block Dentil Shelf (Shelf-DSW4BLK)
25-3/8”
1-5/16”
1-5/16” 2-5/8”
2-5/8”
Smooth-Star Door Panel Dimensions
This space intentionally left blank.
Comp 5 2014 (U1 REVISED) 5.33
8/0 Smooth-Star Flush-Glazed Doors
23-13/16”
5-9/16”
14-1/4”
8’ Full Lite Flush-Glazed (Slab - SN82014U1)
Daylight Opening: 14-1/4" x 78-13/16"
(1123 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
95-3/64”
78-13/16”
15-1/2”4-5/32”
80-1/16”
9-27/64”
8’ Full Lite Flush-Glazed (Slab - SN83025U1, SN82125U1, SN82821U1, SN82621U1)
Daylight Opening: 19-13/16" x 78-13/16"
(2180) (1561 sq.in.)
A
B
C
78-13/16”
6-5/32”
95-3/64”
Daylight Opening: 23-13/16" x 78-13/16"
(2580) (1877 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
Size A C
2/6 29-13/16” 5” 19-13/16” 2/8 31-13/16” 6” 19-13/16”
2/10 33-13/16” 5” 23-13/16”
3/0 35-13/16” 6” 23-13/16”
B
D
21-1/16” 21-1/16” 25-1/16” 25-1/16”
E
4-3/8” 5-3/8” 4-3/8” 5-3/8”
DE
10-5/64”
5.34 2014 (U1 REVISED) Comp 5
6/8 Smooth-Star
Noise Reduction Doors
A
B
C
E
Full Lite Flush (2064, 2264) (Slab - S010STCU1, SP010STCU1)
(Slab - S7010STCU1)
Smooth-Star Door Panel Dimensions
G
D
F
Daylight Opening: 18-29/32" x 62-29/32"
(2064) (1252 sq.in.)
Daylight Opening: 20-15/16" x 62-15/16"
(2264) (1317 sq.in.)
Note: For Optional Grille Locations, See Arch 1.
Size A B C D E 6/8 F 6/6 F 7/0 F
2/6 29-13/16” 3-31/32” 21-7/8” 65-7/8” 4-5/32” 9-1/64” 6-21/32” 13-1/16”
2/6 EC 29-13/16” 3-31/32” 21-7/8” 65-7/8” 3-1/32” 10-9/64” N/A N/A
2/8 31-13/16” 4-31/32” 21-7/8” 65-7/8” 4-5/32” 9-1/64” 6-21/32” 13-1/16”
2/8 EC 31-13/16” 4-31/32” 21-7/8” 65-7/8” 3-1/32” 10-9/64” N/A N/A
2/10 33-13/16” 4-31/32” 23-7/8” 65-7/8” 4-5/32” 9-1/64” 6-21/32” 13-1/16”
2/10 EC 33-13/16” 4-31/32” 23-7/8” 65-7/8” 3-1/32” 10-9/64” N/A N/A
3/0 35-13/16” 5-31/32” 23-7/8” 65-7/8” 4-5/32” 9-1/64” 6-21/32” 13-1/16”
3/0 EC 35-13/16” 5-31/32” 23-7/8” 65-7/8” 3-1/32” 10-9/64” N/A N/A
EC - ELEVATED CUTOUT 6/8 HEIGHT ONLY
Height G
6/6 76-23/32” 6/8 79-3/64” 7/0 83-3/64”
Comp 5 2014 (U1 REVISED) 5.35
8/0 Smooth-Star Noise Reduction Doors
A
B
C
E
Full Lite Flush (2080, 2280) (Slab-S8010STCU1)
(Slab-S76010STCU1)
Daylight Opening: 18-15/16" x 78-15/16"
(2080 for 1" glass) (1495 sq.in.)
D
G
Daylight Opening: 19-1/8" x 79-1/8"
(2080 for 1/2" glass) (1513 sq.in.)
Daylight Opening: 20-15/16" x 78-15/16"
(2280 for 1" glass) (1653 sq.in.)
Daylight Opening: 21-1/8" x 79-1/8"
(2280 for 1/2" glass) (1672 sq.in.)
Note: For Optional Grille Locations,
F
Size A B C D E 8/0 F 7/6 F
2/6 29-13/16” 3-27/32” 22-1/8” 82-1/8” 5-1/16” 7-55/64” N/A
2/6 EC 29-13/16” 3-27/32” 22-1/8” 82-1/8” 2-15/16” 9-63/64” 3-63/64”
2/8 31-13/16” 4-27/32” 22-1/8” 82-1/8” 5-1/16” 7-55/64” N/A
2/8 EC 31-13/16” 4-27/32” 22-1/8” 82-1/8” 2-15/16” 9-63/64” 3-63/64”
2/10 33-13/16” 4-27/32” 24-1/8” 82-1/8” 5-1/16” 7-55/64” N/A
2/10 EC 33-13/16” 4-27/32” 24-1/8” 82-1/8” 2-15/16” 9-63/64” 3-63/64”
3/0 35-13/16” 5-27/32” 24-1/8” 82-1/8” 5-1/16” 7-55/64” N/A
3/0 EC 35-13/16” 5-27/32” 24-1/8” 82-1/8” 2-15/16” 9-63/64” 3-63/64”
EC - ELEVATED CUTOUT
Height G
7/6 89-3/64” 8/0 95-3/64”
See Arch 1.
5.36 2014 (U1 REVISED) Comp 5
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
