COMP 15 Transoms
Elliptical Transoms ......................................................................................................................................15.3
Elliptical Transoms Interior Casings .........................................................................................................15.4
Rectangular Transoms ................................................................................................................................15.5
Half Round Transoms .................................................................................................................................15.6
Transom Glass .............................................................................................................................................15.7
Comp 15 2014 (U1 REVISED) 15.1
Transoms
Transoms
15.2 2014 (U1 REVISED) Comp 15
Width
Elliptical Transoms
Mulled System
Size
3/0-(2) 12” SL
3/0-(2) 14” SL
Continuous Sill
System Size
3/0-(2) 12” SL
3/0-(2) 14” SL
Width
64-21/32”
68-21/32”
Width
63-21/32”
67-21/32”
For 4-9/16”
Jambs
For 6-9/16”
Jambs
13-5/8”
Transoms
Transom
Extender
Comp 15 2014 (U1 REVISED) 15.3
Elliptical Transoms Interior Casings
Height
13-3/32”
Length
11/16”
2-1/2”
Description
3/0 Continuous Sill w/12” SL
3/0 Continuous Sill w/14” SL
3/0 w/Boxed 12” SL
3/0 w/Boxed 12” SL
11/16”
2-1/4”
Description
3/0 Continuous Sill w/12” SL
3/0 Continuous Sill w/14” SL
3/0 w/Boxed 12” SL
3/0 w/Boxed 12” SL
Height: 16-19/32”
11/32”
3/8”
WM444
OAK/PINE
WM351
OAK/PINE
Height: 15-19/32”
Length
67-19/32”
71-19/32”
68-19/32”
72-19/32”
WM366
OAK/PINE
Height: 15-11/32”
Length
67-3/32”
71-3/32”
68-3/32”
72-3/32”
11/16”
2-1/4”
Description
3/0 Continuous Sill w/12” SL
3/0 Continuous Sill w/14” SL
3/0 w/Boxed 12” SL
3/0 w/Boxed 12” SL
11/16”
2-1/4”
Description
3/0 Continuous Sill w/12” SL
3/0 Continuous Sill w/14” SL
3/0 w/Boxed 12” SL
3/0 w/Boxed 12” SL
OAK/PINE
Height: 16-11/32”
3/8”
WM445
WM356
3/8”
OAK/PINE
Height: 15-11/32”
Length
67-3/32”
71-3/32”
68-3/32”
72-3/32”
WM376
OAK/PINE
Height: 15-11/32”
Length
67-3/32”
71-3/32”
68-3/32”
72-3/32”
Transoms
11/16”
3-1/2”
Description
3/0 Continuous Sill w/12” SL
3/0 Continuous Sill w/14 SL”
3/0 w/Boxed 12” SL
3/0 w/Boxed 12” SL
3/8”
Length
69-19/32”
73-19/32”
70-19/32”
74-19/32”
11/16”
3-1/4”
Description
3/0 Continuous Sill w/12” SL
3/0 Continuous Sill w/14” SL
3/0 w/Boxed 12” SL
3/0 w/Boxed 12” SL
3/8”
Length
69-3/32”
73-3/32”
70-3/32”
74-3/32”
15.4 2014 (U1 REVISED) Comp 15
Rectangular Transoms
Width
Mulled System
Size
12” Sidelite 13-1/2”
14” Sidelite 15-1/2”
3/0 Door 37-21/32”
3/0-(2) 12” SL 64-21/32”
3/0-(2) 14” SL
Continuous Sill
System Size
3/0-(2) 12” SL 63-21/32”
3/0-(2) 14” SL
Width
68-21/32”
Width
67-21/32”
Transom
Extender
13-15/32”
Transoms
For 4-9/16”
Jambs
For 6-9/16”
Jambs
Comp 15 2014 (U1 REVISED) 15.5
Half Round Transoms
Width
Height
Transoms
UNIT SIZE WIDTH HEIGHT
3/0 WITH CONTINUOUS 14" SIDELITES 67.656 34.703
3/0 WITH BOXED 14" SIDELITES 68.656 35.203
3/0 WITH CONTINUOUS 12" SIDELITES 63.656 32.703
3/0 WITH BOXED 12" SIDELITES 64.656 33.203
4-9/16”
15.6 2014 (U1 REVISED) Comp 15
Transom Glass
Elliptical Transoms
10-29/32”
Width
Mulled System Size
3/0 WITH 2 12” SL 62-1/32” 94-31/32” 3/0 WITH 2 12” SL 61-1/32” 91-7/32”
3/0 WITH 2 14” SL 66-1/32” 110-5/8” 3/0 WITH 2 14” SL 65-1/32” 106-5/8”
DIMENSIONS
Width Radius Width Radius
Continuous System Size
Radius
DIMENSIONS
Rectangular Transoms
12-3/32”
Width
Mulled System Size
12” SL
14” SL
3/0 Door
3/0 WITH 2 12” SL 62-31/32”
3/0 WITH 2 14” SL 66-31/32”
Width Width
11-13/16” 3/0 WITH 2 12” SL 61-31/32”
13-13/16” 3/0 WITH 2 14” SL 65-31/32”
35-31/32”
Continuous System Size
8-15/32”
Radius
Half Round Transoms
Radius
H
Transoms
L
DESCRIPTION
3/0 WITH 2 12” S/L CIRCLE TOP 61-5/32” 30-7/64” 30-37/64”
3/0 WITH 2 14” S/L CIRCLE TOP 65-5/32” 32-7/64” 32-37/64”
DIMENSIONS
“L” “H” Radius
Comp 15 2014 (U1 REVISED) 15.7
