Article Number: CA-1B8-00S1WN-00
EAN: 4717964397362
CORE V1
Main Features
Connections: Front-side I/O ports with
2 x 3.0 USB and HD Audio x1
Ventilation: 1 preinstalled 200mm fan
Expansion: Dual modular drive rack
design
Support: ATX PSU & DIY liquid cooling
solutions
Technical Data
Case Type : Mini Case
Chassis Measurements : 276 x 260 x 316 mm
(H*W*D) : (10.9 x 10.2 x 12.4 Inch)
Color : Black
Material : SPCC
Side Panel : Transparent window (Interchangeable)
Drive Bays : 2 x 3.5”, 2 x 2.5” (Hidden)
Expansion slots : 2
Motherboards : 6.7” x 6.7” (Mini ITX)
PSU : Standard PS2 PSU (Optional)
CPU Cooler height limitations : 140 mm
VGA-length limitations : 255 mm (Inner chassis)
285 mm (Outer chassis)
Left Side view (without panel)
Rear View
Top view (without panel)
