Co nte nts
Chapter 1. Product Introduction
Tt LC S - Liquid Cooling Support Certifi c a t i o n
Tt LC S Cer tif ied is a Th erm alt ak e exc lus ive cer tif ica tion
app lie d to on ly p rod uct s tha t pa ss th e des ign and
har dco re en thusi ast s sta nd ard s tha t a true LC S cha ssi s
sho uld b e hel d to . The T t LCS c ert if ica tio n was cre ate d
so th at we a t The rmalt ake c an de si gna te to a ll powe r
use rs wh ich c hassi s hav e bee n te ste d to be b est
com pat ibl e with ex tre me li qu id co oli ng conf igu rat ions to
ens ure y ou ge t the bes t per for ma nce f rom t he best
fea tur es an d fitme nt.
Joi n T t C o m m u nity To Receive Benefits
Dea r Val ued C us tom er,
Tha nk yo u for c hoosi ng Th erm al tak e.
As a ne w use r we va lue you r tho ugh ts a nd op ini ons and
you r fee dba ck is imp ort ant t o us . We at T her malta ke
wou ld li ke to u se this o ppo rtu ni ty to i nvi te you to j oin o ur
Com mun ity F orums . Reg ist er t oda y to st art enj oyi ng th e
ful l ben efi ts of our c omm uni ty .
Ben efi ts of b eing a me mbe r:
Qui ck an d res ponsi ve us er su pp ort
Rec eiv e hel p and adv ice w ith n ew b uil ds
Kee p up to d ate w ith new p rod uct r el eas es
Sha re yo ur th ought s and b uil ds w ith t he co mmuni ty
Ent er mo nth ly cont est s and g iv eaw ays
Bra nd of fic ial w ebs it e
htt p:/ /ww w.th erm alt ake.c om/
Glo bal F ace boo k
htt ps: //w ww.f ace boo k.com /Th erm alt ake In c
Taiwa n Fac ebo ok
htt p:/ /ww w.fa ceb ook .com/ The rma lta keT W
Glo bal c omm uni ty fo ru ms
htt p:/ /co mmu nity.th erm alt ake .c om
1.0
Sp eci f ica tio n
1.1
Ac ces s or y
1.2
War n ing a n d Not ice
Chapter 2. Installation Guide
Remo ve Co m pon ent s
2.0
Powe r S upp ly Uni t (PS U ) Ins tal l ati on
2.1
Mo the r bo a rd In s tal lat i on
2.2
3. 5" & 2. 5 " HDD I n sta lla t ion
2.3
PC I Car d I nst all a tio n
2.4
2.5
Ai r Coo l ing I nst a lla tio n
2.6
AI O Liq u id Co oli n g Ins t al l ati on
2.7
I/ O Con n ect ion
2.8
Br ac k et In sta l lat ion
2.9
Remo ve Fi l ter s
01
02
03
06
07
08
09
11
12
13
14
15
16
Page 3
Divider 200 TG Divider 200 TG
Specificatio n
Accessory
Mod el
Cas e Type
Dim ensio n (H*W* D) 364 .7 x 333. 2 x 425.7 m m (14.4 x 1 3.1 x 16. 8 inch)
Sid e Panel
Col or
Mat erial
Coo ling Sy stem
Dri ve Bays
Exp ansio n Slots
Mot herbo ards
I/O P ort
PSU
Fan S uppor t
Rad iator S uppor t
Cle aranc e
Div ider 20 0 TG Div ider 20 0 TG Snow E di tio n
Mic ro Case
Tempe red Gla ss x 3
Bla ck Whi te
SPC C
Fro nt (int ake) :
200 x 2 00 x 30 mm St andar d fan (80 0rpm, 1 3 dBA) x 1
Rea r (exha ust) :
120 x 1 20 x 25 mm fa n (1000 rpm, 16 d BA) x 1
3 x 3.5 ”, 3 x 2.5”
or 6 x 2. 5”
5
6.7 ” x 6.7” (M ini ITX ), 9.6” x 9 .6” (Mi cro ATX)
USB 3 .2 (Gen 2 ) Type-C x 1 , US B 3.0 x 2 , HD Audio x 1
Sta ndard P S2 PSU (o ption al)
Fro nt: 2 x 120 m m, 1 x 120 mm
2 x 140 mm, 1 x 140 mm
1 x 200 mm
Rig ht: 2 x 120 m m, 1 x 120 mm
2 x 140 mm, 1 x 140 mm
Rea r: 1 x 120 mm , 1 x 140mm
Bot tom: 2 x 12 0 mm, 1 x 120 m m
Fro nt: 1 x 240 mm, 1 x 240 mm
1 x 280 mm, 1 x 140 mm
Rig ht: 1 x 240 mm, 1 x 120 m m
1 x 280 mm, 1 x 140 mm
Rea r: 1 x 120 mm
CPU c ooler h eight l imita tion: 1 85 mm
VGA le ngth li mitat ion: 31 0mm (Wi th 27mm r adiat or)
340 mm (Wit hout ra diato r)
PSU l ength l imita tion: 1 80mm (W ith Bot tom Fan )
200 mm (Wit hout Bo ttom Fa n)
Figure
Part Name
Screw 5 x 10 mm
Stand-off #6-32 x 6.5 mm
Screw M3 x 6 mm
Screw #6-32 x 5 mm
Screw #6-32 x 5 mm
Screw #6-32 x 6 mm
Screw 3 x 6 mm
PSU Pad
Buzzer
Zip Tie 150 mm
Q`ty
12
2
18
12
9
4
6
2
1
7
Use For
For Fan
For Motherboard
For 2.5” HDD
For 3.5” HDD
For Motherboard
For PSU
For 3.5” Tray
For PSU
Motherboard Alarm
Cable Management
01 02
Page 4
Divider 200 TG Divider 200 TG
Warning and Noti ce
Chassis dimension
425. 7mm 333. 2mm
364. 7mm
344. 7mm
415. 8mm
Motherboard Compatibility: ITX / mATX
(Up to 244mm w i d e )
X
T
I
X
T
I
CPU cooler max height: 185mm
185m m
VGA length max length: 340mm
TX
mA
TX
mA
310mm
340mm
03 04
240mm
Page 5
Divider 200 TG Divider 200 TG
Remove Compone nts
PSU max length: 180mm
165. 95m m 180m m
05 06
Page 6
Divider 200 TG Divider 200 TG
Power Supply Unit Installation Motherboard In stallation
x 4 x 8
PSU Pa dPSU Pa d
07 08
PSU Pa dPSU Pa d
Page 7
Divider 200 TG Divider 200 TG
3.5” HDD Installation
2.5” HDD Installation
x 4
x 4
09 10
Page 8
Divider 200 TG Divider 200 TG
PCI Card Installation
Air Cooling Installation
Rear
120mm x 1
or
140mm x 1
Front
120mm x 2
or
140mm x 2
or
200mm x 1
Bottom
120mm x 2
11 12
Right
120mm x 2
or
140mm x 2
Page 9
Divider 200 TG Divider 200 TG
AIO Liquid Cooling Installation I/O Connection
Rear
Front
240mm x 1
or
280mm x 1
120mm x 1
Right
240mm x 1
280mm x 1
RESET HD Audio USB 3.0 TYPE-C
Power SW / Power LED / HDD LED
or
13 14
Page 10
Divider 200 TG Divider 200 TG
Bracket Installation
Remove Filters
Front
Top
Right
15
Right
Front
Bottom
16
