Thermal Dynamics Econo-Pak 50 Operating Manual

ECONO-PAK 50
Air Plasma Cutting Power Supply
The System Includes:
• ECONO-PAK 50 Power Supply
• PCH-26 Torch with Leads
Operating Manual
September 1, 1998
Manual No. 0-2450
WARNING
Read and understand this entire Operating Manual and your employer’s safety practices before installing, operating, or servicing the equipment.
WARNING
While the information contained in this Operating Manual represents our best judgement, Thermal Dynamics Corporation assumes no liability for its use.
Econo-Pak 50 Air Plasma Cutting Power Supply Operating Manual Number 0-2450
Published by: Thermal Dynamics Corporation Industrial Park No. 2 West Lebanon, New Hampshire, USA 03784 (603) 298-5711
Copyright 1997 by Thermal Dynamics Corporation
All rights reserved. Reproduction of this work, in whole or in part, without written
permission of the publisher is prohibited. The publisher does not assume and hereby disclaims any liability
to any party for any loss or damage caused by any error or omission in the Econo-Pak 50 Air Plasma Cutting Power Supply Operating Manual, whether such error results from negligence, accident, or any other cause.
Printed in the United States of America
September 1, 1998
RECORD SERIAL NUMBERS FOR WARRANTY PURPOSES
Purchase Date
Power Supply
Torch
TABLE OF CONTENTS
SECTION 1: GENERAL INFORMATION ..................................................................................... 1
1.01 Notes, Cautions and Warnings ...................................................................... 1
1.02 Important Safety Precautions ........................................................................ 1
1.03 Publications ................................................................................................... 2
1.04 Note, Attention et A v ertissement ................................................................... 3
1.05 Precautions De Securite Importantes ............................................................ 3
1.06 Documents De Reference ............................................................................. 5
1.07 Declaration of Conformity .............................................................................. 6
1.08 Statement of W arr anty................................................................................... 7
SECTION 2: INTR ODUCTION & DESCRIPTION........................................................................ 9
2.01 SYSTEM SPECIFICATIONS ......................................................................... 9
2.02 TORCH PARTS............................................................................................ 10
SECTION 3: INSTALLATION ..................................................................................................... 11
3.01 UNPACKING AND CHOOSING A LOCATION.............................................. 11
3.02 ELECTRICAL CONNECTIONS ................................................................... 11
3.03 GAS CONNECTIONS ................................................................................. 12
3.03 GAS CONNECTIONS (Continued).............................................................. 13
SECTION 4: OPERATION ......................................................................................................... 15
4.01 OPERATING CONTROLS ........................................................................... 15
4.02 GETTING STARTED ................................................................................... 16
4.03 OPERATING THE SYSTEM ........................................................................ 17
4.03 OPERATING THE SYSTEM (continued) ..................................................... 18
4.04 OPERATING WITH A HAND T ORCH........................................................... 19
4.05 RECOMMENDED CUTTING SPEEDS ....................................................... 20
SECTION 5: CUST OMER/OPERATOR SERVICE..................................................................... 21
5.01 TR OUBLESHOO TING AND MAINTENANCE .............................................. 21
5.02 BASIC TR OUBLESHOO TING GUIDE.......................................................... 22
5.03 REPLACING CONSUMABLE TORCH PARTS ............................................ 23
SECTION 6: PARTS LISTS........................................................................................................ 25
6.01 INTRODUCTION......................................................................................... 25
6.02 REPLACEMENT - COMPLETE SYSTEMS ................................................. 26
6.03 REPLACEMENT TORCH AND LEAD ASSEMBLIES .................................. 27
6.04 OPTIONS AND ACCESSORIES ................................................................. 28
6.05 REPLACEMENT HAND TORCH PARTS ..................................................... 29
This Page Left Blank ............................................................................................ 31
APPENDIX I: SYSTEM SCHEMATIC......................................................................................... 32
TABLE OF CONTENTS (continued)
SECTION 1:
GENERAL INFORMATION
1.01 Notes, Cautions and Warnings
Throughout this manual, notes, cautions, and warnings are used to highlight important information. These high­lights are categorized as follows:
NOTE
An operation, procedure, or backgr ound informa­tion which requires additional emphasis or is help­ful in efficient operation of the system.
CAUTION
A procedure which, if not properly followed, may cause damage to the equipment.
W ARNING
A procedure which, if not properly followed, may cause injury to the operator or others in the oper­ating area.
1.02 Important Safety Precautions
• Use an air-supplied respirator if ventilation is not adequate to remove all fumes and gases.
• The kinds of fumes and gases from the plasma arc depend on the kind of metal being used, coatings on the metal, and the different processes. Y ou must be very careful when cutting or welding any met­als which may contain one or more of the follow­ing:
Antimony Chromium Mercury Arsenic Cobalt Nickel Barium Copper Selenium Beryllium Lead Silver Cadmium Manganese Vanadium
• Always read the Material Safety Data Sheets (MSDS) that should be supplied with the material you are using. These MSDSs will give you the information regarding the kind and amount of fumes and gases that may be dangerous to your health.
• For information on how to test for fumes and gases in your workplace, refer to item 1 in Subsection
1.03, Publications in this manual.
• Use special equipment, such as water or down draft cutting tables, to capture fumes and gases.
• Do not use the plasma torch in an area where com­bustible or explosive gases or materials are located.
• Phosgene, a toxic gas, is generated from the vapors of chlorinated solvents and cleansers. Remove all sources of these vapors.
WARNING
OPERATION AND MAINTENANCE OF PLASMA ARC EQUIPMENT CAN BE DAN­GEROUS AND HAZARDOUS TO YOUR HEALTH.
To prevent possible injury, read, understand and follow all warnings, safety precautions and in­structions before using the equipment. Call 1-603­298-5711 or your local distributor if you have any questions.
GASES AND FUMES
Gases and fumes produced during the plasma cutting process can be dangerous and hazardous to your health.
• Keep all fumes and gases from the breathing area. Keep your head out of the welding fume plume.
ELECTRIC SHOCK
Electric Shock can injure or kill. The plasma arc process uses and produces high voltage electrical energy. This electric energy can cause severe or fatal shock to the op­erator or others in the workplace.
• Never touch any parts that are electrically “live” or “hot.”
• W ear dry gloves and clothing. Insulate yourself from the work piece or other parts of the welding cir­cuit.
• Repair or replace all worn or damaged parts.
• Extra care must be taken when the workplace is moist or damp.
• Install and maintain equipment according to NEC code, refer to item 9 in Subsection 1.03, Publica­tions.
• Disconnect power source before performing any ser­vice or repairs.
• Read and follow all the instructions in the Operat­ing Manual.
1 GENERAL INFORMATION
FIRE AND EXPLOSION
Fire and explosion can be caused by hot slag, sparks, or the plasma arc.
• Be sure there is no combustible or flammable mate­rial in the workplace. Any material that cannot be removed must be protected.
• Ventilate all flammable or explosive vapors from the workplace.
• Do not cut or weld on containers that may have held combustibles.
• Provide a fire watch when working in an area wher e fire hazards may exist.
• Hydrogen gas may be formed and trapped under aluminum workpieces when they are cut under­water or while using a water table. DO NOT cut aluminum alloys underwater or on a water table unless the hydrogen gas can be eliminated or dis­sipated. T rapped hydr ogen gas that is ignited will cause an explosion.
NOISE
Noise can cause permanent hearing loss. Plasma arc pro­cesses can cause noise levels to exceed safe limits. Yo u must protect your ears from loud noise to prevent per­manent loss of hearing.
• T o pr otect your hearing fr om loud noise, wear pro­tective ear plugs and/or ear muffs. Protect others in the workplace.
• Noise levels should be measured to be sure the deci­bels (sound) do not exceed safe levels.
• For information on how to test for noise, see item 1 in Subsection 1.03, Publications, in this manual.
PLASMA ARC RAYS
Plasma Arc Rays can injure your eyes and burn your skin. The plasma arc process produces very bright ultra violet and infra red light. These arc rays will damage your eyes and burn your skin if you are not properly pr otected.
• To protect your eyes, always wear a welding hel­met or shield. Also always wear safety glasses with side shields, goggles or other protective eye wear.
• Wear welding gloves and suitable clothing to pro­tect your skin from the arc rays and sparks.
• Keep helmet and safety glasses in good condition. Replace lenses when cracked, chipped or dirty.
• Protect others in the work area from the arc rays. Use protective booths, screens or shields.
• Use the shade of lens as recommended in Subsec­tion 1.03, item 4.
1.03 Publications
Refer to the following standards or their latest revisions for more information:
1. OSHA, SAFETY AND HEALTH STANDARDS, 29CFR 1910, obtainable from the Superintendent of Documents, U.S. Government Printing Office, W ash­ington, D.C. 20402
2. ANSI Standard Z49.1, SAFETY IN WELDING AND CUTTING, obtainable from the American Welding Society, 550 N.W. LeJeune Rd, Miami, FL 33126
3. NIOSH, SAFETY AND HEALTH IN ARC WELD­ING AND GAS WELDING AND CUTTING, obtain­able from the Superintendent of Documents, U.S. Government Printing Office, W ashington, D.C. 20402
4. ANSI Standard Z87.1, SAFE PRACTICES FOR OC­CUP ATION AND EDUCA TIONAL EYE AND F ACE PROTECTION, obtainable from American National Standards Institute, 1430 Broadway, New York, NY 10018
5. ANSI Standard Z41.1, STANDARD FOR MEN’S SAFETY-TOE FOOTWEAR, obtainable from the American National Standards Institute, 1430 Broad­way, New York, NY 10018
6. ANSI Standard Z49.2, FIRE PREVENTION IN THE USE OF CUTTING AND WELDING PROCESSES, obtainable from American National Standar ds Insti­tute, 1430 Broadway, New York, NY 10018
7. AWS Standard A6.0, WELDING AND CUTTING CONTAINERS WHICH HAVE HELD COMBUS­TIBLES, obtainable from American Welding Society, 550 N.W. LeJeune Rd, Miami, FL 33126
8. NFPA Standard 51, OXYGEN-FUEL GAS SYSTEMS FOR WELDING, CUTTING AND ALLIED PRO­CESSES, obtainable from the National Fire Protec­tion Association, Batterymarch Park, Quincy, MA 02269
9. NFPA Standard 70, NATIONAL ELECTRICAL CODE, obtainable from the National Fire Protection Association, Batterymarch Park, Quincy, MA 02269
10. NFPA Standard 51B, CUTTING AND WELDING PROCESSES, obtainable from the National Fire Pro­tection Association, Batterymarch Park, Quincy, MA 02269
11. CGA Pamphlet P-1, SAFE HANDLING OF COM­PRESSED GASES IN CYLINDERS, obtainable from the Compressed Gas Association, 1235 Jefferson Davis Highway, Suite 501, Arlington, VA 22202
GENERAL INFORMATION 2
12. CSA Standard W117.2, CODE FOR SAFETY IN WELDING AND CUTTING, obtainable from the Ca­nadian Standards Association, Standards Sales, 178 Rexdale Boulevard, Rexdale, Ontario, Canada M9W 1R3
13. NWSA booklet, WELDING SAFETY BIBLIOGRA­PHY obtainable from the National Welding Supply Association, 1900 Arch Street, Philadelphia, PA 19103
14. American W elding Society Standard A WSF4.1, REC­OMMENDED SAFE PRACTICES FOR THE PREP A­RA TION FOR WELDING AND CUTTING OF CON­TAINERS AND PIPING THAT HAVE HELD HAZARDOUS SUBSTANCES, obtainable from the American Welding Society, 550 N.W. LeJeune Rd, Miami, FL 33126
15. ANSI Standard Z88.2, PRACTICE FOR RESPIRA­TORY PROTECTION, obtainable from American National Standards Institute, 1430 Broadway, New York, NY 10018
1.04 Note, Attention et Avertissement
Dans ce manuel, les mots “note,” “attention,” et “avertissement” sont utilisés pour mettre en relief des informations à caractère important. Ces mises en relief sont classifiées comme suit :
1.05 Precautions De Securite Importantes
AVERTISSEMENT
L’OPÉRATION ET LA MAINTENANCE DU MATÉRIEL DE SOUDAGE À L’ARC AU JET DE PLASMA PEUVENT PRÉSENTER DES RISQUES ET DES DANGERS DE SANTÉ.
Il faut communiquer aux opérateurs et au person­nel TOUS les dangers possibles. Afin d’éviter les blessures possibles, lisez, comprenez et suivez tous les avertissements, toutes les précautions de sécurité et toutes les consignes avant d’utiliser le matériel. Composez le + 603-298-5711 ou votre distributeur local si vous avez des questions.
FUMÉE et GAZ
La fumée et les gaz produits par le procédé de jet de plasma peuvent présenter des risques et des dangers de santé.
NOTE
Toute opération, procédure ou renseignement général sur lequel il importe d’insister davantage ou qui contribue à l’efficacité de fonctionnement du système.
ATTENTION
Toute procédur e pouvant résulter l’endommagement du matériel en cas de non­respect de la procédur e en question.
A VERTISSEMENT
Toute procédure pouvant provoquer des blessures de l’opérateur ou des autres personnes se trouvant dans la zone de travail en cas de non-respect de la procédure en question.
• Eloignez toute fumée et gaz de votre zone de respi­ration. Gardez votre tête hors de la plume de fumée provenant du chalumeau.
• Utilisez un appareil respiratoire à alimentation en air si l’aération fournie ne permet pas d’éliminer la fumée et les gaz.
• Les sortes de gaz et de fumée provenant de l’arc de plasma dépendent du genre de métal utilisé, des revêtements se trouvant sur le métal et des différ ents procédés. Vous devez prendre soin lorsque vous coupez ou soudez tout métal pouvant contenir un ou plusieurs des éléments suivants:
antimoine cadmium mercure argent chrome nickel arsenic cobalt plomb baryum cuivre sélénium béryllium manganèse vanadium
• Lisez toujours les fiches de données sur la sécurité des matières (sigle américain “MSDS”); celles-ci devraient être fournies avec le matériel que vous utilisez. Les MSDS contiennent des renseignements quant à la quantité et la nature de la fumée et des gaz pouvant poser des dangers de santé.
• Pour des informations sur la manière de tester la fumée et les gaz de votre lieu de travail, consultez l’article 1 et les documents cités à la page 5.
3 GENERAL INFORMATION
• Utilisez un équipement spécial tel que des tables de coupe à débit d’eau ou à courant descendant pour capter la fumée et les gaz.
• N’utilisez pas le chalumeau au jet de plasma dans une zone où se trouvent des matières ou des gaz combustibles ou explosifs.
• Le phosgène, un gaz toxique, est généré par la fumée provenant des solvants et des produits de nettoyage chlorés. Eliminez toute source de telle fumée.
• Prévoyez une veille d’incendie lors de tout travail dans une zone présentant des dangers d’incendie.
• Le gas hydrogène peut se former ou s’accumuler sous les pièces de travail en aluminium lorsqu’elles sont coupées sous l’eau ou sur une table d’eau. NE P AS couper les alliages en aluminium sous l’eau ou sur une table d’eau à moins que le gas hydrogène peut s’échapper ou se dissiper. Le gas hydrogène accumulé explosera si enflammé.
CHOC ELECTRIQUE
Les chocs électriques peuvent blesser ou même tuer. Le procédé au jet de plasma requiert et produit de l’éner gie électrique haute tension. Cette énergie électrique peut produire des chocs graves, voire mortels, pour l’opérateur et les autres personnes sur le lieu de travail.
• Ne touchez jamais une pièce “sous tension” ou “vive”; portez des gants et des vêtements secs. Isolez-vous de la pièce de travail ou des autres par­ties du circuit de soudage.
• Réparez ou remplacez toute pièce usée ou endommagée.
• Prenez des soins particuliers lorsque la zone de tra­vail est humide ou moite.
• Montez et maintenez le matériel conformément au Code électrique national des Etats-Unis. (Voir la page 5, article 9.)
• Débranchez l’alimentation électrique avant tout tra­vail d’entretien ou de réparation.
• Lisez et respectez toutes les consignes du Manuel de consignes.
INCENDIE ET EXPLOSION
RAYONS D’ARC DE PLASMA
Les rayons provenant de l’arc de plasma peuvent blesser vos yeux et brûler votre peau. Le procédé à l’arc de plasma produit une lumière infra-rouge et des rayons ultra-vio­lets très forts. Ces rayons d’arc nuiront à vos yeux et brûleront votre peau si vous ne vous protégez pas correctement.
• Pour protéger vos yeux, portez toujours un casque ou un écran de soudeur. Portez toujours des lunettes de sécurité munies de parois latérales ou des lu­nettes de protection ou une autre sorte de protec­tion oculaire.
• Portez des gants de soudeur et un vêtement protecteur approprié pour protéger votre peau contre les étincelles et les rayons de l’arc.
• Maintenez votre casque et vos lunettes de protec­tion en bon état. Remplacez toute lentille sale ou comportant fissure ou rognure.
• Protégez les autres personnes se trouvant sur la zone de travail contre les rayons de l’arc en fournissant des cabines ou des écrans de protection.
• Respectez le teint de lentille recommandé dans le article 4, page 5.
Les incendies et les explosions peuvent résulter des scories chaudes, des étincelles ou de l’arc de plasma. Le procédé à l’arc de plasma produit du métal, des étincelles, des scories chaudes pouvant mettre le feu aux matières com­bustibles ou provoquer l’explosion de fumées inflammables.
• Soyez certain qu’aucune matière combustible ou in­flammable ne se trouve sur le lieu de travail. Protégez toute telle matière qu’il est impossible de retirer de la zone de travail.
• Procurez une bonne aération de toutes les fumées inflammables ou explosives.
• Ne coupez pas et ne soudez pas les conteneurs ayant pu renfermer des matières combustibles.
GENERAL INFORMATION 4
BRUIT
Le bruit peut provoquer une perte permanente de l’ouïe. Les procédés de soudage à l’arc de plasma peuvent provoquer des niveaux sonores supérieurs aux limites normalement acceptables. Vous dú4ez vous protéger les oreilles contre les bruits forts afin d’éviter une perte permanente de l’ouïe.
• Pour protéger votre ouïe contre les bruits forts, portez des tampons protecteurs et/ou des protections auriculaires. Protégez également les autres personnes se trouvant sur le lieu de travail.
• Il faut mesurer les niveaux sonores afin d’assurer que les décibels (le bruit) ne dépassent pas les niveaux sûrs.
• Pour des renseignements sur la manière de tester le bruit, consultez l’article 1, page 5.
1.06 Documents De Reference
Consultez les normes suivantes ou les révisions les plus récentes ayant été faites à celles-ci pour de plus amples renseignements :
1. OSHA, NORMES DE SÉCURITÉ DU TRAVAIL ET DE PROTECTION DE LA SANTÉ, 29CFR 1910, disponible auprès du Superintendent of Docu­ments, U.S. Government Printing Office, Washing­ton, D.C. 20402
2. Norme ANSI Z49.1, LA SÉCURITÉ DES OPÉRATIONS DE COUPE ET DE SOUDAGE, disponible auprès de la Société Américaine de Soudage (American Welding Society), 550 N.W. LeJeune Rd., Miami, FL 33126
3. NIOSH, LA SÉCURITÉ ET LA SANTÉ LORS DES OPÉRATIONS DE COUPE ET DE SOUDAGE À L ’ARC ET AU GAZ, disponible aupr ès du Superin­tendent of Documents, U.S. Government Printing Office, Washington, D.C. 20402
4. Norme ANSI Z87.1, PRA TIQUES SURES POUR LA PROTECTION DES YEUX ET DU VISAGE AU TRAVAIL ET DANS LES ECOLES, disponible de l’Institut Américain des Normes Nationales (Ameri­can National Standards Institute), 1430 Broadway, New Y ork, NY 10018
5. Norme ANSI Z41.1, NORMES POUR LES CHAUSSURES PROTECTRICES, disponible auprès de l’American National Standards Institute, 1430 Broadway, New York, NY 10018
6. Norme ANSI Z49.2, PRÉVENTION DES INCENDIES LORS DE L ’EMPLOI DE PROCÉDÉS DE COUPE ET DE SOUDAGE, disponible auprès de l’American National Standards Institute, 1430 Broadway, New York, NY 10018
7. Norme A6.0 de l’Association Américaine du Soudage (A WS), LE SOUDAGE ET LA COUPE DE CONTENEURS AYANT RENFERMÉ DES PRODUITS COMBUSTIBLES, disponible auprès de la American W elding Society, 550 N.W . LeJeune Rd., Miami, FL 33126
8. Norme 51 de l’Association Américaine pour la Pro­tection contre les Incendies (NFP A), LES SYSTEMES À GAZ AVEC ALIMENTATION EN OXYGENE POUR LE SOUDAGE, LA COUPE ET LES PROCÉDÉS ASSOCIÉS, disponible auprès de la National Fire Protection Association, Batterymarch Park, Quincy, MA 02269
9. Norme 70 de la NFPA, CODE ELECTRIQUE NA­TIONAL, disponible auprès de la National Fire Pro­tection Association, Batterymarch Park, Quincy, MA 02269
10. Norme 51B de la NFPA, LES PROCÉDÉS DE COUPE ET DE SOUDAGE, disponible auprès de la National Fire Protection Association, Batterymarch Park, Quincy, MA 02269
11. Brochure GCA P-1, LA MANIPULATION SANS RISQUE DES GAZ COMPRIMÉS EN CYLINDRES, disponible auprès de l’Association des Gaz Comprimés (Compressed Gas Association), 1235 Jefferson Davis Highway, Suite 501, Arlington, VA 22202
12. Norme CSA W1 17.2, CODE DE SÉCURITÉ POUR LE SOUDAGE ET LA COUPE, disponible auprès de l’Association des Normes Canadiennes, Stan­dards Sales, 178 Rexdale Boulevard, Rexdale, Ontario, Canada, M9W 1R3
13. ivret NWSA, BIBLIOGRAPHIE SUR LA SÉCURITÉ DU SOUDAGE, disponible auprès de l’Association Nationale de Fournitures de Soudage (National Welding Supply Association), 1900 Arch Street, Philadelphia, PA 19103
14. Norme AWSF4.1 de l’Association Américaine de Soudage, RECOMMANDATIONS DE PRA TIQUES SURES POUR LA PRÉPARATION À LA COUPE ET AU SOUDAGE DE CONTENEURS ET TUY AUX AYANT RENFERMÉ DES PRODUITS DANGEREUX , disponible auprès de la American Welding Society, 550 N.W. LeJeune Rd., Miami, FL 33126
15. Norme ANSI Z88.2, PRATIQUES DE PROTEC­TION RESPIRATOIRE, disponible auprès de l’American National Standards Institute, 1430 Broadway, New York, NY 10018
5 GENERAL INFORMATION
1.07 Declaration of Conformity
Manufacturer: Thermal Dynamics Corporation Address: Industrial Park #2
W est Lebanon, New Hampshire 03784 USA
The equipment described in this manual conforms to all applicable aspects and regulations of the ‘Low Voltage Direc­tive’ (European Council Directive 73/23/EEC as amended by Council Directive 93/68/EEC) and to the National leg­islation for the enforcement of this Directive.
Serial numbers are unique with each individual piece of equipment and details description, parts used to manufacture a unit and date of manufacture.
National Standard and Technical Specifications
The product is designed and manufactured to a number of standards and technical requirements among them ar e:
* CSA (Canadian Standards Association) standard C22.2 number 60 for Arc welding equipment.
* UL (Underwriters Laboratory) rating 94VO flammability testing for all printed-circuit boards used.
* ISO/IEC 60974-1 (BS 638-PT10) (EN 60 974-1) applicable to welding equipment and associated accessories.
* Extensive product design verification is conducted at the manufacturing facility as part of the routine design and
manufacturing process. This is to ensure the product is safe, when used according to instr uctions in this manual and related industry standards, and performs as specified. Rigorous testing is incorporated into the manufacturing process to ensure the manufactured product meets or exceeds all design specifications.
Thermal Dynamics has been manufacturing products for more than 30 years, and will continue to achieve excellence in our area of manufacture.
Manufacturers responsible representative: David Ashworth
Vice Pr esident & Managing Director Thermadyne Europe Chorley England.
GENERAL INFORMATION 6
1.08 Statement of Warranty
LIMITED WARRANTY: Thermal Dynamics® Corporation (hereinafter “Thermal”) warrants that its products will be free of defects in workmanship or material. Should any failure to conform to this warranty appear within the time period applicable to the Thermal products as stated below, Thermal shall, upon notification thereof and substantiation that the product has been stored, installed, operated, and maintained in accordance with Thermal’s specifications, instructions, recommendations and recognized standard industry practice, and not subject to misuse, repair, neglect, alteration, or accident, correct such defects by suitable repair or replacement, at Thermal’s sole option, of any components or parts of the product determined by Thermal to be defective.
THIS W ARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A P AR TICULAR PURPOSE.
LIMITATION OF LIABILITY: Thermal shall not under any cir cumstances be liable for special or consequential damages, such
as, but not limited to, damage or loss of purchased or replacement goods, or claims of customers of distributor (hereinafter “Purchaser”) for service interruption. The remedies of the Purchaser set forth herein are exclusive and the liability of Thermal with respect to any contract, or anything done in connection therewith such as the performance or breach thereof, or from the manufacture, sale, delivery, resale, or use of any goods covered by or furnished by Thermal whether arising out of contract, negligence, strict tort, or under any warranty , or otherwise, shall not, except as expr essly pr ovided herein, exceed the price of the goods upon which such liability is based.
THIS W ARRANTY BECOMES INVALID IF REPLACEMENT PAR TS OR ACCESSORIES ARE USED WHICH MA Y IMP AIR THE SAFETY OR PERFORMANCE OF ANY THERMAL PRODUCT.
THIS W ARRANTY IS INVALID IF THE PRODUCT IS SOLD BY NON-AUTHORIZED PERSONS.
The limited warranty periods for Thermal products shall be as follows (with the exception of ST AK PAK II and DRAG-GUN): A maximum of three (3) years from date of sale to an authorized distributor and a maximum of two (2) years from date of sale by such distributor to the Purchaser, and with the further limitations on such two (2) year period (see chart below).
The limited warranty period for STAK PAK II shall be as follows: A maximum of four (4) years from date of sale to an authorized distributor and a maximum of three (3) years from date of sale by such distributor to the Purchaser, and with the further limitations on such three (3) year period (see chart below).
The limited warranty period for DRAG-GUN shall be as follows: A maximum of two (2) years from date of sale to an authorized distributor and a maximum of one (1) year from date of sale by such distributor to the Purchaser, and with the further limitations on such two (2) year period (see chart below).
PARTS PARTS PARTS
PAK UNITS, POWER SUPPLIES STAK P AK II DRAG-GUN All OTHERS LABOR
Main Power Magnetics 3 Years 1 Year 2 Years 1 Year Original Main Power Rectifier 3 Years 1 Year 2 Years 1 Year Control PC Board 3 Years 1 Year 2 Years 1 Year All Other Circuits And Components Including, 1 Year 1 Year 1 Year 1 Year
But Not Limited To, Starting Circuit, Contactors, Relays, Solenoids, Pumps, Power Switching Semi-Conductors
CONSOLES, CONTROL EQUIPMENT, HEAT 1 Year 1 Year 1 Year
EXCHANGES, AND ACCESSORY EQUIPMENT
TORCH AND LEADS
Maximizer 300 Torch N/A 1 Year 1 Year All Other Torches 180 Days 180 Days 180 Days 180 Days
REPAIR/REPLACEMENT PARTS 90 Days 90 Days 90 Days None
Warranty repairs or replacement claims under this limited warranty must be submitted by an authorized Thermal Dynamics® repair facility within thirty (30) days of the repair. No transportation costs of any kind will be paid under this warranty. T ransportation char ges to send pr oducts to an authorized warranty repair facility shall be the r esponsibility of the customer. All returned goods shall be at the customer’s risk and expense. This warranty supersedes all previous Thermal warranties.
Effective May 19, 1998
7 GENERAL INFORMATION
GENERAL INFORMATION 8
SECTION 2: INTRODUCTION & DESCRIPTION
2.01 SYSTEM SPECIFICATIONS
Econo-pak 50
Air Plasma Cutting
System Includes:
Controls
Panel Indicators
Input Power
Output Power
• Econo-pak 50 - The power supply provides 35 amps maximum output cutting current from a standard 208-230 volt, 60Hz AC input service. All electrical, pilot, and gas control circuitry is included.
• Hand Torch with Leads. Cut capacity is 1/2 inch (12.8 mm) steel. Parts-In-Place (PIP) is an integral safety feature of this torch to reduce the risk of electric shock.
• Spare Parts Kit.
SPECIFICATIONS
• ON/OFF Switch
• RUN/SET Switch
• Output Current Control
• Pressure Regulator Control
LED Indicators: AC Power, READY Pressure Gauge
208-230 VAC, 60 Hz, 25/30 Amp Single Phase Continuously variable from 15 to 35 Amps maximum
OCV
Duty Cycle
Work Lead
Cut Capacity
Pilot Circuitry
Gas Connection
Gases
Pressure
Flow
Weight
Dimensions
330 VDC 40% 10 ft (3 m) with clamp 1/2 in (12.8 mm) Steel Capacitor Discharge (CD), Pulsed DC Rear panel entry 1/4 NPT Compressed Air or Nitrogen (N 60 psi (4.2 BAR) 135 scfh (64 lpm) 70 lbs (32 kg) with 12.5' Torch Leads 20 3/4" (527 mm) High
9 3/4" (248 mm) Wide 25" (635 mm) Deep
) Only
2
Manual 0-2450 9 INTRODUCTION & DESCRIPTION
2.02 TORCH PARTS
Torch Parts Selection
The same torch parts are used for drag cutting and standoff cutting. See Section 5.03, Replacing Consumable Torch Parts.
Order replacement parts by catalog number and description.
Shield Cup
Standard Shield Cup
Catalog No. 9-6003
Drag Cutting Tip
(0.031 inch Orifice)
Catalog No. 9-6501
Electrode
Catalog No. 9-6506
Attachment (Copper)
Catalog No. 9-6503
Gas Distributor
Catalog No. 9-6507
A-01745
INTRODUCTION & DESCRIPTION 10 Manual 0-2450
SECTION 3: INSTALLATION
3.01 UNPACKING AND CHOOSING A LOCATION
What's Included with
the Power Supply
Unpacking Procedure
Choosing a Location
CAUTION
Included with each system is:
(1) Work Cable with Clamp (Attached) (1) 230V Single-Phase, Three Wire Input Power Cable (Attached) (1) Operating Manual (1) Spare Parts Kit - Includes:
(5) Drag Cutting Tips..........................................Part No. 9-6501
(3) Electrodes ....................................................... Part No. 9-6506
(1) Gas Distributor ..............................................Part No. 9-6507
1. Unpack each item and remove all packing material.
2. Inspect each item for possible shipping damage. If damage is evident, contact your distributor and/or shipping company before proceeding with system installation.
Select a clean, dry location with good ventilation and adequate working space around all components.
The power supply is cooled by air flow through the front and rear panels. Air flow must not be obstructed. Provide at least 12 inches (300 mm) clearance for both front and rear of system.
Operation without proper air flow will inhibit proper cooling and reduce duty cycle.
NOTE
Review Important Safety Precautions (page iii) to be sure that the selected location meets all safety requirements.
3.02 ELECTRICAL CONNECTIONS
Power Requirements
CAUTION
The unit will operate on single phase 208-230 VAC, 60 Hz. The service should be fused for 30 amps.
The primary power source, power cable, and plug must conform to local electric code and recommended circuit protection and wiring requirements.
Manual 0-2450 11 INST ALLATION
3.03 GAS CONNECTIONS
Gases
Pressure
Flow
CAUTION
WARNING
CAUTION
Checking Air Quality
Filtering
Gas Connections
Compressed Air or Nitrogen (N
), Only
2
60 psi (4.2 BAR) 135 scfh (64 lpm)
Maximum input gas pressure must not exceed 125 psi (8.6 BAR).
This cutting system must not be used with Oxygen (O
).
2
Air supply must be free of oil, moisture, and other contaminants. Excessive oil and moisture may cause double-arcing, rapid tip wear, or even complete torch failure. Contaminants may cause poor cutting performance and rapid electrode wear.
To test the quality of air, place a welding filter lens in front of the torch and turn on the gas. Any oil or moisture in the air will be visible on the lens. Do not initiate an arc!
An air line filter, capable of filtering to at least 5 microns, is required when using air from a compressor to insure that mois­ture and debris from the supply hose does not enter the torch.
The rear panel of the power supply is equipped with a female 1/4 NPT gas input fitting.
Using High Pressure
Gas Cylinders
NOTE
Using Shop Air
CAUTION
To use air or nitrogen from a high pressure gas cylinder:
1. Examine the cylinder valves to be sure they are clean and free of oil, grease or any foreign material. Momentarily open each cylinder valve to blow out any dust which may be present.
2. Each cylinder must be equipped with an adjustable high­pressure regulator capable of pressures up to 75 psi (5.3 BAR) minimum and flows of up to 200 scfh (94 lpm).
3. Set the tank regulator to 75 psi (5.3 BAR). Use the regulator on the front of the power supply to adjust the gas pressure to the unit.
Refer to the manufacturer's specifications for installation and maintenance procedures for high pressure gas regulators.
Do not use an air line filter with high pressure gas cylinders.
INSTALLA TION 12 Manual 0-2450
3.03 GAS CONNECTIONS (Continued)
To use shop air from a compressor, refer to Figure 3-A and:
CAUTION
Replacing Filter
Cartridge
NOTE
Air supply must be free of oil, moisture, and other contaminants. Excessive oil and moisture may cause double-arcing, rapid tip wear, or even complete torch failure. Contaminants may cause poor cutting performance and rapid electrode wear.
1. Install an air filter assembly to the gas input fitting on the front panel of the power supply. The air filter is supplied with 1/4 NPT gas couplings. A quick disconnect fitting is recommended on the filter body cap to allow easy connection to the compressed air source.
2. Connect the air supply hose to the inlet fitting on the air filter body cap.
When connecting a gas fitting to the filter cap, hold the cap flats with a wrench. Over tightening the cap on the filter body can damage the filter cartridge or cap gasket.
Air filter cartridge (Part No. 7-0252) should be replaced every 30 days, depending on the condition of the compressed air. If a noticeable drop in air pressure occurs, the filter has become filled with contaminants and must be replaced.
To replace cartridge, unscrew filter cap from body, slide out old cartridge and insert new filter element. The filter cartridge fits only one way. Filter cap must be hand tight only.
Supply hoses must be at least #4 hose (1/4 in or 6.4 mm mini­mum inside diameter).
AIR FLOW
Optional
Connect to Front Panel 1/4 NPT Gas Fitting
A-00786
Using the System with Shop Air
Filter Cap
Air Line Filter
Assembly
Supply Hose from Source (1/4 NPT)
Connect to Front Panel 1/4 NPT Gas Fitting
Using the System with Cylinder Air
Supply Hose from Regulator (1/4 NPT)
Figure 3-A Air Line Filter Gas Connections
Manual 0-2450 13 INST ALLATION
INSTALLA TION 14 Manual 0-2450
SECTION 4: OPERATION
4.01 OPERATING CONTROLS
60
40
34
80
5
2
20
6
1
bar psi
100
RUN/SET Switch
AC Indicator
Ready Indicator
CURRENT Control
POWER Switch
PRESSURE Gauge
PRESSURE Control
A-01746
RUN/SET Switch
RUN position is used for torch operation. SET position is used for setting gas pressure and purging lines.
AC Indicator
Green light indicates AC input power is present in the system when the ON/OFF switch is in ON position. Indicator will flash for a few seconds when first turned on until the power circuits are ready.
READY Indicator
Green light indicates system ready for operation. Light will be off if the system is overheated or the AC line input voltage is too high. The indicator will also flash for a moment if the torch is shorted.
Current Control
ON/OFF Switch
Adjusts output current from 15 to 35 amps. ON position supplies AC power to activate all system control circuits.
OFF position deactivates control circuits.
Pressure Gauge
Pressure Control
Displays input pressure to the torch. Adjusts pressure from the regulator. Pull knob out and turn clock-
wise to increase pressure to desired level. Push Knob in to lock setting.
Manual 0-2450 15 OPERA TION
4.02 GETTING STARTED
WARNING
Check Torch Parts
NOTE
Check Input Power
Connect Work Cable
Check Gas Supply
Select Output Current
Disconnect primary power at the source before disassembling the power supply, torch, or torch leads.
Follow this set-up procedure each time the system is operated:
1. Check the torch for proper assembly and appropriate front end torch parts (see Section 5.03, Replacing Consumable Torch Parts).
The power supply will not operate unless the torch shield cup is fully seated against the PIP (Parts in Place) pins in the torch head.
2. Check the power source for proper input voltage. Make sure the power source meets circuit protection and wiring require­ments.
3. Check for a solid work cable connection to the workpiece.
4. Select desired gas (air or nitrogen). Make sure gas sources meet pressure and flow requirements (see Section 3.03, Gas Connections). Check connections and turn gas supply on.
5. Select the desired current output level (15 to 35 amps).
Set Operating Pressure
7. Move the RUN/SET switch to SET position. Adjust the gas pressure to 60 psi (4.2 BAR).
8. Set the RUN/SET switch to RUN position.
The system is now ready for operation.
OPERA TION 16 Manual 0-2450
4.03 OPERATING THE SYSTEM
WARNING
WARNING
CAUTION
NOTE
Piloting
Torch Standoff
Disconnect primary power at the source before disassembling the power supply, torch, or torch leads.
Frequently review the Important Safety Precautions at the front of this Manual. Be sure the operator is equipped with proper gloves, clothing, eye and ear protection. Make sure no part of the operator’s body comes into contact with the workpiece while the torch is activated.
Sparks from the cutting process can cause damage to coated, painted, and other surfaces such as glass, plastic and metal.
Handle torch leads with care and protect them from damage.
Piloting is harder on parts life than actual cutting because the pilot arc is directed from the electrode to the tip rather than to a workpiece. Whenever possible, avoid excessive pilot arc time to improve parts life.
Improper standoff (the distance between the torch tip and workpiece) can adversely affect tip life as well as shield cup life. Standoff may also significantly affect the bevel angle. Reducing standoff will generally result in a more square cut.
Edge Starting
Direction of Cut
Dross
For edge starts, hold the torch perpendicular to the workpiece with the front of the tip on the edge of the workpiece at the point where the cut is to start. When starting at the edge of the plate, do not pause at the edge and force the arc to "reach" for the edge of the metal. Establish the cutting arc as quickly as possible.
In the torch, the plasma gas stream swirls as it leaves the torch to maintain a smooth column of gas. This swirl effect results in one side of a cut being more square than the other. Viewed along the direction of travel, the right side of the cut is more square than the left. To make a square-edged cut along an inside diameter of a circle, the torch should move counter clockwise around the circle. To keep the square edge along an outside diameter cut, the torch should travel in a clockwise direction.
On carbon steel, dross on top of the plate is normally caused by a fast torch travel speed or a high torch standoff. This dross is usually hard to remove. Dross along the cut line on the bottom of the plate is more easily removed and is often caused by torch travel speeds that are to slow.
Manual 0-2450 17 OPERA TION
4.03 OPERATING THE SYSTEM (continued)
Common Cutting Problems
Problem Possible Cause
1. Cutting speed too fast
Insu fficient Pen etration
Main Arc
Extinguishes
Excessive
Dross F ormation
Sho rt To rch
Parts Life
2. Torch tilted too much
3. Metal too thick
4. W orn torch parts
5. Cutting current too low
1. Cutting speed too slow
2. Torch standoff too high from workpiece
3. AC line too low - reduce output current
4. W ork cable disconnected
5. W orn torch parts
1. Cutting speed too slow (bottom dross)
2. Cutting speed too fast (top dross)
3. Torch standoff too high from workpiece
4. Improper cutting current
5. W orn torch parts
1. Oil or moisture in air source
2. Exceeding system capability (m aterial too thick)
3. Excessive p ilot arc tim e
4. Air flow too low (incorrect pressure)
5. Improperly assembled torch
Table 4-B Common Causes of Operating Problems
OPERA TION 18 Manual 0-2450
4.04 OPERATING WITH A HAND TORCH
Cutting with a
Hand Torch
1. The torch can be comfortably held in one hand or steadied with two hands. Choose the technique that feels most com­fortable and allows good control and movement. Position the index finger or thumb to press the control switch on the torch handle.
2. For edge starts, hold the torch perpendicular to the workpiece with the front of the tip on the edge of the workpiece at the point where the cut is to start. For piercing, angle the torch slightly to direct sparks away from the torch until the pierce is complete.
3. For drag cuts keep the torch in contact with the workpiece. For standoff cutting, hold the torch 1/16 -1/8 in (2-3 mm) from the work.
4. With the torch in starting position, press and hold the control switch. After an initial gas purge, the pilot arc will come on and remain on until the cutting arc starts.
5. Once on, the main arc remains on as long as the control switch is held down, unless the torch is withdrawn from the work or torch motion is too slow. If the cutting arc is inter­rupted, the pilot arc comes back on automatically.
6. To shut off the torch simply release the control switch. When the switch is released a ten second post-flow will occur. If the torch switch is closed during the post-flow, the cutting arc will restart immediately when the torch is brought within range of the workpiece.
Piercing with a
Hand Torch
Manual 0-2450 19 OPERA TION
1. When piercing with a hand torch, tip the torch slightly so that blowback particles blow away from the torch tip (and opera­tor) rather than directly back into it.
2. Complete the pierce off the cutting line and then continue the cut onto the line. Hold the torch perpendicular to the workpiece after the pierce is complete.
3. Clean spatter and scale from the shield cup and the tip as soon as possible. Spraying or dipping the shield cup in anti­spatter compound will minimize the amount of scale which adheres to it.
4.05 RECOMMENDED CUTTING SPEEDS
Recommended
Cutting Speeds
Cutting speed depends on material, thickness, and the operator’s ability to accurately follow the desired cut line. The following factors may have an impact on system performance:
• Torch parts wear
• Air quality
• Line voltage fluctuations
• Torch standoff height
• Proper work cable connection
NOTE
This information represents realistic expectations using recom­mended practices and well-maintained systems. Actual speeds may vary up to 50% from those shown.
Material Thickness Cut Speed (IPM) Amps G as / Pressure Stand Off
Mild Steel 1/16" (1.6 mm) 200 35 Air / 60 psi Drag - 1/8"
1/8" (3.2 mm) 100 35 Air / 60 psi Drag - 1/8" 1/4" (6.4 mm) 35 35 Air / 60 psi Drag - 1/8" 3/8" (9.6 mm) 15 35 Air / 60 psi Drag - 1/8"
1/2" (12.8 mm) 10 35 Air / 60 psi Drag - 1/16"
Tables 4-C Recommended Cutting Speeds
OPERA TION 20 Manual 0-2450
SECTION 5: CUSTOMER/OPERATOR SERVICE
5.01 TROUBLESHOOTING AND MAINTENANCE
General
NOTE
Routine Maintenance
WARNING
CAUTION
Basic troubleshooting of the Econo-pak 50 plasma cutting system can be performed without special equipment or knowledge, and without opening the enclosure.
This basic troubleshooting guide covers input power, gas supply, and torch problems.
For problems not covered in this Section, contact your authorized distributor.
The only routine maintenance required for the power supply is a thorough cleaning and inspection, with the frequency depending on the usage and the operating environment.
Disconnect primary power to the system before disassembling the torch, leads, or power supply.
Do not blow air into the power supply during cleaning. Blowing air into the unit can cause metal particles to interfere with sensi­tive electrical components and cause damage to the unit.
To clean the unit, open the enclosure and use a vacuum cleaner to remove any accumulated dirt and dust. The unit should also be wiped clean. If necessary, solvents that are recommended for cleaning electrical apparatus may be used.
CAUTION
Manual 0-2450 21 CUSTOMER/OPERATOR
When cleaning care must be taken not to move or damage the electronic components.
5.02 BASIC TROUBLESHOOTING GUIDE
SYMPTOM POSSIBLE CAUSE REMEDY
A. AC indicator not lit. Fan
does not turn.
B. AC indicator lit. READY
indicator dark.
C. AC indicator lit, READY
indicator lit, no gas flow in SET.
1. Circuit Breaker open.
1. Unit is overheated.
2. Airflow obstructed.
3. Pilot circuit overheated. Indicator lits momentarily and unit shuts down.
1. Gas not connected or pressure too low.
2. Air filter or air line blocked or Torch leads blocked
1. Reset Breaker. Use 30 amp service.
1. Make sure the unit has not been operated beyond 40% duty cycle limit.
2. Provide at least 12 inch clearance front and rear
3. Check for proper torch parts assembly, or for shorted torch head.
1. Check source for at least 60 psi (4.2 BAR). In SET position, adjust gas pressure to 60 psi.
2. Replace filter cartridge. Check that air lines and torch leads are free of twists and kinks.
D. AC indicator lit, READY
indicator lit, no gas flow in RUN when torch swirch pressed.
E. AC indicator lit, READY
indicator lit, Torch does not pilot.
F. Torch pilots but does not
cut.
CUSTOMER/OPERATOR SERVICE 22 Manual 0-2450
1. Shield cup not properly installed on torch.
2. Faulty PIP assembly in torch holder.
1. Faulty torch parts
2. Gas pressure too high.
1. Work lead not connected.
2. AC input too low.
1. Check that shield cup is fully seated against torch head.
2. Replace Torch Head Assembly.
1. Inspect torch parts and replace if necessary.
2. Set pressure to 60 psi (4.2 BAR).
1. Make sure work lead is connected securely to bare metal.
2. Use shortest service to breaker panel possible.
5.03 REPLACING CONSUMABLE TORCH PARTS
WARNING
WARNING
NOTE
Disconnect primary power to the system before disassembling the torch, leads, or power supply.
DO NOT TOUCH internal torch parts while the AC indicator on the front panel of the power supply is lit.
The tip, gas distributor, and electrode are held in place by the shield cup. Position the torch with the shield cup facing upward to prevent these parts from falling out when the cup is removed.
Refer to Figure 5-A and:
1. Unscrew and remove the shield cup from the torch. Inspect the cup for damage. Wipe it clean or replace if damaged.
2. Remove the tip. Check for excessive wear (indicated by an elongated or oversized orifice). Clean and replace the tip if necessary.
3. Remove the gas distributor and check for excessive wear, plugged gas holes, or discoloration. Replace if necessary.
4. Remove the electrode. The face of the electrode should not be recessed more than 0.10 inch (2.5 mm). If it is worn beyond this point it must be replaced.
CAUTION
A-00780
5. Reinstall the parts and shield cup on the torch as shown. Hand tighten the shield cup until it is seated on the torch head. If resistance is felt when installing the cup, check the threads before proceeding with installation.
Improper assembly or use of non standard torch parts can cause the torch head to short and may overheat or damage the torch.
Gas
Distributor TipElectrode
Torch Head Assembly
Standard
Shield Cup
Figure 5-A Torch Consumable Parts
Manual 0-2450 23 CUSTOMER/OPERATOR
CUSTOMER/OPERATOR SERVICE 24 Manual 0-2450
SECTION 6: PARTS LISTS
6.01 INTRODUCTION
About the Parts List
Ordering Information
Returns
This Section contains the Parts Lists and Replacement Parts. Parts listed without item numbers are not shown, but may be
ordered by the catalog number shown.
Order replacement parts by catalog number and complete de­scription of the part or assembly, as listed in the description column of the Parts List. Also include the model and serial number of the torch. Address all inquiries to your authorized Thermal Dynamics distributor.
If a Thermal Dynamics product must be returned for service, contact your Thermal Dynamics distributor. Materials returned to Thermal Dynamics without proper authorization will not be accepted.
Manual 0-2450 25 P ARTS LISTS
6.02 REPLACEMENT - COMPLETE SYSTEMS
Complete systems include: Power Supply with primary power cable, Work Cable, PCH-26 Torch with Leads, Torch Spare Parts Kit, and Operating Manual.
Description Qty Catalog #
Econo-Pak 50 with PCH-26 70° Torch
208/230 Volt Single Phase with 12.5 ft (3.8 m) Leads 1 1-3500-2 208/230 Volt Single Phase with 25 ft (7.6 m) Leads 1 1-3501-2
Econo-Pak 50 with PCH-26 90° Torch
208/230 Volt Single Phase with 12.5 ft (3.8 m) Leads 1 1-3500-1 208/230 Volt Single Phase with 25 ft (7.6 m) Leads 1 1-3501-1
PARTS LISTS 26 Manual 0-2450
6.03 REPLACEMENT TORCH AND LEAD ASSEMBLIES
Description Qty Catalog #
Replacement Torch With Leads Only:
PCH-26 70° Hand Torch with 12.5 ft (3.8 m) Leads 1 2-3501 PCH-26 70° Hand Torch with 25 ft (7.6 m) Leads 1 2-3511 PCH-26 90° Hand Torch with 12.5 ft (3.8 m) Leads 1 2-3500 PCH-26 90° Hand Torch with 25 ft (7.6 m) Leads 1 2-3510
Manual 0-2450 27 P ARTS LISTS
6.04 OPTIONS AND ACCESSORIES
Description Qty Catalog #
Single Stage Air Filter Kit 1 7-0250
Replacement Air Filter Cartridge 1 7-0252
Dual Stage Air Filter 1 7-3500
First Stage Replacement Cartridge 1 9-1021 Second Stage Replacement Cartridge 1 9-1022
Smart Cart 1 7-7777 ' Circle Cutting Guide 1 7-3291
Spare Parts Kit 1 5-3500
Tip, Air, 0.031 inch Orifice, Drag Cutting 5 9-6501 Electrode, Air 3 9-6506 Distributor, Gas 1 9-6507 Box, Utility 1 8-3213
PARTS LISTS 28 Manual 0-2450
6.05 REPLACEMENT HAND TORCH PARTS
Item # Qty Description Catalog #
1 1 Assembly, PIP (Parts-In-Place) Pins and Wire 9-6290 2 2 O-Ring 8-0533 3 1 Holder, Torch, Split, PCH-26 70° Two Parts w/Screws 9-6259
1 Holder, Torch, Split, PCH-26 90° Two Parts w/Screws 9-6260
4 1 Assembly, Basic Head, PCH-26 70° 9-5807
1 Assembly, Basic Head, PCH-26 90° 9-5808 5 1 Distributor, Gas 9-6507 6 1 Tip, Air, 0.031 inch Orifice, Drag Cutting 9-6501 7 1 Electrode, Air 9-6506 8 1 Shield Cup, Standard 9-6003
1 Shield Cup Attachment, MaximumLife (Used with 9-6003) 9-6503 9 1 Handle, Split, PCH-26 Two Parts w/Screws 9-6291
10 1 Lead Assembly, Composite Cable
12.5 ft (3.8m) Length 4-6071
25 ft (7.6m) Length 4-6072 11 1 Assembly, Torch Switch 9-1058 12 1 #6-32 x 3/16 Phillips Pan Head Screw See Note 13 1 #6 Internal Star Washer See Note
NOTE: Item can be purchased locally.
9
11
2
3
13
12
3
1
7
5
6
4
10
9
A-01748
8
Manual 0-2450 29 P ARTS LISTS
PARTS LISTS 30 Manual 0-2450
This Page Left Blank
Manual 0-2450 31 APPENDIX
APPENDIX I: SYSTEM SCHEMATIC
A-01747
APPENDIX 32 Manual 0-2450
Econo-pak 50 System Schematic
Manual 0-2450 33 APPENDIX
A-01747
APPENDIX 34 Manual 0-2450
