Product Overview
True Wireless
Earbuds
Charging
Case
Contents
1. Pre-use Setup
BEANS+
TRUE WIRELESS EARBUDS
USER MANUAL
CP-TW04
2. How To Charge
1. Place the earbuds in the charging case
2. Connect charging case to a USB power
supply or device with USB port.
V19-01
Multi-function button
+ LED light
Microphone
Charging Interface
Eartips
Magnetic Closure
TYPE-C Input
USB Output
LED Light
Eartips
Select and mount the eartips to the earbuds.
For the optimal experience, it is recommended
to try each of the different eartip sizes.
Note: Charge the earbuds for at least 1 hour before use.
4. How To Wear3. Powerbank Output 5. How To Pair (Auto Pairing)
Correct wearing
position
1. Tilt and insert the earbud into your ear.
2. Rotate slightly to get better fit and
performance.
Rotate
Slightly
1.Pick up the earbuds from charging case
2.Turn on bluetooth of your device
2.2 (FIRST TIME) Search and connect to Earbuds
Blue and white flash
CP-TW04 Connect
6 Battery Status
7. Touch Control
8. Earbuds LED Status
Phone Call
1
2
Earbuds are charging
Earbuds are fully charged
Charging case is charging
Charging case is fully charged
Earbuds are charging
Earbuds are fully charged
SPECIFICATION
Frequency Response : 20 - 20KHz
Bluetooth Version : 5.1
Bluetooth Range : 10m
Stand by Time : 100 Hours
Playtime : 7 hrs (63hrs On-The-Go)
Charging Time : 3H (Charging Case),
Battery Capacity : 1300mAh (Charging Case)
Dimensions : 68*47*35 mm
Net Weight : 89g (charging case)
Headphone Dimensions : 25*24*19 mm (Earbud)
Headphone Net Weight : 5g (Each)
217-190008
1.5H (Earbuds)
60mAH (Earbuds)
(Charging Case)
1911
Manual On/Off
Power On
Sec
2
Sec
4 Power Off
or idle 5 mins
Siri / Google Assistant
Siri /
4
Google Assistant
Warning
Always store the earbuds in the charging case and
safely protected.
Avoid storing the earbuds in hot or cold environments
to prevent depletion of the battery capacity
Avoid storing the earbuds for extended periods of time
without recharging them.
If the earbuds or the charging case become dirty, it is
recommended to clean them with a soft cloth that has
been dampened with clean water.
The OS version of mobile devices may affect
performance of earbuds, it is recommended to update
the OS of your mobile device to the latest version before
use.
It is strongly recommended to clean and dry the
earbuds properly when it has been exposed to water
and sweat.
Don't put the earbuds into charging case while there is
moist, doing so can cause severe damage to the
product. Earbuds charging case is not waterproof.
Remove from power source once the product is fully
charged. Extended periods of over-charging will
decrease battery life.
2
Music Play
2
Sec
2
Sec
2
3
3
Store the product in a dry area. Keep away from fire,
heat, moist and erosive materials.
Do not use rough chemical such as soap or cleanser to
scrub the product.
Do not dissemble, damage, or expose the product to
water or fire. Warranty will be voided by any misuse of
the product.
If the battery is expanded or emits smell, stop using
the product immediately.
+
-
Power On
Blue LED flash * 1
Pairing
White & Blue LED flash alternatively
Pairing Successful
No LED
Charging
White LED on
Playing Music
No LED
Fully Charged
Blue LED on for 5 sec and LED off
Low Battery
White LED flash * 2 every 5 Sec
BE THE CULTURE.
BORN NIFTY.
Find out more at
www.thecoopidea.com
thecoopidea
Inspirations from New Zealand. Designed in Hong Kong.
Produced in China. Copyright 2019 The Coop Idea Ltd.
