thecoopidea CP-TW02 User Manual

USERMANUAL

TRUE WIRELESS
EARBUDS

CP-TW02 V19-06

Product overview

True Wireless
Earbuds

Charging
Case

Multi-Function Button
+ LED light

Microphone

Charging interface

Ear Cap

Micro USB input

LED Light

Magnetic Closure

Specification

Frequency Response
Bluetooth Version
Bluetooth Range
Recharge Earbuds
Battery
Input

Case Dimensions
Case Net Weight
Earbuds Dimensions

Earbudse Net Weight
Waterproof Rating
Stand by Time
Palytime

Charging Time(Earbuds)
(Charging case)

:20 - 20KHz
:5.0
:10m
:６ Times
:800mAh
:5V/1A （Micro）

5V/1A （Wireless）
:65x40x30mm （L x W x H)
:４０ g
:27x24x20mm（each）
（L x W x H）
:５g
:IPX７
:100hrs
:Up to 5hrs

(Up to 35hrs On-The-Go)

:1hr
:2hrs (Micro)/4hrs (Wireless)

Package Contents

1x Beans PRO True Wireless Earbuds (Pair)
1x Sport Eartips (Pairs)
1x Eartip S, M, L (Pairs)
1x Beans PRO Charging Case
1x Micro USB Cable

CHARGE AND ACTIVATE

Charge your BEANS PRO before first time use.

First time use

Before using BEANS PRO, charge it for at least 1 hour.

STEP

Remove the film cover on charging interface

STEP

Put Earbuds into the charging case

Only put a dry BEANS PRO into the charger.

Two ways of charging

STEP

By Micro USB

Cpnnect charging case to your computer or a
power supply via micro USB cable.
plug in micro USB port and charge the case.

By Wireless Charge

Place the Charging case on wireless charging pad.

PerfectFit

Normal Eartips Sport Eartips

Best for Sport

Put on sport eartips with normal eartips

Best for music

Put on narmal eartips

Insert Earbuds

STEP

Tilt and insert BEANS PRO firmly in your ear.

Perfect Fit

STEP

Adjust the BEANS PRO by rotating it backwards.

Turning Earbuds On

Power On

Pick up 1 from charge case or
Hold A both buttons for 2 secs

"Power On"

Bluetooth pairing

Pairing Mode

Pick up 1 from charge case or

Hold A both buttons for 4 secs
(When Earbuds are turned off
outside charging case)

“Pairing”

BLUE

BLUE

Earbuds Pairing

Earbuds Pairing
Success

Left Earphone： Blue LED flash
3 times then Blue & White LED
flash alternatively

Right Earphone： Blue LED
flash 5 times then White light
flash once every 8 seconds

Left Earphone： Blue LED flash
once every 6 seconds

Roght Earphone： White LED
flash once every 6 seconds

"Connected"
“Left Channel” on left
“Right Channel” on Right

Turning Earbuds Off

Power off

Auto power off

Put earbud back into case 2 or
Hold 1 either button for 4 secs

Idle 1 for 10mins

"Power Off"

ManualPairing/ForgetPairing

1. Turn off the earphones

2. Hold the MFB of both

earphones for 10-15 secs until 2
indication sound be heard

3. Turn off the earphones and
turn on the earphones again

4. L and R earphones are paired
and enter pairing mode with
mobile devices

Charging Earbuds

Earphone charging

White light on

Earphone fully charged

White light off

Charging case charging

White light flash

Charging case
fullycharged

White light on

Earphone charging in
charging case

Charging case Blue light on

Earphone fullycharged
in charging case

Charging case Blue light
off

Call / music
Control

MFB（Left） MFB（Right）

Pick up call or

Hang up

Reject call

Switch between
phone/ headset
(during call)

Play / Pause

Next track

Next track

Volume up

Volume down
Siri/ Google assistant

TAP

HOLD 2SCE

or

or

or

Warning

Always store the warbuds in the charging case and
safely protected.

Aviod storing the earbuds in hot or cold
environments to prevent depletion of the battery
capacity.

Aviod storing the earbuds for extended periods of
time without recharging them.

If the earbuds or the charging case become dirty, it
is recommended to clean them with a soft cloth that
has been dampened with clean water.

The OS version of movile devices may affect
performanace of Beans Pro, it is recommandes to
update the OS of your mobile device to the latest
version before use.

Beans Pro is waterproof (IPX7 reated) which
withstand heavy sweat or rain, and being rinsed with
fresh water under the tap. Beans Pro is not designed
to enjoy music while swimming. We recommened
that you do not submerge them in salt or chlorinated
water or clean and dr y Beans Pro properly when it
has been exposed to water and sweat.

Swimming pools that are enriched with heavy
chemicals can ultimately lead to damaging Beans Pro
from the inside.

Don’t put the Beans Pro into Charging case while
it’s still wet or moist. Doing so can cause severe
damage to the electronics or housing of Beans Pro.
BeansPro Charging case is not waterproof.

Remove from power source once the product is fully
charged. Extended periods of over-charging will
decrease battery life.

Store the product in a dry area. Keep away from fire,
heat, moist and erosive materials.

Do not use rough chemical such as soap or cleanser
to scrub the product.

Do not dissemble, damage, or expose the product to
water or fire. Warranty will be voided by any misuse
of the prduct.

If the battery is expanded or emits smell, stop using
the product immediately.

QUESTIONS

Find the answer at

www.thecoopidea.com

Inspirations from New Zealand. Designed in Hong Kong.

Produced in China. Copyright 2019 The Coop Idea Ltd.
