User Manual
ACTIVE SUBWOOFER
TA15
Safety Precautions
Flying and installation of this speaker cabinet must be carried out by suitably qualified
personnel following the approved safety standards.
Do not attempt to clean the plastic enclosure with solvents or petrochemical based
cleaners.
Do not place objects which are sources of heat on the speaker cabinet such as lighting
equipment or smoke machines.
Do not expose the speaker cabinet to direct precipitation or stand in water. Liquid getting
into the box will risk a short circuit and will be hazardous.
Do not stack the speaker cabinet in a manner that could cause injury should a cabinet
become dislodged.
Attention
Before connecting or operating your new THOMANN MUSIKHAUS speaker, please study
the accompanying instruction manual paying particular attention to the operating
precautions and wiring procedure.
THOMANN MUSIKHAUS will not assume responsibility for incorrect installation or
operation of this product.
1. Volume control.
2. Active indicator.
3. L/R Line input.
4. 115V/230V voltage input
selector.
5. Power ON/OFF switch.
6. Phase inverting switch.
7. High cut.(80Hz~250Hz
adjustable)
8. Limit indicator.
9. L/R Line output.
10. Protection fuse.
11. Power supply input. Make
sure that the voltage selector
is set for your country's
correct voltage.
VOLUME
HIGH CUT
LIMIT
ACTIVE
INPUT
OUTPUT
L
R
WARNING: DO NOT SUSPEND OVERHEAD.
PLEASE FOLLOW THE INSTRUCTIONS
SUPPLIED WITH THE LOUDSPEAKER.
1
2
3
1
2
3
1
2
3
1
2
3
0
115V/60Hz
230V/50Hz
ON
OFF
USE ONLY WITH A 250V FUSE
2
3
4
5
7
6
8
9
10
11
INV
POWER: 400W
TA15
ACTIVE SUBWOOFER
No:
CAUTION
Specifications
* In the interests of product development, THOMANN MUSIKHAUS reserves the
right to change and improve all specifications quoted.
Black
15 x1(Bass)
125dB
400W
<1%
Balance - 20kOhm, Unbalance - 10kOhm
XLR, K3P, J3P
115V/230V, 50Hz/60Hz
34kg
40.4kg
Cabinet Colors:
Driver Quantity:
Frequency Response(-3dB):
Max SPL(1m):
Rated power:
THD:
Input impedance:
Connectors:
Power supply:
Dimensions(WxHxD mm/pcs):
Packing Dimensions(WxHxD mm/pcs)
Net Weight(Kg/pcs):
Gross Weight(Kg/pcs):
35Hz-250Hz
600 460 490mm
720 590 610mm
Super bass active speaker
System:
