Oval 4, Oval 6, Oval 10
passive speaker
user manual
Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: info@thomann.de
Internet: www.thomann.de
11.06.2018, ID: 410109, 410113, 410117, ...
Table of contents
1 General notes............................................................................................................................................... 4
1.1 Further information........................................................................................................................... 5
1.2 Symbols and signal words............................................................................................................... 6
2 Safety instructions..................................................................................................................................... 8
3 Features....................................................................................................................................................... 10
4 Installation.................................................................................................................................................. 12
4.1 Wall mounting................................................................................................................................... 13
4.2 Tips on handling speakers............................................................................................................ 14
5 Technical specifications....................................................................................................................... 15
5.1 Oval 4 (item no. 410109, 410111, 410112).............................................................................. 15
5.2 Oval 6 (item no. 410113, 410115, 410116).............................................................................. 18
5.3 Oval 10 (item no. 410117, 410118)............................................................................................ 20
6 Protecting the environment.............................................................................................................. 22
Table of contents
Oval 4, Oval 6, Oval 10
3
1 General notes
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General notes
passive speaker
4
1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search
Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides
Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service
If you have any problems with the device the customer service will
gladly assist you.
General notes
Oval 4, Oval 6, Oval 10
5
1.2 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
General notes
passive speaker
6
Warning signs Type of danger
Warning – danger zone.
General notes
Oval 4, Oval 6, Oval 10
7
2 Safety instructions
This device is intended to be used in a sound reinforcement system. Use the device only as
described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be
assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
passive speaker
8
CAUTION!
Possible hearing damage
The device can produce volume levels that may cause temporary or permanent
hearing impairment. Over an extended period of time, even levels that seem to
be uncritical can cause hearing damage.
Decrease the volume level immediately if you experience ringing in your ears or
hearing impairment. If this is not possible, keep a greater distance or use sufficient ear protectors.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
Oval 4, Oval 6, Oval 10
9
3 Features
Special features of this passive 2 way speaker:
n Speakers: 2 × 1" tweeter, 1 × 4" woofer
n
Mounting points: 2 × threaded socket M5
n
Terminal connections
n
Wall bracket included
n
Housing colour: white
n
Grille colours: black (item no. 410109), white (item no. 410111), red (item no. 410112)
n Speakers: 2 × 3" tweeter, 1 × 6" woofer
n
Mounting points: 2 × threaded socket M8
n
Terminal connections
n
Wall bracket included
n
Housing colours: black (item no. 410115), white (item no. 410116), red (item no. 410113)
n
Housing colour: white
n
Grille colours: black (item no. 410115), white (item no. 410116), red (item no. 410113)
Oval 4 (item no. 410109,
410111, 410112)
Oval 6 (item no. 410113,
410115, 410116)
Features
passive speaker
10
n Speakers: 2 × 4" tweeter, 1 × 10" woofer
n
Mounting points: 2 × threaded socket M8
n
Terminal connections
n
Wall bracket included
n
Housing colour: white
n
Grille colours: black (item no. 410118), white (item no. 410117)
Oval 10 (item no. 410118,
410117)
Features
Oval 4, Oval 6, Oval 10
11
4 Installation
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Create all connections while the device is off. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
NOTICE!
Possible property damage by magnetic fields
Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate
distance to devices that can be adversely affected or damaged by an external
magnetic field.
Installation
passive speaker
12
4.1 Wall mounting
The following figure shows how the supplied wall bracket can be used.
Installation
Oval 4, Oval 6, Oval 10
13
4.2 Tips on handling speakers
We recommend you to set up the speakers in a way, that the sound signals can reach the audience unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound
will be evenly spread with maximum range throughout the audience area.
Always use high grade cable to connect your equipment. Otherwise you won't reach maximum sound quality.
For optimum results both impedance and power handling of the speakers must match the
requirements of the amplifier. Always follow the technical specifications of the speakers! The
overall impedance of the connected loudspeakers must not deceed the minimum output
impedance of the amp. The amps max. RMS output power should be 50 % above the power
handling capacity of the connected speakers.
If you notice distortion during operation, either the amp or the speaker is overloaded. This may
permanently damage the amp or the speaker. Always reduce the volume when you hear distortion.
Installation
passive speaker
14
5 Technical specifications
5.1 Oval 4 (item no. 410109, 410111, 410112)
Speakers: 2 × 1" tweeter
1 × 4" woofer
Power handling 25 W (RMS), 50 W (Music), 100 W (Peak)
Impedance 8 Ω
Sensitivity 88 dB (1 W @ 1 m)
Maximum sound pressure 102 dB (1 m)
108 dB (peak)
Frequency range (–3 dB) 120 Hz … 20 kHz (–3 dB)
Crossover frequency 6,3 kHz
Dispersion angle (H × V) 90° × 90°
Technical specifications
Oval 4, Oval 6, Oval 10
15
Dimensions (W × H × D) 238 mm × 135 mm × 142 mm
Weight 2.02 kg
Technical specifications
passive speaker
16
The following figure shows the sound pressure level (1) and impedance (2) as a function of the
signal frequency.
Frequency response
Technical specifications
Oval 4, Oval 6, Oval 10
17
5.2 Oval 6 (item no. 410113, 410115, 410116)
Speakers: 2 × 3" tweeter
1 × 6" woofer
Power handling 80 W (RMS), 160 W (Music), 320 W (Peak)
Impedance 8 Ω
Sensitivity 88 dB (1 W @ 1 m)
Maximum sound pressure 107 dB (1 m)
113 dB (peak)
Frequency range (–3 dB) 80 Hz … 16 kHz (–3 dB)
Crossover frequency 2,5 kHz
Dispersion angle (H × V) 140° × 160°
Dimensions (W × H × D) 399 mm × 229 mm × 241 mm
Weight 4.65 kg
Technical specifications
passive speaker
18
The following figure shows the sound pressure level (1) and impedance (2) as a function of the
signal frequency.
Frequency response
Technical specifications
Oval 4, Oval 6, Oval 10
19
5.3 Oval 10 (item no. 410117, 410118)
Speakers: 2 × 4" tweeter
1 × 10" woofer
Power handling 150 W (RMS), 300 W (Music), 600 W (Peak)
Impedance 8 Ω
Sensitivity 90 dB (1 W @ 1 m)
Maximum sound pressure 111 dB (1 m)
118 dB (peak)
Frequency range (–3 dB) 45 Hz … 22 kHz (–3 dB)
Crossover frequency 1,2 kHz
Dispersion angle (H × V) 120° × 120°
Dimensions (W × H × D) 550 mm × 336 mm × 316 mm
Weight 9.05 kg
Technical specifications
passive speaker
20
The following figure shows the sound pressure level (1) and impedance (2) as a function of the
signal frequency.
Frequency response
Technical specifications
Oval 4, Oval 6, Oval 10
21
6 Protecting the environment
For the transport and protective packaging, environmentally friendly materials have been
chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that
they are collected for recycling. Please follow the notes and markings on the packaging.
This product is subject to the European Waste Electrical and Electronic Equipment Directive
(WEEE) in its currently valid version. Do not dispose with your normal household waste.
Dispose of this device through an approved waste disposal firm or through your local waste
facility. When discarding the device, comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.
Disposal of the packaging material
Disposal of your old device
Protecting the environment
passive speaker
22
Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de
