The box CL 115 SUB User Manual

CL 112 / CL 115 SUB

active subwoofer

user manual

Musikhaus Thomann e.K.
Treppendorf 30
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [e-mail]
Internet: www.thomann.de

29.04.2013

Table of contents

1 General notes............................................................................................................................................... 4

2 Safety instructions..................................................................................................................................... 7

3 Features....................................................................................................................................................... 11

4 Installation.................................................................................................................................................. 12

4.1 Tips on handling speakers............................................................................................................ 14

5 Connections and operating elements........................................................................................... 15

6 Technical specifications....................................................................................................................... 19

7 Plug and connection assignments.................................................................................................. 21

8 Protecting the environment.............................................................................................................. 25

Table of contents

CL 112 / CL 115 SUB

3

1

General notes

This user manual contains important information on safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to other users, be sure
that they also receive this manual.

Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.

General notes

active subwoofer

4

This section provides an overview of the symbols and signal words used in this user manual.

Signal word Meaning
DANGER! This combination of symbol and signal word

indicates an immediate dangerous situation
that will result in death or serious injury if it is
not avoided.

CAUTION! This combination of symbol and signal word

indicates a possible dangerous situation that
can result in minor injury if it is not avoided.

NOTICE! This combination of symbol and signal word

indicates a possible dangerous situation that
can result in material and environmental
damage if it is not avoided.

Warning signs Type of danger

Warning – high-voltage.

Symbols and signal words

General notes

CL 112 / CL 115 SUB

5

Warning signs Type of danger

Warning – danger zone.

General notes

active subwoofer

6

2

Safety instructions

This device is intended to be used in a sound reinforcement system. Use the device only as
described in this user manual. Any other use or use under other operating conditions is consid‐
ered to be improper and may result in personal injury or property damage. No liability will be
assumed for damages resulting from improper use.

This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.

DANGER!
Danger for children

Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!

Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!

Never let children unattended use electrical devices.

Intended use

Safety

Safety instructions

CL 112 / CL 115 SUB

7

DANGER!
Electric shock caused by high voltages inside

Within the device there are areas where high voltages may be present. Never
remove any covers.

There are no user-serviceable parts inside.

DANGER!
Electric shock caused by short-circuit

Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis‐
tered electrician.

Safety instructions

active subwoofer

8

CAUTION!
Possible hearing damage

The device can produce volume levels that may cause temporary or permanent
hearing impairment. Over an extended period of time, even levels that seem to
be uncritical can cause hearing damage.

Decrease the volume level immediately if you experience ringing in your ears or
hearing impairment. If this is not possible, keep a greater distance or use suffi‐
cient ear protectors.

NOTICE!
Risk of fire

Do not cover the device nor any ventilation slots. Do not place the device near
any direct heat source. Keep the device away from naked flames.

Safety instructions

CL 112 / CL 115 SUB

9

NOTICE!
Operating conditions

This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.

NOTICE!
Power supply

Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.

Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.

Safety instructions

active subwoofer

10

3

Features

Special features of the device:

n Inputs: XLR and 1/4" phone sockets
n Outputs: NL4 chassis connector for passive speakers (top)
n 15" woofer (item no. 109892)
n 12" woofer (item no. 109893)
n 36 mm pole mount flange
n Butterfly handles
n Transport casters
n PU coated
n Protective cover optionally available

Features

CL 112 / CL 115 SUB

11

4

Installation

Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.

For operation, the device must be placed on its rubber feet. Therefore tip the unit over its pro‐
tected edge. Do not take the device into operation while standing on its casters. Otherwise
there's a danger of overheating and the chance for uncontrolled movement.

Establish all connections as long as the unit is switched off. Use the shortest possible high­quality cables for all connections.

Installation

active subwoofer

12

CAUTION!
Risk of injury due to heavy weight

Due to the heavy weight of the device, at least two persons are required for trans‐
port and installation.

NOTICE!
Possible property damage by magnetic fields

Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate
distance to devices that can be adversely affected or damaged by an external
magnetic field.

Installation

CL 112 / CL 115 SUB

13

4.1

Tips on handling speakers

We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐
ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound
will be evenly spread with maximum range throughout the audience area.

Always use high grade cable to connect your equipment. Otherwise you won't reach max‐
imum sound quality.

For optimum results both impedance and power handling of the speakers must match the
requirements of the amplifier. Always follow the technical specifications of the speakers! The
overall impedance of the connected loudspeakers must not deceed the minimum output
impedance of the amp. The amps max. RMS output power should be 50 % above the power
handling capacity of the connected speakers.

If you notice distortion during operation, either the amp or the speaker is overloaded. This may
permanently damage the amp or the speaker. Always reduce the volume when you hear dis‐
tortion.

Installation

active subwoofer

14

5

Connections and operating elements

Rear panel CL 112 SUB

Connections and operating elements

CL 112 / CL 115 SUB

15

Rear panel CL 115 SUB

Connections and operating elements

active subwoofer

16

1 LED POWER

This LED indicates that the device is switched on and operational.

2 Rotary control SUB LEVEL

Use this rotary control to adjust the subwoofer's volume.

3 Slider switch SUB PHASE

Use this slider switch to inverse the phasing (0° / 180°). This can prevent unwanted frequency extinguishing effects in
interaction with other speakers.

4 Rotary control MAIN LEVEL

Use this rotary control to adjust the overall volume (subwoofer plus connected external speakers).

5 LED PROTECT (CL 115 SUB only)

This LED lights up red when the unit switches to protection mode. In this case, check the cables for short circuit or
incorrect connection. If this LED lights up constantly, please contact our Service Centre. Find the contact data at
www.thomann.de.

Connections and operating elements

CL 112 / CL 115 SUB

17

6 Phone sockets INPUT RIGHT / INPUT LEFT

Inputs for balanced or unbalanced line level signals.

7 XLR sockets INPUT RIGHT / INPUT LEFT

Inputs for balanced signals with line level.

8 NL4 chassis connectors SAT POWER OUT RIGHT / SAT POWER OUT LEFT

Speaker outputs.

9 Mains switch POWER

To turn the device on or off.

10 IEC chassis connector with fuse holder for power supply.

If the fuse blows you have to replace it by a new one with same specifications. Before, you must disconnect the unit
from the mains power supply.

Connections and operating elements

active subwoofer

18

6

Technical specifications

CL 112 Sub (item no. 109893) CL 115 Sub (item no. 109892)

System Active subwoofer
Speakers 1 × 12" woofer 1 × 15" woofer
Inputs XLR sockets (balanced)

1/4" phone sockets (balanced or unbalanced)
Outputs Lockable NL4 chassis connectors (1+/1-)
Impedance for passive speakers (top) to be con‐

nected

min. 4 Ω

Crossover frequency 150 Hz 130 Hz
Output power for built-in speaker 120 W (RMS) 220 W (RMS)
Output power for passive speakers (top)

2 × 120 W (RMS) 2 × 220 W (RMS)
Sound pressure level 118 dB (max.) 122 dB (max.)

Technical specifications

CL 112 / CL 115 SUB

19

CL 112 Sub (item no. 109893) CL 115 Sub (item no. 109892)

Operating supply voltage

AC 220 – 240 V , 50/60 Hz
Power consumption 600 W 1000 W
Fuse 3.15 A / 250 V, slow-blow, 5 × 20 mm 5.0 A / 250 V, slow-blow, 5 × 20 mm
Dimensions (W × D × H) 420 mm × 475 mm × 500 mm 460 mm × 565 mm × 610 mm
Weight 29 kg 40 kg

Technical specifications

active subwoofer

20

7

Plug and connection assignments

This chapter will help you select the right cables and plugs to connect your valuable equip‐
ment in such a way that a perfect sound experience is ensured.

Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a
plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short
circuit or ‘just’ in poor transmission quality!

Unbalanced transmission is mainly used in semi-professional environment and in hifi use.
Instrument cables with two conductors (one core plus shielding) are typical representatives of
the unbalanced transmission. One conductor is ground and shielding while the signal is trans‐
mitted through the core.

Unbalanced transmission is susceptible to electromagnetic interference, especially at low
levels, such as microphone signals and when using long cables.

In a professional environment, therefore, the balanced transmission is preferred, because this
enables an undisturbed transmission of signals over long distances. In addition to the conduc‐
tors ‘Ground’ and ‘Signal’, in a balanced transmission a second core is added. This also transfers
the signal, but phase-shifted by 180°.

Introduction

Balanced and unbalanced trans‐
mission

Plug and connection assignments

CL 112 / CL 115 SUB

21

Since the interference affects both cores equally, by subtracting the phase-shifted signals, the
interfering signal is completely neutralized. The result is a pure signal without any noise inter‐
ference.

1 Signal
2 Ground, shielding

1 Signal (in phase, +)
2 Signal (out of phase, –)
3 Ground

1/4" TS phone plug (mono,
unbalanced)

1/4" TRS phone plug (mono, bal‐
anced)

Plug and connection assignments

active subwoofer

22

1 Signal (left)
2 Signal (right)
3 Ground

1 Ground, shielding
2 Signal (in phase, +)
3 Signal (out of phase, –)

1/4" TRS phone plug (stereo,
unbalanced)

XLR plug (balanced)

Plug and connection assignments

CL 112 / CL 115 SUB

23

1 Ground, shielding
2 Signal
3 Bridged to pin 1

1, + Signal 1 (in phase)
1, – Signal 1 (out of phase)

XLR plug (unbalanced)

NL4 connections

Plug and connection assignments

active subwoofer

24

8

Protecting the environment

For the transport and protective packaging, environmentally friendly materials have been
chosen that can be supplied to normal recycling.

Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that

they are collected for recycling. Please follow the notes and markings on the packaging.

This device is subject to the European directive 2002/96/EC.
Do not dispose of the device with your normal household waste.
Dispose of this device through an approved waste disposal firm or through your local waste

facility. When discarding the device, comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.

Disposal of the packaging mate‐
rial

Disposal of your old device

Protecting the environment

CL 112 / CL 115 SUB

25

Notes

active subwoofer

26

Musikhaus Thomann e.K. · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de
