Data sheet Home and Building control
theLuxa P300 KNX WH KNX
Article number: 1019610
theLuxa P300 KNX WH Article number: 1019610
Description
■
Motion detector (PIR)
■
Automatic lighting control based on presence and brightness
■
For integration into KNX building systems
■
For outdoor use
■
For installation on walls and ceilings
■
Integrated temperature sensor
■
For larger, commercial outdoors properties such as offices, public buildings,
hotels, schools, car parks and warehouses
■
Easy to program with KNX ETS software
■
Adjustable brightness switching value and switch-off delay
■
Sensitivity can be reduced
■
Area limit via lens attachment
■
Mixed light measurement
■
Teach-in of current brightness value possible
■
Pulse function
■
Test function for checking detection area
■
Installation on flush-mounted socket possible (60 mm)
■
Single-handed plug-in installation
■
Instant start-up possible via factory preset
■
Controls are place protected
■
Corner angle included
■
Spacer and corner angle included
Technical data
Operating voltage KNX Bus voltage, <10 mA
Setting range brightness 1 – 3000 lx
Detection angle 300°
Creep under protection Ø 6 m
Installation type Wall and ceiling installation
Light switch-off delay 1 s - 60 min
Light measurement Mixed light measurement
Ambient temperature -25 °C … +45 °C
Colour White
Protection class III
Type of protection IP 55
Subject to technical changes and misprints
additional information at:
www.theben.de/product/1019610
13.01.2018
Page 1 of 3
Data sheet Home and Building control
theLuxa P300 KNX WH KNX
Article number: 1019610
Detection range
Mounting height
(A)
2 m 4 m 12 m
2,5 m 5 m 16 m
3 m 5 m 16 m
3,5 m 5 m 16 m
4 m 4 m 12 m
Head on to (r) Diagonally (t)
Scale drawings
Accessories
Corner angle theLuxa P WH
■
Article number: 9070904
Details ▶ www.theben.de
Spacer theLuxa P WH
■
Article number: 9070908
Details ▶ www.theben.de
theSenda P
■
Article number: 9070910
Details ▶ www.theben.de
Subject to technical changes and misprints
additional information at:
www.theben.de/product/1019610
13.01.2018
Page 2 of 3
