Texet TR-3003 User Manual [ru]
USER GUIDE
Руководство по эксплуатации
TR-3003
PORTABLE AUDIO SYSTEM
ПОРТАТИВНАЯ АУДИОСИСТЕМА
Device and controls
Устройство и органы управления
1
2 3
7 8
9 11 1012 13
2
4 5 6
ENG
1 — M Button to select main functions
of the portable audio system
2 — Playback/pause or on/off
(by long press) button
3 — V+ Button to increase the sound volume level
4 — Button to go to the previous subject
5 — Button to go to the next subject
6 — V- Button to decrease the sound volume level
7 — ON/OFF Portable audio system on/off button
8 — Flashlight on/off button
9 — microSD slot for microSD memory cards
10 — USB Host Interface for USB flash drives
11 — Headphone output
12 — Mini USB DC (AUX) interface to charge
portable audio system and connect PC,
line input to connect external devices
13 — Flashlight
3
RUS
1 — M Кнопка переключения режимов работы
портативной аудиосистемы
2 — Кнопка воспроизведения/паузы.
При долгом нажатии – включения/выключения
3 — V+ Кнопка увеличения уровня громкости
4 — Кнопка перехода к предыдущему файлу
5 — Кнопка перехода к следующему файлу
6 — V- Кнопка уменьшения уровня громкости
звука
7 — ON/OFF Кнопка включения/выключения
портативной аудиосистемы
8 — Кнопка включения/выключения фонарика
9 — microSD слот для microSD карт памяти
10 — USB хост интерфейс для подключения
USB флеш накопителя
11 — Выход для наушников
12 — Mini USB DC (AUX) интерфейс для заряда
портативной аудиосистемы и подключения
к ПК, линейный вход для подключения
внешних устройств
13 — Фонарик
4
Package contents
Комплектность
1. Portable audio system
2. Battery teXet (analogue Nokia BL-5C) 1100 mAh
3. Universal cable for charging
and connecting external devices
4. User guide
5. Warranty certificate
1. Портативная аудиосистема
2. Аккумуляторная батарея teXet
(аналог Nokia BL-5C) 1100 мАч
3. Универсальный кабель для заряда
и подключения внешних устройств
4. Руководство по эксплуатации
5. Гарантийный талон
TBP-2214
5
ENG
Thank you for purchasing our portable audio system
teXet TR-3003. Before you start operating the unit,
please read this manual to take full advantage of the
audio system and extend its life. Save this manual to
refer to it in the future if the need arises.
This manual contains information on the technical
characteristics of the device, controls of the portable
audio system, all functions and modes of operation, as
well as a list of security measures.
Note: Due to continuous product improvement, the
manufacturer reserves the right to modify the software,
hardware, and specifications without prior notice to the
end user. Current information is always available on the
website www.texet.ru
Appearance of the menu screens shown in the
illustrations in the manual may differ slightly from the
existing products.
6
Technical specifications
Overall dimensions
Weight 119 g
Display LCD
Battery Li-Ion 3,7 V,
Time of operation in playback
mode
External power source USB 5 В, 0,5-1 А
Frontal speakers 45 mm, 4 Ohm
Rear speakers Passive
Output power 3 W
Reproducible frequencies 85 Hz – 18 kHz
Line input response (L) and (R)
1
Depending on the level of the sound
2
The charging device is not included and must be purchased
separately.
130 x 62 x 22 mm
1100 mAh
(analogue
Nokia BL-5C)
8-12 hours
subwoofer
300 mV/channel
1
2
7
Signal-to-noise ratio 70 dB
Nonlinear-distortions
coefficient
< 0.55%
FM band range 87,5-108,0 MHz
MP3 player
Supported formats MP3
Bitrate 8 – 320 kBps
External media memory
capacity (USB and microSD)
External media file system
format
Maximum MP3 files number
on external drive
up to 32Gb
FAT32
2000
Number of levels tab folders up to 5
Number of libraries/folders 999
Working range -5 to + 40 °C
8
1. Start of operation
When turning on the portable
audio system, the display shows
the following information:
Setting the clock
Press and hold down the M button to successively
adjust the time value and date: hours, minutes,
seconds, year, month, and day. Press M button to
confirm the selected value:
Setting the value «Hours»
Setting the value «Minutes»
Setting the value «Year»
9
