Texet TPA-2170 User Manual [ru]

Руководство по эксплуатации

USER GUIDE

Пайдалану бойынша нұсқаулық

Керівництво з експлуатації

TPA-2170

BLUETOOTH™ PORTABLE SPEAKER

Портативная колонка Bluetooth™

Шағын колонкасы Bluetooth™

Портативна колонка Bluetooth™

BlueFun

Сontrols Органы управления Басқару жүйесі Органи управління

DC 5V

AUX

5 9

ENG ............................3

RUS .........................11

KZ ............................21

UKR .........................24

ENG

BLUETOOTH™ PORTABLE SPEAKER

Power button. Receive and end a phone call.

2 AUX: Line-in jack for external devices, such as MP3 players, PC

tablets, artphones, and mobile telephones

3 LED light 4 DC 5V: Interface for charging and for connecting to a PC

5 Mic

Pause/resume playback button. Button to select main

functions

Volume-down/select previous le button

Volume-up/select next le button. Mute/unmute button in

eakerphone mode

9 microSD: MicroSD card slot

QUICK START GUIDE

Package contents

1. Bluetooth™ portable speaker BlueFun– 1 pc

2. microUSB cable – 1 pc

3. AUX cable – 1pc

4. Silicon cuff – 3 pcs

5. Handstrap – 3 pcs

6. User guide- 1 pc

7. Warranty certicate – 1 pc

Specications

Overall dimensions 52 x 52 x 50 mm Weight 107,5 g Battery Li-Ion 3,7 V, 600 mAh Time of operation in playback mode Up to 8 hours External power source USB 5 V, 0,5-1 А Bluetooth™ Broadcom v. 3.0 Bluetooth™ proles A2DP, Headset

Simultaneous pairing of multiple Bluetooth™ devices capability

Speakerphone Built-in microphone for

4 external Bluetooth™ devices

incoming/outgoing calls in Hands-free mode

Speaker 45 mm, 4 Ohm Output power 3 W

Depending on the level of the sound

The charging device is not included and must be purchased

separately.

Reproducible frequencies 150 Hz – 18 kHz Line input response 420 mV Signal-to-noise ratio > 80 dB Nonlinear-distortions coefcient < 0.55%

MP3 player

Supported formats MP3 Bitrate 32 – 320 kBps External media memory capacity

(microSD)

up to 32Gb

External media le system format FAT32 Working range -5 to + 40 °C

Press and hold the button speaker. Wait for the «Welcome» prompt from the voice menu. Choose the «BlueFun» external device from the search menu to pair with an external Bluetooth device. If the external device prompts you for a PIN, enter «0000» The LED light will turn blue when the pairing process is complete. Use the button to receive or end a telephone call. Press and hold the buttons to adjust the volume. Use the button to play/pause a le. Use the buttons to select the previous/next le from external media. To charge the battery, connect one end of the microUSB cable to the DC 5V port. Plug the other end into a USB port on a computer or into a USB wall charger.

to switch on the BlueFun portable

USER GUIDE

Thank you for purchasing our Bluetooth™ portable speaker teXet TPA-2170 BlueFun. Before you start operating the unit, please read this manual to take full advantage of Bluetooth™ portable speaker and extend its life. Save this manual to refer to it in the future if the need arises. This manual contains information on the technical characteristics of the device, controls of the Bluetooth™ portable speaker, all functions and modes of operation.

Note: Due to continuous product improvement, we reserve the right to

modify the software, hardware, and specications without prior notice

to the end user. Current information is always available on the website www.texet.eu

1. Start of operation

Press and hold the button to switch on the BlueFun portable speaker. Wait for the «Welcome» prompt from the voice menu. When switched on, the LED light will rapidly ash blue. The «Search for devices» prompt from the voice menu means that the BlueFun portable speaker is ready to pair with external Bluetooth devices. Repeatedly press and hold the button for the BlueFun portable speaker: Bluetooth™, MP3 player, or AUX. If an audio cable or microSD card is connected when the BlueFun is switched on, then the AUX or MP3 player mode will start, and the «Welcome» prompt will be skipped. The voice menu is a function of the Bluetooth™ mode.

to choose different modes

2. Pairs with external Bluetooth™ devices

Attention! The distance between the BlueFun portable speaker and a paired external device should not exceed 10 meters.

On the external device, enable Bluetooth™ and begin searching for devices. When the list of discovered devices appears on the screen, choose «BlueFun» If the external device prompts you for a PIN,

enter «0000» Wait for the «Pairing» prompt from the voice menu. The LED light will turn blue when the pairing process is complete. In most cases, when the connection is lost1 the BlueFun portable speaker will automatically re-pair with your external device. If pairing does not begin automatically, then switch the BlueFun portable speaker off and then on. You can simultaneously pair BlueFun with up to 4 external Bluetooth™ devices.

3. Plays music les from external Bluetooth™ devices

Play music on your external device. During playback, the BlueFun portable speaker LED light will slowly ash blue. Use the button

to play and pause les. Use the button to select the

previous/next le. Files will be played sequentially by folder. Press and hold the button to adjust the volume. You can also adjust the volume and select les by using the menu or the buttons on the external device.

4. Receives telephone calls. Hands-free pability

The BlueFun portable speaker allows you to receive calls and provides hands-free calling with a built-in loudspeaker and microphone. When there is an incoming call, playback is paused, and the BlueFun loudspeaker will either emit special beeps or play your mobile device’s ringtone. Press the button to receive the call. Press the button again to end the call and resume playback. If you need to mute your microphone during a call, press the + button. You will hear a «Mute on» conrmation. Repeatedly press the + button to unmute the microphone. After the «Mute off» conrmation, you will be able to continue your conversation. If you do not want to take the call, you can reject it on your mobile device. Receiving calls is a Bluetooth™ function and is not possible when in AUX or MP3 mode.

Depending on the model of the external device

5. MP3 player operation

Insert the microSD card in the microSD slot. Playback will start automatically. Use the buttons to select the previous/next le. Use the button to pause or resume playback. During playback, the BlueFun portable speaker’s LED light will slowly ash blue. Press and hold the button to adjust the volume. When switched on, the BlueFun portable speaker recalls all previous settings: volume level, current le. Information about playing MP3 les from external media:

• File system format for external media: FAT32

• Maximum memory for external media: 32 Gb

6. Connects to external audio devices through the

AUX input

Connect your external device (MP3 player, PC tablet, smartphone, notebook, or mobile phone) to the AUX port with an audio cable. Start playback on your external device. Use the button to adjust the volume. Press the button to turn the sound off/on during playback.

7. Rechargable battery

Connect any USB wall charger (5V, 0.5-1A) to the DC 5V port using a microUSB cable. The LED light will turn red, indicating that charging has begun. After the battery is charged, the LED light will turn off. You can speed up charging by turning off the BlueFun portable speaker.

8. Troubleshooting guide

1. Fails to turn off

• Check the battery’s charge level.

• Plug the BlueFun into a power source to reboot.

2. Fails to charge

• Make sure the charging cable is connected.

3. No sound

• Check the volume level.

• Make sure there are MP3 les on the external media.

• Check the battery’s charge level.

• Check the BluetoothТМ connection.

4. The les on the external media are unreadable

• Check the le system format of the microSD card.

• Check the microSD card for viruses.

5. No sound for incoming/outgoing calls

• Make sure nothing is blocking the microphone; be sure not to cover the microphone with your hand when talking.

• Check the volume level.

• Make sure the microphone is not muted.

6. The speaker emits static

• Make sure that mobile devices are no more than 30 cm away from the BlueFun portable speaker.

7. Will not pair with external BluetoothТМ devices

• Make sure the BlueFun is completely charged.

• When pairing, position the mobile device as close as possible to the BlueFun (not more than 1 meter away).

• Check your BluetoothТМ device’s menu to make sure that «discoverable» mode is enabled.

• After pairing, some external BluetoothТМ devices require additional conguration of the Bluetooth connection. To do this, choose the BlueFun from the list of paired devices and select «congure connection.»

• If the connection is lost because the external device is more than 10m away or BluetoothТМ on the external mobile device is disabled and re-pairing does not start automatically, then switch the BlueFun portable speaker off and then on.

• The BlueFun is paired to 2 external mobile devices and the connection to one of them is already established. If this is the case, you must disconnect the rst device, then the connection to the second device will automatically be established.

• After pairing your device with the BlueFun, four more external
