SPECIFICATION
Model: CD1912
Voltage: 220-240VAC,50Hz
Current: 1.8A
Paper entry width: 220mm
Shred size: 5mm x 38mm
Shred paper capacity: 12 A4 Sheets 70gsm/1 Credit Card/1 x CD/DVD
Shred speed: 3.2 Mtrs/Min
Waste bin Volume: 19L
Noise level: 71.6db
Duty cycle: 2 Mins On/30 Mins Off
Net weight: 5.1Kgs
Dimension: 353 x 236 x 463mm
Type designation:
BS60950-1:2006
EMC Directive 2004/108/EC
Test Standards:EN55014-1:2006
EN55014-2:1997+A1:2001
EN61000-3-2:2006
EN61000-3-3:2008
Visit www.texet.com for details on other Texet products.
UK: Waste Electrical products/batteries should not be disposed of with household waste.
Separate disposal facilities exist, for your nearest facilities, see www.recycle-more.co.uk
or in store for details.
Made in China
Instruction manual
CROSS CUT SHREDDER
CD1912
Please Read the Following Instructions Carefully before Use, and Keep them for Future Use.
http://www.texet.com
Thank you for purchasing the TEXET Cross Cut Shredder, CD1912, with normal use and
maintenance, your shredder will provide years of satisfactory performance. Please read
the instruction manual carefully and retain for future reference.
To protect this Shredder correctly and avoid any damage, please
ensure you understand the following Icons:-
Please do not spray any flammable gas, water or oil onto this Shredder.
Please keep children away from the Shredder, the sharp blades may harm
them.
Please keep cloths, ties and the like away from the paper entry slot.
To prevent damage to the cutters remove paper clips, and other
fasteners before shredding.
Please keep your hands out of the paper entry slot and the sharp blades
may cause injury.
Please keep your hair away from the shredder/paper entry slot.
The incorrect operation of this appliance may cause personal injury or damage the
shredder. The Plug Socket outlet should be easily accessible.
BS Plug Fuse – 5A Fitted
GENERAL SAFETY
When using electrical appliance, basic precautions should always be followed to reduce the
risk of fire, electrical shock and injury to persons including the following;
The Shredder is only intended for private/domestic and small office use. Any other uses not
recommended by the manufacture, may result in the warranty being void. Do not use the
shredder to shred film, OHP Pouches, adhesive stickers, cloths or any plastics, other that
credit cards, as these may cause damage.
Remove the Shredder from its packaging and check to make sure it is in good condition
before using. Keep the packaging for storage and transportation.
This Shredder is not intended for use by persons, including children, with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the Shredder by a person responsible
for their safety.
Extreme caution is necessary where children or persons with reduced physical, sensory or
mental capabilities may come into contact with the Shredder when in use.
Do not let children play with parts of the packaging, such as plastic bags.
Ensure the power supply to the socket into which the Shredder is plugged, is in accordance
with the rating label on the shredder and that the socket is earthed.
Do not use the Shredder if the Power Cord is damaged. If the Power Cord is damaged it
must be replaced by a recognized service agency or other qualified person.
Always turn the Power off before unplugging the Shredder and make sure your hands are
dry to prevent electric shock.
Do not use outdoors.
Always unplug the Shredder when not in use.
Setup:
1. Remove the shredder from the outer carton.
2. Place the shredder head onto the bin. The shredder head is fitted with as a safety switch
and this switch needs to sit on top of the Rib that is located on the inside of the Waste Bin,
(left hand side at the back), as indicated by the Safety Interlock labels on the Shredder Head
and Waste Bin.
3. The shredder needs to be placed on a flat stable surface.
Shredder Capacity:
The CD1912 will shred 12 sheets of A4 70g paper at once, 1 Credit Card or 1 CD/DVD and
will accept paper width up to 220mm.When shredding smaller items like envelopes or credit
card receipts/, insert them through the middle of the feed slot. Please note there Is a
separate slot for Credit Cards and CD/DVD’s.
The paper sensor is located in the centre of the main feed slot. When paper is inserted, the
sensor starts the cutters. When the paper has gone through the shredder, the sensor will
switch the cutters off.
Operating the Shredder:
1. Prepare the paper to be shredded by removing paper clips and any other objects that
may jam in the feed slot.
2. Only feed 12 sheets of 70g A4 paper at any one time or 1 Credit Card or 1 CD/DVD.
3. Set the select switch on top of the shredder to AUTO, OFF or REV position for the
desired operation
AUTO
: Activates the auto shred function, the shredder will start automatically when an item
is inserted into the paper feed slot and will stop once the paper has been shredded.
OFF
: This position is recommended when emptying the shredder bin or when the shredder
is not in use for a prolonged period of time.
REV
: Reverses the shredding direction and backs items out of the shredder in the event of a
paper jam.
Paper Jams:
The CD1912 is equipped with a motor overload protection device, the normal duty cycle for
continuous shredding at maximum capacity, is 2 minutes on & 30 minutes off. The power
may terminate automatically in case of the following situations:
1. Operating the shredder at maximum capacity continuously for a prolonged period of
time, e.g. more than 2 minutes without stopping.
2. Exceeding the shredding capacity e.g. inserting more than 12 sheets at one time, or if
the paper is not fed squarely into the feed slot.
Both of these operations may result in the activation of the automatic motor overload
protection, which terminates the power to the unit. If this occurs, you should:
1. Unplug the power cord from the AC outlet and wait at least 30 minutes for the overload
protection to reset.
2. Plug the power cord back into the AC outlet and place the switch in REV. Pull the
remaining paper out of the cutters. Place the switch back to the AUTO position if
necessary.
3. With the switch in the AUTO position and the feed slot clear, you are now ready to
resume normal shredding.
If the shredder overheats, the red overheat light will come on and it will automatically shut
down, it will restart again after 30 minutes, once the shredder has cooled down
Clearing the Blades of Paper Jams
If paper becomes jammed during shredding, move the switch to reverse and remove any
excess paper from the feed slot. Move the switch back to auto and see if this clears the jam,
If not move the switch alternately between REV and Auto 2-3 times, this should clear the
paper jam. Put the switch back to Auto and carry on shredding.
ALWAYS UNPLUG THE SHREDDER BEFORE ATTEMPTING TO MANUALLY REMOVE
AN ITEM FROM THE PAPER ENTRY.
DO NOT, UNDER ANY CIRCUMSTANCES, INSERT METAL OBJECTS INTO THE ENTRY
FEED SLOT OR THE BLADES, TO REMOVE THE JAMMED PAPER.
Maintenance
Warning:
When you want to maintain the shredder, please make sure you have switched off the
shredder and removed the plug from its socket.
Use a dry soft cloth when you want to clean the shredder.
The shredder cover and waste bin are made of plastic; therefore please do not use
gasoline, benzene impregnate thinners to avoid fading or scratches.
Do not allow water to enter the shredder head when cleaning.
To maintain the quality of your shredder blades please use Texet LB12 lubricating
sheets once a month.
Waste Emptying:
1. When you empty the waste bin, please make sure the shredder is switched off and
unplugged.
2. Place the shredder head back onto the bin correctly.
Paper is easily wrapped around the shredder head if the waste bin is allowed
to get too full, therefore please empty the waste bin after shredding 100 A4
Sheets.
Disposal:
Please dispose of this product responsibly at an approved disposal site or recycling facility.
Do not dispose of this product in household waste.
TROUBLE SHOOTING
Troubles Reason Solution
Shredder does
not work after
paper is
inserted.
1. The
power
cord may
not be
properly
connecte
d.
2. The motor has been over
heated.
3. The paper feed may be
jammed.
4. Shredder head is not placed
properly on basket.
1. Check the power cord is correctly
plugged in both the plug socket and the
shredder.
2. Wait for about 30 minutes and try the
shredder again.
3. Reverse the paper feed and remove any
jammed paper, then try again.
4. Place shredder head securely on
basket, correctly front facing, ensuring
contact with the basket is made.
Shredder does
not stop after
shredding has
finished
1. The mechanical sensor may
be jammed by paper
1. Clean the paper entry and try again,
ensuring you remove the plug from the
socket first.
Shredder
makes a high
noise
1. The shredder may not be
placed on a flat/stable surface.
1. Replace the shredder onto a flat/stable
surface.
Shredder does
not shred paper
1. Too much paper is inserted.
2. The paper size inserted may
be larger than the paper entry.
3. The paper may be inclined
when placed into the paper
entry.
1. Check to see if you have exceeded the
ra
ted capacity of paper (12 sheets of 70 g).
2. Reverse the shredder and take out the
paper, fold in half and try again.
3. Re-insert the paper vertically.
